IEM M2 Owners Manual

Page 1 of 9

IEM Owners Manual

v1 9/22/07

M2 Wireless In-Ear Monitor System

M2R UHF Stereo Receiver

M2T UHF Stereo Transmitter

EP3 Dynamic Earphones

This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.

This device complies with INDUSTRY CANADA R.S.S. 210, en conformité avec IC: RSS-210/CNR210.

Operation is subject to the following conditions: 1) This device may not cause harmful interference and 2) this device must accept any interference received, including interference which may cause undesired operation. Changes or modifications not expressly approved by Audio-Technica could void your authority to operate this equipment.

CAUTION! The circuits inside the receiver and transmitter have been precisely adjusted for optimum performance and compliance with federal regulations. Do not attempt to open the receiver or transmitter. To do so will void the warranty, and may cause improper operation.

Warning: To prevent fire or shock hazard, do not expose this appliance to rain or moisture.

Attention: Pour prévenir feu ou choc électrique, ne pas exposé l'appareil à la pluie ou à l'humidité.

About RF Interference

Please note that wireless frequencies are shared with other radio services.

According to Federal Communications Commission regulations, “Wireless microphone operations are unprotected from interference from other licensed operations in the band. If any interference is received by any Government or non-

Government operation, the wireless microphone must cease operation...” If you need help with operation or frequency selection, please contact your local dealer or Audio-Technica. Extensive wireless information also is available at www.audio-technica.com.

Warning—Use as low volume levels as possible.

IEM M2 Owners Manual

Page 2 of 9

To prevent damage to your eardrums, never use this system at excessive volume levels. Listening to loud sounds for an extended period may cause temporary or permanent hearing damage.

System components

[with illustrations]

M2R UHF Stereo Receiver

M2T UHF Stereo Transmitter with AC adapter

EP3 Dynamic Earphones

Quick start guide

M2R Stereo Receiver

M2T Stereo Transmitter

1.Plug in the included AC adapter and connect to transmitter’s DC input.

2.Insert 2 AA batteries in the M2R Stereo Receiver following polarity as indicated.

3.Set M2R Stereo Receiver and M2T Stereo Transmitter to the same frequency. (See page __.)

4.Power on M2R Stereo Receiver with volume in minimum position; power on M2T Stereo Transmitter. Check to see that RF LED on M2R Stereo Receiver is illuminated.

5.Power off receiver and transmitter

6.Connect audio source(s) to inputs on the rear panel of the transmitter.

7.Power on M2T Stereo Transmitter.

8.Adjust attenuator on rear panel of M2T Stereo Transmitter to appropriate level. (See page __.)

9.Adjust trim level on front panel of M2T Stereo Transmitter, if needed. (See page __.)

10.Plug EP3 Dynamic Earphones into earphones locking output jack on M2R

Stereo Receiver. NOTE: Do not put the earphones in your ears at this point.

11.Turn on receiver with volume in minimum position.

12.With volume on receiver at minimum position, put earphones into your ears and gradually increase volume until appropriate level is reached.

M2 Wireless In-Ear Monitor System—Introduction

Thank you for buying the Audio-Technica M2 Wireless In-Ear Monitor System. This feature-rich in-ear monitor system is designed to provide you with comfortable high-fidelity sound on stage.

The M2 is a frequency-agile in-ear monitor system designed to make stage monitoring more effective, comfortable, portable, and intelligible. The M2R

Stereo Receiver allows the user to create and control his/her own mix on stage with Personal Mix Control that offers independent control of volume and mix at the receiver. The M2T Stereo Transmitter offers two ¼”/XLR combo input

IEM M2 Owners Manual

Page 3 of 9

connectors into which users can directly connect instruments, microphones or other line-level and mic-level inputs (from a mixing console, for example). The EP3 earphones are equipped with a proprietary Audio-Technica dynamic driver offering a full frequency response and richly detailed high-fidelity sound. The clean, articulate mix allows performers to hear themselves at comfortable SPLs. The earphones come with three sizes of rubber flexible eartips and a universal-fit foam tip for a custom fit, increased isolation and long-wearing listening comfort.

Note: M2 “L” Band receivers must be used only with “L” Band transmitters; the same holds true for M2 “M” Band receivers and transmitters. For multiplechannel applications, as many as eight systems may be used together per frequency band.

Features

•High-fidelity sound with clean, articulate mix allows you to hear yourself better at lower SPLs

•100 selectable UHF channels

•Up to 8 simultaneous systems per frequency band

•Three receiver modes: Personal Mix, stereo, and mono

•Personal Mix Control allows you to adjust your own mix on stage

•3.5 mm line-in jack connects to ambient microphone, click track & more

•LED indicators provide easy-to-read level monitoring

•XLR loop output (true pass-through) connects signal to mixing console, additional IEM system or recording device with no signal degradation

•Adjustable squelch eliminates annoying static

•Pilot tone protects against RF interference when the transmitter is turned off

•Limiter (defeatable) helps protect your hearing from sudden peaks

•Portable system is quick to load and set up

•Reduces on-stage audio clutter for better overall mix & less feedback

•Use any number of M2R Stereo Receivers (with individual mixes) on the same frequency

•EP3 earphones with proprietary dynamic driver offer full frequency response and outstanding isolation

•Personal fit with 3 sizes of rubber eartips plus an ear-conforming foam tip

Front panel transmitter

Rear panel transmitter

1.Power LED. Lights red when power is applied.

2.Power switch. Depress once to turn on. Depress again to turn off.

3.L/1 and R/2 trim control. Controls level of corresponding audio input.

4.Input Level indicator. Shows signal level from audio input L/1 and R/2.

5.Frequency group selector. Selects frequency group.

6.Frequency channel selector. Selects frequency channel.

7.Flexible antenna. Permanently attached antenna transmits to receivers.
