DETACHABLE FRONT PANEL AM/FM/MPX RADIO WITH

COMPACT DISC PLAYER, CD CHANGER CONTROLS AND

QUARTZ CLOCK

Released 4-24-00. Revision A: Corrected pages 8,9,10,12,13. 6-13-00.

Revision B: Changed clock description and setting procedure 11-3-00. Revision C: Translated to Spanish 12-5-00. Revision D: Added CD-R and CD-RW specification notice 5-9-02. Revision E: Incorporated new front panel layout and text changes.

128-5780E

1 of 48

INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS

INSTALLATION INSTRUCTIONS

INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS

This unit is designed for installation in cars, trucks, and vans with an existing radio opening. In many cases, a special installation kit will be required to mount the radio to the dashboard. These kits are available at electronics supply

IONSIONS

IONS

stores and car stereo specialist shops. Always check the kit application before purchasing to make sure the kit

works with your vehicle. If you need a kit but cannot find it available, call our toll-free “HELP” line (1-800-645-4994).

UNIVERSAL INSTALLATION PROCEDURE USING MOUNTING SLEEVE

1. Remove the detachable front panel if it is attached to the chassis by pushing the “Release” button. Slide the mounting sleeve off of the chassis. If it is locked into position, use the removal tools (supplied) to disengage it.

2. Check the dashboard opening size by sliding the mounting sleeve into it. If the opening is not large enough, carefully cut or file as necessary until the sleeve easily slides into the opening. Do not force the sleeve into the opening or cause it to bend or bow. Check that there will be sufficient space behind the dashboard for the radio chassis.

3. Locate the series of bend tabs along the top, bottom, and sides of the mounting sleeve. With the sleeve fully inserted

ION INSTRUCION INSTRUC

ION INSTRUC

into the dashboard opening, bend as many of the tabs outward as necessary so that the sleeve is firmly secured

to the dashboard.

4. Place the radio in front of the dashboard opening so that the wiring can be brought through the mounting sleeve. Follow the wiring diagram carefully and make certain all connections of the wiring harness are secure and insulated

ALLALL

ALL

with wire nuts or electrical tape to insure proper operation of the unit. After completing the wiring connections, attach the front panel and turn the unit on to confirm operation (ignition switch must be “on”). If unit does not operate, re-check all wiring until problem is corrected. Once proper operation is achieved, turn off the ignition switch and

INSTINST

INST

proceed with final mounting of the chassis.

5. Carefully slide the radio into the mounting sleeve making sure it is right-side-up until it is fully seated and the spring clips lock it into place.

6. Attach one end of the perforated support strap (supplied) to the screw stud on the rear of the chassis using the hex nut provided. Fasten the other end of the perforated strap to a secure part of the dashboard either above or below the radio using the screw and hex nut provided. Bend the strap to position it as necessary.

CAUTION: The rear of the radio must be supported with the strap to prevent damage to the dashboard from the

7. Re-attach the front panel to the chassis. Establish a location for the remote input jack (usually the underside of the dashboard) if it is a feature of the radio. Anchor it in place using two self-tapping screws (M5x6). Do not over-tighten screws. Test radio operation by referring to the Operating Instructions for the unit.

INSTALLATION USING KITS

1. If your vehicle requires the use of an installation kit to mount this radio, follow the instructions included with the installation kit to attach the radio to the mounting plate supplied with the kit.

2. Wire and test the radio as described in Step 4 above.

3. Install the radio/mounting plate assembly to the sub-dashboard according to the instructions of the installation kit.

4. Attach the support strap to the radio and dashboard as described in Step 6 above.

5. Replace the dashboard trim panel.

ISO INSTALLATION PROCEDURE

This unit has threaded holes in the chassis side panels which may be used with the original factory mounting brackets of some Toyota, Nissan, Mitsubishi, Isuzu, Hyundai and Honda vehicles to mount the radio to the dashboard. Please consult with your local car stereo specialist shop for assistance on this type of installation.

1. Remove the existing factory radio from its dashboard or center console mounting. Save all hardware and brackets as they will be used to mount the new radio.

2. Carefully un-snap the plastic frame from the front of the new radio chassis. Remove and discard the frame.

3. Remove the factory mounting brackets and hardware from the existing radio and attach them to the new radio.

CAUTION: DO NOT EXCEED M5 X 6 MM MAXIMUM SCREW SIZE.

4. Wire the new radio to the vehicle as per step 4 above.

5. Mount the new radio assembly to the dashboard or center console using the reverse procedure of step 1.

weight of the radio or improper operation due to vibration.

LONGER SCREWS MAY TOUCH AND DAMAGE COMPONENTS INSIDE THE CHASSIS.

128-5780E

2 of 48

OLL-FREE INSTOLL-FREE INST

OLL-FREE INST

OLL-FREE INSTOLL-FREE INST

The installation and wiring connections for this unit are so simple, we doubt you'll need our help, but, if you do, we're here to help you. Just call our toll-free telephone assistance line at 1-800-645-4994 during the days and hours shown (U.S.A. and Canada only).

