4000 & 5000 Series

Professional UHF Wireless Systems

Installation and Operation

0168

Professional UHF Wireless Systems

Installation and Operation

Notice to individuals

with implanted cardiac pacemakers

or AICD devices:

Any source of RF (radio frequency) energy

may

interfere with normal functioning of the implanted device. All wireless microphones have low-power transmitters (less than 0.05 watts output) which are unlikely to cause difficulty, especially if they are at least a few inches away. However, since a “body-pack” mic transmitter typically is placed against the body, we suggest attaching it at the belt, rather than in a shirt pocket where it may be immediately adjacent to the medical device. Note also that

any medical-device disruption will cease when the RF transmitting source is turned off

. Please contact your physician or medicaldevice provider if you have any questions, or experience any problems with the use of this or any other RF equipment.

CAUTION! The circuits inside the receiver and transmitter have been precisely adjusted for optimum performance. Do not attempt to open the receiver or transmitter. To do so will void the warranty, and may cause improper operation.

This device complies with the European R&TTE directive 1999/05/EC. Operation is subject to the condition that this device does not cause harmful interference.

Dispose of exhausted batteries in accordance with local/national regulations. Do not dispose of exhausted batteries in a fire or incinerate.

Remove outer cover in order to access power rating and model number information. (handheld transmitter) Do not use the body-pack if the antenna shows any signs of damage. (body-pack transmitter)

The systems can be supplied in five frequency bands within the UHF range.

Please note: Frequency usage is different for each country. Your Audio-Technica agent will have all the necessary details on the available legal frequencies for your area.

Band C: 541.500 - 566.375 MHz

Band D: 655.500 - 680.375 MHz

Band E: 795.500 - 820.000 MHz

Band F: 840.125 - 864.875 MHz

WARNING:

This apparatus shall not be exposed to dripping or splashing. No objects filled with liquids, such as vases, shall be

placed on this apparatus. Do not install this apparatus in a confined space such as a bookcase

or similar unit. The apparatus should be placed close enough to the AC outlet so

that you can easily grasp the power cord plug at any time.

CAUTION! Do not expose batteries to excessive heat, such as direct sunlight or open fires.

ATTENTION! Ne pas exposer les piles à une chaleur excessive, telle que la lumière directe du soleil ou le feu.

For use in China, it is necessary for the user to utilize a CCC certified power cord.

To prevent electric shock, do not remove the cover. There are no user-serviceable parts inside. Internal adjustments are for qualified professionals only. Refer all servicing to qualified service personnel.

Pour prévenir un choc électrique, ne pas ouvrir le couvercle. Il n’y aucune pièces de rechanges à l’intérieur. Tout ajustement interne doit être fait par une personne qualifié seulement. Référez tout réparation au personnel qualifié.

AVIS

RISQUE DE CHOC ÉLECTRIQUE

NE PAS OUVRIR

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Warning: To prevent fire or shock hazard, do not

expose this appliance to rain or moisture.

Attention: Pour prévenir feu ou choc électrique, ne pas exposé l’appareil à la pluie ou à l’humidité.

WARNING: This apparatus must be grounded.

This product is a safety class 1 product. There must be an uninterruptible safety earth ground from the main power source to the product’s AC input. Whenever it is likely that the protection has been impaired, disconnect the power cord until the ground has been restored.

ATTENTION: Cet appareil doit être mise à la terre.

Cet appareil est de classe de sûreté 1. Il doit y avoir un ininterrompable de mise à la terre de sécurité provenant de la source principale de courant de l’appareil de l’entrée du courant alternatif. Quand la protection a été affaiblie, débrancher le fil de courant jusqu’à la mise à terre a bien été réétablie.

CAUTION: For continued protection against fire hazard, replace only with same type/rating of fuse.

AVIS: Pour poursuivre la protection contre le feu, replacez la fusible de même type/cote.

WARNING: There are some sharp edges inside. To reduce the risk of injury, do not remove cover.

ATTENTION: Bord tranchant à l’intérieur. Pour réduire le risque de blessure, ne pas ouvir le couvercle.

Contents

Introduction ....................................................................................................................................6

System Configurations..............................................................................................................6

Operating Frequencies..............................................................................................................7

Receivers ..................................................................................................................................7

Multi-channel Systems..............................................................................................................8

Transmitters ..............................................................................................................................8

Receiver Installation ........................................................................................................................8

Location ....................................................................................................................................8

Output Connections ..................................................................................................................8

Antennas ..................................................................................................................................8

Antenna Power ........................................................................................................................8

Front-mount Antennas ..............................................................................................................9

Headphone Jack........................................................................................................................9

Power Connections ..................................................................................................................9

“Link” Connections ..................................................................................................................9

Ethernet Connections (AEW-R5200 only)................................................................................10

Receiver Controls and Functions ..................................................................................................10

AEW-R5200 Front Panel Controls and Functions ....................................................................10

AEW-R5200 Rear Panel Controls and Functions......................................................................11

AEW-R4100 Front Panel Controls and Functions ....................................................................12

AEW-R4100 Rear Panel Controls and Functions......................................................................13

Common Receiver Controls ..........................................................................................................14

Power On/Off..........................................................................................................................14

Level Alert Light (LED) ............................................................................................................14

LCD Window ..........................................................................................................................14

Mode/Set Button ....................................................................................................................14

Up/Down Arrow Buttons ........................................................................................................14

Changing Receiver Settings..........................................................................................................14

Menu Mode ............................................................................................................................14

Edit Mode................................................................................................................................14

Quitting and Saving Changes ..................................................................................................14

Receiver Controls and Functions ..................................................................................................15

IntelliScan

™

Channel Assignment System ..............................................................................15

Receiver Locks........................................................................................................................15

Antenna Power ......................................................................................................................15

Digital Tone Lock

™

Squelch ......................................................................................................15

Meter Hold ..............................................................................................................................16

Using “PRESET” Store and Recall ..........................................................................................16

Receiver Functions (Chart) ............................................................................................................17

Transmitter Controls and Functions ............................................................................................18

LCD Window ..........................................................................................................................18

Power/Mute Button ................................................................................................................18

Power On/Off..........................................................................................................................18

Mute On/Off............................................................................................................................18

Power/Mute Locks..................................................................................................................19

Audio Input Selector (UniPak

™

Transmitter) ............................................................................19

Setting Audio Input Level ........................................................................................................19

Preset/Default Settings ..........................................................................................................20

UniPak™ Transmitter Functions (Chart) ......................................................................................21

Handheld Transmitter Functions (Chart)......................................................................................21

Transmitter Setup..........................................................................................................................22

Battery Selection and Installation ............................................................................................22

Battery Condition Indicator......................................................................................................22

UniPak

™

Transmitter Input Connection ....................................................................................23

UniPak

™

Transmitter Antenna ..................................................................................................23

Handheld Transmitter Antenna................................................................................................23

UniPak™Transmitter Mounting Clip ........................................................................................23

System Operation..........................................................................................................................24

Selecting/Setting Receiver Frequency ....................................................................................24

Setting Receiver Frequency Manually ....................................................................................24

Setting Receiver Frequency Using IntelliScan

™

......................................................................25

Setting Transmitter Frequency ................................................................................................26

Setting Transmitter Audio Input Level......................................................................................26

RF Power Adjustment ............................................................................................................26

RF Interference ......................................................................................................................26

Specifications ................................................................................................................................27

Optional System Accessories ......................................................................................................28

Artist Elite Wireless Operating Frequencies/Groups..................................................................29

Serial Number Log ........................................................................................................................42

Warranty Statement......................................................................................................................44

Guide to Illustrations

Receiver Location (Figure A)....................................................................................................8

Connecting Linked Receivers (Figure B)..................................................................................9

AEW-R5200 Front Panel Controls and Functions (Figure C) ..................................................10

AEW-R5200 Rear Panel Controls and Functions (Figure D) ..................................................11

AEW-R4100 Front Panel Controls and Functions (Figure E) ..................................................12

AEW-R4100 Rear Panel Controls and Functions (Figure F) ....................................................13

Receiver LCD Window (Figure G)..........................................................................................13

Transmitter LCD Window (Figure H)......................................................................................18

UniPak

™

Transmitter Exterior (Figure J)..................................................................................18

Handheld Transmitter Exterior (Figure K) ..............................................................................18

UniPak

™

Transmitter Battery Door (Figure L)..........................................................................22

Installing Batteries in UniPak™Transmitter (Figure M)............................................................22

Opening Handheld Transmitter (Figure N) ............................................................................22

Handheld Transmitter Interior Controls (Figure P)..................................................................22

Installing Batteries in Handheld Transmitter (Figure Q) ..........................................................22

Receiver Frequency/Group Display (Figure R) ......................................................................25

IntelliScan™Channel Assignment System

The IntelliScan

™

automatic channel assignment system, provided on both the 4000 and 5000 Series receivers, greatly simplifies the selection of usable frequencies in a multi-channel wireless system. The receivers are first linked together with included communication cables. The selected “Master” receiver then “knows” how many total channels it is looking for. It can scan the available frequencies, checking for local interference sources, selecting a group of channels that will all work together (using a built-in frequency plan), and automatically setting the other receivers accordingly. Once this procedure is completed, it’s just a matter of setting the transmitter frequencies to match those of the receivers.

Artist Elite Transmitters

Transmitter models in the Artist Elite Series include:

• AEW-T1000 UniPak

™

body-pack transmitter

• AEW-T3300 Handheld mic/transmitter with AEW-C3300 cardioid condenser capsule

• AEW-T4100 Handheld mic/transmitter with AEW-C4100 cardioid dynamic capsule

• AEW-T5400 Handheld mic/transmitter with AEW-C5400 cardioid condenser capsule

• AEW-T6100 Handheld mic/transmitter with AEW-C6100 hypercardioid dynamic capsule

All components in the 4000/5000 Series may be used together in a variety of unit combinations and system configurations to create extremely flexible and powerful solutions for a variety of applications.

Introduction

Thank you for choosing an Audio-Technica professional wireless system. You have joined thousands of other satisfied customers who have chosen our products because of their quality, performance and reliability. This Audio-Technica wireless microphone system is the successful result of years of design and manufacturing experience.

Recent advances in the quality and sophistication of professional live-sound systems have been nothing short of revolutionary. Tours, clubs, broadcast events, corporate facilities and worship venues sound better than ever, utilizing better system design and better components in the audio chain.

That’s why Audio-Technica has been partnering with industry professionals on the front line of this revolution – the top touring companies, award show designers, FOH and monitor engineers, audio consultants and artists – to learn what it takes to make the best-sounding, most reliable and consistent microphones for the live-sound industry.

We listened carefully. Then, we applied this knowledge to the creation of the Artist Elite

™

line of high-performance microphones and wireless systems. Our ultimate design goal was this: Each model must extend the performance of a sound system, not limit it.

Artist Elite Receivers

Artist Elite 4000 Series and 5000 Series wireless systems by Audio-Technica share a range of transmitters in common, both body-pack and handheld types. The difference between the two series is simply in the choice of receiver:

4000 Series AEW-R4100 half-rack single receiver with

multi-unit, multi-channel control linking.

5000 Series AEW-R5200 full-rack independent dual

receiver with multi-unit, multi-channel control linking, plus Ethernet computercontrol connection, and software for graphical user interface.

Operating Frequencies

4000/5000 Series systems and components operate on approximately 200 frequencies for each 25MHz-wide UHF frequency band. See frequency listing on page 3:

For simplicity, model numbers used throughout this manual will reference only the basic model number.

Artist Elite Series components feature an advanced digital Tone Lock

™

squelch system and unique Dual Compander design (patents pending). As a result, Artist Elite Series transmitters and receivers must be used together in Tx-Rx pairs and should not be mixed with components from other Audio-Technica wireless systems, or with those of other manufacturers.

All Artist Elite Series components feature soft-touch controls for quick, easy access to a formidable range of functions; an LCD information display in each unit provides convenient visual indication of unit settings and operation. Digital data send by the transmitters is available for display on the receivers.

Receivers

Both Artist Elite receiver models feature True Diversity reception. Two antennas feed two completely independent RF sections on the same frequency; automatic logic circuitry continuously compares and selects the superior received signal, providing better sound quality and reducing the possibility of interference and dropouts.

Both receivers offer a choice of approximately 200 operating frequencies in a 25 MHz-wide UHF frequency range. AEW wireless are designed with a channel spacing that exceeds the transmitters’ maximum modulation deviation, so even adjacent channels are actually usable, unlike some other wireless systems on the market. (For operation of two or more systems at the same time, please consult the multi-channel plan on page 30, or use the IntelliScan function for frequency selection.)

AEW-R4100:

A single synthesized UHF receiver in a half-rack 1U case. Its power supply operates on 100–240V 50/60 Hz AC power worldwide with the appropriate IEC-type power input cordset.

AEW-R5200:

Two independent synthesized UHF receiver channels in a full-rack 1U case. Its common power supply operates on 100–240V 50/60 Hz AC power worldwide with the appropriate IEC-type power input cordset. In addition, a “passthrough” AC outlet on each receiver with included AC jumper cable permits daisy-chaining of an entire AEW-R5200 receiver stack, freeing AC outlets for other equipment.

Multi-channel Systems

Artist Elite systems provide extensive monitoring and control facilities. Transmitter data, in addition to being available at the transmitter, is conveyed in digital form to and displayed on the associated receiver.

Linked systems:

Both Artist Elite receivers provide linking jacks and cables. AEW-R4100 and AEW-R5200 receivers may be combined in linked multi-channel systems, if desired.

Ethernet-based monitoring and control (AEW-R5200):

Some wireless systems on the market offer remote control/monitoring of the receiver via a serial interface, but the Audio-Technica AEWR5200 receiver takes this a significant step further by including control over IP using standard networking protocol and Ethernet interfacing. This permits receivers in a system to be integrated, monitored and controlled from a single computer in real-time. And not only can an individual channel of an individual receiver be examined and its settings modified: if the transmitter on that channel is activated, thanks to the digital data link, data from the associated transmitter can also be monitored.

