Audiovox 1286158 User Manual

Page 1
OO
DISC
CLR
WNER'S MANUWNER'S MANU
WNER'S MANU
OO
WNER'S MANUWNER'S MANU
ALAL
AL
ALAL
SEL
PWR
LOUD
CDC
LUM
O
E
V
DISC
5
+
DISC
SEL
BAND
ACC-60
SCN
1
AUX
MO/AUX
ACC-60ACC-60
ACC-60
ACC-60ACC-60
RPT
2
RDM
43
4x40 WATTS
PGM
5
1
2
TUNE
3
5
TRK
4
MEM
T/F
CLK
6
CLR
AM/FM/MPX RADIO
WITH
FOLD-DOWN DETACHABLE FRONT PANEL,
5-DISC COMPACT DISC PLAYER
AND QUARTZ CLOCK
REL
AS/PS
Page 2
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
This unit is designed for installation in cars, trucks, and vans with an existing radio opening. In many cases, a special installation kit will be required to mount the radio to the dashboard. These kits are available at
IONSIONS
IONSIONS
IONS
electronics supply stores and car stereo specialist shops. Always check the kit application before purchasing to
TT
TT
T
make sure the kit works with your vehicle. If you need a kit but cannot find it available, call our toll-free “HELP” line
(1-800-645-4994).
UNIVERSAL INSTALLATION PROCEDURE USING MOUNTING SLEEVE
1. Remove the detachable front panel to prevent damage to the face and/or controls; use the Release (REL) button to allow the panel to fold down. Then withdraw the panel from the mounting plate. Slide the mounting sleeve off of the chassis. If it is locked into position, use the removal tools (supplied) to disengage it.
2. Check the dashboard opening size by sliding the mounting sleeve into it. If the opening is not large enough, carefully cut or file as necessary until the sleeve easily slides into the opening. Do not force the sleeve into the opening
ION INSTRUCION INSTRUC
ION INSTRUCION INSTRUC
ION INSTRUC
TT
TT
or cause it to bend or bow. Check that there will be sufficient space behind the dashboard for the radio chassis.
T
AA
AA
A
3. Locate the series of bend tabs along the top, bottom, and sides of the mounting sleeve. With the sleeve fully inserted into the dashboard opening, bend as many of the tabs outward as necessary so that the sleeve is firmly secured to the dashboard.
ALLALL
ALLALL
ALL
4. Place the radio in front of the dashboard opening so that the wiring can be brought through the mounting sleeve. Follow the wiring diagram carefully and make certain all connections of the wiring harness are
INSTINST
INSTINST
INST
secure and insulated with wire nuts or electrical tape to insure proper operation of the unit. After completing the wiring connections, attach the front panel and turn the unit on to confirm operation (ignition switch must be “on”). If unit does not operate, re-check all wiring until problem is corrected. Once proper operation is achieved, turn off the ignition switch and proceed with final mounting of the chassis.
5. Carefully slide the radio into the mounting sleeve making sure it is right-side-up until it is fully seated and the spring clips lock it into place.
6. Attach one end of the perforated support strap (supplied) to the screw stud on the rear of the chassis using the hex nut provided. Fasten the other end of the perforated strap to a secure part of the dashboard either above or below the radio using the screw and hex nut provided. Bend the strap to position it as necessary.
CAUTION: The rear of the radio must be supported with the strap to prevent damage to the dashboard from
7. Re-attach the front panel to the chassis and test radio operation by referring to the Operating Instructions for
INSTALLATION USING KITS
1. If your vehicle requires the use of an installation kit to mount this radio, follow the instructions included with
2. Wire and test the radio as described in Step 4 above.
3. Install the radio/mounting plate assembly to the sub-dashboard according to the instructions of the installation kit.
4. Attach the support strap to the radio and dashboard as described in Step 6 above.
5. Replace the dashboard trim panel.
ISO INSTALLATION PROCEDURE
This unit has threaded holes in the chassis side panels which may be used with the original factory mounting brackets of some Toyota, Nissan, Mitsubishi, Isuzu, Hyundai and Honda vehicles to mount the radio to the dashboard. Please consult with your local car stereo specialist shop for assistance on this type of installation.