DAY

MON. - FRI. SATURDAY

NUT (5MM)

SCREW (5MM)

NUT (5MM)

FASTEN THIS END TO SECURE PART OF DASHBOARD. DRILL HOLE IF NECESSARY.

FOR PROPER OPERATION OF THE CD PLAYER, THE CHASSIS MUST BE MOUNTED WITHIN 20° OF HORIZONTAL. MAKE SURE THE UNIT IS MOUNTED WITHIN THIS LIMITATION.

SIDE VIEW

CHASSIS

PACIFIC

5:30AM - 4PM 6AM - 2PM

UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE

UNIVERSAL INSTALLATION USING MOUNTING SLEEVE

UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE

PERFORATED STRAP

FASTEN THIS END TO SCREW STUD ON REAR OF CHASSIS

MOUNTING SLEEVE

CAUTION:

20° MAX.

FRONT PANEL

ALLALL

ALL

ALLALL

MOUNTAIN

6:30AM - 5PM

7AM - 3PM

EXISTING DASH OPENING FILE EDGES TO FIT IF NECESSARY - DO NOT OVERFILE NOTE: IF DASH IS SOLID, USE REAR SIDE (WITHOUT THE LIP) OF MOUNTING SLEEVE AS A TEMPLATE & CUT OPENING

SCREW STUD

ION ASSISTION ASSIST

ION ASSIST

ION ASSISTION ASSIST

7:30AM - 6PM

8AM - 4PM

RADIO

REMOVAL TOOLS

CENTRAL

NCENCE

NCE

NCENCE

EASTERN

8:30AM - 7PM

9AM - 5PM

BEND TOP TABS UPWARD

BEND BOTTOM TABS DOWNWARD

DETACHABLE FRONT PANEL

INST

INSTINST

INSTINST ALL

ALLALL

ALLALL A

ION INSTRUC

ION INSTRUCION INSTRUC

IONS

IONSIONS

ISO INSTALLATIONISO INSTALLATION

ISO INSTALLATION

ISO INSTALLATIONISO INSTALLATION

REMOVE THE PLASTIC FRAME FROM THE FRONT OF THE CHASSIS BY CAREFULLY UN-SNAPPING IT.

UN-SNAP AT 2 PLACES EACH ON TOP AND BOTTOM

PLASTIC FRAME

MAXIMUM

SCREW SIZE

M5 x 6

FACTORY MOUNTING BRACKETS

TYPICAL INSTALLATION

MAXIMUM

SCREW SIZE

M5 x 6

128-5780E

3 of 48

DIO WIRINGDIO WIRING

DIO WIRING

DIO WIRINGDIO WIRING

REFER TO PAGE 5 FOR SPEAKER WIRING

ANTENNA

RADIO WIRING

EXISTING ANTENNA CABLE

ANTENNA SOCKET ON REAR OF RADIO

AUTOMATIC

ANTENNA

FILTER/FUSE

BOX

BLUE IMPORTANT

THE BLUE WIRE CAN BE USED TO REMOTELY ACTIVATE AN AUTOMATIC ANTENNA OR AN EXTERNAL AMPLIFIER (SEE ANTENNA OR AMPLIFIER MANUAL)

RED

SCREW

BLACK

THIS WIRE MUST BE CONNECTED AS SHOWN OR RADIO WILL NOT OPERATE PROPERLY

CONTAINS: ONE 1-AMP FUSE ONE 10-AMP FUSE

SEE PAGE 4 FOR SPEAKER WIRING

14 PIN PLUG

MATING 14 PIN SOCKET

METAL PART OF DASH (DRILL HOLE IF NECESSARY)

YELLOW

IMPORTANT

CAR

FUSEBLOCK

"RADIO" OR "ACCESSORY" FUSE

CAR BATTERY

POSITIVE (+) TERMINAL 12 VOLT BATTERY

RADIO

REMOTE INPUT JACK

128-5780E

4 of 48

SPESPE

SPE

SPESPE

ER WIRINGER WIRING

ER WIRING

ER WIRINGER WIRING

REFER TO PAGE 4 FOR RADIO WIRING

RCA

JACKS

LINEOUT

FOR USE WITH

OPTIONAL EXTERNAL

AMPLIFIERS

RED=RIGHT REAR

WHITE=LEFT REAR

REMOTE INPUT INPUT JACK FOR USE WITH EXTERNAL CD PLAYER, CASSETTE PLAYER, OR MP3 PLAYBACK

9-PIN PLUGS

LEFT FRONT SPEAKER

! THE AMPLIFIERS IN THIS RADIO ARE ONLY DESIGNED FOR USE WITH 4 SPEAKERS. !

NEVER COMBINE (BRIDGE) OUTPUTS FOR USE WITH 2 SPEAKERS.