Because standard control over IP is used, Ethernet-connected AEW systems can range from a single laptop controlling a free-standing multi-channel system, to local area network-based systems, to systems controlled via the Internet, even from great distances. Complete setup and operating information for computer-connected AEW systems will be found in the separate Computer Interface manual provided with AEW-R5200 receivers and 5000 Series systems.

Transmitters

The versatile AEW-T1000 UniPak

™

body-pack transmitter features a metal case and includes field-replaceable helical and flexible-wire antennas. It has both low- and high-impedance inputs plus a bias connection, for use with dynamic and electret condenser microphones, as well as Hi-Z instrument pickups. In addition to its programmable functions, the transmitter includes a three-position sliding control cover to limit access, if desired, to only the Power/Mute button, or to no controls at all, as appropriate for the application and/or user.

The handheld microphone/transmitters feature metal-body construction. Four models are available, incorporating a variety of capsules from the Artist Elite

™

wired-microphone series

created for professional live-sound venues.

All Artist Elite Series transmitters use two 1.5V AA batteries for economical operation and wide availability. The receiver and both transmitters have “fuel gauge” battery condition indicators with low-battery warnings.

Please note that in multiple-system applications there must be a transmitter-receiver combination set to a separate frequency for each input desired (only one transmitter for each receiver). Because the wireless frequencies are within UHF TV frequency bands, only certain operating frequencies may be usable in a particular geographic area. Also, only certain of the available operating frequencies may be used together. Operating frequencies and multi-channel suggestions will be found on pages 29-30. (Use of the IntelliScan channel assignment system will determine and set appropriate frequencies automatically.)

Receiver Installation

Location

For best operation the receiver should be at least 3 ft. (1 m) above the ground and at least 3 ft. away from a wall or metal surface to minimize reflections. The transmitter should be at least 3 ft. from the receiver, as shown in Figure A. Keep antennas away from noise sources such as digital equipment, motors, automobiles and neon lights, as well as away from large metal objects.

Output Connections

There are two audio outputs on the back panel: an XLR Mic Output (25 mV) and a

/4" (6.3 mm) phone jack Instrument Output (50 mV). The two isolated audio outputs permit simultaneous feeds to two different inputs.

AEW-R4100:

This receiver offers a balanced XLR Mic jack and an

unbalanced Instrument

/4" TS phone jack. Output levels of both

are adjusted by the rear-panel Attenuator (ATTN) switch.

AEW-R5200:

Since there are two independent channels of receiver in the AEW-R5200, there are two sets of output jacks. All audio outputs on the AEW-R5200 are transformer-isolated and balanced. The ground connections of both outputs on each receiver channel may be interrupted (“lifted”) by use of their associated Ground Lift switch. This permits feeding mixers with different ground levels without an additional external splitter. The Instrument output is a balanced

/4" TRS jack with “audio +” on the Tip, “audio –” on the Ring and ground (shield) on the Sleeve. The rear-panel Attenuator (ATTN) switch for each receiver channel adjusts levels of both outputs in its channel.

Use the appropriate shielded audio cable for connections between the receiver and the input(s) of the mixer or other equipment.

Antennas

Attach a pair of UHF antennas to the antenna input jacks. The antennas are normally positioned in the shape of a “V” (both 45° from vertical) for best reception. In addition to rotating at the connector, the included half-wave antennas pivot from straight to right-angle.

Antennas can be remotely located from the receiver. However, due to signal loss in cables at UHF frequencies, use the lowestloss RF cables practical for any cable runs over 25 feet. RG8-type is a good choice. Use only copper-shielded cable, not CATV-type foil-shielded wire. Audio-Technica offers auxiliary antennas, and quality RF cables in four lengths; see the Optional System Accessories section on page 28.

Antenna Power

The antenna input jacks also can provide +12V DC output on their center pins to power inline RF devices. A maximum of 20 mA can be drawn from each of the jacks. While an accidental short-circuit will not harm the internal 12V supply, make certain that an antenna cable shield does not contact the center conductor. Antenna Power (“

ANT.PWR

”) is selected (switched on or off) from the LCD menu. (On the AEW-R5200, Antenna Power will be found in the menu on Channel 1 only.)

Figure A

Receiver Installation

(Continued)

Front-mount Antennas

AEW-R4100:

Provision has been made to move the antenna jacks from the rear to the front of the receiver. However, because this involves opening the receiver case and exposing AC power circuitry, instructions are not included in this manual. A qualified service technician must perform this modification.

AEW-R5200:

BNC-to-BNC connectors and jumper cables are included with the unit to permit mounting antennas on the front panel.

• BNC-BNC through-panel connectors: Remove the nut and

lock-washer from each connector. Install the connectors

from the front

into the two panel holes. Note that the flat on the threaded section must be aligned with the flat in each panel hole. Secure each connector from the back with its lock-washer and nut, tightening the nut firmly.

• BNC-BNC cable jumpers: Connect the jumpers to the rear antenna jacks first; then attach them to the BNC connectors on the front panel. Make certain the bayonet twist-rings are

fully latched

on the connectors at both ends.

Headphone Jack

A headphone jack on the front panel provides monitoring of the receiver’s output. The

/4" TRS jack is intended for use with stereo headphones. The Phones Level control affects the headphone jack only. Note: On an operating unit,

be careful not to press the Power switch accidentally when inserting a headphone jack or adjusting the headphone level.

In addition to interrupting receiver operation, even a momentary loss of power to a single unit within a linked multi-channel system will cause the loss of linking connection to the affected receiver and all those “downstream” from it.

AEW-R5200:

Press and release the Phones Level control knob to switch headphone monitoring from Channel 1 to Channel 2 and back again. Small, lighted indicators just above the knob show which receiver channel is being monitored.

Power Connections

The switching power supply is designed to operate properly from any AC power source 100–240V, 50/60 Hz without user adjustment. Simply connect the receiver to a standard AC power outlet,

using only an IEC-type input cordset approved for the

country of use.

Power to the unit is controlled by the front-panel

Power switch.

AEW-R5200:

An auxiliary AC “jumper” (pass-through) outlet is provided on the rear panel, and a ”jumper” power cordset is included, to simplify power connections by “daisy-chaining” an array of AEW-R5200’s. Maximum output from the auxiliary outlet is 5 Amperes, which will easily handle a full complement of AEW-R5200 units.

“Link” Connections

Artist Elite Series multi-channel systems can comprise all AEW-R4100, all AEW-R5200, or combinations of AEW-R4100 and AEW-R5200 receivers. As many as 19 Artist Elite wireless systems may be operated simultaneously. The exclusive IntelliScan

™

channel assignment system provides easy, automatic scanning of the RF spectrum and assignment of usable, compatible frequencies to all linked AEW receiver channels.

Both AEW receiver models can be interconnected using Link In/Out jacks and included link cables. In addition, the AEW-R5200 offers a built-in Ethernet 10BaseT connection, with interface software provided on CD-ROM. See the separate AEW Control Interface manual provided with AEW-R5200 receivers and 5000 Series systems.

All AEW receivers in a linked multi-channel system should be interconnected with included link cables. When the system is properly configured, the “slave” units will “link data in” to the “Master” unit. (See Figure B for an example.)

1. First, decide which receiver will be the “Master” unit. Connect a link cable to the Link In

jack

only

. (In an AEW-R5200, the Channel 1 unit is the Master and Channel 2 becomes the first “slave.”)

2. Connect the free end of the link cable from the Master unit (in #1 above) to the Link Out

jack of the desired “next” unit.

3. Connect one end of a new link cable to the Link In

jack of

the unit in #2 above.

4. Connect the free end of the link cable from the unit in #2 above to the Link Out

jack of the desired “next” unit.

5. Continue this process of “daisy-chaining” the system’s receivers together with link cables. The “last” unit in the system will have a cable connected to its Link Out jack, but

connection to its Link In jack.

Installing link cables starting with the last slave unit and working toward the Master unit is also acceptable practice.

The attachment order of link cables establishes the numerical order of the receivers in the multi-channel system, from the selected Master unit through all the slave units. (In the case of AEW-R5200 receivers, a unit’s Channel 1 always comes before its Channel 2.) In a multi-channel system that includes both models of receivers, it’s common practice to position all the AEW-R5200 units

first

in the chain; followed any AEW-R4100 units.

Note 1: For the receiver linking to work, all receivers in the system must have AC power applied

at the same time

, or the

Master receiver must be turned on

last

Note 2: In addition, if AC power is interrupted or a link connection is broken at

any

receiver in a linked system,

even for an instant

, receivers from that unit onward are no longer linked to the system. When all power and linking have been restored,

the system must be restarted by turning all the receivers Off, then On

(all turned on simultaneously, or the Master receiver must be

turned on

last

). This will re-initialize the system and

re-establish all the data links.

Figure B

AEW-R5200

AEW-R4100

MASTER SLV 1

SLV 2 SLV 3

SLV 4 SLV 5

SLV 6

SLV 7

OUT

IN (N/A)

OUT (N/A)

LINKS

Ethernet connections (AEW-R5200):

An RJ-45 jack on the rear panel of each AEW-R5200 provides an Ethernet 10BaseT data/control connection from both of its channels to an external computer system. Data monitored includes actual, real-time “

”

and “

” levels for receiver channels with

direct

Ethernet connections to the associated computer. All other linked receivers in a system supply control-function access and all their data – except for “

” and “AF” levels – to the

computer connected to the Master receiver.

Multiple AEW-R5200 receivers in a system can each provide realtime “

” and “AF” levels to the associated computer if

each

AEW-R5200 has its own Ethernet connection, through an Ethernet hub, to the computer.

Other than being able to “see” the “

” and “AF” levels, all functions of all receivers in a linked system can be monitored and controlled from the computer connected to the Master receiver.

Details of the computer setup and operation will be found in a separate AEW Control Interface manual provided with AEW-R5200 receivers and 5000 Series systems.

Receiver Installation

(Continued)

6 / 10 LCD WINDOW: Liquid Crystal Display indicates control

settings and operational readings. See Figure G on page 13 for details.

7 / 11 UP/DOWN BUTTONS: Press Up or Down arrow

button, in conjunction with the Mode/Set button, to step through menus, select operating frequency and edit receiver function choices.

8 / 12 MODE/SET BUTTON: Use in conjunction with the

Up/Down arrow buttons to step through menus, choose operating frequency and select receiver function options.

13 FRONT-MOUNT ANTENNAS: Cables and panel connectors

are included with the AEW-R5200 to permit attaching antennas at the front panel.

Front Panel Controls and Functions (Fig. C)

1 POWER SWITCH: Press Power switch in and the receiver

readouts will light.

2 HEADPHONE OUTPUT:

/4" (6.3 mm) TRS (“stereo”) phone jack. Plug in either a mono or "stereo" headphone to monitor receiver signal.

3 HEADPHONE LEVEL CONTROL / CHANNEL SWITCH:

Adjusts the level of the headphone jack only; it does not affect receiver audio output. Press-and-release the knob to switch between Channel 1 and Channel 2.

4 HEADPHONE CHANNEL INDICATOR: Shows which receiver

channel is feeding the monitor headphones.

Channel 1 / Channel 2

5 / 9 ALERT INDICATOR: The Alert Indicator lights:

(a) When the receiver is in the Mute mode, (b) When no RF signal is received from the transmitter, (c) When only one or two RF signal-strength bars are on, (d) When the transmitter is in the Mute mode, (e) When audio modulation level from the transmitter is

close to the clipping point (AF +6 bar), or

(f) When the “LOW BAT” warning appears in the LCD

(transmitter battery is weak).

Receiver Controls and Functions

Figure C AEW-R5200 Receiver Front Panel

POWER

OFF

MODE/SET

OUTPUT

PHONES

UHF SYNTHESIZED DIVERSITY RECEIVER AEW-R5200

MIN MAX

PUSH SEL

LEVEL

RX NAME

4 5

Figure D AEW-R5200 Receiver Rear Panel

ANT. B

OUTPUT

(BAL)

INSTRUMENT

EXTERNAL

MUTE

0/-6/-12

ATTN (dB)

BALANCED MIC OUTPUT

GROUND

LIFT

GROUND

NETWORK

INTERFACE

ANT. A

OUTPUT

(BAL)

INSTRUMENT

EXTERNAL

MUTE

0/-6/-12

ATTN (dB)

BALANCED MIC OUTPUT

GROUND

LIFT

GROUND

100V-240V 50/60Hz

OUTPUT 5A/500W MAX

WARNING: THIS APPARATUS MUST BE EARTHED.

LINK

OUT

Rear Panel Controls and Functions (Fig. D)

14 ANTENNA INPUT JACK: BNC-type antenna connector for

Tuner “B.” Attach the antenna directly, or extend it with a low-loss antenna cable. See the ”Antennas” section on page 8 for more details. Antenna power at +12 volts is available at both antenna jacks; select it via the LCD menu on Channel 1.

15 / 22 EXTERNAL MUTE: Permits manual and absolute

muting of the receiver via a

/4" TS phone jack and a userprovided external switch. “Shorting” the jack (closing the switch connection) mutes the receiver channel. When External Mute has been applied, the only way to un-mute the receiver is to open the External Mute switch connection.

16 / 23 INSTRUMENT OUTPUT JACK:

/4" transformer-isolated TRS balanced phone jack output. Tip: “audio +”; Ring: “audio –”; Sleeve: ground (shield). Can be connected to an aux-level input of a mixer, guitar amp or tape recorder. Using the associated Ground Lift switch permits feeding equipment with different ground levels.

17 / 24 AF OUTPUT ATTENUATOR: Three-position switch

adjusts audio output level of both audio output jacks, with attenuation of 0 dB, –6 dB or –12 dB.