1. Remove the existing factory radio from its dashboard or center console mounting. Save all hardware and
2. Carefully un-snap the plastic frame from the front of the new radio chassis. Remove and discard the frame.
3. Remove the factory mounting brackets and hardware from the existing radio and attach them to the new radio.
CAUTION: DO NOT EXCEED M5 X 8 MM MAXIMUM SCREW SIZE. LONGER SCREWS MAY TOUCH AND
22
2
22
4. Wire the new radio to the vehicle as per step 4 above.
5. Mount the new radio assembly to the dashboard or center console using the reverse procedure of step 1.
the weight of the radio or improper operation due to vibration.
the unit.
the installation kit to attach the radio to the mounting plate supplied with the kit.
brackets as they will be used to mount the new radio.
DAMAGE COMPONENTS INSIDE THE CHASSIS.
Page 3
TT
OLL-FREE INSTOLL-FREE INST
T
OLL-FREE INST
TT
OLL-FREE INSTOLL-FREE INST
The installation and wiring connections for this unit are so simple, we doubt you'll need our help, but, if you do, we're here to help you. Just call our toll-free telephone assistance line at 1-800-645-4994 during the days and hours shown (U.S.A. and Canada only).
DAY
MON. - FRI. SATURDAY
SLEEVE ADAPTER
HALF-SLEEVE
1
PACIFIC
5:30AM - 4PM 6AM - 2PM
UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE
UNIVERSAL INSTALLATION USING MOUNTING SLEEVE
UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE
PERFORATED SUPPORT STRAP
DASHBOARD
ALLALL
AA
ALL
A
ALLALL
AA
MOUNTAIN
6:30AM - 5PM
7AM - 3PM
TIME ZONE
2
1. SLIDE RADIO INTO HALF-SLEEVE.
2. SECURE TO STRAP USING BOL T IF POSSIBLE.
3. REINSTALL ANY ITEMS YOU REMOVED FROM THE DASHBOARD.
TT
ION ASSISTION ASSIST
T
ION ASSIST
TT
ION ASSISTION ASSIST
CENTRAL EASTERN
7:30AM - 6PM
8AM - 4PM
FASTEN THIS END TO SECURE PART OF DASHBOARD
BOLT (M4 X 8 MAX)
BEND TOP TABS UPWARD
SLEEVE ADAPTER (REF)
AA
NCENCE
A
NCE
AA
NCENCE
8:30AM - 7PM
9AM - 5PM
FASTEN THIS END TO BOLT HOLE IN REAR CENTER OF CHASSIS
BEND BOTTOM TABS DOWNWARD
HALF-SLEEVE (REF)
INST
INSTINST
INSTINST ALL
ALLALL
ALLALL A
AA
AA
T
TT
TT
ION INSTRUC
ION INSTRUCION INSTRUC
ION INSTRUCION INSTRUC
T
TT
TT
IONS
IONSIONS
IONSIONS
ISO-DIN FINAL INSTALLATION
1. REMOVE TRIM RING FROM FRONT OF RADIO.
2. MOUNT FACTORY BRACKETS ON NEW RADIO USING EXISTING SCREWS FROM OLD RADIO.
3. SLIDE RADIO AND FRAME INTO DASH OPENING
AND SECURE.
4. INSTALL DASH P ANELS PREVIOUSLY REMOVED.
33
3
33
Page 4
RR
AA
DIO WIRINGDIO WIRING
R
A
DIO WIRING
RR
AA
DIO WIRINGDIO WIRING
REFER TO PAGE 5 FOR SPEAKER WIRING
DIO WIRINGDIO WIRING
DIO WIRINGDIO WIRING
DIO WIRING
AA
AA
A RR
RR
R
44
4
44
Page 5
SPESPE
AA
KK
SPE
SPESPE
REFER TO PAGE 4 FOR RADIO WIRING
ER WIRINGER WIRING
A
K
ER WIRING
AA
KK
ER WIRINGER WIRING
! NEVER COMBINE (BRIDGE) OUTPUTS FOR USE WITH 1 SPEAKER. !
NEVER GROUND NEGATIVE SPEAKER LEADS TO CHASSIS GROUND.
! FAILURE TO WIRE EXACTLY AS SHOWN BELOW MAY CAUSE ELECTRICAL DAMAGE TO
THE RADIO.
WARNING!
SPE
SPESPE
SPESPE A
AA
AA K
KK
KK ER WIRING
ER WIRINGER WIRING
ER WIRINGER WIRING
55
5
55
Page 6
IONSIONS
DISC
CLR
IONSIONS
IONS
TT
TT
T
1
3,4,5,6,7,8
17
13,14,15
31 33
16,32
28,29
10,18,19
SEL
PWR
2
ING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUC
TT
TT
T
AA
AA
A
OPEROPER
OPEROPER
OPER
66
6
66
9
11
1 POWER (PWR) BUTTON
11
Press this button to turn the unit on and off. When the ignition switch is on, the radio will turn on automatically when the CDC, BAND or AUX button is pressed.