! NEVER GROUND NEGATIVE SPEAKER LEADS TO CHASSIS GROUND. ! FAILURE TO WIRE EXACTLY AS SHOWN BELOW MAY CAUSE ELECTRICAL DAMAGE TO

THE RADIO.

RADIO

WARNING!

NOTE: CHECK WITH YOUR RAMPAGE/AUDIOVOX CAR STEREO SPECIALIST OR CALL 1-800-645-4994 FOR RECOMMENDATIONS OF THE MODELS THAT WILL WORK WITH YOUR RADIO.

DIN CABLE (SUPPLIED WITH CD CHANGER).

8-PIN DIN SOCKET FOR CONNECTION TO OPTIONAL CD CHANGER

4-PIN PLUGS

SEE PAGE 3 FOR RADIO WIRING

OPTIONAL CD CHANGER

RIGHT FRONT SPEAKER

COMPACT

SPE

SPESPE

SPESPE A

KK ER WIRING

ER WIRINGER WIRING

WHITE w/BLACK STRIPE

WHITE

GREEN

GREEN w/BLACK STRIPE

GRAY w/BLACK STRIPE

GRAY

VIOLET

VIOLET w/BLACK STRIPE

HELP!

1-800-645-49941-800-645-4994

1-800-645-4994

1-800-645-49941-800-645-4994

Monday - Friday Saturday

LEFT REAR SPEAKER RIGHT REAR SPEAKER

8:30am - 7:00pm Eastern 9:00am - 5:00pm Eastern

128-5780E

5 of 48

OPEROPER

OPER

OPEROPER

IONSIONS

IONS

ING INSTRUCING INSTRUC

ING INSTRUC

A OPEROPER

OPEROPER

OPER

11 16 17 35 36

ING INSTRUCING INSTRUC

ING INSTRUC

ING INSTRUCING INSTRUC

VOL

3, 4, 5, 6, 7

TUNE/ SKIP/ TRACK

BAND LOUD

31,30

AS/PS

SEL

(BEHIND PANEL)

IONSIONS

IONS

IONSIONS

82425

CLAS

POP

PTYST

ME/CR

MP3

AFSW LOUD

1 2 3 4 5 6

PAU SCN RPT SHF D.DN D.UP

ROCK

TAPE INLOCEON

CDPMONOTP REC

27,3328,3420,3919,3821,3718

T/F MONO

P.EQLOC

MODE

MUTE

26, 32

1 ON/OFF POWER BUTTON

Press this button to turn the unit on or off. If the unit is off and the ignition switch is "on", the unit will turn on automatically when a disc is inserted, or when the "MODE" switch or "BAND" switch is pressed.

2 VOLUME / LEVEL CONTROL

To increase the volume level, press the button. The volume will increase and the level will be shown on the display panel from a minimum of “VOL 00” to a maximum of “VOL 39”. To increase the volume quickly, keep the button pressed. To decrease the volume level, press the button. Keep the button pressed to decrease the volume quickly. The display will automatically return to the normal indication 5 seconds after the last volume adjustment or when another function is activated. These buttons are also used in conjunction with the ''AUDIO SELECT" (SEL) button 3 to adjust the bass, treble, balance, and fader levels as described in 4, 5, 6 and 7.

3 AUDIO SELECT (SEL) BUTTON

This button is used to select the audio function (volume, treble, bass, balance, or fade) to be adjusted using the Volume/Level Control ing the "SEL" button will select bass (“BAS” on the display), treble ("TRE"), balance (“BAL”), fader (“FAD”) or volume (“VOL”). The display will automatically return to the normal indication 5 seconds after the last adjustment or when another

2. Press-

function is activated. The unit will produce a single beep tone whenever the button is pressed.

4 BASS CONTROL

To adjust the bass level, first select the Bass mode by pressing the "SEL" button 3 so that the “BAS” indication appears on the display panel. Within 5 seconds of choosing the Bass mode, press the or button of the Level Control 2 to adjust the bass response as desired. The bass level will be shown on the display panel from a minimum of -12 to a maximum of +12 (0 is flat response). The display will automatically return to the normal indication 5 seconds after the last adjustment or when another function is activated.

5 TREBLE CONTROL

T o adjust the treble level, first select the T reble mode by pressing the "SEL" button 3 so that the “TRE” indication appears on the display panel. Within 5 seconds of choosing the Treble mode, press the

or button of the Level Control 2 to adjust the

treble response as desired. The treble level will be shown on the display panel from a minimum of

-12 to a maximum of +12 (0 is flat response). The display will automatically return to the normal indication 5 seconds after the last adjustment or when another function is activated.

6 LEFT/RIGHT BALANCE CONTROL

To adjust the left-right speaker balance, first select

the Balance mode by pressing the "SEL" button 3 so

that the “BAL” indication appears on the display

128-5780E

6 of 48

panel. Within 5 seconds of choosing the Balance mode, press the Control 2 to adjust the balance as desired. The balance position will be shown on the display panel from “BAL.L 16” (full left) through “BAL.R 16” (full right). When the volume level between the left and right speakers is equal, “BAL 00” will be shown on the display panel. The display will automatically return to the normal indication 5 seconds after the last adjustment or when another function is activated.

