Audio-Technica AT-PL50 User Manual

Automatic Stereo Turntable System
AT-PL50
Installation and Operation
Automatic Stereo Turntable System
Installation and Operation
Warning: To prevent fire or shock hazard, do not expose this appliance to rain or moisture. Attention: Pour prévenir feu ou choc électrique, ne pas exposé l’appareil à la pluie ou à l’humidité.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
To prevent electric shock, do not remove the cover. There are no user-serviceable parts inside. Internal adjustments are for qualified professionals only. Refer all servicing to qualified service personnel.
Pour prévenir un choc électrique, ne pas ouvrir le couvercle. Il n’y aucune pièces de rechanges à l’intérieur. Tout ajustement interne doit être fait par une personne qualifié seulement. Référez tout réparation au personnel qualifié.
AVIS
RISQUE DE CHOC ÉLECTRIQUE
NE PAS OUVRIR
Introduction
Thank you for pur been a leading manufactur products for more than 40 years. We are pleased to provide this turntable, with its excellent performance and many convenient features, for your enjoyment.
The AT-PL50 stereo turntable system features:
• Fully automatic operation
• Two speeds: 33
• Professional aluminum turntable platter
• Integral Audio-Technica Dual Magnet replaceable diamond stylus
• Integral, switchable stereo phono pre-amplifier. Permits use of turntable with stereo amplifiers having either magnetic-phono inputs or “AUX” (high-level) inputs; also allows convenient use of turntable with most powered speakers
• Damped Lift/cueing mechanism with front-panel control
• Handsome removable dust cover
To assure maximum satisfaction from this product, please read the information and follow the instructions presented in this manual. Please keep the manual in an accessible location for future reference.
We suggest that you save all the packaging materials for possible future storage, moving or shipping.
CAUTION: To avoid stylus damage, make certain the included stylus guard is in place whenever the turntable is being installed, moved or cleaned.
chasing the AT-PL50. Audio-Technica has
1
/3rpm and 45 rpm
er of innovative stereo phonograph
phono cartridge with
Stylus assembly
Stylus (“Needle”)
Stylus guar
d
2
Figure 1 Inputs and pre-amp selector switch
“AUX”
Input
Jacks
e-amp
Pr Selector
Switch
Initial Setup
PHONO
Amplifier
White Red
AC
AC
Setting the Pre-amp Switch
For incr stereo phono pre-amplifier. The Pre-amp Selector Switch is located under the turntable platter, in the rear-center (Fig. 1). If the system amplifier you are using has a PHONO input, set the Pre-amp Selector Switch to the “OFF” position. If your amplifier does not set the Pre-amp Selector Switch to the “ON” position and connect the turntable’s output cables to the AUX or other high-level input on the amplifier (described later).
Assembling the Turntable
1. Carefully place the turntable platter on the center
2. While holding both ends of the red tape ribbon on the
3. Once the belt is seated in the pulley’s groove, carefully
4. Place the turntable mat on top of the turntable platter
5. If desired, the hinged dust cover may be removed.
eased flexibility of use, this turntable has an internal
have a PHONO input,
spindle, making certain the platter is fully seated on the spindle.
turntable belt, carefully pull the belt over the motor pulley (Fig. 2a). (If the belt drops off, remove the turntable platter and put the belt back on it, as described on page 6.)
remove the ribbon. Make certain the belt is not twisted.
(Fig. 2b).
Hold both sides of the dust cover and pull upward gently and evenly to detach the cover from the
ntable (Fig. 2c). Keep the cover in a safe, clean
tur place.
Figure 2 Assembling the turntable
2a Drive belt
Red ribbon
Drive belt
2b Record mat
2c Dust cover r
emoval
Motor spindle
3
Connecting to Stereo System
Connect the r
1. input and the
ed RCA-type pin-plug to the
white
RCA-type pin-plug to the
right
channel
left
channel input of the amplifier. Fig. 1, page 3.)
2. With the tone arm still fastened to the tone arm rest, slowly turn the turntable platter
clockwise ten times, to make certain the automatic mechanism is fully cycled.
3. Remove the vinyl tie that holds the tone arm on its rest.
4. Connect the power cord plug to an AC outlet.
Connecting to Computers or Audio Devices with 3.5 mm Input
T-PL50 connects without adapters to devices equipped
The A with RCA connectors. For maximum flexibility, we have included two adapter cables to fit other popular audio inputs.