22
2 VOLUME CONTROL
22
To increase the volume level, rotate the VOLUME control in the clockwise direction. The volume will increase and the level will be shown on the display panel from a minimum of V -0 to a maximum of V -46 T o decrease the volume level, rotate the con­trol in the counterclockwise direction. The display will automatically return t o the nor­mal indication 5 seconds after the last vol­ume adjustment or when another function is activated. This control is also used in conjunction with the SEL/LOUD button to adjust the bass, treble, balance and fader levels as described in
33
3 SELECT (SEL)/LOUD BUTTON
33
This button is used to select the audio function (volume, bass, treble, balance or fade) to be adjusted using the VOLUME
LOUD
CDC
LUM
O
E
V
5
+
BAND
26
4 5 6 7.
4x40 WATTS
DISC
DISC SEL
ACC-60
27
SCN
RPT
1
MO/AUX
2
20 21 22 232425
control. Pressing the Select button once will set the unit for volume adjustment (VOL will mo­mentarily appear on the display panel, followed a few seconds later by V -- and the setting num­ber). Pressing the button additional times will select bass adjustment (BAS on display panel), treble adjustment (TRE), balance (BAL), fader (FAD), and volume (VOL) again. The display will return to the normal indication 5 seconds after the last adjustment or when another function is activated. Refer to paragraph function of this button.
44
4 BASS CONTROL
44
To adjust the bass level, first select the Bass mode by pressing the SEL/LOUD button until the BAS indication appears on the display panel. Within 5 seconds of choosing the Bass mode, rotate the VOLUME Control to adjust the bass response as desired. The bass level will be shown on the display panel from a minimum of B -6 to a maximum of B +6 (B 0 represents flat response). The display will automatically return to the normal indication 5 seconds after the last adjustment or when another function is activated.
12
RDM
PGM
5
43
REL
1
2
TUNE
3
5
AS/PS
TRK
4
MEM
CLK
T/F
6
CLR
11
30
8 for the LOUD
Page 7
55
5
TREBLE CONTROL
55
To adjust the treble level, first select the Treble mode by pressing the SEL/LOUD button until the TRE indication appears on the display panel. Within 5 seconds of choosing the Treble mode, rotate the VOLUME control to adjust the treble response as desired. The treble level will be shown on the display panel from a minimum of T -6 to a maximum of T +6 (T 0 represents flat response). The display will auto­matically return to the normal indication 5 seconds after the last adjustment or when another function is activated.
66
6 LEFT/RIGHT BALANCE CONTROL
66
To adjust the left-right speaker balance, first select the Balance mode by pressing the SEL/LOUD but­ton until the BAL indication appears on the display panel. Within 5 seconds of choosing the Balance mode, rotate the VOLUME control clockwise to ad­just it to the right channel speakers, or counterclock­wise to adjust it to the left channel speakers. The balance position will be shown on the display panel from L 12 (full left) to R 12 (full right). When the volume level between the left and right speak­ers is equal, C 00 will be shown on the display panel. The display will automatically return to the normal indication 5 seconds after the last ad­justment or when another function is activated.
77
7 FRONT/REAR F ADER CONTROL
77
To adjust the front-rear speaker balance, first select the Fader mode by pressing the SEL/ LOUD button until the FAD indication appears on the display panel. Within 5 seconds of choosing the Fader mode, rotate the VOLUME control clock­wise or counterclockwise to adjust the front-rear speaker levels as desired. The fader position will be shown on the display panel from F 12 (full front) to R 12 (full rear). When the volume level between the front and rear speakers is equal, C 00 will appear on the display panel. The display will auto­matically return to the normal indication 5 sec­onds after the last adjustment or when an­other function is activated.
88
8 LOUDNESS CONTOUR (LOUD)
88
When listening to music at low volume levels, this feature will boost the bass and treble ranges to
compensate for the characteristics of hu­man hearing. Press and hold the SEL/ LOUD button for at least 2 seconds to acti­vate this feature as indicated by LOUD on the display panel. Pressing the button again for 2 seconds will de-activate the function and LOUD will disappear from the display.
99
AM/FM BAND SELECTOR
9
99
During radio play, each time the button is pressed, the radio band changes. The indications AM will appear on the display panel accord­ing to your selection.