18 / 25 MIC OUTPUT JACK: XLRM-type connector. Pin 1:

ground (shield); Pin 2: “audio +”; Pin 3: “audio –”. A standard 2-conductor shielded cable can be used to connect the receiver output to a balanced microphone-level input on a mixer or integrated amplifier. This output is transformerisolated from the

/4" TRS Instrument output jack.

19 / 26 GROUND LIFT SWITCH: Disconnects the ground of

both the Mic and Instrument output jacks on the associated receiver channel. Normally, the switch should be to the right (ground connected). If hum caused by a ground loop occurs, slide switch to the left (ground lifted).

20 NETWORK INTERFACE CONNECTOR: An Ethernet

connection on the AEW-R5200 provides full communication and monitor/control by an associated computer. See the separate AEW Control Interface manual for computer setup and operation.

21 ANTENNA INPUT JACK: Connector for Tuner “A.” Attach

the antenna directly, or extend it with a low-loss antenna cable.

27 LINK IN JACK: Connect the provided cable to this jack with

the index mark on the plug aligned toward the screw head to the right of the jack. The receiver with a Link In

and no Link

Out

connection is the “Master” unit. (With an AEW-R5200 in the Master position, its Channel 1 is the system’s Master and its Channel 2 is the first “slave.”)

28 LINK OUT JACK: Connect the provided cable to this jack

with the index mark on the plug aligned toward the screw head to the right of the jack. The receiver with a Link Out and no Link In connection is the last slave in a multi-unit system.

29 AUXILIARY AC OUTLET: An auxiliary AC pass-through outlet

and included “jumper” power cordset simplify making power connections to an array of AEW-R5200’s. Maximum output from the auxiliary AC outlet is 5 Amperes.

30 AC POWER INPUT: IEC-type connector for 100V–240V AC,

50/60 Hz power input. No adjustment for mains voltage/ frequency is necessary.

31 REAR RACK MOUNT: Mounts are provided at the rear of the

side panels to permit attachment to rear rack rails in racks so equipped. The additional support is especially helpful when equipment is transported.

Receiver Controls and Functions

(Continued)

31 14 15 16 17 18 19 20 21 22 23 24 25 26

36 LCD WINDOW: Liquid Crystal Display indicates control

settings and operational readings. See Figure G on page 13 for details.

37 UP/DOWN BUTTONS: Press Up or Down arrow buttons, in

conjunction with the Mode/Set button, to step through menus, select operating frequency and edit receiver function choices.

38 MODE/SET BUTTON: Use in conjunction with the Up/Down

arrow buttons to step through menus, choose operating frequency and select receiver function options.

39 MOUNTING ADAPTERS: For mounting the receiver in any

standard 19" rack. Attach to the receiver with the screws supplied. (Use an optional AT8628a joining-plate kit to mount two AEW-R4100 receivers side by side.)

Front Panel Controls and Functions (Fig. E)

32 POWER SWITCH: Press Power switch in and the receiver

readouts will light.

33 HEADPHONE OUTPUT:

/4" (6.3 mm) TRS (“stereo”) phone jack. Plug in either a mono or “stereo” headphone to monitor receiver signal.

34 HEADPHONE LEVEL CONTROL: Adjusts the level of the

headphone jack only; it does not affect receiver audio output.

35 ALERT INDICATOR: The Alert Indicator lights:

close to the clipping point (AF +6 bar), or

(f) When the “LOW BAT” warning appears in the LCD

(transmitter battery is weak).

Receiver Controls and Functions

(Continued)

Figure E AEW-R4100 Receiver Front Panel

UHF SYNTHESIZED DIVERSITY RECEIVER AEW-R4100

ALERT

MODE/SET

POWER

OFF

PHONES

MIN–

LEVEL

–MAX

RX NAME

Figure F AEW-R4100 Receiver Rear Panel

OUTPUT

(UNBAL.)

INSTRUMENT

0/-6/-12

ATTN (dB)

BALANCED MIC OUTPUT

GROUND

LIFT

GROUND IN

–

LINK – OUT

ANT. A

WARNING: THIS APPARATUS MUST BE EARTHED.

˜

100V-240V 50/60Hz



ANT. B



Rear Panel Controls and Functions (Fig. F)

40 ANTENNA INPUT JACK: BNC-type antenna connector for

Tuner “B.” Attach the antenna directly, or extend it with a low-loss antenna cable. See the “Antennas” section on page 8 for more details.

41 INSTRUMENT OUTPUT JACK:

/4" phone jack. Can be connected to an aux-level input of a mixer, guitar amp or tape recorder. On the AEW-R4100, this is an unbalanced TS phone jack.

42 AF OUTPUT ATTENUATOR: Three-position switch adjusts

audio output level of both audio output jacks with attenuation of 0 dB, –6 dB or –12 dB.

43 MIC OUTPUT JACK: XLRM-type connector. A standard

2-conductor shielded cable can be used to connect the receiver output to a balanced microphone-level input on a mixer or integrated amplifier.

44 GROUND LIFT SWITCH: Disconnects the ground pin of the

balanced output jack (43) from ground. Normally, the switch should be to the right (ground connected). If hum caused by a ground loop occurs, slide switch to the left (ground lifted).

45 LINK IN JACK: Connect provided cable to this jack with the

index mark on the plug aligned toward the screw head above the jack. The receiver with a Link In

and no Link Out

connection is the “Master” unit.

46 LINK OUT JACK: Connect provided cable to this jack with

the index mark on the plug aligned toward the screw head above the jack. The receiver with a Link Out

and no Link In

connection is the last unit in a multi-unit system.

47 ANTENNA INPUT JACK: Connector for Tuner “A.” Attach

the antenna directly, or extend it with a low-loss antenna cable.

48 AC POWER INPUT: IEC-type connector for 100V–240V AC,

50/60 Hz power input. No adjustment for mains voltage/ frequency is necessary.

Receiver Controls and Functions

(Continued)

4140

RX NAME

RX LOCK

TX LO

TX HI

T X LOCK

T X NAME

Figure G Receiver LCD Window

51 53 58 5952 57

49 RF SIGNAL LEVEL INDICATOR: Shows the strength of the

RF signal received from the transmitter. Also indicates which Tuner (A or B) has the better reception and is in operation. When the METER HOLD function is on, the lowest-level RF signal received from the transmitter is indicated by a flashing bar.

50 ALPHANUMERIC DISPLAY: Shows Receiver Name (57),

Transmitter Name (57), or Link Address (MASTER, or SLV and the slave number). The factory setting displays “DEF” in Receiver Name mode (“RX NAME”). Once the settings have been changed, the unit will display the last setting and mode selected. Also flashes the “

LOW.BAT

” warning

when the associated transmitter’s batteries are weak.

51 TRANSMITTER BATTERY INDICATOR: Displays a maximum

of four bar segments, with four bars indicating full power.

52 FREQUENCY DISPLAY: Indicates the current frequency

setting in MHz.

53 “

EDIT

”: Appears and flashes when the receiver is in edit

mode.

54 TRANSMITTER RF POWER DISPLAY: Indicates either

“

TX LO

” or “

TX HI

”.

55 “

TX LOCK

”: Appears when the transmitter is in one of its

three lock settings (

ALL.LOC, MUT.LOC

PWR.LOC

56 “

RX LOCK

”: Appears when the receiver is in one of its

three lock settings (

ALL.LOC, PC.LOC or RX.LOC

57 TX/RX NAME: Indicates whether the transmitter name or

the receiver name is displaying in the top line of the LCD display.

58 “

MUTE

”: Appears when the receiver or transmitter is muted, when the receiver is not receiving an audio signal, or when the receiver is externally muted by use of the EXTERNAL MUTE jack.

59 AF LEVEL INDICATOR: Shows the audio modulation level of

the received signal. When the METER HOLD function is on, the bar corresponding to the highest level reached will stay lit.

Receiver Controls and Functions

(Continued)

Receiver Controls Power On/Off

Press the power switch to turn the receiver on. After a short power-up sequence, the display shows the operating frequency and the alert light is illuminated (if no active transmitters are present on this frequency). The receiver may also display a system position (i.e., “MASTER”, “SLV-#”) or an assigned transmitter or receiver name (if this feature has been set up—the display recalls the setting from the last time power was applied). Refer to page 16 on setting up receiver names or page 20 on setting up transmitter names.

Level

This control is used to set a comfortable listening level for the headphone jack. Turn the control clockwise to increase the level.

LCD Window

The LCD (Liquid Crystal Display) window provides visual indication of key operating and configuration parameters. It is also used in conjunction with the Mode/Set and Up/Down arrow buttons to change user-configurable functions.

Alert Light (LED)

The alert light illuminates to indicate to the user that something needs attention; for example, the transmitter batteries are low, or the transmitter is muted or turned off. Refer to page 10 for a complete description of alert light indications.

Mode/Set Button

The Mode/Set button has different functions depending on the status of the receiver. Two distinct operations are associated with this button:

Touch:

A momentary press of the Mode/Set button. It is used to enter Menu mode, to enter Edit mode, or to Escape without making any changes to current settings.

Hold:

A press and hold (about two seconds) of the Mode/Set button. It is used to accept a new setting when the receiver is in Edit mode or to save the current settings to one of the five user-defined name presets or the internal memory location (“NAME?”).

Up/Down Arrow Buttons

The Up/Down arrow buttons are used in conjunction with the Mode/Set button to scroll through the function menu in Menu mode or through the available choices for a given function in Edit mode.

When the receiver is in normal operating mode, the Up/Down arrow buttons scroll through Receiver Address (“MASTER” or “SLV-#”), Receiver Preset Name, or Transmitter Preset Name.

How to change receiver settings Enter Menu mode

With the receiver in the normal operating mode,

touch

the Mode/Set button. The top line of the receiver display shows “FRQ” preceded by one, two, or three asterisks.

Touch

the Up/Down arrow buttons to scroll through the available functions that may be changed. (See the chart on page 17 for a list of functions and display indication.) Note that the display’s lower line indicates the current setting for a given function.

Enter Edit mode

When the function to be edited is displayed,

touch

the Mode/Set button. The small word “EDIT” flashes in the bottom of the display, indicating Edit mode.

Touch

the Up/Down arrow buttons to scroll through the

available choices for the function, stopping on the desired choice.

Hold

the Mode/Set button to accept the new choice. “STORED” appears in the display when the choice is accepted. The receiver then reverts to Menu mode.

Continue this process until all desired function-setting changes are complete.

Note: To escape from Edit mode without making any changes,

touch

the Mode/Set button. “ESCAPE” appears briefly in the

display, and the receiver reverts to Menu mode.

Quitting and saving changes

The receiver has several methods of saving function settings. Each receiver has five loadable user presets that may be given individual names (up to six characters), along with a special, nonloadable memory location called “NAME?” that can store the most recent settings until they are changed.

To save a set of receiver function settings, use the Up/Down arrow buttons to scroll until the display shows “QUIT.” The procedure for saving the current settings depends upon the desired location:

Saving to the “NAME?” location

If the current receiver settings do

not

need to be identified with a name, the special “NAME?” location may be used to store them. As with the “last number redial” function on a telephone, these settings remain stored in the receiver even if power is turned off. They disappear only if one of the settings is modified.

To store settings in the “NAME?” location,

touch

the Mode/Set

button. The display shows “NAME?” for the receiver name.

Saving updated settings to the currently loaded user “PRESET#” location

To update the receiver settings in the currently loaded user preset that is already named,

hold

the Mode/Set button. The display shows “STORE XXXXXX” (where XXXXXX indicates the preset’s name).

Hold

the Mode/Set button a

second

time. The first character

of the name flashes.

Hold

the Mode/Set button a

third

time. The display briefly shows

“STORED”, and the receiver reverts to normal operation.

Receiver Controls and Functions

(Continued)

Saving to a different user PRESET# location

To store settings to a different user preset location,

hold

the Mode/Set button. The receiver shows “STORE XXXXXX” (where XXXXXX indicates the loaded preset’s name).

Touch

the Up/Down buttons to scroll to another preset location (the display shows the user-defined name for each location, or “PRESET#” if no name has been assigned).

At the desired preset location,

hold

the Mode/Set button. The

first character of the name becomes the cursor and flashes.

Touch

the Up/Down arrow buttons to scroll through the characters until the desired character is displayed.

Touch

the Mode/Set button to accept the character and advance to the next character. To advance the cursor without changing the character,

touch

the Mode/Set button.

After setting the last character,

hold

the Mode/Set button to

store the name and revert to normal operation.

Holding

the Mode/Set button at any time during the naming process while the cursor is flashing will store the setting and return the receiver to normal operation.

Note: To escape the naming process,

touch

the Mode/Set

button repeatedly until the last character is flashing, and then

touch

the Mode/Set button again to escape. At the flashing

“ESCAPE” display,

touch

the Mode/Set button to go back to the

beginning of the name, or

hold

the Mode/Set button to return to

“QUIT.”

Receiver Functions IntelliScan

™

Channel Assignment System

The IntelliScan

™

channel assignment system, provided on both the AEW-R4100 and AEW-R5200 receivers, eliminates the trouble and frustration normally encountered while attempting to find and select usable, compatible frequencies in a multi-channel system. The Artist Elite receivers are simply connected together with included communication link cables. A “Master” receiver then “knows” how many total channels it is looking for. It can scan the available frequencies, checking for local interference sources, selecting a group of channels that will all work together (using a built-in frequency plan), and automatically setting the other linked AEW receivers accordingly. Once this procedure is completed, the transmitter frequencies must be set to match the receiver frequencies.

Receiver Locks

Programmable locks restrict the ability to change receiver settings, reducing the possibility of unauthorized access or unintended changes during performances.

Setting

Description

NO.LOC

Receiver functions and frequency settings can be edited from the receiver’s front panel or from an associated computer via an Ethernet connection to a linked AEW-R5200.

ALL.LOC

Receiver functions and frequency settings

cannot

be edited from the front panel or from a computer via an Ethernet connection to a linked AEW-R5200.