The first of these adapter cables–dual RCA to stereo 3.5 mm mini-plug (male)–is designed to fit most popular computer* audio inputs. It may also be used to connect the turntable's RCA output to other equipment, including:
• a stereo/boombox* equipped with a 3.5 mm mini input
• powered speakers* equipped with a 3.5 mm mini input
• a mixer* or PA system* equipped with a 3.5 mm mini jack
The second included adapter cable–dual RCA to stereo 3.5 mm mini-plug (female)–permits connection of the turntable output to amplified speakers* or similar devices. The 3.5 mm ster
eo mini-
jack on the cable adapter accepts stereo mini-plugs.
On both cables, the “tip” carries the signal for the left channel, the “ring” carries the right signal, and the “sleeve” is ground/common.
To use either adapter cable, connect the turntable's red and white RCA-type plugs to the cable adapter's RCA-type jacks.
* When using either cable adapter, always set the AT-PL50 turntable’s Pre-amp Selector Switch to the “ON” position. (Switch is located under the AT-PL50 turntable platter.)
Automatic Operation
1. Remove the stylus guard from the stylus assembly (Fig. 3).
2. Put a record on the turntable. If needed, use the 45 rpm adapter (Fig. 4).
3. Select the size of record: 12" or 7" (Fig. 5).
Select the speed: 33
4.
5.
t:
Star
Gently push the ST
1
/3rpm or 45 rpm (Fig. 6).
T button (Fig. 7a). The
AR turntable will start and the tone arm automatically will move to the lead-in groove. When the record has fin­ished playing, the tone arm automatically will return to the tone arm rest and the turntable will shut off.
Stop: To stop playing the record before it reaches the
6. end, press the STOP button (Fig. 7b). The tone arm will lift and return to the tone arm rest, and the turntable will shut off.
7.
Pause: To pause the record before it has completed playing, pr
ess the tone ar
the Lift button again to continue playing the r
m Lift button (Fig. 7c). Pr
ecor
d.
NOTE: If connection is desired to a mono amplifier/speaker, make certain to use a stereo-to-mono adapter, available from your dealer or an electronic parts store. Inserting a mono plug in the stereo jack will disable one of the stereo channels. Other adapter cable configurations will be available from dealers and parts stores for connecting to devices needing different terminations.
Operation
Figure 3
Figure 4
ess
Stylus assembly
Stylus (“Needle”)
Stylus guard
45 rpm adapter
4
Caution: When the tone arm reaches the end of the record, it will lift and return to the tone arm rest automatically. When this happens,
do not interfere with the tone arm’s motion, or damage to the mechanism may occur.
If the tone arm does not return automatically to the tone
m rest after the record has finished playing, simply press
ar the STOP button to complete operation.
Manual Operation
1. Remove the stylus guard from the stylus assembly
(Fig. 3).
2. Put a record on the turntable. If needed, use the 45
rpm adapter (Fig. 4).
3. Select the size of record: 12" or 7" (Fig. 5).
4. Select the speed: 33
1
/3rpm or 45 rpm (Fig. 6).
5. Press the Lift button IN to raise the tone arm (Fig. 7c).
3. Gently move the tone arm so the stylus is over the
point on the record where play is desired to begin.
4. Press the Lift button again to gently lower the tone
arm and play record.
Replacing the Stylus
Figure 5
Figure 6
(Out)
(In)
Figure 7
7a 7b 7c
(Out)
(In)
While holding the head of the tone arm, rotate the front of the stylus assembly in a forward and down motion to remove it (Fig. 8). (As you remove the old assembly, note its position and “feel,” to aid in properly installing the new one.)
Install the new stylus assembly as shown in Figures 9a/9b, being careful not to touch the actual stylus. Make certain that the projection at the back of the assembly is fully seated in the cartridge body
first (Fig. 9a), and that the assembly “clicks” up into place, with no gap between its top edge and the front of the black plastic tone arm head (Fig. 9b). Replace the stylus after 400 hours of use.
To maintain original performance, insist upon a genuine Audio-Technica brand replacement stylus. Look for the Audio-Technica trademark ( ) on the front of the stylus assembly and on the packaging.
Figure 8 Removing the stylus
Figure 9 Installing a new stylus
9a
Engage in body first
9b
No gap here
5
T
roubleshooting
urntable does not operate
T
1. Make certain the turntable’s AC cord is plugged into an
AC outlet, and that the AC outlet is “live.”