During CD play, pressing this button will change to radio operation without ejecting the disc.
blbl
bl UP/DOWN TUNING ( / )/CD TRACK
blbl
(TRK) SELECTION
During radio operation, each time the Up TUNE button ( )is pressed, the radio will tune two frequency steps higher. Similarly, each press of the Down TUNE button ( ) will tune two frequency steps lower. Press­ing either button for longer than 1 second and then releasing will activate the auto­matic seek tuning function, whereby the ra­dio will seek the next station in the selected direction and stop and remain at that fre­quency.
Pressing and holding either button for longer than 1 second will cause the radio to con­tinue tuning rapidly in the selected di­rection until the next available station and momentarily stop there. Tuning will continue unless the button is released at the desired station. During CD player operation, these buttons are used to select a desired track on the disc. (Refer to Track Select.)
bmbm
bm AUTO-STORE TUNING (AS)
bmbm
PRE-SET SCAN TUNING (PS)
Press this button momentarily to scan the 6 stations in the pre-set memories of
II
I, AM
II
IIII
II, FM
IIII
II
I, FM
II
IIII
II, or FM
IIII
IIIIII
III
IIIIII
OPER
OPEROPER
OPEROPER A
AA
AA
T
TT
TT
ING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
T
TT
TT
IONS
IONSIONS
IONSIONS
77
7
77
Page 8
the band in use. The unit will stop at each pre-set station for 10 seconds before continu-
IONSIONS
IONSIONS
IONS
ing to the next pre-set station (the frequency
TT
TT
T
on the display panel will flash during Pre-Set Scan operation). Press the button again momentarily to stop Pre-Set Scan operation and remain on the selected frequency.
Pressing the button for longer than 2 sec­onds will activate the Auto-Store Tuning fea­ture. The radio will automatically scan the band
ING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUC
in use and enter strong local stations into
TT
TT
T
the pre-set memory positions for that
AA
AA
A
band. LOC will appear on the display as tuning occurs. If you have already set the pre-set memories of that band to your favor-
OPEROPER
OPEROPER
OPER
ite stations, activating the Auto-Store Tun­ing feature will erase those stations and enter the new stronger stations. This fea­ture is most useful when traveling in a new area where you are not familiar with the lo­cal stations.
bnbn
bn STA TION PRE-SET MEMORIES
bnbn
T o manually set any of the 6 pre-set memory buttons, use the following procedure:
1. Turn the unit on and select the desired band.
2.Select the first station to be pre-set using the TUNE/TRK buttons.
3. Press and hold the pre-set button to be set for approximately 2 seconds. The pre-set number CH 1-6 will appear on the display, indicating the station is now set into the memory position of that pre-set button and can be recalled at any time by momentarily pressing that button.
4.Repeat the above procedure for the remaining 5 pre-sets on the band in use and for the other 4 bands of the unit.
bobo
bo FM STEREO/LOCAL (LOC) INDICATIONS
bobo
The unit receives both stereo and monaural signals. During FM radio operation, the unit is usually receiving a stereo signal as indi-
88
8
88
cated by the stereo icon ( play. If a stereo sig nal is too weak for com-
) on the dis-
fortable listening, the stereo indication will ap­pear intermittently or not at all; if an AM or monau­ral signal is received, the icon will disappear from the display panel.
bpbp
bp LIQUID CRYST AL DISPLA Y P ANEL
bpbp
The Liquid Crystal Display (LCD) panel displays the frequency, time, and activated functions.
NOTE:It is a characteristic of LCD panels that, if
subjected to cold temperatures for an extended period of time, they may take longer to illuminate than under normal conditions. In addition, the visibility of the numbers on the LCD may slightly decrease. The LCD readout will return to normal when the temperature increases to a normal range.
bqbq
bq FUNCTION DISPLA Y
bqbq
The Function Display consists of a single bar graph which displays a bar graph which provides a visual representation of the audio signal power
As the volume is increased, the number of
level. illuminated segments will increase.
br br
br DISC SLOT
br br
With the label surface facing up, gently insert each disc into the slot until the soft-loading mecha­nism engages and draws the disc into the player. The number of discs loaded will appear both on the front panel display disc icon (flashing white segment) and on the DISC INF display on the rear of the front panel. The discs will be loaded in order beginning with the number (1-5) currently displayed. Disc play will begin when the CDC button is pressed; and play will start with track 1 on the last disc loaded, unless another disc is selected using the DISC SEL button on the front side of the panel.