FRONT/REAR FADER CONTROL

To adjust the front-rear speaker balance, first select the Fader mode by pressing the "SEL" button that the “FAD” indication appears on the display panel. Within 5 seconds of choosing the Fader mode, press the or button of the Level Control 2 to adjust the front-rear speaker balance as desired. The fader position will be shown on the display panel from “FAD.R 16” (full rear) through “FAD.F 16” (full front). When the level between the front and rear speakers is equal, “FAD 00” will be shown on the display panel. The display will automatically return to the normal indication 5 seconds after the last adjustment or when another function is activated.

8 LOCAL (LOC) OPERATION

This feature sets the signal level at which the radio will stop during Manual Up/Down, Seek and/or AutoStore (AS) tuning; thus, only strong (local) stations will be received and selected. When Auto-Store (AS) tuning is not in effect, LOC will disappear from the display panel, and the radio will stop at a wider range of signals, including weaker (more distant) stations.

9 AUDIO MUTE (MUTE)

This button is used to mute the volume from the system. By pressing the button, a flashing "MUTE" indication will appear on the display panel and the volume will be muted. Pressing the Mute button again, or activating the Volume Control 2 Select ("SEL") button 3 "LOUD" button, or Equalizer ("EQ") button will return the volume level to the setting in use before the Mute function was activated.

blbl

bl BAND/LOUDNESS CONTOUR SELECTION

blbl

(BAND/LOUD)

During radio operation, each momentary press of this button will change the radio band. The indication “AM1”, “AM2”, “FM1”, “FM2”, or “FM3” will appear on the display panel according to your selection. During disc play, pressing this button will stop play of the disc and switch to radio operation without

or button of the Level

3 so

ejecting the disc. During this time, the IN indication will remain on the display panel to show that a disc is still loaded in the unit. Press the "Mode" button beginning of the last track in play. When listening to music at low volume levels, the loud feature will boost the bass and treble ranges to compensate for the characteristics of human hearing. Press the BAND/LOUD button for at least 2 seconds to activate this feature and the indication LOUD will appear on the display panel. Pressing the button again for 2 seconds will deactivate the feature (the LOUD indication will disappear from the display panel).

bmbm

bm MANUAL UP/DOWN TUNING (+ / -)

bmbm

AUTOMATIC SEEK TUNING

Each time the + button is tapped, the radio will tune one frequency step higher. Similarly, each tap of the - button will tune one frequency step lower. To manually tune in a station, tap the button of the appropriate direction until the desired frequency is reached.

Pressing either button for longer than 2.0 seconds and then releasing will activate the Automatic Seek Tuning function. The radio will seek the next available station and stop at that frequency . The Seek function can be stopped by pressing the button again or activating any other tuning function.

bnbn

bn AUTO-STORE TUNING (AS)

bnbn

PRE-SET SCAN TUNING (PS)

During radio operation, press this button momentarily to scan the 6 stations pre-set into the memories of that band. The unit will stop at each pre-set station for 5 seconds before continuing to the next pre-set station. During this time, the pre-set station number ("CH") in the band will flash. Press the button again momentarily to stop Pre-Set Scan operation and remain on the selected frequency. The station number ("CH") stops flashing.

Pressing the button for longer than 2 seconds will activate the Auto-Store Tuning feature which will automatically scan the band and enter up to 6 strong stations into the 6 pre-set memories (the indication “AST” will flash on the display panel to show that Auto-Store Tuning is in progress). After entering the stations into the memories, the unit will automatically stop at each station for 5 seconds so each can be heard. If you have already set the pre-set memories to your favorite stations, activating the Auto-Store feature will erase those stations and enter the new strong stations. This feature is most useful when

cr to return to disc play from the

OPER

OPEROPER

OPEROPER A

ING INSTRUC

ING INSTRUCING INSTRUC

IONS

IONSIONS

128-5780E

7 of 48

travelling in a new area where you are not familiar with the local stations.

bobo

ST ATION PRE-SET MEMORIES

bobo

IONSIONS

IONS

To set any of the 6 pre-set memories in each band, use the following procedure:

1. Turn the radio on and select the desired band.

2. Select the first station to be pre-set using the Manual Up/Down or Automatic Seek Tuning Controls

3. Press the pre-set button ("1-6") to be set and continue to hold it in. After approximately 2 seconds, the pre-set number will appear on the

ING INSTRUCING INSTRUC

ING INSTRUC

display panel, indicating that the station is now

set into that pre-set memory position. The station can now be recalled at any time by pressing that button.

4. Repeat the above procedure for the remain in

OPEROPER

OPER

pre-sets on that band and for the other 4 bands on the unit.

bpbp

bp LIQUID CRYSTAL DISPLAY PANEL

bpbp

FUNCTIONS

The Liquid Crystal Display (LCD) panel displays the frequency, time, and all activated functions, including five bar graphs which provide a visual representation of the volume level and the left and right channel balance levels. The volume level is represented by three thin bar graphs. As the volume is increased, the number of illuminated segments will increase. The left and right channels are represented by the wider bar graphs. As the strength of the signal applied to either the left or right channel increases, the number of illuminated segments will increase.