ALL.LOC

must be changed via the receiver’s Menu before other settings can be changed.

PC.LOC

Receiver functions and frequency settings can be edited from the receiver’s front panel, but they

cannot

be edited from an associated computer (via an Ethernet connection to a linked AEW-R5200).

RX.LOC

Receiver functions and frequency settings can be edited from an associated computer (via an Ethernet connection to a linked AEW-R5200), but they

cannot

be edited

from the receiver’s front panel.

When

any

lock condition is applied to a receiver (

ALL

., RX. or PC.),

the LCD window displays a small “

RX LOCK

” just to the right of the frequency. If an action is attempted that currently is locked out, the LCD will briefly display “

LOCKED

”, then return to its

previously displayed contents.

Note: Locks remain in place even when receiver power is turned off. However, locks may be removed by using the Menu.

Antenna Power

This function turns on the 12V AC antenna power for use with powered antennas or accessories.

Digital Tone Lock

™

Squelch

The Artist Elite Series employs a unique digital Tone Lock squelch system that provides enhanced rejection of interference. In addition to providing highly effective control of unwanted noise, the Tone Lock signal from the transmitter also conveys data with the transmitter’s name (Tx Name), battery condition, mute status and lock status back to the receiver for display. In addition to displaying in the receiver’s LCD window, the data are also displayed on an Ethernetconnected computer.

The squelch level is adjustable in fifteen 2-dB steps, providing a 30 dB range. Increasing the squelch level – also called “tightening the squelch” – can cause a reduction in usable range of the wireless transmitter, so use the lowest value that reliably mutes the unwanted RF signals. (If interference is a problem, first consider trying a different frequency, either manually or by scanning.)

Note: While the receiver is in Edit mode, no action (no buttons pressed) for approximately 30 seconds causes the receiver to revert to Menu mode.

While the receiver is in Menu mode, no action for approximately 30 seconds causes the receiver to revert to normal operating mode. Any setting changes stored will remain in the “NAME?” memory location, and the receiver will display “NAME?” because the settings were not saved to a user preset. This will occur even if a user preset was previously loaded.

Receiver Controls and Functions

(Continued)

Meter Hold

When activated (“

METER HOLD

”), this function permits the bar

meters in the LCD window to capture and display the

highest

level “

” audio modulation (a solid bar) and the

lowest

-level

“

” signal (a flashing bar) received from the transmitter. This is particularly useful when setting up the system initially, performing a sound-check, or diagnosing operating problems. The default setting is Off (“

METER NORMAL

”).

When the Meter Hold is On, it is possible to reset it – to obtain a new set of RF and AF readings – without turning it off-and-on using the Menu/Edit functions. Simply press the transmitter’s Power/Mute button once (to mute the transmitter) and

wait

until the receiver’s Alert light comes on

, indicating the Mute condition. Then press the transmitter’s Power/Mute button once again, to un-mute the transmitter.

After the Alert light goes out

, a new set of min/max RF/AF readings will be indicated on the bar meters. (Note that, depending upon the digital updating-and-confirming sequence of the Mute condition data from the transmitter, it can take from a few to many seconds for the Alert light condition to change.

The Meter Hold readings are not reset until the Alert light has turned on, then off.

)

Note: Any or all of these receiver functions may be stored to, or loaded from, one of the five user presets.

Using "PRESET" Store and Recall

There are two aspects to Preset operation:

Storing

a particular

collection of settings for future use (“

STORE

”), and

recalling

stored collection of settings (“

LOAD

”). All Artist Elite receivers and transmitters permit the storing and recalling of up to five userdefined Preset combinations—with customized names, if desired—plus the recalling of the factory-defined Default (“

DEF

”)

settings.

While the standard Preset names (“

PRSET1

” – “

PRSET5

”) can be used, customized receiver and transmitter identification can simplify system operation, especially in larger systems. For example, a guitar channel’s Rx Name could be “

GUITAR

”, while the transmitters for the performer’s two different guitars could be named “GTR-1” and “GTR-2”.

To store Preset configurations:

Touch

the Mode/Set button once to move to Menu mode.

Touch

the Up arrow twice to move to “

PRESET

” in the LCD window. (The second line of LCD will show currently loaded presets.)

Touch

the Mode/Set button once. “

LOAD

” (or “

STORE

”)

appears in the LCD.

Touch

the Up or Down arrow once, if needed, to change the

selection to “

STORE.

”

Hold

the Mode/Set button until “

PRSET1

” (or the name of the currently loaded Preset) appears on the second line of the LCD.

6. If desired,

touch

the Up or Down arrow to cycle through the

available choices: “

PRSET1

” through “

PRSET5

” (or their

previously changed names).

7. Accept or enter a name for the Preset: a. To accept the

standard

name “

PRSET1

“ – “

PRSET5

” (or previously stored name) for a new Preset configuration and to update (overwrite) any previously stored configuration choices:

a1. At the desired choice,

hold

Mode/Set until the first character blinks, giving an opportunity to change the name.

a2. To accept the standard (or existing) name,

hold

the

Mode/Set button again until “

STORED

” appears in the window. This stores the standard or existing Preset name with the associated function choices and returns the unit to normal operation. The name of the stored preset will appear in the top line of the display.

b. To enter a

custom

name for a Preset:

b1. At the desired choice,

hold

the Mode/Set button.

The first character blinks.

b2. Using the Up or Down arrow, move through the

available characters (see box below) until the desired character is reached.

Touch

an arrow button for single

steps, or

hold

it down to scroll through the characters

at increasing speed.

b3.

Touch

the Mode/Set button

once

to accept the first character and move to the second character, which now is blinking. Use an Up/Down arrow button to find the desired second character;

touch

the Mode/Set button once to accept it and move to the third position. Repeat this selection process until the character for the sixth position has been selected.

b4. Once the sixth character has been selected as desired,

hold

the Mode/Set button until “

STORED

” appears in the window. This stores the custom Name with the associated function choices and returns the unit to normal operation. The display shows the custom name in the top line.

Note: If a correction or change is desired while entering characters, simply

touch

the Mode/Set button

once

when the sixth (last) character has been reached. The window will flash “

ESCAPE.” Touch

the Mode/Set button once more to start the name-entry process over at the first character. (To leave any characters as they are, simply

touch

Mode/Set

once to skip over them.)

Available receiver Name character choices:

A …through… Z,

__ (underscore) … (

space

) …

[ (

left bracket

) … ] (

right bracket

* … + … -- … / ,

0 …through… 9,

| … < … > … ?

Receiver Controls and Functions

(Continued)

Receiver Functions

Function Menu

Default Value Choices (Edit) ▲▼ Wrap-around*

▲▼ Frequency Lowest in band Approximately 200 discrete frequencies Yes

▲▼ Scan**/*** No value Scan start --

▲▼ Lock

NO.LOC NO.LOC ALL.LOC PC.LOC RX.LOC

Ye s

▲▼ Antenna Power**

OF F OF F ON

Ye s

▲▼ Squelch - (one bar) 15 steps, 2 dB each No

▲▼ Meter

NO RMA L N ORM AL H OLD

Ye s

▲▼ Preset

PRESET

Press once, then select

LOAD

STORE

Ye s

▲▼

LOAD: DEF DEF

(default),

PRSET1

through

PRSET5

Ye s

▲▼

STORE: PRSET1 PRSET1

through

PRSET5

Ye s

▲▼ Quit (exit Menu)

QUIT

Press Mode/Set once to exit --

* Continue in the same Up/Down direction and choices “wrap around” to the other end of the range. ** AEW-R5200: Scan and Antenna Power selections in LCD menu on Channel 1 only. *** Scan selection is not available when the receiver has been linked as a slave unit.

Table 1. Receiver Functions

To load (recall) a Preset:

Touch

the Mode/Set button once to move to Menu mode.

Touch

the Up arrow twice. LCD top line shows “PRESET.”

Touch

the Mode/Set button once. “

LOAD

” (or “

STORE

”)

appears in the LCD.

4. If needed,

touch

the Up arrow once to change the selection

to “

LOAD.

”

Hold

the Mode/Set button. The name of the currently

loaded Preset appears on the second line of the LCD.

Touch

the Up or Down arrow to cycle through the available

choices, stopping on the desired choice.

Hold

the Mode/Set button until “

LOADED

” appears briefly in the LCD. The receiver reverts to normal operation with the selected preset’s functions loaded. The top display line indicates the loaded preset and the bottom line the current frequency.

To revert to factory-default values:

Touch

the Mode/Set button once to move to Menu mode.

Touch

the Up arrow twice. “

PRESET

” shows in the LCD

window.

Touch

the Mode/Set button once. “

LOAD

” (or “

STORE

”)

appears in the LCD.

Touch

the Up arrow once, if needed, to change the

selection to “

LOAD.

”

Hold

the Mode/Set button. The name of the currently

loaded Preset appears on the second line of the LCD.

Touch

the Up/Down arrow buttons to cycle through the

available choices until “DEF” appears in the display.

Hold

the Mode/Set button to load the factory default

settings. “

LOADED

” appears briefly in the LCD. The receiver then reverts to normal operation at factory-default values. “DEF” appears in the upper line of the LCD.

Note: Loading the default setting will also revert the receiver frequency to default to the first frequency value in the Band used

AEW-T1000 UHF TRANSMITTER

Power On/Off

To turn the transmitter on,

hold

the Power/Mute button until the red power indicator and the LCD window come on (about 1–2 seconds). The operating frequency shows in the window after the power-up sequence.

To turn the transmitter off,

hold

the Power/Mute button again, until the red power indicator and the LCD window are extinguished (about 1–2 seconds). The LCD window shows “

PWR.OFF

” before shutdown.

Mute On/Off

When the transmitter is muted, it produces RF with no audio signal modulation. When the transmitter is un-muted, it produces both RF and audio.

To mute the transmitter (cut off the audio, but continue the RF output),

touch

the Power/Mute button

once

. A small “

MUTE

”

appears in the LCD window, just below the frequency (Figure H-

2).

To un-mute the transmitter (restore the audio),

touch

the

Power/Mute button

once

again. The “

MUTE

” disappears from

the LCD window.

Refer to Figures H through Q for an overview of transmitter functions and controls.

LCD Window

The Liquid Crystal Display presents a great deal of setup and operating information clearly and conveniently (Figure H). The LCD in the transmitters is designed for greatest contrast and best viewing with the window rotated somewhat

away

from the viewer (about 30 degrees), not straight-on, for a more convenient holding/viewing position.

Power/Mute Button

The transmitters have a combination Power and Mute switch (Figure J/K). When used in combination with the programmed choices explained below, the various functions available to the transmitter user may be tailored to fit personal preferences or particular situations.

Transmitter Controls and Functions

Battery Door

LCD Window

Figure J

Antenna

Audio Input Jack

Mounting Clip

Set Button

Power/Mute Button

Up/Down Arrows

Sliding Control Cover (3-position)

Power-on LED

Figure K

LCD

Window

Power-on

LED

Power/Mute

Button

Antenna Housing

H-1. Normal Operation

* AEW-T1000 only:

“INST”

H-2. Operation with Mute On

H-4. Edit Mode (Frequency)

Figure H

BATT MIC

H-3. Menu Mode (Frequency)

BATT MUTE MIC

BATT MIC

EDIT

Flashing

▼

Touch:

A momentary press of the Mode/Set button. It is used to enter Menu mode, to enter Edit mode, or to Escape without making any changes to current settings.

Hold:

Transmitter Controls and Functions

(Continued)

Audio Input Selector

The UniPak

™

body-pack transmitter provides input connections for both low-impedance (Lo-Z) microphones and highimpedance (Hi-Z) instruments. A wide range of Audio-Technica Wireless Essentials

™

microphones and cables is available pre-terminated with the appropriate professional latching connector. (See page 28.)

Selection of the desired input – microphone or instrument – is made through the function menu. Depending upon the input selected, a small “

MIC

” or “

INST

” will continue to show in the LCD window, just below the frequency. (In the handheld transmitters, “

MIC

” will always show in the LCD window.)

Setting Audio Input Level

AEW-T1000 UniPak:

A 10-position audio input gain setting, selected through the function menu, serves to match the audio input level to the transmitter for best modulation with minimum distortion. Available choices are +12 dB to –6 dB in 2 dB steps. The default value is +6 dB.

AEW-T4100 and AEW-T6100 Dynamic Handhelds:

A 4-position audio input gain setting, selected through the function menu, serves to match the audio input level to the transmitter for best modulation with minimum distortion. Available choices are +12 dB to –6 dB in 6 dB steps. The default value is +6 dB.

AEW-T3300 and AEW-T5400 Condenser Handhelds:

A 3-position audio input gain setting, selected through the function menu, serves to match the audio input level to the transmitter for best modulation with minimum distortion. Available choices are +12 dB, +6 dB and 0 dB. The default value is +6 dB. In addition, a mechanical pad switch on the condenser capsule (inside the screw-on wire mesh grille) can provide another 6 dB of attenuation. For best performance, adjust the input level using the function menu choices, keeping the capsule’s mechanical switch at 0 dB. If more audio attenuation is needed than the menu provides, then set the capsule’s pad switch to –6 dB.

For all transmitters:

Select the highest audio level setting that does not result in over-modulation with the highest audio/ instrument input levels (an AF indication on the receiver no higher than “+3”); watch the receiver’s “

” meter “+6” indication and the Alert light to make certain they are not triggered often by the highest audio levels.

The transmitter’s red LED power indicator, which is on during normal operation, will blink

off

if the peak audio input reaches

overload level.

Power/Mute Locks

Programmable Power/Mute Locks limit the functioning of the Power/Mute button as desired for particular users and/or applications. Power can be locked On; Mute can be locked Off. Selection of the desired locks, if any, is made through the function menu:

Setting

Description

NO.LOC

The normal Power and Mute functions are fully operational.

