AudioSource EQ Eight- II User Manual

Owner’s Manual

Congratulations on your purchase. We trust that you will enjoy the value and quality of your AudioSource EQ Eight/Series II for many years. To ensure the best performance from your unit, please take a few moments to read this manual. Also, be sure to retain this document for future reference.

BASIC GUIDELINES

A graphic equalizer is a powerful tool for very detailed control over the sound of your speakers. Before adjusting the sliders, it is very important to clearly define your objectives. Carefully listen to your system and ask yourself what you'd like to change about its sound. If you want more bass, for example, either raise the sliders for the lowest frequencies or lower the sliders on the midrange and higher frequencies. Do this for both the left and right channels. Conversely, if you'd like to hear more high frequencies, either raise the sliders for the highest frequencies or lower the midrange and bass frequencies.

USING THE CONTROLS

Power

Press this button to turn the power on the unit on or off. The red LED will light to show power is on.

EQ Rec.

Press this button to record with the equalization curve you have just set. This can be useful when making a cassette tape to play in your car. With this button in the off position, the copy will be recorded without equalization.

Monitor

Press this button to hear the sound from your cassette deck. Your deck should be connected into the tape in and tape out jacks on the rear panel of the EQ 8/Series II.

Audio/Video

This button selects between audio (such as CD) or video (such as DVD or VCR) input sources. To select audio, press this button. To select video, do not press this button. The red LED will be lit only when audio is selected. Of course, the EQ Eight/Series II equalizes only sound; at no time does the EQ Eight/Series II alter any picture, and no video-type connections are included.

EQ/Pass

Use this switch to instantly compare the equalized and unequalized sound. Press this button to hear the equalized sound. The red LED will light to show this selection. Leave this switch in the out position to hear the unequalized sound.

EQ Sliders

There are ten sliders per channel (ten for the left channel and ten for the right channel). The lowest frequency sliders are on the left, the highest frequency on the right. Usually, identical adjustments should be made for both channels. Each of these sliders has a range of 12 dB to boost or cut its particular frequencies.

These sliders are one octave apart from one another. This corresponds with the entire range of human hearing. The last page of this owner's manual contains a chart, showing which sliders to adjust to affect the sound of various instruments. For instance, the lowest note of a bass guitar is around 42 Hz. Adjusting the sliders at 30 Hz and 60 Hz can adjust the volume of the bass guitar, bass drum, and any other musical instruments that occupy this frequency range.

Spectrum Analyzer Display

This provides a visual display for you to monitor the relative signal levels in each of the EQ sliders. The spectrum analyzer display is divided into ten columns of LED's which correspond to the ten EQ sliders.

Note: If any part of this product is damaged or missing, do not contact your AudioSource dealer. Please call us directly at 800-435-7115.

Ten-Band Stereo Graphic Equalizer with Spectrum Analyzer Display

EQ Eight/Series II

1234567

HOOKING IT ALL UP

The EQ Eight/Series II should be connected through the tape monitor loop between your receiver (or integrated amplifier or preamplifier) and your tape deck (or CD player, VCR, DVD player, etc.). In other words, the sound goes from the tape deck into the EQ Eight/ Series II, where you adjust the sound, then into your receiver, which sends the adjusted sound to the speakers and to your ears.

When adjusting connections, turn off or unplug your component, so you won't hear any unexpected "pops" while connecting the cables.

1. Connect the Tape Out or Tape Record jacks (different components use different words) on the back of your receiver/integrated amplifier/preamplifier to the Audio In jacks of the EQ Eight/Series II.

2. Connect the Main Out jacks of the EQ Eight/Series II into the Tape In or Tape Monitor jacks of your receiver/integrated amplifier/ preamplifier to completes the loop.

3. To connect a tape deck, CD player, VCR, DVD player or other such component to the EQ Eight/Series II, follow the diagram below. For example, connect the Line In or Record jacks from a tape deck to the Tape Rec jacks on the EQ Eight/Series II. Next, connect the Line Out or Monitor jacks on your tape deck to the Tape Mon jacks on the EQ Eight/Series II. To listen to your cassette deck, p ress the Monitor switch on the EQ Eight/Series II.

4. You may use the Video In jacks on the EQ Eight/Series II to connect any high output source, such as a CD player, tape deck, or the audio outputs of a VCR or DVD player.

5. Always make sure to engage the Tape Monitor button on your receiver, no matter which input source you listen to. This allows the equalized signal to be heard on any source material.

This manual provides detailed instructions for setting up your equipment. We also offer friendly, toll-free assistance.

1.800.HELP.115

Frequency Response . . . . . . . . . .5 Hz to 100 kHz ±1 dB

Signal to Noise Ratio . . . . . . . . . . . . . . . . . . . . . .>85 dB

Input Impedance . . . . . . . . . . . . . . . . . . . . . .100k Ohms

Output Impedance . . . . . . . . . . . . . . . . . . . . .600 Ohms

Load Impedance . . . . . . . . . . . . . . . . . . . . . .10k Ohms+

Inputs . . . . . . . . . . . . . . . . . . . . . . . .Audio, Video, Tape

Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Main, Tape

Control Range . . . . . . . . . . . . . . . . . . . . . . . . . . .±12 dB

Dimensions . . . . . . . . . . . 16.5" x 2.25" x 7.125, 5.5 lbs.

Power Consumption . . . . . . . . . . . . . . . . . . . . . .6 Watts

EQ Eight/Series II Specifications

Design and specifications are subject to change without notice.
