Audiovox 1285757A User Manual
Model: APS-610
Owner’s Manual
4 Button Remote Security System
with Dual Stage Shock Sensor
IMPORTANT !
system is equipped with selectable manual override circuitry. It is possible that you will need
to manually override your security system if the transmitter becomes lost, or inoperative due to
battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is nec-
essary to fully understand the procedure required to enable your vehicle in such situations.
In addition, the chart on the last page of this manual has a section for the particular features
and options installed in your vehicle as well as the override method selected.
manual override is pre-selected from the factory,
ured for "Custom Code" operation. Confirm the override mode selected on the last page of this
manual, and familiarize yourself with the selection on it's operation.
FEATURES:
w 2 Four Button Programmable RF Trans-
mitters (capable of accepting 4 transmitters)
w Five Channel Receiver
w Anti Code Grabbing Technology
w Selectable Manual Override Mode
w Remote Panic in all modes
w Protected Valet
w User Programmable Manual Override
Code
w 7 Function LED - Arm / Disarm / Zone 1
/ Zone 2 / Zone 3 / Valet / Arming
w Intrusion Alert with Memory
w Audible Arm / Disarm / Defective Zone /
T amper Confirmation
w Instant Siren Activation
w Starter Disable
w True Last Door Arming (hardwire only)
w Defective Zone By-Pass
w Hardwire or Voltage Sense Selectable
w Active or Passive Arming Selectable
w Programmable Auto Lock On / Off
In order to provide the highest possible level of security to your vehicle, this
Valet Switch
however, the system can be config-
w Programmable Auto Unlock On / Off
w Programmable Door Lock Pulse Duration 1
Second/3.5 Seconds/1 Sec L/Dbl. U/L
w Programmable Active or Passive Door
Locks
w User Programmable Permanent Chirp Delete
w On Command RF Chirp Delete from Trans-
mitter Or Selectable Through Software
w 6 Tone Multi Tone Siren (And or)
w Car Horn Activation for additional alarm
response
w Additional Negative Trigger Input
w RF Inhibit with ignition on
w Parking Light Flasher
w Remote Trunk Release (must have
electronic trunk release)
w Remote Keyless Entry With Optional
Access Guard (must have power door
locks)
w Illuminated Entry
w Plug In Dual Stage Shock Sensor
OPTIONS:
w Starter Disable
w Remote Trunk Release (must have electronic trunk release)
w Remote Keyless Entry (must have power door locks)
w Multiple Vehicle Capable
w Remote Starter
w Remote Power Window Roll Up
w Remote Garage Door Interface
w Headlight Illumination During Arming/Disarming, Or Both
YOUR "ANTI CODE GRABBING" TRANSMITTERS
The transmitters included with your new security system use the most advanced
and secure form of radio frequency transmission available on any current automotive security system. Some of today’s sophisticated auto thieves use a device
known as a code grabber, which will receive and store the signal from your keychain transmitter, and re transmit at a later time to disarm your system.
Your anti code grabbing transmitters will change their signal every time the button
is pressed, so when a thief grabs then retransmits your signal, the alarm system
will not
respond.
If your transmitter button is pressed more than fifty times while it is out of range of
the vehicle (children playing with your keys), the transmitter will not operate when
you return to the vehicle, and will need to be realigned to the receiver. To do this,
simply press the lock button two times within a one second time period. The
system will now respond to that transmitter each time a button is pressed.
NOTE: Your system has the option of using a siren, the vehicle horn, or both for the
sounding device. Where the siren is referenced below, the horn or both may in fact
chirp, or beep.
ARMING THE SYSTEM - ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.
2. Press and release the Lock button on the keychain transmitter.
þ Red dash mounted LED begins to flash slowly.
þ Parking Lights flash one time.
þ Siren sounds one chirp.
If the siren sounds 3 chirps, then you have left a door, trunk, or
hood lid ajar. Simply close the opened entry point to provide full
protection. If the siren did not sound when arming, then the
chirps have been turned off and you should refer to the section
titled " ELIMINATING THE ARM / DISARM CHIRPS " in this manual.
o Doors Lock - Optional
o Headlight Illumination - Optional
SILENT ARMING - ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.
2. Press and hold the Lock button on the keychain transmitter for 2 seconds.
þ Red dash mounted LED begins to flash slowly.
þ Parking Lights flash one time.
þ Siren will not sound.
If the siren sounds 3 chirps, then you have left a door, trunk, or
hood lid ajar. Simply close the opened entry point to provide full
protection.
o Doors Lock - Optional
o Headlight Illumination - Optional
Page 2
ARMING THE SYSTEM - P ASSIVE ( AUTOMA TIC )
1.Turn off the engine, exit the vehicle, close and lock all doors, hood lid and trunk
lid.
þ Red dash mounted LED begins to flash rapidly, indicating 30 second
passive arming has begun.
2.Opening any protected entry point during the 30 second passive arming cycle
will immediately suspend automatic arming, and the 30 second passive arming
cycle will restart when all doors are closed. At the end of the passive arming
cycle;
þ Red dash mounted LED begins to flash slowly.
þ Parking Lights flash one time.
þ Siren sounds one chirp
If the siren did not sound when arming, then the chirps have
been turned off and you should refer to the section titled
“ELIMINATING THE ARM / DISARM CHIRPS “ in this manual.
o Doors Lock - Optional
Door locking during passive arming is a selectable feature. The
alarm can be programmed to allow the doors to lock only when
arming using the keychain transmitter, and they will not
automatically lock during passive arming.
PROTECTION WHILE THE SYSTEM IS ARMED
þ Opening any protected door, hood, or trunk lid will cause the alarm to
immediately sound. The alarm will continue to sound for 30 seconds,
then stop and continue to monitor all protected entry points. If the thief
left a door opened, the alarm will sound for six 30 second cycles,
remain armed and ignore that triggered zone.
þ Whenever the system is armed, the red dash mounted LED indicator
will slowly flash. This serves as a visual deterrent to the potential thief.
The LED is a very low current bulb, and will not cause the vehicle’s
battery to drain, even when left unattended for extended periods.
þ Whenever the system is triggered, the vehicle’s parking lights will
flash for the full 30 second alarm cycle, attracting visual attention to
the vehicle.
o Optional - Whenever the system is armed, the vehicle’s starting circuit
will be bypassed. If the thief should choose to ignore the siren, the
vehicle can not be started.
þ Any mild impact to the vehicle’s glass will cause the alarm to sound a
short series of warning tones.
þ Any strong impact to the vehicle’s glass will cause the alarm to trigger
for the full 30 second alarm cycle.
DISARMING THE SYSTEM
1. As you approach the vehicle, press and release the Unlock button on the keychain
transmitter.
Page 3