ALL.LOC

Power is locked On and Mute is locked Off when “

ALL.LOC

” is applied. When in the

ALL.LOC

mode, the transmitter may be

turned off by (1) re-accessing the

.LOC

Menu and changing the setting, (2) pressing and holding the Up arrow button

and

the Set

button

at the same time

, until the power goes off, or (3) removing and re-installing the batteries. When the transmitter is turned on again, it will power up in the

NO.LOC

mode.

MUT.LOC

In this mode, the audio cannot be muted (Mute function is locked Off). The Power functioning is unaffected.

“Mute” Note: If

ALL.LOC

MUT.LOC

applied

while the transmitter is muted

, pressing the Power/Mute button once will return the transmitter to un-muted operation; thereafter the Mute function is disabled (Mute Off) until the .LOC setting is changed again.

PWR.LOC

Power is locked On when “

PWR.LOC

” is applied. The Mute functioning is unaffected. When in the

PWR.LOC

mode, the transmitter

may be turned off by: (1) Re-accessing the

.LOC

Menu and changing the setting,

(2) Pressing and holding the Up arrow button

and

the Set button

at the same time

, until the power goes off, or (3) Removing and re-installing the batteries. When the transmitter is turned on again, it will power up in the

NO.LOC

mode.

Note: Only the

ALL.LOC

PWR.LOC

Power function will change when batteries are removed;

NO.LOC

and

MUT.LOC

settings

remain stored in memory.

If an action is attempted that currently is locked out, the transmitter LCD will briefly display “

LOC.KED

”, then return to its

previously displayed contents.

Whenever any lock condition is applied to a transmitter, its associated

receiver

will display a small “

TX LOCK

” in the LCD

window, just to the right of the frequency.

Transmitter Controls And Functions

(Continued)

To load (recall) a Preset:

Touch

the Set button once to move to Menu mode. (The

window changes to frequency, if Name had been displayed.)

Touch

the Up arrow twice to move to “

PRESET

” in the LCD

window.

Touch

the Set button once. “

LOAD

” (or “

STORE

”) appears

in the LCD.

4. If needed,

touch

the Up or Down arrow once, to change the

selection to “

LOAD.

”

Hold

the Set button until “

LOAD

xxxxxx

” (the current Preset)

appears in the LCD.

Touch

the Up or Down arrow to change the selection from

“

xxxxxx

” to the desired Preset.

Hold

the Set button until “

LOADED

” appears briefly in the LCD. The transmitter reverts to normal operation with the selected preset’s settings loaded. To toggle between transmitter name and frequency,

touch

an Up or Down

arrow button.

To revert to factory-default values:

Touch

the Set button once to move to Menu mode.

Touch

the Up arrow twice. “

PRESET

” shows in the LCD

window.

Touch

the Set button once. “

LOAD

” (or “

STORE

”) appears

in the LCD.

Touch

the Up or Down arrow once, if needed, to change the

selection to “

LOAD.

”

Hold

the Set button. The current Preset appears in the LCD.

Touch

the Up or Down arrow buttons to cycle through the

available choices until “DEF” appears in the display.

Hold

the Set button to load the factory default settings. “LOADED” appears briefly in the LCD. The transmitter reverts to normal operation at the default settings.

Preset/Default Settings

A “

PRESET

” selection in the menu permits the storing of up to five different user-definable configurations. Customized names, using letters, numbers and symbols, can also be created and stored for Presets 1–5. In addition, a Default (“

DEF

”) choice permits returning all transmitter functions to their factory-default settings.

To store Preset configurations:

Touch

the Set button once to move to Menu mode.

Touch

the Up arrow twice to move to “

PRESET

” in the LCD

window.

Touch

the Set button once and “

LOAD

” (or “

STORE

”) will

appear in the LCD.

Touch

the Up or Down arrow once, if needed, to change the

selection to “

STORE

”.

Hold

the Set button until “

STORE

” changes to

“

PRSET1

” (or the name of the currently loaded Preset).

6. If desired,

touch

the Up or Down arrow to cycle through the

available choices: “

PRSET1

” through “

PRSET5

” (or their

previously changed names).

7. Accept or enter a name for the Preset:

a. To accept the

standard

name (

PRSET1 – PRSET5

, or the previously stored name) for a new Preset configuration and to update (overwrite) any previously stored configuration choices:

a1. At the desired Preset,

hold

the Set button until the first

character blinks.

a2.

Hold

the Set button again until “

STORED

” appears in the window. This stores the standard Preset name with the associated function choices and returns the transmitter to normal operation.

b. To enter a

custom

name for a Preset:

b1. At the desired Preset,

hold

the Set button until the first

character blinks.

b2. Using the Up or Down arrow, move through the

available characters (see box below) until the desired character is reached.

Touch

an arrow button for single steps, or hold it down to scroll through the characters at increasing speed.

b3.

Touch

the Set button once to accept the first character and move to the second character, which now is blinking. Use an Up/Down arrow to find the desired second character;

touch

the Set button once to accept it and move to the third position. Repeat this selection process until the character for the sixth position has been selected. (It is not necessary to change or step through all six characters before storing the result. At any point in the process, simply

hold

the Set button

until “

STORED

” appears in the window.)

b4. Once the sixth character has been selected as desired,

hold

the Set button until “

STORED

” appears in the window. This stores the custom Name with the associated function choices and returns the transmitter to normal operation.

Note: If a correction or change is desired while entering characters, simply

touch

the Set button

once

when the sixth (last) character has been reached. The window will flash “

ESCAPE.” Touching

the Set button

once more

will start the name-entry process over at the first character. (To leave any characters as they are, simply

touch

the Set

button once to skip over them.)

Available transmitter Name character choices (listed in the Uparrow direction):

A …through… Z,

__ (underscore) … (

space

[ (

left bracket

) … ] (

right bracket

* … + … -- … /,

0 …through… 9,

| … < … > … ?

Note: Loading the default setting resets the transmitter frequency to default to the first frequency value in the Band used.

UniPak Transmitter Functions

Function Menu

Default Value Choices (Edit) ▲▼ Wrap-around*

▲▼ Frequency Lowest in band Approximately 200 discrete frequencies Yes

▲▼ RF Power

RF LOW RF LOW RF HI

Ye s

▲▼ Audio Input Level

+6 dB –6 dB to+12 dB

in 2 dB steps No

▲▼ Power/Mute Locks

NO.LOC NO.LOC ALL.LOC MUT.LOC PWR.LOC

Ye s

▲▼ Input Select

MIC MIC INSTR

Ye s

▲▼ Preset Configurations

PRESET LOAD STORE

Ye s

▲▼

LOAD: DEF DEF

(default),

PRSET1

through

PRSET5

Ye s

▲▼

STORE: PRSET1 PRSET1

through

PRSET5

Ye s

▲▼ Quit (exit Menu) QUIT Press Set once to exit --

* Continue in the same Up/Down direction and choices “wrap around” to the other end of the range.

If accessing de-regulated band 863.125 - 864.875 MHz then RF power should be assigned to "RF Low”

Table 2. UniPak Transmitter Functions

Transmitter Controls and Functions

(Continued)

Handheld Transmitter Functions

Function Menu

Default Value Choices (Edit) ▲▼ Wrap-around*

▲▼ Frequency Lowest in band Approximately 200 discrete frequencies Yes

▲▼ RF Power

RF LOW RF LOW RF HI

Ye s

▲▼ Audio Input Level

Dynamic

+6 dB –6 dB 0 dB +6 dB +12dB

Condenser**

+6 dB 0 dB +6 dB +12dB

▲▼ Power/Mute Locks

NO.LOC NO.LOC ALL.LOC MUT.LOC PWR.LOC

Ye s

▲▼ Preset Configurations

PRESET LOAD STORE

Ye s

▲▼

LOAD: DEF DEF

(default),

PRSET1

through

PRSET5

Ye s

▲▼

STORE: PRSET1 PRSET1

through

PRSET5

Ye s

▲▼ Quit (exit Menu) QUIT Press Set once to exit --

* Continue in the same Up/Down direction and choices “wrap around” to the other end of the range. ** Additional 6 dB pad switch on capsule.

If accessing de-regulated band 863.125 - 864.875 MHz then RF power should be assigned to "RF Low”.

Table 3. Handheld Transmitter Functions

Transmitter Setup

Battery Selection and Installation

Each transmitter uses two 1.5V AA batteries, not included. Alkaline type is recommended. Always replace both batteries.

Make certain the transmitter power is Off before replacing batteries.

UniPak™Transmitter Battery Installation

1. Open the battery compartment door by sliding the catch down (Figure L). (If no batteries are inside, the door will not spring open by itself.)

Observe correct polarity as marked on the metal contacts on the door

and carefully insert two fresh 1.5V AA alkaline

batteries (Figure M).

3. Close the door, making certain the latch clicks securely in place.

Handheld Transmitter Battery Installation

1. While holding the lower body cover (near the LCD window), grasp the upper part of the transmitter body just

below

the grille and unscrew it at least four complete turns (Figure N); then slide the lower body cover down until it stops (Figure P). Once the cover has been lowered, turn the transmitter over to reveal the battery compartment on the side opposite the LCD window.

Observe correct polarity as marked inside the battery compartment

and carefully insert two fresh 1.5V AA alkaline batteries (Figure Q). Insert the first battery and slide it down. Then insert the second battery, bottom first, into the space remaining. Make certain the batteries are fully seated in the battery compartment.

3. Slide the lower body cover back up the body, then screw the housing together.

Do not overtighten.

Note: Remove batteries from the handheld transmitter starting at the

bottom

(– end) of the top battery (Figure Q). The top (+ end) of the top battery is captured in a recess and will not come straight out.

Battery Condition Indicator

After the batteries are installed, turn the power on by

pressing

and holding

the Power/Mute button. The small red power-on LED (see Figure J/K on page 18.) should light and the LCD window should come on. If this does not happen, the batteries are installed incorrectly or they are dead. The transmitter’s “fuel gauge” battery indicator displays a maximum of four bar segments. When the LCD flashes “

LOW.BAT

”, the batteries should be replaced immediately to ensure continued operation. (The receiver also displays the transmitter’s battery condition in the LCD window with bar segments; the Alert indicator and a flashing “

LOW.BAT

” come on to warn of a low-battery

condition.)

Figure L

Figure M

▼

Figure P

SET

LCD

Window

Power-on

LED

Up/Down

Arrows

Set Button

Figure Q

Serial Number

Start from this end

to remove batteries

Figure N

▼

Transmitter Setup

(Continued)

UniPak Transmitter Input Connection

Connect an audio input device (microphone or guitar cable) to the audio input jack on the bottom of the transmitter. A number of Audio-Technica professional microphones and cables are available separately, pre-terminated with a UniPak input connector (see “Optional System Accessories” on page 28). The cable connector latches automatically when inserted into the transmitter jack. To unlatch and remove the connector, simply pull up on the connector’s knurled metal collar.

UniPak Transmitter Antenna

The AEW-T1000 transmitter includes two field-replaceable antennas. A flexible-wire antenna is supplied mounted on the transmitter, while a separate short, helical antenna is supplied with the accessories. Either antenna simply screws into the transmitter’s antenna fitting. Check the installed antenna occasionally to make certain it is snugly attached (only fingertight). The helical antenna is more convenient physically but may not have the operating range of the wire antenna. The wire antenna should hang down, at its full length, from the bottom of the transmitter. If the received signal is marginal, experiment with different transmitter positions on your body or instrument; try the wire antenna; or try repositioning the receiver.

Do not attempt to modify either transmitting

antenna. Replace them only with the same parts

, available from

the Audio-Technica Service Department.

Handheld Transmitter Antenna

The antenna for the handheld mic/transmitter is in the black, nonmetallic section at the bottom of the unit (see Figure K on page

18). For best results, hold the mic/transmitter naturally, around its painted metal case. Holding or otherwise covering the antenna housing may reduce operating range.

UniPak Transmitter Mounting Clip

The UniPak transmitter’s mounting clip may be installed with the case positioned either “up” or “down,” depending upon which is preferred for the particular application. To turn the clip around, spring the ends of the clip out of the two holes on the sides of the transmitter case (see Figure J on page 18) and reinstall it facing in the opposite direction.

System Operation

Artist Elite wireless receivers and transmitters are extremely versatile components with many operating features and functions, some of which are not obvious. As a result, we suggest the following approaches to assure a “comfort level” with any new equipment:

1. Begin using a single receiver/transmitter pair at their Default (“

DEF

”) settings, to become familiar with equipment functions and operation before doing any customizing. (If the Default frequency is not usable in your area, change the frequency to one that is suitable.)

2. Before installing/starting up a large multi-channel system, explore the functions and operation of only two or three receiver/transmitter pairs together.

Basic Operation – Single AEW-R4100 receiver system:

Turn down the AF Level of the mixer or amplifier. Switch on the receiver. Do

not

switch on the transmitter yet.

Turning on the Receiver

The Alert indicator and the LCD window lights up; the normal operation LCD display appears after 1–2 seconds. If any of the bars show in the “

” bar-graph meters, there may be RF interference in the area. If this occurs, select another frequency as explained below. (If the Meter Hold function has been selected, one of the RF bars in each column will be flashing, indicating the lowest RF levels received.)

Selecting/Setting Receiver Frequency

Selection of the desired operating frequency is made through the function menus. There must be no local interference on that frequency. If the Default frequency (lowest in band) happens not to be usable, the receiver frequency may be set manually by using the frequency charts starting on page 29, or by using the IntelliScan function.

• Manual frequency selection:

Adjust the receiver frequency

as detailed in the next section.

• IntelliScan frequency selection:

The receiver’s IntelliScan function may be employed to select a usable operating frequency automatically, as detailed in the section following on page 25.

Note: Once the receiver frequency is set, the associated

transmitter

must be set manually to the receiver’s

exact

frequency. See page 26 for the correct procedure.

Setting Receiver Frequency Manually

Touch

the Mode/Set button once. “FRQ” appears on the first line of the LCD window with the current frequency setting on the second line. (The receiver is now in Menu mode.)