NOTE: It is a characteristic of LCD panels that, if

bqbq

bq DISC SLOT

bqbq

With the label surface facing up, gently insert the disc into the slot until the soft-loading mechanism engages and disc play begins. The indication illuminates and becomes animated, the IN symbol lights, and the track number and elapsed time will appear on the display panel.

CAUTION: This unit is designed for play of

bm.

subjected to cold temperatures for an extended period of time, they may take longer to illuminate than under normal conditions. In addition, the visibility of the numbers on the LCD may slightly decrease. The LCD read-out will return to normal when the temperature increases to a normal range.

standard 5" (12cm) Compact Discs ONLY. Do not attempt to use 3" (8cm)

CD-Singles in this unit, either with or without an adaptor, as damage to the player and/or disc can occur. Such damage will not be covered by the Warranty on this product.

brbr

br TRACK SELECT

brbr

These buttons are used to quickly select the beginning of a particular track. With each momentary tap of the Forward Track Select button (+ ), the next higher track number will be selected as shown on the display panel. Similarly, with each momentary tap of the Backward Track Select button ( lower track number will be selected.

bsbs

bs CUE/REVIEW FUNCTIONS

bsbs

High-speed audible search to any section of the disc can be made by the Cue and Review functions. Press and hold the Cue button (+ ) to advance rapidly in the forward direction or the Review button ( -) to advance rapidly in the backward direction. During either function, the elapsed time within each track will automatically be shown on the display panel.

btbt

bt CD TRACK ONE POSITION (TOP) SELECTOR

btbt

During disc play, press this button to return to beginning of first track on disc. Disc counter will return to zero and "TRACK" number 01 will appear on displa y panel.

bubu

bu REPEA T PLAY SELECTOR (RPT)

bubu

During disc play, press this button to repeat the play of the selected track (“RPT” will appear on the display panel). Play of the track will continue to repeat until the button is pressed again and the “RPT” indication disappears from the display panel. Repeat Play mode will also be cancelled by activating the Random Play cl or Track Scan cm functions.

clcl

cl RANDOM PLAY SELECTOR (SHF)

clcl

During disc play, press this button to play the tracks on the disc in a random or shuffled order (“RND”) will appear on the display panel). In Random Play mode, pressing the Forward Track Select (+ ) or Backward Track Select ( -) will also select tracks in a random order instead of the normal progression. Additional presses will select tracks in random order. The Random Play mode can be cancelled by pressing the button again (“RND”) indication will disappear from the display panel) or by activating the Repeat Play bu or Track Scan cm functions.

cmcm

cm TRACK SCAN (SCN)

cmcm

During disc play, press this button to play the first 10 seconds of each track on the disc (“SCAN” will ap-

-), the next

128-5780E

8 of 48

pear on the display panel). When a desired track is reached, press the Scan button again to cancel the function and play of the selected track will continue. Track Scan mode will also be cancelled by activating the Repeat Play bu or Random Play cl functions.

cncn

cn DISC EJECT ( )

cncn

Disc play is stopped, the disc is ejected and the unit will change to radio operation by pressing this button. If the disc is not removed from the unit and the button is pressed again, the disc will be re-loaded and begin playing.

If the disc is not removed from the disc slot within 15 seconds of being ejected, it will automatically be re-loaded into the unit to prevent it from being accidentally damaged. Play of the disc can be resumed by using the CD Mode Selector cr to choose CD player function.

coco

co TIME/FREQUENCY SELECTOR (T/F)

coco

This unit can display the clock time, radio frequency or CD player functions on the display panel. Pressing the Time/Frequency Selector button when the radio frequency or CD player track indication is shown will change the display to show the time. The time display will automatically return to the radio frequency or CD player function indication after 5 seconds.

cpcp

cp FM MONO/STEREO SELECTOR (MONO)

cpcp

During FM radio operation, this button is used to select mono or stereo reception of the broadcast signal. Under normal reception conditions, the unit should be left in the stereo mode, as indicated by "ST " on the display panel when listening to an FM stereo signal. If the stereo signal is too weak for comfortable listening, press the button to switch to mono reception (the "ST " indication will disappear from the display panel). To return to the stereo reception mode, press the button again so that the "ST " indication returns.

cqcq

cq EQUALIZER SELECTOR (P.EQ)

cqcq

The P.EQ button applies preset sound effects to the unit's audio output signal. The P.EQ button, when pressed, will activate one of three operating modes ("ROCK, CLAS, or POP"). When the P.EQ function is active, the bass and treble levels cannot be changed. When the P.EQ function is not active, the unit returns to the user-set bass and treble levels.