NOTE: This unit is designed for play of standard
5" (12cm) Compact Discs attempt to use 3" (8cm) CD-Singles in this unit, either with or without an adap­ter, as damage to the player and/or disc can occur. Such damage will not be cov­ered by the Warranty on this product.
ONLY. Do not
Page 9
bsbs
3
4
2
1
bs CD PLA Y/PAUSE SELECT OR (CDC/ II )
bsbs
When listening to the radio with a disc loaded in the unit ( nated on the display panel), press this button to
return to disc play mode from the beginning of the last track in play.
During disc play, press this button to temporarily stop play of the disc (PAUS will appear on the display panel). Press the button again to resume play from the point at which it was stopped. Pause mode will also be canceled by activating any other disc function.
btbt
bt TRACK (TRK) SELECT ( / )
btbt
The Track Select functions are used to quickly access the beginning of a particular track. Each time the Forward Track Select ( ) button is pressed, the next higher track number will be selected as shown on the display panel. Simi­larly, each time the Backward Track Select ( ) button is pressed, the next lower track number will be selected as shown on the display panel.
bubu
bu CUE/REVIEW FUNCTIONS ( / )
bubu
High-speed audible search to any section of the disc can be made by the Cue and Review functions. Press and hold the Cue button ( ) to advance rapidly in the forward direction or the Review button ( ) to advance rapidly in the backward direction. During either function, the elapsed time within each track will automatically be shown on the display panel.
clcl
cl TRACK SCAN SELECTOR (SCN)
clcl
During disc play, press this button to play the first 10 seconds of each track on the disc in play (SCN will appear on the display panel and the track num­ber will flash). When a desired track is reached, press the Track Scan button again to cancel the function and play of the selected track will con­tinue. Track Scan mode will also be canceled by activating the Repeat Play or Random Play func­tions.
cmcm
cm TRACK REPEAT PLA Y SELECTOR (RPT)
cmcm
During disc play, press this button to repeat th e play of the selected track (RPT will appear on
1
2
3
icon disc number segment illumi-
5
4
the display panel). Play of the track will con­tinue to repeat until the button is pressed again and the RPT indication disappears from the display panel. Repeat Play mode will also be canceled by activating the Track Scan or Random Play functions.
cncn
cn
REPEAT A - B SELECTOR (RPT A -B)
cncn
The Repeat A - B function is used to select a section of the disc other than a complete track to be repeated. Press and hold the button at the beginning of the section that you wish to have repeated (RPT and A will appear on the display panel). Allow the disc to play to the end of the section that you wish to have repeated and then press and hold the button again (the A on the dis­play panel will change to a b). The selected section will be played repeatedly until the function is canceled by pressing the RPT A-B button again or activating any other disc function.
co co
co RANDOM PLAY SELECTOR (RDM)
co co
During disc play , press this button to play the tracks on the disc in a random shuffled order (RDM will appear on the display panel). In Random Play mode, the Forward Track Select ( ) will also select tracks in the random order instead of the normal progres­sion. Backward Track Select ( ) will go back to the beginning of the track in play if it has played longer than 5 seconds or to a random track if it has played less than 5 seconds. The Random Play mode can be canceled by pressing the button again ( RDM indication will disappear from the display panel).
cpcp
cp MEMORY/CLEAR SELECTOR (MEM/CLR)
cpcp
Up to 18 tracks can be programmed for play in any order you select. The following pro­cedure is used to program the order of track play:
1. Select a disc in the unit to begin disc play.
2. Select the first track to be programmed using the Track Select buttons
OPER
OPEROPER
OPEROPER A
AA
AA
T
TT
TT
ING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
T
TT
TT
IONS
IONSIONS
IONSIONS
99
9
99
Page 10
(TUNE/TRK) and press the MEMory
3
4
2
1
Selector button. The indication M - 01
IONSIONS
IONSIONS
IONS
will momentarily appear on the display
TT
TT
T
panel, indicating that the selected track has been entered as the first one to be played in Programmed Play mode.
3. Select the second track to be pro­grammed (this could be on another disc) using the Track Select button and then
ING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUC
press the Memory Selector button. M -02
TT
TT
T
will appear on the display, and the
AA
AA
A
selected track has been entered as the second one to be played in Programmed Play mode.