Touch

the Mode/Set button again. The small flashing word “EDIT” appears at the bottom of the window. (The receiver is now in Edit mode.)

3. Use the Up/Down arrow buttons to change the frequency.

Touch

either arrow for single steps, or

hold

either arrow for rapid cycling through the band. Frequencies “wrap around” to the other end of the range when the top or bottom of the band is reached. Choose a frequency appropriate for your area, avoiding frequencies with active TV channels. (See the frequency listings from page 29.)

Note: The top line of the LCD indicates when frequencies belong to multi-frequency groups. Asterisks (*) are displayed in front of “FRQ” to indicate membership in one of more of the three groups (Figure R on page 25). See page 34 for frequency group listings.

4. To choose this frequency,

hold

the Mode/Set button until the word “STORED” appears in the receiver’s window. (If you do not wish to complete this selection,

touch

the Mode/Set

button

once

. The word “ESCAPE” appears briefly in the

window, and the receiver returns to Menu mode.)

5. When finished entering a frequency,

touch

the Up arrow

button

once

. The display reads “QUIT.”

There are several ways to quit, depending on whether the current Name is to be retained or the frequency stored to a user preset. See page 14 for help with Quitting and saving changes.

To quickly store the new frequency into the “NAME?” location,

touch

the Mode/Set button. The receiver shows “NAME?” in the top line and the new frequency in the bottom line.

Note: You must now set the transmitter to the exact same frequency for the system to operate!

The details of setting up and operating a multi-channel system vary greatly in complexity, depending upon the number of receivers and nature of the system. Because the feature-rich nature of AEW units can greatly increase this complexity, we suggest starting with a simpler, straightforward setup and use to become familiar with the equipment and its capabilities.

Single AEW-R4100 receiver system:

Begin using a receiver and transmitter at their Default (“

DEF

”) settings, to become familiar with equipment functions and operation before doing any customizing. (If the Default frequency is not usable in your area, manually change only the frequency to one that is suitable, as described on page 25.)

Single AEW-R5200 receiver system (two channels):

Start out using only Channel 1, treating this the same as the single AEW-R4100 above.

Multiple-receiver system with link cables only:

The link cables provide data and control between receivers. The IntelliScan

™

feature scans for clear channels and assigns non-conflicting frequencies to all linked receivers. (If IntelliScan is not used, the receiver frequencies may all be set individually/manually, as with any standard receiver, using the multi-channel information on page 30.)

Multiple-receiver system with Ethernet-connected computer interface:

Refer to the separate AEW Control Interface manual for setup and operation of a computer-based system. Basic hardware aspects of the receivers, and all transmitter setup/operating information, are in the manual you are now reading.

Touch:

A momentary press of the Mode/Set button. It is used to enter Menu mode, to enter Edit mode, or to Escape without making any changes to current settings.

Hold:

System Operation

(Continued)

Note: An asterisk in two or more locations indicates this frequency is in more than one group.

Setting Receiver Frequency Using IntelliScan

Single-receiver systems (either an AEW-R4100 or an AEW-R5200):

Turn down the AF level of the associated mixer or amplifier.

Make certain that any AEW transmitters are turned

off.

(Other RF-

generating devices in the area should be turned

, if

possible.)

Touch

the Mode/Set button once to enter the Menu mode. (On an AEW-R5200, use Channel 1 to perform the IntelliScan for both channels.)

Touch

the Down arrow once. The display shows “SCAN.”

Hold

the Mode/Set button to start the scan. The second line displays “------” during the scan and then briefly displays “SCAN OK” when the scan is successfully completed.

4. The display on the receiver then shows “RESET NAMES.” The receiver remains in this state (system is muted) until one of the following steps is completed:

a. To accept and use this frequency with the currently

loaded/named preset,

touch

the Mode/Set button. The LCD briefly displays “STORED” and reverts to normal operation. At this point, the display shows the receiver name/preset currently loaded. (Note: This frequency is now stored with the associated named preset and is recalled when that preset is reloaded.)

b. To accept and use this frequency and store it in the special

“NAME?” location,

hold

the Mode/Set button. The LCD displays “NAME?” on the top line. (Note: Doing this allows a new frequency to be used without affecting previously stored preset data. However, the receiver shows “NAME?” instead of the preset’s name.)

To store this frequency along with other settings into one of the user presets, refer to the instructions on page 15.

IMPORTANT! If one of the above steps is not completed, the receiver will remain in the “RESET NAMES” state indefinitely (system is muted), and it will

not

automatically back out to

normal operating mode.

Multiple-receiver systems:

Turn down the AF level of the associated mixer or amplifier. Make certain that any AEW transmitters are turned

off.

(Other RF-

generating devices in the area should be turned

, if

possible.)

1. Make certain all the receivers are connected (daisy-chained) with link cables. The receiver with only a Link In (no Link Out connection) becomes the Master receiver. (See “Link connections” on page 9.)

2. Switch on

all

the slave receivers first; switch on the Master

receiver

last

. Alternatively, all receivers can be turned on

simultaneously

, as when using AC power plug strips controlled by a single AC switch. (If an AC power or link connection is interrupted, even briefly,

all

receivers must be turned off and the power-up sequence repeated to assure complete system control.)

3. Using controls on the Master receiver, follow all the steps listed for single-receiver systems to assign compatible frequencies for all receivers by using IntelliScan.

4. The display on the Master shows “RESET NAMES”, and the display on each slave shows “SCAN” and the new frequency. The receivers remain in this state (system is muted) until one of the following steps is completed to accept the new frequency plan:

a. To accept and use this frequency plan with the currently

loaded/named presets,

touch

the Mode/Set button. If a user preset was previously loaded on the receiver, the LCD briefly displays “STORED” and reverts to normal operation. The LCD then displays the previously loaded user preset or receiver name and the new frequency. (Note: This frequency is now stored with the associated named preset and is recalled when that preset is reloaded.) If no user preset was loaded (i.e., the default settings were in effect), the LCD shows “NAME?” and the new frequency.

b. To accept and use this frequency

and

store it in the special

“NAME?” location,

hold

To store this frequency along with other settings into one of the user presets, refer to the instructions on page 15.

Note: These changes affect

all linked receivers.

IMPORTANT! If one of the above steps is not completed, the

Master and all linked slave receivers will remain in the “RESET NAMES” state indefinitely (system is muted) and will

not

automatically back out to normal operating mode.

Note: A “SCAN ERROR” message may be attributable to one or more of the following:

• The link connection was broken somewhere in the chain.

• The power to one or more of the linked receivers was turned off.

• Not enough available frequencies existed for IntelliScan to assign all receivers a frequency.

If IntelliScan cannot locate enough available frequencies, it will set as many as it can on the linked receivers.

Figure R

Group 1

Group 2

Group 3

System Operation

(Continued)

Turning on the Transmitter

Turn on the transmitter by

holding

the Power/Mute button (see Figure J/K on page 18) for a second or two, until the red power indicator and the LCD window have come on. (When using a handheld transmitter, unscrew and slide down the lower body cover, as shown in Figures N/P on page 22.)

Setting Transmitter Frequency

Touch

the Set button once. The small word “

” appears

above the frequency.

Touch

the Set button again and

the small

flashing

word “

EDIT

” appears to the right of

“

.” (The actual frequency flashes twice, then “

EDIT

”

continues to flash.)

2. Use the Up/Down arrow buttons to change the transmitter

frequency.

Touch

either arrow for single steps, or hold down either arrow for rapid cycling through the range. Frequencies “wrap around” when the top or bottom of the band is reached. Select the

exact

frequency displayed on the

receiver.

3. To activate this frequency selection,

hold

the Set button until

the word “

STORED

” appears in the transmitter’s window.

(If you do not wish to complete this selection, just

touch

the

Set button

once

: the word “

ESCAPE

” appears briefly in

the window, and the transmitter returns to the Menu mode.)

4. When finished entering a frequency,

touch

the Up arrow

button

once

to move to “

QUIT.

” Then

touch

the Set button

once

to exit the menu. The word “

” in the transmitter window disappears, indicating the return to normal operation.

5. If desired, assign a standard or custom Preset Name at this time as described on page 20 (To store Preset configurations), so this particular configuration can be recalled in the future. If a new name is not assigned, the transmitter will continue to operate on this frequency (and with these settings) until some other change in settings is made.

When the transmitter is switched on and in normal operation, the receiver’s two “

” signal-level bar meters will display from bottom to top, with more bars indicating increased signal reception. For optimum performance, at least four bars, and preferably five or more bars, on at least one of the RF indicators should be displayed at all times.

Setting Levels

Correct adjustment of transmitter audio input, receiver audio output, and mixer/amplifier input and output levels is important for optimum system performance.

Setting Transmitter Audio Input Level

Multiple-position audio input gain settings, selected through the function menu, serve to match the audio input level to the transmitter for best modulation and highest signal-to-noise ratio with minimum distortion.

Select the highest setting that does not result in overmodulation with the highest audio/instrument input levels (an AF indication on the receiver no higher than “+3”); watch the receiver’s “

” bar-graph “+6” indication and the Alert light to make certain that they are not triggered by the highest audio levels.

Also, the transmitter’s red LED power indicator, which is on during normal operation, will blink

off

if the peak audio input

reaches overload level.

Available Level Settings

AEW-T1000 UniPak

™

: Choices are +12 dB to –6 dB in –2 dB

steps. The default setting is +6 dB.

AEW-T4100/6100 Dynamic Handhelds:

Choices are +12 dB, +6

dB, 0 dB and –6 dB. The default setting is +6 dB.

AEW-T3300/5400 Condenser Handhelds:

Choices are +12 dB, +6 dB and 0 dB. The default setting is +6 dB. A mechanical switch on the condenser capsule activates a 6 dB pad. For best performance, adjust the input level using the function menu choices first, keeping the capsule’s pad switch at 0 dB. If more audio attenuation is needed, set the capsule’s switch to –6 dB.

RF Power Adjustment

RF power may be set to “

RF HI

” (35 mW nominal) or “

RF LOW

” (10 mW nominal) through the function menu. The default setting is “

RF LOW.

” While the Hi setting normally provides maximum operating range, the Low setting will help extend battery life. The Low setting may also be preferred when using multi-channel systems, or when operating very close to the receiver, to reduce the possibility of interference or overload.

EU Regulations require handheld transmitter operation to be set at "RF Low" 10 mW nominal. In addition, body pack devices when accessing the de-regulated band 863.125-864.875 MHz must also be set to "RF Low" 10 mW nominal.

RF Interference

Wireless microphone operations are unprotected from interference from other licensed operations in the band. If any interference is received by any Government or non-Government operation, the wireless microphone must cease operation.

If you need assistance with operation or frequency selection, please contact your dealer or the Audio-Technica professional division. Extensive information on using wireless microphones is also available on the Audio-Technica Web site at www.audio-technica.com.

Touch:

A momentary press of the Mode/Set button. It is used to enter Menu mode, to enter Edit mode, or to Escape without making any changes to current settings.

Hold:

Specifications

†

OVERALL SYSTEM

UHF Operating Frequency Refer to the frequency band list below* Number of Channels Approx. 200 total Frequency Stability ±0.005%, Phase Lock Loop frequency

control Modulation Mode FM Normal Deviation ±5 kHz Operating Range 90m typical Operating Temperature Range 5° C to 45° C Frequency Response 70 Hz to 15 kHz

AEW-R4100 & AEW-R5200 RECEIVERS

Receiving System Dual independent RF sections, automatic-

switching diversity Image Rejection 60 dB typical Signal-to-noise Ratio 115 dB at 40 kHz deviation

IEC-weighted, 1kHz modulation Total Harmonic Distortion ≤1% (10 kHz deviation at 1 kHz) Sensitivity 20 dBµV (S/N 60 dB at 5 kHz deviation,

IEC-weighted) Intermediate Frequency 65.75 MHz, 10.7 MHz Audio Output (ATTN switch at “0”)

Microphone 25 mV (at 1 kHz, ±5 kHz deviation,

10k ohm load)

Instrument 50 mV (at 1 kHz, ±5 kHz deviation,

10k ohm load)

AEW-R5200: Both outputs are transformer

isolated and balanced Audio Output Attenuator (ATTN) Three-position switch: 0 / -6 / -12 dB Output Connectors

Microphone XLRM-type Instrument

AEW-R4100

/4" (6.3 mm) TS unbalanced phone jack

AEW-R5200

/4" (6.3 mm) TRS balanced phone jack

Headphone Output

Connector

/4" (6.3 mm) TRS (“stereo”) phone jack

Power Output 10 mW + 10 mW at 1 kHz, ±5 kHz

deviation into 32 ohms; maximum output,

220 mW + 220 mW into 32 ohms.