crcr

MODE SELECTOR (MODE)

crcr

This button is used to select the radio, or the playback mode for the CD player or remote CD changer (if installed). Each press of the button will select a different mode as indicated on the display panel. During CD player operation, this button may be used to change to radio or remote CD changer mode ("CDC") without ejecting the disc (the IN indication will remain on the display panel to show that a disc is still loaded in the unit). Press the button again to return to integral CD player mode and resume play of the disc from the point at which it was stopped.

cscs

ctct

cscs

These buttons are used to increase or decrease selection of a desired disc for play in the remote CD changer. To advance to a higher number disc, press the "CD+" button disc, press the "CD-" button ct. The number of the disc in play will be shown on the display panel.

cucu

cu FRONT PANEL RELEASE BUTTON

cucu

This button is used to release the mechanism that holds the front panel to the chassis. To detach the front panel, press the button so that the left side of the panel is released. Grasp the released side and pull it off of the chassis. To re-attach the panel, position the right side of the panel in place first and then press the left side of the panel until the mechanism locks it into place.

dldl

dl THEFT-DETERRENT L.E.D.

dldl

The theft-deterrent Light Emitting Diode (L.E.D.) is located behind the front panel and is accessible when the front panel is removed. The flashing light serves as a visual warning to the would-be thief that the unit has been disabled by removal of the front panel.

dmdm

dm RESET BUTTON

dmdm

A "RESET" button is located on the front of the chassis (front panel must be removed to access the button). The "RESET" circuitry is provided to protect the microprocessor circuitry and should only be activated under the following circumstances as it will erase the time and pre-set memories:

DISC SELECT (CD+ & CD-)

ctct

cs. To return to a lower number

1. Upon initial installation after all wiring is completed.

2. After the position of the frequency step switch on the bottom of the chassis has been changed.

3. If there is a malfunction of any of the switches on the unit, pressing the "RESET" button may clear the system and return to normal operation.

OPER

OPEROPER

OPEROPER A

ING INSTRUC

ING INSTRUCING INSTRUC

IONS

IONSIONS

128-5780E

9 of 48

NOTES ON USE OF FRONT P ANEL

1. Make sure the front panel is right-side-up when attaching it to the chassis as it cannot be attached when up-side down.

2. Do not press very hard on the front panel when attaching it to the chassis. No more than light to moderate pressure should be needed.

3. When attaching the front panel, make sure the right side is correctly engaged before pressing

ING THE CLOCKING THE CLOCK

ING THE CLOCK

the left side to lock it into position.

4. When taking the front panel with you, please use the supplied carrying case to protect the panel from dirt and damage. Make sure there is no dust or dirt on the electrical terminals on the back of the panel as this could cause intermittent operation or other malfunctions.

IONS / SETIONS / SET

IONS / SET

DET ACHING THE FRONT PANEL

Release Button

A TTACHING THE FRONT PANEL

ING INSTRUCING INSTRUC

ING INSTRUC

NOTES ON USE OF REMOTE INPUT JACK

The remote input jack provides the user option of applying an external audio source to the radio.

OPEROPER

OPER

The audio jack is compatible with most "Walkman" CD and cassette players, or an MP3 digital audio playback unit. When the external source is connected, o nly that media is played by the radio; no other input sources (radio or CD) are operative.

SETSET

ING THE CLOCKING THE CLOCK

SET

ING THE CLOCK

SETSET

ING THE CLOCKING THE CLOCK

1. Turn the vehicle ignition and radio “on”.

2. Press the Time/Frequency Selector button co to display the time.

3. While the time is being displayed, press the Time /Frequency Selector button co together with the

Manual Down Tuning button ( -) to adjust the hours or the Manual Up Tuning button (+ ) to adjust the minutes to the correct time.

4. Five seconds after the last hour or minute adjustment is made, the time will be set in the unit and normal

operation can resume.

Engage right side first

128-5780E

10 of 48

SPECIFICATIONSSPECIFICATIONS

SPECIFICATIONS

SPECIFICATIONSSPECIFICATIONS

SPECIFICA

SPECIFICASPECIFICA

Size: 7" W x 2" H x 6-5/16" D

178 mm x 50 mm x 163 mm Operating Voltage: 12 volts DC, negative ground Output Power: 140 watts maximum

( 35 watts x 4 channels) Output Wiring: Floating-ground type designed for 4 speaker use.

Front and rear channels CANNOT be combined (bridged)

for use with 2 speakers.

RCA low-level outputs (rear channels). Output Impedance: Compatible with 4 ohm speakers. Low-Level Output: 2.0 volts (2,000 mv.) Tuning Range: AM:530 - 1,720 KHz. (10 KHz. step)

FM:87.5 - 107.9 MHz. (200 KHz. step) Sensitivity: < 70 V FM Stereo Separation: > 20 dB CD Frequency Response: 20 - 20,000 Hz. +0 / -3 dB CD Signal/Noise Ratio: 85 dB CD Channel Separation: 65 dB

IONS

IONSIONS

CD Distortion: 0.2%

*Specifications are subject to change without notice.

