ANTT-1
EntryLevelAnalogueProducts
DearCustomer,
ThankyouforpurchasingtheAudioNoteTT-1turntable.Afewminutes
readingtheseinstructionswillensuremaximumenjoymentandeaseof
use.
1.Carefullyunpackallpartsandremovepolythenebagsetc.
2.Placeturntableonalevelflatsurfacefreefromvibration.Awall
mountedshelforpreferablyanequipmentstandwouldbeidealforthis
purpose.
3.Removetransitscrewstoreleasethesprungsub-chassis.Removethe
armboardfasteningboltswiththe3mmallenkeyprovided.Thiswillallow
easyinstallationofthechosentonearmandcartridge.Installthetonearm
parallelwiththeedgeofthearmboard(althoughonlyanaesthetic
requirement)andinstrictaccordancewiththemanufacturer’s
instructions.Refitthearmboardandtonearmtotheturntableand
replacefasteningboltswithoutfullytighteningthem.Atthisstagethe
drivebeltshouldbefittedaroundthesmalldrivepulleyandacrylicdrive
hub,finallyplacingtheplatterontothetopofthehub.Noticethetwo
groovesinthedrivepulley.Thetopgrooveisfor33rpmandthebottom
for45rpmplayback.
4.Withthetonearmandplatterinplacethesprungsub-chassiscanbe
properlylevelled.Makingsurethattheturntableplynthislevel,adjustthe
threechassisadjustmentscrewswiththe4mmallenkeyprovided.The
bottomedgeoftheplattershouldbe5mmabovetheplynth.Turnthe
screwsclockwisetoraisethesuspensionandanti-clockwisetolowerit.
Atthisstageaffixthetonearmcableintothewhiteclipatthebackfothe
plynth,makingsurethesuspensioncanmovefreelyupanddown,then
tightenthearmboardbolts.Thefinaltonearmandcartridgealignment
adjustmentscannowbemade.
5.Sometonearmshaveaseparateearthleadwhichcanbeattachedto
theearthingpost.Othertonearmsdonotrequirethis.
6.Donotremovethedrivehubfromthebearingassemblyasaquantity
ofoilandballbearinghavebeenfittedfromthefactory.Asmallsyringeof
oilhasbeensuppliedincaseoflossorspillage,ofwhichonly2-3drops
arerequired.
7.Theattractivegreypaintfinishisextremelyhardwearingandstable.
Tokeepupitsvisualappealitshouldbedustedcarefullywithaclean,
softpaintbrushasrequired.Formorestubbornmarksorstains,a
degreasingfluidapprovedforpaintedsurfacesonaspongecanbe
used.
Thankyoufortakingafewminutestoreadthese
simpleinstructionsandwewishyouhours
ofenjoymentandhappylistening.
Tonearmcableclamp
Chassisadjustmentscrews
Earthpost
Specifications:
Motor:
PowerSource:
PowerConsumption:
Speeds:
DriveSystem:
Distance:
(Spindletoarm-mount
Dimensions:
AudioNoteistheonlyhighendhificompanytodesignand
manufacturecompleteanalogueanddigitalsystemsin-house.Our
productrangespansCartridges,Tonearms,DACs,CD-Transports,
Amplifiers,Loudspeakers,SpeakerstandsandCablesplusawide
rangeofcarefullyselectedhighqualitycomponents.
Thesamesonicassessmentcriteriaareappliedtoeachindividual
componentandthereforeallourcomponentswillremainconsistent
witheachotherregardlessofprice.Weregardthesystemasa
wherecomplimentarydesignparametersandtheirrealisationresult
inalevelofemotionalinvolvementandmusicalenjoyment
unobtainableinothersystems.
24Poleprecisionhightorque
motormountedonanantiÂvibrationassembly.
240v50Hzor110v60Hz
dependingondestination
country.
3.3VA
33&45rpm,Manualchange
Precisionmouldedround
sectionrubberbelt.
220mm
centre)
47x36x17cmincludinglidand
feet
AudioNote(UK)Ltd.,25MontefioreRoad,Hove,EastSussexBN31RD,UnitedKingdom
Tel:+44(0)1273220511Fax:+44(0)1273731498www.audionote.co.uk