AEW-R5200: Headphones switchable

between Channel 1 and Channel 2 External Mute (AEW-R5200)

/4" (6.3 mm) TS unbalanced phone jack,

each channel Antenna Terminal Voltage DC 10V-12V, 20 mA (BNC-type jack) Computer Interface (AEW-R5200)

Type Ethernet, 10 BaseT mode Connector RJ-45 Proprietary Software Supplied on CD-ROM

Power Supply

AEW-R4100 100–240V AC 50/60 Hz, 8W AEW-R5200 100–240V AC 50/60 Hz, 15W

Pass-through AC Power Outlet 100–240V AC 50/60 Hz, 5A maximum (AEW-R5200)

Dimensions

AEW-R4100 211.0 mm W x 44.0 mm H

x 235.0 mm D

AEW-R5200 482.0 mm W x 44.0 mm H

x 275.5 mm D

Net Weight (without accessories)

AEW-R4100 1.7 kg AEW-R5200 4.0 kg

Accessories Included

Both receivers IEC-type AC power cable; two flexible

UHF half-wave antennas; link cable

AEW-R4100 Rack-mount adapters AEW-R5200 IEC-type AC pass-through cable;

front-mount antenna cables and

connectors; CD-ROM with computer

control interface software; AEW-TB44

transmitter bag

ATW-T1000 UNIPAK™TRANSMITTER

RF Power Output High: 35 mW; Low: 10 mW, nominal

Spurious Emissions According to R & TTE Directive Dynamic Range

Microphone ≥110 dB, A-weighted

Instrument ≥100 dB, A-weighted Input Connections High impedance, low impedance, bias Batteries (not included) Two 1.5V AA alkaline Current Consumption High: 185 mA; Low: 165 mA, typical Battery Life Approximately 6 hours (High); 8 hours

(Low), depending on battery type and use pattern

Dimensions 66.0 mm W x 87.0 mm H x 24.0 mm D

;not including antenna Net Weight (without batteries) 125 g Accessory Included Helical antenna

HANDHELD TRANSMITTER

RF Power Output High: 35 mW; Low: 10 mW, nominal Spurious Emissions According to R & TTE Directive Dynamic Range ≥110 dB, A-weighted Microphone Element

AEW-T3300 Cardioid Condenser AEW-T4100 Cardioid Dynamic AEW-T5400 Cardioid Condenser

AEW-T6100 Hypercardioid Dynamic Batteries (not included) Two 1.5V AA alkaline Current Consumption High: 185 mA; Low: 165 mA, typical Battery Life Approximately 6 hours (High); 8 hours

(Low), depending on battery type and use pattern

Dimensions

AEW-T3300, AEW-T5400 239.0 mm long, 50.0 mm diameter

AEW-T4100, AEW-T6100 237.0 mm long, 48.0 mm diameter Net Weight (without batteries)

AEW-T3300 270 g

AEW-T4100 276 g

AEW-T5400 285 g

AEW-T6100 275 g Accessory Included AT8456a stand clamp; Screw adapter

†

In the interest of standards development, A.T.U.S. offers full details on its test methods to other industry professionals on request.

Specifications are subject to change without notice.

The systems can be supplied in five frequency bands within the UHF range.

Please note: Frequency usage is different for each country. Your Audio-Technica agent will have all the necessary details on the available legal frequencies for your area.

Band C: 541.500 - 566.375 MHz

Band D: 655.500 - 680.375 MHz

Band E: 795.500 - 820.000 MHz

Band F: 840.125 - 864.875 MHz

Optional System Accessories

WIRELESS ESSENTIALS™ MICROPHONES AND CABLES

All Wireless Essentials accessories are terminated for use with AEW-T1000 and other UniPak™transmitters.

AT829cW Miniature cardioid condenser lavalier microphone.

Includes clothing clip and windscreen.

MT830cW Subminiature omnidirectional condenser lavalier

microphone. Includes clothing clip and windscreen.

MT830cW-TH “Theater” model, same as MT830cW except beige color

mic and cable for concealment.

AT831cW Miniature cardioid condenser lavalier microphone.

Includes clothing clip and windscreen.

AT851cW Surface-mount wide-range hemi-cardioid condenser

microphone.

AT857AMLcW 19" gooseneck cardioid microphone.

Mounts to 5/8"-27 thread. Includes windscreen.

AT889cW Headworn noise-canceling condenser microphone.

Includes windscreen and cable clip.

AT899cW Subminiature omnidirectional condenser lavalier microphone.

Includes AT899AK accessory kit.

AT899cW-TH “Theater” model, same as AT899cW except beige color mic

and cable for concealment. Includes AT899AK-TH accessory kit.

ATM35cW Cardioid condenser instrument microphone.

Includes AT8418 clip-on instrument mount.

ATM73cW Headworn cardioid condenser microphone.

Includes windscreen.

ATM75cW Headworn cardioid condenser microphone.

Includes windscreen.

PRO 8HEcW Headworn hypercardioid dynamic microphone.

Includes windscreen and cable clip.

PRO 35xcW Cardioid condenser instrument microphone.

Includes AT8418 clip-on instrument mount. AT8319 Hi-Z instrument/guitar cable with 1/4" phone plug. AT8317

Connecting cable for UniPak transmitter with an XLRF-type

input connector, for Lo-Z microphones with XLRM-type

output terminations.

RECEIVER ACCESSORIES

AT8628b Joining-plate kit allows rack-mounting two AEW-R4100

receivers side-by-side in a single (1U) 19" rack space.

ATW-A20 Pair of UHF ground-plane antennas with

/8"-27 thread for mounting to microphone stands, etc. Takes RF cables with BNC connectors, not included; see RF Cables below.

AEW-DA860UK UHF (840-865 MHz) active unity-gain antenna distribution

system provides two “1-in, 4-out” RF channels; connects a pair of antennas to as many as four diversity receivers. A cascade output is provided as a directional coupler to drive additional distribution amps. Includes four DC interconnect cables to power up to four receivers, eight RF output cables and two rack-mount adapters. Mounts in a single (1U) 19" rack space.

AEW-DA600D As AEW-DA860UK above but UHF 656-680 MHz

AEW-DA800EU As AEW-DA860UK above but UHF 795-820 MHz

ATW-A49 Wide Band Paddle Antenna 440-900 MHz RF Cables Low-loss design, 50 ohm impedance, with BNC-to-BNC

connectors:

AC12 RG58-type cable (12') AC25 RG8-type cable (25') AC50 RG8-type cable (50') AC100 RG8-type cable (100')

TRANSMITTER ACCESSORIES

AEW-TB44 Transmitter bag, fits four AEW handheld and four AEW

body-pack transmitters. Included with 5000 Series systems.

AT8114 Foam windscreen for handheld transmitter. AT8141 Water-resistant pouch for UniPak transmitter. AT8390 Shielded audio cable with

/4" to 1/4" phone plugs. Available in a variety of lengths. (Also available with one straight and one 90° phone plug as the AT8316.)

AT8456a Stand clamp for handheld transmitter, 5/8"-27 threads.

TV Ch. Band C : 541.500 - 566.375 MHz

29 541.500 541.625 541.750 541.875 542.000 542.125 542.250 542.375

29 542.500 542.625 542.750 542.875 ~ ~ ~ ~

30 543.000 543.125 543.250 543.375 543.500 543.625 543.750 543.875

30 544.000 544.125 544.250 544.375 544.500 544.625 544.750 544.875

30 545.000 545.125 545.250 545.375 545.500 545.625 545.750 545.875

30 546.000 546.125 546.250 546.375 546.500 546.625 546.750 546.875

30 547.000 547.125 547.250 547.375 547.500 547.625 547.750 547.875

30 548.000 548.125 548.250 548.375 548.500 548.625 548.750 548.875

30 549.000 549.125 549.250 549.375 549.500 549.625 549.750 549.875

31 550.000 550.125 550.250 550.375 550.500 550.625 550.750 550.875

31 551.000 551.125 551.250 551.375 551.500 551.625 551.750 551.875

31 552.000 552.125 552.250 552.375 552.500 552.625 552.750 552.875

31 553.000 553.125 553.250 553.375 553.500 553.625 553.750 553.875

31 554.000 554.125 554.250 554.375 554.500 554.625 554.750 554.875

31 555.000 555.125 555.250 555.375 555.500 555.625 555.750 555.875

31 556.000 556.125 556.250 556.375 556.500 556.625 556.750 556.875

31 557.000 557.125 557.250 557.375 557.500 557.625 557.750 557.875

32 558.000 558.125 558.250 558.375 558.500 558.625 558.750 558.875

32 559.000 559.125 559.250 559.375 559.500 559.625 559.750 559.875

32 560.000 560.125 560.250 560.375 560.500 560.625 560.750 560.875

32 561.000 561.125 561.250 561.375 561.500 561.625 561.750 561.875

32 562.000 562.125 562.250 562.375 562.500 562.625 562.750 562.875

32 563.000 563.125 563.250 563.375 563.500 563.625 563.750 563.875

32 564.000 564.125 564.250 564.375 564.500 564.625 564.750 564.875

32 565.000 565.125 565.250 565.375 565.500 565.625 565.750 565.875

33 566.000 566.125 566.250 566.375 ~ ~ ~ ~

Artist Elite Series UHF Wireless Operating Frequencies

TV Ch. Band D: 655.500 - 680.375 MHz

44 --- --- --- --- 655.500 655.625 655.750 655.875

45 656.000 656.125 656.250 656.375 656.500 656.625 656.750 656.875

45 657.000 657.125 657.250 657.375 657.500 657.625 657.750 657.875

45 658.000 658.125 658.250 658.375 658.500 658.625 658.750 658.875

45 659.000 659.125 659.250 659.375 659.500 659.625 659.750 659.875

45 660.000 660.125 660.250 660.375 660.500 660.625 660.750 660.875

45 661.000 661.125 661.250 661.375 661.500 661.625 661.750 661.875

46 662.000 662.125 662.250 662.375 662.500 662.625 662.750 662.875

46 663.000 663.125 663.250 663.375 663.500 663.625 663.750 663.875

46 664.000 664.125 664.250 664.375 664.500 664.625 664.750 664.875

46 665.000 665.125 665.250 665.375 665.500 665.625 665.750 665.875

46 666.000 666.125 666.250 666.375 666.500 666.625 666.750 666.875

46 667.000 667.125 667.250 667.375 667.500 667.625 667.750 667.875

47 668.000 668.125 668.250 668.375 668.500 668.625 668.750 668.875

47 669.000 669.125 669.250 669.375 669.500 669.625 669.750 669.875

47 670.000 670.125 670.250 670.375 670.500 670.625 670.750 670.875

47 671.000 671.125 671.250 671.375 671.500 671.625 671.750 671.875

47 672.000 672.125 672.250 672.375 672.500 672.625 672.750 672.875

47 673.000 673.125 673.250 673.375 673.500 673.625 673.750 673.875

48 674.000 674.125 674.250 674.375 674.500 674.625 674.750 674.875

48 675.000 675.125 675.250 675.375 675.500 675.625 675.750 675.875

48 676.000 676.125 676.250 676.375 676.500 676.625 676.750 676.875

48 677.000 677.125 677.250 677.375 677.500 677.625 677.750 677.875

48 678.000 678.125 678.250 678.375 678.500 678.625 678.750 678.875

48 679.000 679.125 679.250 679.375 679.500 679.625 679.750 679.875

49 680.000 680.125 680.250 680.375 --- --- --- ---

Artist Elite Series UHF Wireless Operating Frequencies

TV Ch. Band E : 795.500 - 820.000 MHz

61 795.500 795.750 796.000 796.250 796.500 796.700 796.900 797.100

61 797.300 797.500 797.700 797.900 ~ ~ ~ ~

62 798.100 798.300 798.500 798.750 798.850 798.875 798.900 798.925

62 798.950 799.000 799.250 799.400 799.450 799.475 799.500 799.750

62 800.025 800.225 800.500 800.525 800.550 800.575 800.600 800.625

62 800.650 800.775 800.975 801.100 801.125 801.150 801.175 801.200

62 801.225 801.250 801.425 801.450 801.475 801.500 801.750 801.925

62 801.975 802.000 802.025 802.075 802.200 802.225 802.250 802.325

62 802.500 802.575 802.775 802.975 803.025 803.050 803.075 803.250

62 803.500 803.550 803.575 803.600 803.625 803.700 803.750 804.000

62 804.250 804.500 804.825 804.900 805.075 805.150 805.200 805.300

62 805.700 805.775 ~ ~ ~ ~ ~ ~

63 806.925 807.450 807.500 808.500 808.550 808.575 808.600 808.625

63 808.650 809.125 809.500 809.750 809.925 809.950 809.975 810.000

63 810.025 810.075 810.200 810.225 810.325 810.500 810.550 810.575

63 810.975 811.100 811.500 811.550 811.575 811.600 811.700 811.750

63 812.000 812.250 812.500 812.775 812.800 812.825 812.850 812.900

63 813.075 813.100 813.125 813.200 813.300 813.500 813.700 813.750

63 813.775 813.800 813.900 ~ ~ ~ ~ ~

64 814.100 814.300 814.500 814.750 814.850 ~ ~ ~

64 814.875 814.900 814.925 814.950 815.000 815.250 815.400 815.425

64 815.450 815.475 815.500 815.750 816.025 816.225 816.500 816.525

64 816.550 816.575 816.600 816.625 816.650 816.775 816.975 817.100

64 817.125 817.175 817.200 817.225 817.250 817.425 817.450 817.475

64 817.500 817.750 817.925 817.950 817.975 818.000 818.025 818.075

64 818.200 818.225 818.325 818.500 818.575 818.775 818.975 819.025

64 819.050 819.075 819.250 819.500 819.550 819.575 819.600 819.700

64 819.750 820.000 ~ ~ ~ ~ ~ ~

Artist Elite Series UHF Wireless Operating Frequencies

TV Ch. Band F: 840.125 - 864.875 MHz

67 840.125 840.250 840.375 840.500 840.625 840.750 840.875 841.000

67 841.125 841.250 841.375 841.500 841.625 841.750 841.875 842.000

67 842.125 842.250 842.375 842.500 842.625 842.750 842.875 843.000

67 843.125 843.250 843.375 843.500 843.625 843.750 843.875 844.000

67 844.125 844.250 844.375 844.500 844.625 844.750 844.875 845.000

67 845.125 845.250 845.375 845.500 845.625 845.750 845.875 ~

68 ~ ~ ~ ~ ~ ~ ~ 846.000

68 846.125 846.250 846.375 846.500 846.625 846.750 846.875 847.000

68 847.125 847.250 847.375 847.500 847.625 847.750 847.875 848.000

68 848.125 848.250 848.375 848.500 848.625 848.750 848.875 849.000

68 849.125 849.250 849.375 849.500 849.625 849.750 849.875 850.000

68 850.125 850.250 850.375 850.500 850.625 850.750 850.875 851.000

68 851.125 851.250 851.375 851.500 851.625 851.750 851.875 852.000

68 852.125 852.250 852.375 852.500 852.625 852.750 852.875 853.000

68 853.125 853.250 853.375 853.500 853.625 853.750 853.875 ~

69 854.375 854.500 854.625 854.750 854.875 854.900 855.000 855.125

69 855.250 855.275 855.375 855.500 855.625 855.750 855.875 855.900

69 856.000 856.125 856.175 856.250 856.375 856.500 856.575 856.625

69 856.750 856.875 857.000 857.125 857.250 857.375 857.500 857.625

69 857.750 857.875 857.950 858.000 858.125 858.200 858.250 858.375

69 858.500 858.625 858.650 858.750 858.875 859.000 859.125 859.250

69 859.375 859.500 859.625 859.750 859.875 860.000 860.125 860.250

69 860.375 860.400 860.500 860.625 860.750 860.875 860.900 861.000

69 861.125 861.200 861.250 861.375 861.500 861.550 861.625 861.750

de reg 863.125 863.250 863.375 863.500 863.625 863.750 863.875 864.000

de reg 864.125 864.250 864.375 864.500 864.625 864.750 864.875 ~

Artist Elite Series UHF Wireless Operating Frequencies

TV Ch. Frequency - MHz

30 542.750 30 543.000 30 545.500 30 546.000 30 547.125 30 547.375 30 549.500 30 549.750

