Audiovox 128-6210A User Manual
ELECTRONICS COR
P .
SATELLITE DIGITAL AUDIO
CONTROL AND
RECEIVER SYSTEM
for Use With
XM® SATELLITE RECEIVER
SYSTEM
MODEL SRXM-001
®
OO
WNER'SWNER'S
O
WNER'S
OO
WNER'SWNER'S
MAMA
MA
MAMA
NUALNUAL
NUAL
NUALNUAL
128-6210A
1 of 12
CONTENTS
Trademarks ...................................................................................................... 2
How to Subscribe to XM® Radio .................................................................... 2
Introduction ...................................................................................................... 2
How the System Operates ............................................................................. 2
Satellite System Control Unit (SCU) ................................................................ 3
Satellite Radio Receiver Unit (RRU) ................................................................ 4
Satellite Radio RF Modulator ............................................................................ 4
Functional Operation ....................................................................................... 5
Powering Up the System ........................................................................ 5
Selecting a Satellite Channel ................................................................... 5
Using the Up/Down Buttons ............................................................... 6
Displaying the Identification (ID) Code ................................................ 6
Selecting Channel Categories or Groups ........................................... 6
Directly Accessing a Channel ............................................................ 7
Presetting a Desired Channel ............................................................. 7
Special Functions Using the Shift Button ............................................... 7
Direct FM Frequency Selection ........................................................... 8
System Default Shift Code .................................................................. 8
LCD Contrast Shift Code ..................................................................... 8
LCD Backlight Dimming Shift Code ...................................................... 8
Button Confirmation Tone Shift Codes ................................................ 8
LCD Backlight Color Shift Codes ......................................................... 9
Category/Normal Selection Mode Shift Codes ................................... 9
Channel Skip Shift Code...................................................................... 9
Display Messages ........................................................................................... 9
Troubleshooting Considerations ..................................................................... 10
Specifications .................................................................................................. 10
Warranty .......................................................................................................... 11
Trademarks
XM® is a registered trademark of XM® Satellite Radio. All Rights Re-
served. www.xmradio.com
Other product names mentioned in this manual may be trademarks
or registered trademarks of their respective companies and are hereby
acknowledged.
How To Subscribe to XM® Radio
Listeners can subscribe by visiting XM® on the Web at
www.xmradio.com, or by calling XM’s® Listener Care at (800) 852-
9696. Customers should have their Radio ID ready; for details, refer
to “Display the ID Code”.
Introduction
XM® Satellite Radio is a new and exciting audio experience on your
radio dial; it provides you with digital audio programming at the touch
of a button. By using two geo-stationary satellites, XM® Radio provides
digital quality sound, with a choice of 100 channels of diverse programming, including music, news, history, sports, and talk.
To make this system available to the motoring public, Audiovox has
engineered a state-of-the-art XM® Satellite Radio System, consisting
of a Satellite Antenna (purchased separately), a Satellite Radio Receiver Unit (RRU), a Satellite Radio RF Modulator, a Satellite System
Control Unit (SCU) and an optional wireless remote control. By using
the FM section of any car stereo system, the RF signal information is
demodulated and produces the audio output to your existing stereo
system speakers. Since XM® Satellite Radio will operate through the
FM stereo system, adjustment of the audio functions (volume, tone,
balance, etc.) is made by using the controls on the car radio, while
selection of the desired audio channel is made using the Satellite
System Control Unit (SCU).
How the System Operates
Control of system functions is achieved by the wired SCU, which can
be conveniently mounted to the dashboard in a number of configurations. In addition, an optional wireless remote (Audiovox P/N SAT-RC)
to control SCU functions is also available. The XM® Satellite Radio
signals are received by the antenna and are routed to the RRU, whose
2
128-6210A
2 of 12
RF output is supplied to the RF Modulator. The RF Modulator, in turn, is
O RADIO
ANTENNA J
CK
VEHICLE
ANTENNA
RF MODULA
TELLITE ANTENNA
(PURCHASED SEP
ARA
TELY)Y)
capable of transmitting on seven (7) FM frequencies; namely, 88.1MHz,
88.3MHz, 88.5MHz, 88.7MHz, 88.9MHz, 89.1MHz and 89.3MHz. The frequency is selected using the FM band of the existing vehicle radio.
