Silver-Plated Braid &
Copper Foil Shields
Hard Cell
Foam
S-3
COMPOSITE VIDEO: 'S' VIDEO
X-SECTION COMING SOON
6.1% Silver
Center Conductor
AQ Solder,
Silver-Plated
THE DEFINITION OF S: CinemaQuest “S” video cables include two identical maximum performance
coaxial cables, one for the “Y” (black and white) signal and one for the “C” (color information) signal. In
single-channel “composite” video, the Y and C signals are combined to run on a single cable. Using S-video
avoids the degradation caused by the process of combining and separating the Y and C signals. When
available, three-channel Component video (CQ YIQ cables) is better because the Pb and Pr color
information is not combined into a single C signal.
THE INGREDIENTS: S-3 uses a 6.1% Silver Center Conductor (6.1% SPC) insulated with Hard Cell Foam
(HCF). Normal 1.25% silver-plate greatly improves high frequency performance for a fraction of the cost of
solid silver. A 6.1% silver conductor is much closer to all silver, still for a fraction of the cost. Nitrogen
Injected HCF reduces distortion caused by the insulating material. The combination Copper foil and Silver-
Plated braid shield provides 100% protection coverage and lower distortion. Silver-Plated connectors are
professionally attached with superior AudioQuest solder.
