PROFESSIONAL SPEAKER
POLE 533
USER MANUAL
Installation
2
a. Introduction
Thanks for making the acquisition of the POLE 533 speaker. To obtain optimum performance of this product, we
recommend that you read carefully the following. Also keep this manual, it may be useful in the case of an
dismantling and/or reinstallation.
b. Connections
Respect the polarity for the cable connection (+ Red, - Black).
1
c. Wall Mount
To mount the speaker on a wall, first fasten the bracket (1) on the speaker with the screws provided. Drill the
wall to attach the bracket (2) following the coast below. The wall fixing screws must be adapted to the weight of
the speaker.
Once fixed, check the strength of the docking. Connect the cables as indicate above, then reassemble the
speaker with the bracket (1) on the bracket (2). Fix the orientation of the system by using the clamping screw (3).
155 mm
60 mm
58 mm
(1)
(2)
(1)
(2)
(3)
Caractéristiques
2
3
Disposal
3
Warranty
4
This symbol indicates that the disposal of this product is submitted to local regulations.
Please contact your local dealer.
This appliance is warranted parts and labor against any manufacturing defects for a period of two years from
the date of purchase by the first user.
1. The unit has been installed and implemented by observing the safety instructions in this operating manual.
2. The device was not diverted from its destination, either voluntary or accidental, and suffered no
deterioration or modification other than those described here or explicitly authorized by AUDIOPOLE.
3. All modifications or repairs have been carried out by an authorized service station.
4. The defective product must be returned with the dealer who made the sale or to an authorized service
station with proof of purchase.
5. The device was properly packaged to avoid damage in transport.
Type 1 way
Transducer x 3 Full range 76 mm (3")
Power handling 50 W RMS
Impedance 16 Ω
Frequency response 60 Hz - 20 kHz @ -10dB
Sensitivity 90 dB (1m/1W)
Coverage 150° x 120°
Material ABS
Dimensions (H x L x D) 120 mm x 315 mm x 175 mm
Weight 1.9 kg
Accessories Wall bracket
22, rue Édouard Buffard, Z.A.C. de la Charbonnière, Montévrain - 77771 Marne-la-Vallée Cedex 4 - France
Tél : + 33 (0)1 60 54 32 00 - Fax : + 33 (0) 1 60 54 31 90 - www.audiopole-pa.com - www.audiopole.fr