2. Check the drive belt to make certain it is on correctly.
(See Figur A) Remove the record mat from the turntable platter
(Fig. 10a). Place the mat in the cardboard packaging sleeve for safekeeping. Through an opening in the turntable platter, visually inspect to see if the drive belt is ar
B) If the drive belt is not ar and r the left and right openings on the turntable platter; and, using the fingers to press down on the turntable hous­ing’s surface, pull the platter Avoid pressing on the tone arm.
C) With the turntable platter bottom side up, place the belt along the outside wall of the turntable platter's drive rim, making cer flat all the way around (Fig. 10d).
D) Put the turntable back on the center spindle, make certain it is fully seated, and align one of its openings over the motor pulley position.
E) Through the opening, carefully hook the turntable belt with a finger or with the original red ribbon ( use a sharp object) and pull the belt over the motor pulley (Fig. 10e). Make certain the belt is not twisted between the pulley and the platter’s drive rim.
F) Put the record mat back on the platter.
G) While holding the tone arm in its rest position, slowly turn the platter by hand clockwise at least 10 rotations to clear the mechanism’s automatic cycle.
e 10.)
ound the motor pulley (Fig. 10b).
ound the motor pulley: Lift
emove the turntable. Place a thumb into each of
straight up (Fig. 10c).
tain that the belt is smooth and
never
Figure 10 Checking the drive belt
10a
10b
10c
Drive belt
10d
10e
Motor pulley
6
Troubleshooting, continued
Turntable operates, but no sound at all
1. The stylus guard is still in place.
2. The tone arm Lift button is pressed in.
3. Amplifier controls set incorrectly: wrong input select­ed, tape monitor on, speakers switched off, etc.
4. Check the stylus on phono cartridge for correct place­ment. Refer to the instructions for replacing the stylus on page 5.
Turntable operates, but no sound, or sound not loud enough
1. If the turntable is connected to an AUX (high-level) input: The Pre-amp Selector Switch may be set to the “OFF” position (phono-input level).
2. The input gain of the amplified speaker or similar device may be too low.
3. The stylus assembly may not be fully seated in the
Sound is very distorted
1. Turntable connected to an amplifier’s PHONO input:
Turntable moves slightly up and down
1. Usually this is a normal condition and not a problem.
tridge body. (See Fig. 9 on page 5.)
car
If the pre-amp switch is set to the “ON” position (AUX high-level output), a phono input will be overloaded.
If this causes the turntable to be unable to trace the record, please contact your dealer or our service department.
Make very certain the surface upon which the turntable is resting is not picking up vibrations from the floor or walls, or from direct speaker sound.
Specifications
Type Belt drive turntable, fully automatic Platter Motor DC servo-controlled Speeds 331/3/ 45 rpm
Wow and flutter 0.25% WRMS Signal-to-noise ratio Cartridge Integral Dual Magnet
Output level
Preamp “Off” 2.5 mV nominal at 1 KHz, 5 cm/sec
Preamp “On” 200 mV nominal at 1 KHz, 5 cm/sec Phono preamp gain 38 dB nominal, RIAA equalized Power Dimensions 14.17" W x 3.82" H x 14.06" D
Net weight 5.3 lbs. (2.4 kg) Furnished accessories Dual RCA (female) to
Replacement stylus
Aluminum
45 dB
with diamond stylus
120V AC, 60 Hz, 3W
360 mm W x 97 mm H x 357 mm D
plug (male) stereo adapter cable; dual RCA (female) to (female) stereo adapter cable; 45 rpm adapter
ATN3600L
stereo cartridge
1
/8" (3.5 mm) mini-
1
/8" (3.5 mm) mini-plug
Tips For Better Performance
When opening or closing the turntable cover, handle it gently, moving it either at the center or equally
om both sides.
fr
Do not touch the stylus tip with your fingers; avoid
• bumping the stylus on the turntable mat or a record’s edge.
Clean the stylus tip frequently, using a soft brush
with a back-to-front motion only.
If you use a stylus cleaning fluid, use it very sparingly.
Wipe the dust cover and turntable housing gently with a soft cloth. Use only a small amount of mild
gent solution to clean the tur
deter
.
cover
ntable and dust
Never apply harsh chemicals or solvents to any part of the turntable system.
Prior to moving the turntable, always unplug it from the AC outlet and fasten the tone arm on the tone arm rest with the vinyl twist-tie.
7