CD-R AND CD-RW PLAYBACK CAPABILITY

This model can play most CD-R and CD-RW media that contains audio programs. Playback of both CD-R and CD-RW depends on the conditions of the recording equipment

and the CD-R or CD-RW disc quality. In some cases, a CD-R or CD-RW disc cannot be played on this unit.

128-5780E

11 of 48

1010

CD CH

CD CHCD CH

CD CH

CD CHCD CH

OLOL

Built into this radio are controls to operate an

optional CD changer. Please check with your

NGER CONTR

NGER CONTRNGER CONTR

Rampage/Audiovox car stereo specialist or call 1-800-645-4994 for recommendations of the models that will work with this radio.

Adjustment of the audio functions (volume, tone, balance, and fader) for the CD changer

NGER CONTRNGER CONTR

NGER CONTR

operate in the same manner as they do for

radio play. The following controls will operate

OLOL

the CD changer when it is installed and

connected to this radio. Refer to the owner’s

CD CHCD CH

CD CH

manual included with the CD changer for instructions on the installation and correct loading and use of the CD magazine.

dn CD CHANGER MODE SELECTOR (MODE)

During radio or CD play, press this button to select operation of the CD changer as shown by CDC on the display panel. Disc play will begin and the disc and track number will be shown on the display panel. If a new magazine has been loaded into the changer, play will begin from the first track of the first disc in the magazine. If a magazine was already in the changer, play will resume from the track on the disc previously in play.

do & dp DISC SELECT (CD+ & CD-)

These buttons are used to select the desired disc for play. To advance to a higher number disc, press the CD+ button do. To return to a lower number disc, press the CD- button dp. The number of the disc in play will be shown on the display panel.

dq TRACK SELECT (+ / -)

The Track Select functions are used to quickly access the beginning of a particular track.

1212

Each time the Forward Track Select (+

1111

NGER CONTRNGER CONTR

NGER CONTR

NGER CONTRNGER CONTR

OLOL

in side of the button is pressed, the next higher track number will be selected as shown on display panel. Similarly, each time the Backward Track Select ( button is pressed, the next lowertrack number will be selected as shown on the display panel.

-) side of the

dr CUE/REVIEW FUNCTIONS (+ / -)

High-speed audible search to any section of the disc can be made by the Cue and Review functions. Press and hold the Cue (+ of the button to advance rapidly in the forward direction (the disc play symbol will rotate foward on the display panel) or the Review ( -) side of the button to advance rapidly in the backward direction (the disc symbol will rotate backwards on the display panel).

) side

ds TRACK/DISC SCAN SELECTOR (SCN)

When the SCAN button is pressed, the SCAN indication will appear on the display panel, and the first 10 seconds of each track on the disc will be played in order. When a desired track is reached, press the SCAN button twice with a one second interval between presses and play of the selected track will continue (SCAN will disappear from the display panel). The Track Scan mode will also be canceled by activating any other disc function (Track Select, Cue/ Review, Repeat or Random Play).

When the SCAN button is pressed twice, the DISC and SCAN indications will appear on the display panel and the first 10 seconds of each track on each disc in the magazine will be played. When a desired disc is reached, press the Scan button again and play of the selected disc will continue ( DISC and SCAN will disappear from the display panel). The Disc Scan mode will also be canceled by activating any other disc function (Disc or Track Select,

)

Cue/Review, Repeat Play etc.).

128-5780E

12 of 48

dt DISC/TRACK REPEAT PLAY (RPT)

When the Repeat button is pressed, the RPT indication will appear on the display panel and play of the selected track will be continually repeated until the Track Repeat mode is canceled by pressing the Repeat button again or by activating the Disc Select

do and dp, Scan

ds or Random Play du functions.

When the Repeat button is pressed twice the DISC and RPT indications will appear on the display panel and play of the selected disc will be continually repeated until the Disc Repeat mode is canceled by pressing the Repeat button again or by activating the Scan ds or Random Play du functions.

du DISC/TRACK RANDOM PLAY (SHF)

When the Random button is pressed, the RND indication will appear on the display panel and

the tracks on the disc will be played in a random, shuffled order. The Track Select button also select tracks in the shuffled order instead of the normal progression. The Random Track mode can be canceled by pressing the Random button again or by activating the Disc Select do and dp, Scan ds or Repeat Play dt functions.