(The default FM frequency is 88.5MHz.) Select the FM frequency having
the least noise or static, and then use the SCU to choose the XM
channel for your listening pleasure.
1
®
2, 8
1
4
7
3
2
5
6
8
9
0
3
3
2
1
6
5
4
9
8
7
0
SFT
AUDIO OUT
LR DIN OUTSAT.TER.
SATELLITE RADIO
RECEIVER UNIT
(RRU)
R L
TO RRU
TO SCU
SATELLITE RADIO RF MODULATOR
POWER
TO CAR TO RADIO
ANT.
ANT.
RF MODULA
TOR
SATELLITE SYSTEM
TO RADIO
ANTENNA J
ACK
TO O VEHICLE
ANTENNA
CONTROL UNIT
(SCU)
SATELLITE ANTENNA
(PURCHASED SEP
VEHICLE-RF MODULATOR POWER
CABLE
13-PIN DIN CABLE
RCA to RCA CABLE
ARA
TEL
XM® Satellite Receiver System
SATELLITE SYSTEM CONTROL UNIT (SCU)
The SCU provides for complete control of the system by means of its
Liquid Crystal Display (LCD) and associated function buttons.
AUDIO OX
SFT
567
Satellite System Control Unit (SCU)
1. Liquid Crystal Display (LCD): Presents a display of various
system functions, such as channel/category number, type of
broadcast, song title, performer(s), advisory/error messages,
etc.
2. Down Directional ( ) Button: When momentarily pressed,
channel number decreases with each press; when pressed and
held, the channel number decreases continuously. Release the
button when the desired channel number is displayed. When used
in conjunction with the Shift (SFT) button, the
MUTE
enabled.
3. Keypad Buttons 0-9: These buttons are used to directly enter a
desired channel number. They are also used when entering and
recalling preset channel numbers into memory.
4. Up Directional ( ) Button: When momentarily pressed,
channel number increases with each press; when pressed and
held, the channel number increases continuously. Release the
button when the desired channel number is displayed. When used
in conjunction with the Shift (SFT) button, the
SCAN
enabled.
3
4
9
function is
function is
128-6210A
3 of 12
5. Infrared Detector: Provides detection of the infrared control
signal transmitted by an optional wireless remote control unit
(P/N SAT-RC) for remote operation. Make sure no obstructions
are blocking the signal path.
6. Shift (SFT) Button: When momentarily pressed, this button
provides access to additional functions, such as audio MUTE,
channel SCAN, direct channel access, category select, etc.
7. Power On/Off ( ) Button: Press this button to apply power
to the Satellite Radio Receiver. The associated stereo radio
must be turned on and off separately using its power switch.
8. Mute Function Button: Momentarily press the shift (SFT) but-
ton; then press and hold the down directional ( ) button to
enable the audio mute function. When enabled, the audio program is muted and the Mute icon ( ) appears in the lower
right corner of the SCU display. Press any button to exit the mute
function.
9. Scan Function Button: Momentarily press the shift (SFT)
button; then press and hold the Up directional ( ) button to
enable the up channel scan function. When enabled, each
channel is scanned in the up direction for 10 seconds before
moving on to the next active channel. Each channel number
appears in reverse image (white-on-black) format. This permits channel preview or introductory sampling of channel programming. Press any button to exit the scan function.
SATELLITE RADIO RECEIVER (RRU)
The RRU is the central data receiving equipment required to process
the satellite signals from the external antenna; it contains the processing logic needed to recognize, decode and distribute the incoming program information. The RRU is typically installed under the seat or in the
trunk/rear of the vehicle.
SATELLITE RADIO RF MODULATOR
The RF Modulator receives the satellite RF signals from the RRU and
provides the necessary FM pass-band logic to recognize and pass these
signals on to your existing vehicle’s FM stereo system. So, when your
radio is tuned to one of the FM frequencies between 88.1MHz and
89.3MHz, you can enjoy XM® programming. The RF Modulator is typically mounted behind or under the dashboard.
4
128-6210A
4 of 12
