100% Coverage Shield
Hard Cell
Foam
S-A
COMPOSITE VIDEO: 'S' VIDEO
26 AWG Solid Silver-Plated Long-Grain Copper
(SP-LGC) Conductors
Nitrogen Injected Foam PE Insulation
Foil / Mylar / Foil Shield
Tinned Copper Braided Shield
Black PVC Jacket
Clear PVC Jacket
1.25% Silver
Center Conductor
AQ Solder,
Gold-Plated
THE DEFINITION OF S: CinemaQuest “S” video cables include two identical maximum performance
coaxial cables, one for the “Y” (black and white) signal and one for the “C” (color information) signal. In
single-channel “composite” video, the Y and C signals are combined to run on a single cable. Using S-video
avoids the degradation caused by the process of combining and separating the Y and C signals. When
available, three-channel Component video (CQ YIQ cables) is better because the Pb and Pr color
information is not combined into a single C signal.
THE INGREDIENTS: The Ingredients: S-A uses a large 24 awg Silver-Plated center conductor insulated
with Hard Cell Foam (HCF). Silver-Plating greatly improves high frequency performance for a fraction of the
cost of solid silver. Nitrogen Injected HCF reduces distortion caused by the insulating material, and helps
maintain a stable 75Ω. The combination foil and Silver-Plated braid shield provides 100% protection
coverage and lower distortion. Gold-Plated connectors are professionally attached with superior AudioQuest solder.