When the Random button is pressed again, the DISC and RND indications will appear on the display panel and the tracks on the disc will be played in a random, shuffled order. After all tracks on the disc have been played, a new disc will be selected and all the tracks on this disc will be randomly played. This will continue until the Random Disc mode is canceled by pressing the Random button again or by activating the Scan

ds or Repeat Play dt functions.

dp will

CD CH

CD CHCD CH

NGER CONTR

NGER CONTRNGER CONTR

OLOL

OLOL S

CD CHCD CH

CD CH

CD CHCD CH

NGER ERRNGER ERR

NGER ERR

NGER ERRNGER ERR

OR CODESOR CODES

OR CODES

OR CODESOR CODES

128-5780E

13 of 48

1212

CD PLCD PL

CD PL

CD PLCD PL

If a problem should develop while operating the CD player, an error code (ER-1, ER-2, ER-3, etc.) may appear on the display panel. This can indicate a number of problems with the unit, including a mechanical error or an error in the microprocessor control of the player. If an error

OR CODESOR CODES

OR CODES

code should appear, try ejecting and re-loading the disc into the player. While the disc is out of the unit, make sure it is clean, undamaged, and loaded correctly (label surface up). You may also try activating the RESET button dm on the unit, but this will also erase the time and pre-set memories.

If the suggested measures do not solve the problem, contact an approved warranty station near

NGER ERRNGER ERR

NGER ERR

you for further assistance.

ND CD CHND CD CH

ND CD CH

If a problem should develop while operating the CD changer, the following error codes may appear on the display panel.

YER AYER A

YER A

CD PL CD PL

CD PL

In any of the above situations, try ejecting the CD magazine from the changer and make sure the discs are clean, undamaged, and loaded correctly (refer to the Owner’s Manual of the CD changer). Re-load the magazine and check for proper operation. You may also try activating the RESET button

If the suggested measures do not solve the problem, contact an approved warranty station near you for further assistance.

ER-1: Indicates that there is no magazine loaded in the CD changer. ER-2: Indicates a problem with the magazine eject function. ER-3: Indicates an error in the disc loading function. ER-4: Indicates an error in the disc un-loading function. ER-5: Indicates an error in the magazine position. ER-6: Indicates an error in the laser pick-up position. ER-7: Indicates an error in the laser focus on the disc.

CD CHCD CH

CD CH

CD CHCD CH

CD CH

CD CHCD CH

dm on the unit, but this will also erase the time and pre-set memories.

YER ERRYER ERR

YER ERR

YER ERRYER ERR

NGER ERRNGER ERR

NGER ERR

NGER ERRNGER ERR

NGER ERR

NGER ERRNGER ERR

OR CODESOR CODES

OR CODES

OR CODESOR CODES

OR CODES

OR CODESOR CODES

OR CODES

OR CODESOR CODES

1313

128-5780E

14 of 48

CARE AND MAINTENANCECARE AND MAINTENANCE

CARE AND MAINTENANCE

CARE AND MAINTENANCECARE AND MAINTENANCE

The radio section of your new sound system does not require any maintenance. We recommend that you keep this manual for reference on the many features found in this unit as well as how to set the clock.

The compact disc player section also requires no routine maintenance, but proper understanding of its use and handling will help you obtain maximum enjoyment of its capabilities. The following points should be observed:

! When cleaning the interior of the vehicle, do not get water or cleaning fluids on the unit. ! The CD player is a precision instrument and will not operate properly in extreme heat or cold.

In case of such conditions, wait until the interior temperature of the vehicle reaches a normal temperature before using the player.

! If the temperature inside the player gets too hot, a protective circuit will automatically stop

play of the disc. In this case, allow the unit to cool off before operating the player again.

! Never insert anything other than a 5" (12 cm) compact disc into the player as the mechanism

can be damaged by foreign objects.

! Do not attempt to use 3" (8 cm) CD-Single discs in this unit, either with or without an adaptor,

as damage to the player and/or disc may occur. Such damage will not be covered by the Warranty on this product.

! When not using the disc player, always remove the compact disc. Do not leave an ejected

disc sitting in the disc slot as this can expose it to sunlight and other causes of damage.

! Do not attempt to open the unit chassis. There are no user serviceable parts or adjustments inside. ! When the vehicle warms up during cold weather or under damp conditions, moisture may

condense on the lens of the disc player. Should this occur, the player will not operate properly until the moisture has evaporated.

! The unit is designed with a vibration dampening CD mechanism to minimize interruption of

disc play due to normal vibration in a moving vehicle. When driving on very rough roads, however, occasional sound skips may occur. This will not scratch or damage the disc and normal play will resume when the rough conditions cease.

CACA

CACA RE A

RE ARE A

RE ARE A ND MA

ND MAND MA

INTENA

INTENAINTENA

NCE

NCENCE

HANDLING COMPACT DISCS

Dirt, dust, scratches, and warpage can cause skips in the playback and deterioration of sound quality. Please follow these guidelines to take care of your compact discs:

! Use only compact discs with the mark . ! Fingerprints, dust, and dirt should be carefully wiped off the disc’s playing surface (shiny side)

with a soft cloth. Wipe in a straight motion from the inside to the outside of the disc.

! Never use chemicals such as record sprays, household cleaners or thinner to clean compact

discs. Such chemicals can irreparably damage the disc’s surface.

! Discs should be kept in their storage cases when not in use. ! Do not expose discs to direct sunlight, high temperatures or high humidity for extended periods. ! Do not stick paper, tape, or labels on the disc surfaces nor write on them with any type of marker.

128-5780E

15 of 48
