Page 1
Model AA-RS10CS
Owner’s Manual
3 Channel Remote Car Starter
FEATURES :
w 2 Three Button Programmable RF Transmitters
w Three Channel Receiver
w Code Hopping Technology
w ( + ) and ( - ) Keyless Entry Outputs
w On-Board Start Relay
w On-Board Accessory Relay
w On-Board Ignition 1 Relay
w On-Board Ignition 2 Relay
w Ignition 2 Relay Selectable On or Off During Cranking
w On-Board Parking Light Relay
w Ignition 3 / Shock By-Pass / GM VAT Output (relay required)
w Tach Signal Learning Circuit
w Two ( + ) and Two ( - ) Safety Shutdown Circuits
w Alarm By-Pass Output
w Channel 2 Output for Remote Trunk Release (relay required)
w Channel 3 Output to Control Optional Accessories
w Selectable Steady or Flashing Parking Lights for Run Indication
w Selectable 10 or 15 Minute Run Time
w Selectable 1 Second or 3.5 Second Door Lock Output Pulse
(capable of accepting 4 transmitters)
Page 2
YOUR “CODE HOPPING” TRANSMITTERS
The transmitters included with your new remote start
1
system use the most advanced and secure form of radio
frequency transmission available on any current automotive
2
3
remote system. Some of today’s sophisticated auto
thieves use a device known as a code grabber, which
will receive and store the signal from your keychain
transmitter, and re-transmit at a later time to disarm
your system.
Y our code hopping transmitters will change their signal every time
the button is pressed, so when a thief grabs then re-transmits
your signal, the alarm system
will not
respond.
If your transmitter button is pressed more than fifty times while it is
out of range of the vehicle (children playing with your keys), the
transmitter will not operate when you return to the vehicle, and will
need to be re-aligned to the receiver. To do this, simply press
button 1 two times within a one second time period. The system
will now respond to that transmitter each time a button is pressed.
KEYLESS ENTRY
1. Button 1 on the transmitter is used to lock and unlock the vehicle's
doors. To lock or unlock the doors simply press and release this
button one time. As a keyless entry unit, for your convenience, the
parking lights will flash once when the doors are locked and twice
when the doors are unlocked.
REMOTE ST ARTING THE VEHICLE
The AA-RS10CS will not start the vehicle if any one of the following situations exists;
The vehicle's hood lid is opened.
The gear shift selector is not in Park.
The brake pedal is depressed.
The safety control switch is in the Off position.
Page 2
Page 3
1. T o start the vehicle, press and release the second transmitter button two
times within 2 seconds. The vehicle will start and remain running for the
pre-programmed 10 or 15 minute run cycle. As a visual indication, the
parking lights will flash or remain on depending on the setting by your
installation center.
2. When you arrive at the vehicle, turn the ignition key to the ON position
(not the spring loaded start position), then step on the brake pedal to
disengage the remote starter. The vehicle will continue to run, but now
on it's own power.
NOTE:The engine will stop running before the pre-programmed run
cycle has expired if you perform any one of the following
functions;
- Press and release the KEY icon transmitter button on the
keychain transmitter two times within 2 seconds.
- Depress the brake pedal.
- Open the vehicle's hood
- Move the safety control switch to the Off position.
SAFETY CONTROL SWITCH
The control switch allows you to temporarily disable the remote starting
function of the system and moving this switch to the Off position is
recommended whenever the vehicle is being serviced. When the system
is disabled, the remote door locks and optional accessories will remain
operational.
ADDITIONAL REMOTE FUNCTION (CHANNEL 2)
This system has an additional feature that can be connected to a number
of different optional accessories. Some of the more common uses for this
channel are;
o Remote Trunk Release
o Remote Window Closure
o Remote Garage Door Interface
Page 3
Page 4
To activate the optional accessory, press and hold the transmitter's button
2 for 4 seconds.
NOTE:The feature that has been added to channel 2 will always be
act iva ted using the same transmitter button that remotely starts
the vehicle. There is no way to move the channel 2 function to a
different transmitter button.
ADDITIONAL REMOTE FUNCTION (CHANNEL 3)
This system has an additional feature that can be connected to a number
of different optional accessories. Some of the more common uses for
this channel are;
o Remote Trunk Release
o Remote Window Closure
o Remote Garage Door Interface
To activate the optional accessory, press the transmitter button with the
word OPTION on it. The optional accessory will immediately engage.
FUNCTION SETTING CHART
To be completed by installer
Door Lock Time 3.5 o 1 Sec. o
Lights Pulse o Steady o
Run Time 10 Min. o 15 Min. o
© 2000 Audiovox Electronics Corporation, Hauppauge N.Y. 11788 128-5849