OPEROPER
OPEROPER
OPER
4. In similar manner, continue selecting other tracks (up to a maximum of 18) to be played in programmed order. The indication FULL will appear on the display panel if attempting to program more than 18 selections.
cqcq
cq PROGRAMMED PLA Y SELECTOR (PGM)
cqcq
To play the tracks in the selected order after programming is completed, press the Pro­grammed Play button so that the PGM indi­cation appears on the display panel. Play will begin of the first track selected in the programmed order. During Pro­grammed Play mode, the Track Select func­tions will operate in the programmed order instead of the normal progression. Track Scan and Track Repeat can be selected during Programmed Play and will operate on the programmed tracks.
To de-activate Programmed Play and return to play of all tracks on the disc in normal order, press the Programmed Play button again so that the PGM disappears from the display panel. Activating the Cue/Review functions or the Random Play mode will also cancel Programmed Play mode.
Clearing Programmed Play Memory: T o clear
1010
10
1010
the Programmed Play memory, press the Memory Clear button at any time during Pro­grammed Play mode (PGM on display
panel). PGM will disappear from the display panel, M --- CL will appear momentarily, and the pro­gram will be erased. The Programmed Play memory will also be cleared automatically when the disc(s) is ejected.
NOTE: Program Play memory will be maintained
crcr
cr DISC SELECT (DISC SEL) BUTTON
crcr
When this button is pressed during disc play, the next CD in order is selected for play. The selected DISC segment number (1-5) is highlighted on the front panel disc icon ( ) and flashes while play is active. The segment number also flashes dur­ing radio operation if the disc(s) is still installed.
cs cs
cs AUXILIARY (AUX) BUTTON
cs cs
If an portable audio device, is connected to the Left and Right auxiliary input jacks, this source can be selected for play through the radio by pressing the AUX button. When the button is pressed, A --in appears on the display panel. When the auxiliary input is being used, no other audio input sources (radio or CD) are operational.
ctct
ct P ANEL DISC SELECT (DISC SEL) BUTTON
ctct
The back of the front panel contains a DISC SEL button which is used in conjunction with the disc
number LCD and Disc Eject ( a particular CD you wish to remove and/or replace. When the DISC SEL button is pressed, the disc number display to the left sequences through discs 1-5. Stop at the number disc you wish to eject and press the eject button. The selected disc will be ejected.
cucu
cu DISC EJECT ( )
cucu
Disc play is stopped; the disc currently selected for play is ejected and the unit will revert to radio operation by pressing this button (EJT will briefly appear on the display panel). When the disc is ejected, no cd appears on the display; press BAND to return to radio operation. The disc must be removed from the unit or be reloaded. P res sin g the Di sc Eject button for at least 2 seconds will eject all discs from the unit in sequence, beginning with the disc currently in play.
if the disc is left in the player when the unit is shut off.
1
2
3
5
4
) button to select
Page 11
dldl
dl TIME/FREQUENCY DISPLA Y SELECTOR (T/F)
dldl
Press this button to call the time display on the incorporated quartz clock. Press the button again to return to radio frequency or disc display, or it will return automatically after 5 seconds.
dmdm
dm THEFT-DETERRENT LED
dmdm
A light-emitting diode (LED) with lens is mounted on the front of the chassis behind the panel mount­ing plate; the LED will flash at 1-second intervals when the panel folds down, and will flash at 2­second intervals when the panel is removed from the radio. The flashing light serves as both a visual reminder that the panel has been released, or as a warning to a would-be thief that the unit has been disabled by removal of the front panel.
dndn
dn RESET BUTTON
dndn
A RESET button is accessible on the rear of the front panel when it is in the fold-down position. The reset circuitry is provided to protect the microproces­sor circuitry and should only be activated un­der the following circumstances.
1. Upon initial installation after all wiring is completed.
2. If there is a malfunction of any of the switches on the unit or of the CD player, pressing the RESET button may clear the system and return the unit to normal op­eration.
CAUTION: Pressing the RESET button will cause all discs to be ejected. When the RESET button is pressed be certain that the front panel is in the down position.
dodo
do FRONT PANEL RELEASE (REL) BUTTON
dodo
This button is used to release the mecha­nism that holds the front panel to the chas­sis. To detach the front panel, press the but­ton; the panel will fold down to the horizontal position. At the center of the panel, press the release clip to disengage the panel from the mounting plate, and pull the panel straight out until it clears the mounting plate guides. To re-attach the panel, position the panel so both sides engage the mounting plate guides; then slide the panel home until the mecha­nism locks it into place in the mounting plate.