31 550.375 31 550.625 31 557.250 31 557.500

~ 32 558.750 32 559.250 32 559.500 32 562.000 32 562.250 32 563.375 32 563.625

~ 33 566.000 33 566.250

Artist Elite Series Wireless Operating Frequencies

Suggested Frequencies for Multi-channel Systems Operation

Band C: 541.500 - 566.375 MHz (TV Ch. 30-33)

TV Ch. Frequency - MHz

29 541.500

30 542.750 30 543.250 30 544.375 30 544.750 30 545.750 30 547.500 30 547.750

31 554.250 31 556.125 31 557.250 31 557.500

~ 32 559.375 32 560.000 32 561.875 32 562.250 32 563.250 32 563.500 32 565.500

~ 33 566.000

TV Ch. Frequency - MHz

29 541.500

~ 30 542.125 30 543.250 30 543.500 30 544.000 30 546.250 30 547.875 30 548.250 30 549.750

~ 31 555.750 31 556.625

~ 32 558.250 32 559.375 32 560.125 32 561.500 32 562.625 32 564.000 32 564.250 32 565.625

~ 33 566.125

Ma x. = 21 M ax. = 20 Max . = 1 9

For multi-channel systems, use frequencies from Group 1 or Group 2 or Group 3. * Number of wireless frequencies in TV Channel.

Group 1

Group 2

* 1

Group 3

TV Ch. Frequency - MHz

44 655.500

45 658.000 45 658.375 45 659.250 45 659.500 45 661.500 45 661.750

46 662.375 46 662.750

47 669.625 47 671.750

48 674.750 48 675.125 48 675.750 48 676.125 48 678.000 48 678.250 48 679.000 48 679.500 49 (None)

Artist Elite Series Wireless Operating Frequencies

Suggested Frequencies for Multi-channel Systems Operation

Band D: 655.500 - 680.375 MHz (TV Ch. 44-49)

TV Ch. Frequency - MHz

44 655.875

45 656.250 45 657.500 45 658.500 45 659.750 45 660.000 45 660.500 45 661.750 46 664.375 46 665.500

47 671.625 47 672.000

48 674.000 48 674.500 48 675.500 48 675.750 48 676.750 48 678.250

49 680.250

TV Ch. Frequency - MHz

44 655.500 44 655.750 45 656.625 45 656.875 45 658.500 45 658.750 45 659.500

46 662.750 46 663.000 46 665.250 47 671.250 47 672.375 47 673.125 48 674.125 48 674.500 48 675.375 48 675.625 48 678.625 48 679.125

49 (None)

Ma x. = 19 M ax. = 19 Max . = 1 9

For multi-channel systems, use frequencies from Group 1 or Group 2 or Group 3. * Number of wireless frequencies in TV Channel.

Group 1

* 1

Group 2

* 1

Group 3

* 2

TV Ch. Frequency - MHz

61 795.750 61 796.250 61 796.500

62 798.500 62 798.750 62 799.750 62 800.225 62 802.225 62 802.500 62 803.500

63 810.025 63 812.000 63 812.500 63 813.700

64 814.500 64 815.750 64 816.225 64 818.225 64 818.500

`64 819.250

Artist Elite Series Wireless Operating Frequencies

Suggested Frequencies for Multi-channel Systems Operation

Band E: 795.500 - 820.000 MHz (FRANCE) (TV Ch. 61-64)

TV Ch. Frequency - MHz

61 795.750 61 796.250 61 796.500 61 797.900

~ 62 798.750 62 799.000 62 800.500 62 802.500 62 802.775 62 803.500 62 803.750

~ 63 810.225 63 811.500 63 812.000 63 812.250

~ 64 814.750 64 815.750 64 816.225 64 818.500 64 818.975

TV Ch. Frequency - MHz

61 795.000 61 795.750 61 795.500

~ 62 798.300 62 798.750 62 799.750 62 800.500 62 802.975 62 803.250 62 804.250 62 804.500

~ 63 811.750 63 812.000 63 812.500

~ 64 814.300 64 815.500 64 815.750 64 817.500 64 818.225 64 820.000

Ma x. = 20 M ax. = 20 Max . = 2 0

For multi-channel systems, use frequencies from Group 1 or Group 2 or Group 3. * Number of wireless frequencies in TV Channel.

Group 1

Group 2

Group 3

TV Ch. Frequency - MHz

62 798.925 62 800.525 62 801.475 62 803.025 62 803.550 62 804.825 62 805.150

~ 63 811.700 63 812.825 63 813.125

~ 64 816.625 64 817.175 64 817.425 64 817.975 64 819.050 64 819.600

Artist Elite Series Wireless Operating Frequencies

Suggested Frequencies for Multi-channel Systems Operation

Band E: 795.500 - 820.000 MHz (GERMANY) (TV Ch. 62-64)

TV Ch. Frequency - MHz

62 798.900 62 799.475 62 801.425 62 802.025 62 803.075 62 803.625 62 806.925 62 809.125

~ 63 811.575 63 813.300

~ 64 815.425 64 816.525 64 817.100 64 817.925 64 818.225 64 819.025

TV Ch. Frequency - MHz

62 798.950 62 800.625 62 801.200 62 801.450 62 803.700 62 804.825 62 805.075

~ 63 809.975 63 812.800 63 813.100

~ 64 816.650 64 817.175 64 817.450 64 817.975 64 819.050 64 819.575

Ma x. = 16 M ax. = 16 Max . = 1 6

For multi-channel systems, use frequencies from Group 1 or Group 2 or Group 3. * Number of wireless frequencies in TV Channel.

Group 1

Group 2

Group 3

TV Ch. Frequency - MHz

62 800.500 62 800.775 62 801.450 62 801.750 62 803.250 62 804.000 62 804.500 62 805.300

~ 63 811.750 63 812.850 63 813.100 63 813.700

~ 64 816.975 64 817.250 64 817.925 64 819.250 64 819.750 64 820.000

Artist Elite Series Wireless Operating Frequencies

Suggested Frequencies for Multi-channel Systems Operation

Band E: 795.500 - 820.000 MHz (NORDIC) (TV Ch. 62-64)

TV Ch. Frequency - MHz

62 800.225 62 800.525 62 801.450 62 801.975 62 804.000 62 804.250 62 805.200 62 805.700

~ 63 811.500 63 813.200 63 813.775 63 814.100

~ 64 815.250 64 815.500 64 818.075 64 818.325 64 819.250 64 819.750

TV Ch. Frequency - MHz

62 801.200 62 801.450 62 802.075 62 802.325 62 803.750 62 804.250 62 804.500 62 805.775 62 808.650

~ 63 812.500 63 813.300

~ 64 815.475 64 816.975 64 817.250 64 818.200 64 818.775 64 819.700 64 820.000

Ma x. = 18 M ax. = 18 Max . = 1 8

For multi-channel systems, use frequencies from Group 1 or Group 2 or Group 3. * Number of wireless frequencies in TV Channel.

Group 1

Group 2

Group 3

TV Ch. Frequency - MHz

67 840.250 67 840.625 67 841.375 67 842.750 67 843.375 67 844.625

68 847.000 68 847.250 68 848.375 68 850.125

69 854.625 69 854.900 69 857.125 69 858.250 69 858.625 69 860.400 69 861.125

~ de reg 863.125 de reg 863.375 de reg 864.375 de reg 864.875

Artist Elite Series Wireless Operating Frequencies

Suggested Frequencies for Multi-channel Systems Operation

Band F: 840.125 - 864.875 MHz (TV Ch. 67-69)

TV Ch. Frequency - MHz

67 840.625 67 841.250 67 842.875 67 843.125 67 843.875 67 844.250

68 846.250 68 846.750 68 847.500 68 849.000 68 849.875 68 850.125

~ 69 857.950 69 859.375 69 860.125 69 861.125 69 861.750

de reg 863.125 de reg 863.625 de reg 863.875 de reg 864.875

TV Ch. Frequency - MHz

67 840.625 67 840.875 67 841.625 67 842.875 67 843.875 67 844.500 67 845.375 67 845.750

~ 68 846.500 68 848.875 68 849.500

~ 69 855.500 69 855.750 69 857.625 69 858.650 69 859.000 69 860.625

de reg 863.125 de reg 863.375 de reg 863.875 de reg 864.125

Ma x. = 17 e x de reg Max . = 1 7 ex de r eg M ax. = 17 ex d e re g

For multi-channel systems, use frequencies from Group 1 or Group 2 or Group 3. * Number of wireless frequencies in TV Channel.

Group 1

Group 2

Group 3

For licensing information, please contact your dealer or the radio authority in your country.

DECLARATION OF CONFORMITY

TCF No. AEENLD-WL0811002

We, Audio-Technica Ltd of the below address, hereby declare, at our solo responsibility, that the following products conform to the Essential Requirements of the Radio and Telecommunications Terminal Equipment Directive 1999/5/EC in accordance with the tests conducted to the appropriate requirements of the relevant standards, as listed herewith.

Product: UHF Wireless Microphone System

Model/Type Number: AEW-R4100 Receiver AEW-R5200 Receiver AEW-T3300 Transmitter AEW-T4100 Transmitter AEW-T5400 Transmitter AEW-T6100 Transmitter AEW-T1000 Transmitter

Directive and Standard Used: Radio EN 300422-2 V1.1.1 (2000-08) EN 300422-1 V1.2.2 (2000-08) EMC EN 301489-9 V1.4.1 (2007-11) EN 301489-1 V1.6.1 (2005-09) LVD EN 60065:2002+A1: 2006

Year of Affixing CE marking: 2003

:erutangiS

Date: November 19 2008

ekooR nairdA :emaN

rotceriD gniganaM :noitisoP

For future reference, please record your system information here:

Receivers: AEW-R4100 S/N_____ _____ _____ _____ _____ _____ _____

Serial Number appears on the label on the bottom of the receiver.

AEW-R5200 S/N_____ _____ _____ _____ _____ _____ _____

Serial Number appears on the label on the bottom of the receiver.

Transmitters: AEW-T1000 S/N_____ _____ _____ _____ _____ _____ _____

Serial Number appears on the label on the back of the transmitter.

S/N_____ _____ _____ _____ _____ _____ _____

AEW-T3300 S/N_____ _____ _____ _____ _____ _____ _____

Serial Number appears in a recess in the battery compartment of the transmitter.

S/N_____ _____ _____ _____ _____ _____ _____

AEW-T4100 S/N_____ _____ _____ _____ _____ _____ _____

Serial Number appears in a recess in the battery compartment of the transmitter.

S/N_____ _____ _____ _____ _____ _____ _____

AEW-T5400 S/N_____ _____ _____ _____ _____ _____ _____

Serial Number appears in a recess in the battery compartment of the transmitter.

S/N_____ _____ _____ _____ _____ _____ _____

AEW-T6100 S/N_____ _____ _____ _____ _____ _____ _____

Serial Number appears in a recess in the battery compartment of the transmitter.

S/N_____ _____ _____ _____ _____ _____ _____

Disclaimer

Audio-Technica operates a policy of continuous development. Audio-Technica reserves the right to make changes and improvements to any of the products described in this document without prior notice. Under no circumstances shall Audio-Technica be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused. The contents of this document are provided ”as is”. Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Audio-Technica reserves the right to revise this document or withdraw it at any time without prior notice. The availability of particular products may vary by country. Please check with the distributor for your territory. In some countries there may be restrictions in using this equipment. Please check with your local radio frequency authorities.

Two-Years Limited Warranty

Audio-Technica microphones and accessories purchased in the UK and EU / Europe are guaranteed for two years from date of purchase by Audio-Technica Ltd. to be free of defects in materials and workmanship. In the event of such defect, product will be repaired promptly without charge or, at our option, replaced with a new product of equal or superior value, if the faulty product is delivered to Audio-Technica Ltd., prepaid, together with the proof of purchase. Prior approval from Audio-Technica Ltd. is required for return. This warranty excludes defects due to normal wear, abuse, shipping damage, or failure to use product in accordance with instructions. This warranty is void in the event of unauthorized repair or modification. For return approval and shipping information, contact the Service Department, Audio-Technica Ltd. Tel: +44 (0)113 277 1441.

Outside the U.K, please contact your local dealer for warranty details.

Visit our Web Site!

www.audio-technica.com

Audio -Technica Ltd

Technica House , Royal London Industrial Estate, Old Lane, Leeds LS11 8AG England Tel: +44 (0) 113 277 1441 - Fax: +44 (0) 113 270 4836 - Email: sales@audio-technica.co.uk

Audio Technica AEW-T1000, AEW-R4100, AEW-R5200, AEW-T3300, AEW-T4100 Installation And Operation Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