NOTES ON USE OF FRONT PANEL
1. Make sure the front panel is right-side-up when attaching it to the chassis as it cannot be attached when up-side down.
2.Do not press very hard on the front panel when attaching it to the chassis. No more than light to moderate pressure should be needed.
3. When attaching the front panel, make sure the right side is correctly engaged before pressing the left side to lock it into position.
4. When taking the front panel with you, please use the supplied carrying case to protect the panel from dirt and damage.
OPER
OPEROPER
OPEROPER A
AA
AA
T
TT
TT
ING INSTRUC
ING INSTRUCING INSTRUC
ING INSTRUCING INSTRUC
T
TT
TT
IONS
IONSIONS
IONSIONS
PANEL MOUNTING PLATE
MOUNTING PLAT E GUIDE (2 PLACES)
PANEL RELEASE CLIP (PRESS TO REMOVE PANEL FROM MOUNTING PLATE)
FRONT PANEL
RESET BUTTON (32)
DISC SELECT DISPLAY
DISC SLOT
THEFT DETERRENT LED
DISC SELECT (DISC SEL) BUTTON
CD EJECT ( ) BUTTON
1111
11
1111
Page 12
SETSET
TT
ING THE CLOCKING THE CLOCK
SET
T
ING THE CLOCK
SETSET
TT
ING THE CLOCKING THE CLOCK
1. Switch the vehicle ignition “on” and the radio “on” (radio frequency or disc track number will be shown on the display panel).
OR CODESOR CODES
OR CODESOR CODES
OR CODES
2. Press and hold the time button (T/F) approximately 2 seconds until the time display appears with AM or PM and the colon ( : ) flashing. Release the T/F button.
3. Press the Down Tuning button ( ) to adjust the hours and the AM/PM indication, and the Up Tuning button ( ) to adjust the minutes to the correct time.
4. When the correct time is shown on the display panel, wait 5 seconds for the display to return to the normal indication.
ERROR CODESERROR CODES
ERROR CODES
ING THE CLOCK / ERRING THE CLOCK / ERR
ING THE CLOCK / ERRING THE CLOCK / ERR
ING THE CLOCK / ERR
TT
TT
T
If a problem should develop while operating the CD player, the following error codes may be displayed on the display panel:
SETSET
SETSET
SET
INF-1: Indicates mechanical malfunction. Press the Reset button dn. INF-2: Indicates mechanical malfunction. Press the Reset button dn. INF-3: Indicates mechanical malfunction. Press the Reset button dn. INF-4: Indicates disc focus error. Press the Reset button dn. INF-5: Indicates disc focus error. Press the Reset button dn.
ERROR CODESERROR CODES
1212
12
1212
INF-6: Indicates mechanical malfunction. Press the Reset button dn. INF-7: Indicates data error . Press the Reset button dn.
INF-8: Indicates disc reading error. Eject the disc, make sure
it is clean, undamaged, and loaded correctly (label side up). Re-load the disc and check for proper operation or try another disc.
INF-9: Indicates disc lever error. Press eject button.
If the suggested measures do not solve the problem, contact an approved warranty station near you for further assistance.
Page 13
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICA
SPECIFICASPECIFICA
SPECIFICASPECIFICA
Size: 7" W x 2" H x 6-1/4" D
178 mm x 50 mm x 160 mm Operating Voltage: 12 volts DC, negative ground Output Power: 160 watts maximum
(40 watts x 4 channels) Output Wiring: Floating-ground type designed for 4 speaker use.
Front and rear channels CANNOT be combined
(bridged) for use with 2 speakers.
RCA low-level outputs (rear channels). Output Impedance: Compatible with 4-8 ohm speakers. Low-Level Output: 2.0 Volts (2000 mv) Tuning Range: AM: 530-1,720 kHz. (10 kHz. step)
FM: 87.5-107.9 MHz. (200 kHz. step) Sensitivity: AM: 20 uV.
FM: 3.0 uV. FM Stereo Separation: 30 dB CD Frequency Response: 20-20,000 Hz. ±1 dB CD Signal/Noise Ratio: 70 dB CD Channel Separation: 60 dB CD Distortion: 0.10%
T
TT
TT
IONS
IONSIONS
IONSIONS
*Specifications are subject to change without notice.
1313
13
1313
Page 14
CARE AND MAINTENANCECARE AND MAINTENANCE
CARE AND MAINTENANCE
CARE AND MAINTENANCECARE AND MAINTENANCE
The radio section of your new sound system does not require any maintenance. We
NCENCE
NCENCE
NCE
recommend that you keep this manual for reference on the many features found in this unit as well as how to set the clock.
The compact disc player section also requires no routine maintenance, but proper understanding of its use and handling will help you obtain maximum enjoyment of its
INTENAINTENA
INTENAINTENA
INTENA
capabilities. The following points should be observed:
! When cleaning the interior of the vehicle, do not get water or cleaning fluids on the unit. ! The CD player is a precision instrument and will not operate properly in extreme heat or cold.
ND MAND MA
ND MAND MA
ND MA
In case of such conditions, wait until the interior temperature of the vehicle reaches a normal temperature before using the player.
RE ARE A
RE ARE A
RE A
! If the temperature inside the player gets too hot, a protective circuit will automatically stop
play of the disc. In this case, allow the unit to cool off before operating the player again.
CACA
CACA
CA
! Never insert anything other than 5" (12 cm) compact discs into the player as the
mechanism can be damaged by foreign objects.
! Do not attempt to use 3" (8 cm) CD-Single discs in this unit, either with or without an adaptor,
as damage to the player and/or disc may occur. Such damage will not be covered by the Warranty on this product.
! When not using the disc player, always remove the compact disc. Do not leave an ejected
disc sitting in the disc slot as this can expose it to sunlight and other causes of damage.
! Do not attempt to open the unit chassis. There are no user serviceable parts or adjustments inside. ! When the vehicle warms up during cold weather or under damp conditions, moisture may
condense on the lens of the disc player. Should this occur, the player will not operate properly until the moisture has evaporated.
! The unit is designed with a vibration dampening CD mechanism to minimize interruption of
disc play due to normal vibration in a moving vehicle. When driving on very rough roads, however, occasional sound skips may occur. This will not scratch or damage the disc and normal play will resume when the rough conditions cease.
HANDLING COMPACT DISCS
Dirt, dust, scratches, and warpage can cause skips in the playback and deterioration of sound quality. Please follow these guidelines to take care of your compact discs:
! Use only compact discs with the mark . ! Fingerprints, dust, and dirt should be carefully wiped off the disc’s playing surface (shiny side)
with a soft cloth. Wipe in a straight motion from the inside to the outside of the disc.
! Never use chemicals such as record sprays, household cleaners or thinner to clean compact
discs. Such chemicals can irreparably damage the disc’s surface.
1414
14
1414
! Discs should be kept in their storage cases when not in use. ! Do not expose discs to direct sunlight, high temperatures or high humidity for extended periods. ! Do not stick paper, tape, or labels on the disc surfaces nor write on them with any type of marker.
Page 15
WARRANTY
WARRANTYWARRANTY
WARRANTYWARRANTY
12 MONTH LIMI12 MONTH LIMI
12 MONTH LIMI
12 MONTH LIMI12 MONTH LIMI
AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company's option) without charge for parts and repair labor.
To obtain repair or replacement within the terms of this Warranty, the product is to be delivered with proof of warranty coverage (e.g. dated bill of sale), specification of defect(s), transportation prepaid, to the warranty center at the address shown below.
This Warranty does not extend to the elimination of car static or motor noise, to correction of antenna problems, to costs incurred for installation, removal, or reinstallation of the product, or damage to tapes, compact discs, speakers, accessories, or vehicle electrical systems.
This Warranty does not apply to any product or part thereof which, in the opinion of the Company, has suffered or been damaged through alteration, improper installation, mishandling, misuse, neglect, accident, or by removal or defacement of the factory serial number/bar code label(s). THE EXTENT OF THE COMPANY'S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY'S LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY HEREUNDER INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 30 MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. No person or representative is authorized to assume for the Company any liability other than expressed herein in connection with the sale of this product.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damage so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal rights and you may also have other rights which vary from state to state.
TED WTED W
TED W
TED WTED W
AA
RRRR
AA
NTNT
A
RR
AA
RRRR
YY
A
NT
Y
AA
NTNT
YY
U.S.A.: AUDIOVOX CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788 • 1-800-645-4994 CANADA: CALL 1-800-645-4994 FOR LOCATION OF WARRANTY STATION SERVING YOUR AREA
Form No. 128-4270E
1515
15
1515
Page 16
16
© 2001 Audiovox Electronics Corp., Hauppauge, NY 11788
1616
16
1616
Printed in China
128-6158
128-6158
16 of 20
Loading...
