Audioline AL702 User Manual
English
702
Cordless Telephone with Phonebook
User Guide
1 Mute/Erase
2 Scroll UP/Redial
3 Disconnect and On/Off Button
4 Recall (R) Button
5 Intercom Function
6 Scroll DOWN /Caller ID
7 Talk Button
8 OK/ Menu Button
9 Phone Book
English
Index
Installation 4
Unpacking........................... 4
Connection ......................... 4
Belt Clips............................. 6
Battery ................................ 6
Turning the Handset
On/Off................................. 6
Battery Charge Indicator .... 7
Range ................................. 7
The Display......................... 8
Base Unit Indicator ............. 8
Operation 9
Making a Call ...................... 9
Receiving a Call.................. 9
Redial Button ...................... 9
Volume Control ................... 9
Mute Button ........................ 9
Paging................................. 10
Key Lock ............................. 10
Timer................................... 10
Recall.................................. 10
Caller Identication 11
Menu 13
Settings 16
Warning Signals ................. 16
Ringer Signal Volume ......... 16
Volume Control ................... 16
Ringer Melody .................... 17
User Name.......................... 17
Language............................ 17
Settings 18
PIN Code ............................ 18
Tone/Pulse Dialling............. 18
PBX Function...................... 18
Pause Time......................... 19
Reset Defaults .................... 19
Expanded System 20
General Information............ 20
Multiple Handsets............... 20
Show RFPI Number............ 21
Register a New Handset..... 21
De-register a Handset ........ 22
Select Base Unit................. 22
Intercom Function ............... 22
Transferring Calls Between
Handsets ............................ 23
Conference ......................... 23
Phone Book 14
Other 24
Troubleshooting .................. 24
Guarantee........................... 25
Declaration of Conformity... 31
www.doro.com 3
English
Installation
Unpacking
The package should include the following items:
- Handset - Mains adapter
- Base unit - Line cord
- 2 NiMH rechargeable batteries - Belt clip
Models with an extra handset (+1) include an additional handset, batteries,
charger and adapter.
Connection
1. Locate and clip the supplied desk top bracket to the underside of the base
unit.
2. Connect the mains adapter to the socket on the base unit and to an
electrical wall socket.
3. Remove the battery cover from the back of the handset. Insert the batteries
into the handset ensuring correct battery polarity is observed. Replace the
battery cover.
4. Place the handset in the base unit, with the keypad facing outwards. Once
the handset is correctly placed on the base unit a beep will be heard, and the
battery charge indicator in the display will begin to ash.
5. Charge the handset batteries without interruption for 24 hours initially
(thereafter fully discharged batteries will take up to 10 hours to recharge).
6. ONCE CHARGED, connect the telephone line cord to the socket marked
t
on the underside of the base unit and then to a telephone network wall
socket.
7. A click will be heard when the modular plug is correctly connected.
4 www.doro.com
English
Installation
Only for models with an extra handset (+1):
8. Connect the mains adapter to the socket on the charger unit and to
an electrical wall socket.
9. Remove the battery cover from the back of the handset. Insert the batteries
into the handset ensuring correct battery polarity is observed. Replace the
battery cover.
10. Place the handset in the charger unit, with the keypad facing outwards. Once
the handset is correctly placed a beep will be heard, and the battery charge
indicator in the display will begin to ash.
11. Charge the handset batteries without interruption for 24 hours initially
(thereafter fully discharged batteries will take up to 10 hours to recharge).
12. Put the extra handset in the charger, with the keypad facing outwards.
ONCE CHARGED if the additional handset fails to operate please refer to
page 21 regarding handset registration.
Please note!
Under power failure conditions, this telephone will not operate. Please ensure that a separate
telephone, not dependent on local power, is available for emergency use.
The earpiece of the handset may attract small ferromagnetic objects such as staples and pins,
care should be taken when placing the handset near these items.
Do not place the base unit close to other electrical equipment, such as television sets, monitors,
telecom equipment, fans etc. This is to reduce the risk of interference problems. Do not place
the base unit in areas of high humidity or where it will be exposed to direct sunlight or other
major heat sources.
www.doro.com 5
English
Installation
Belt Clips
A belt clip is included, which can be tted on the back of the handset. The belt
clip enables the handset to be attached to a belt, waistband or similar. To attach
the clip, press it into place over the back of the handset. On either side of the
handset, there are indents for the clips to clasp onto.
Battery
The telephone is supplied with environmentally friendly nickel metal hydride
(NiMH) batteries, 2 x AAA 1.2v. As with all batteries performance may degrade
over time, should you notice that the standby time has reduced considerably or
there are signs of leakage, both batteries should be replaced.
Fully charged batteries will last for approx. 100 hours in standby or approx.
7 hours call time. The stated times apply under normal room temperatures and
when using fully charged batteries.
Completely discharged batteries will take about 10 hours to fully recharge
(24 hours from new).
Please note that the battery charge indicator in the display ashes while
charging. The ashing will stop when the battery is fully charged.
The base unit has an automatic charging mechanism that prevents the batteries
from being overcharged or damaged due to prolonged charging.
Please note!
The charging system used in this model may cause the handset and the batteries to become warm.
This is normal, and will not harm the equipment.
When the telephone is installed for the rst time, the batteries must be charged for 24 hours
before using the telephone. Use DORO original batteries only. The guarantee does not cover any
damages caused by incorrect batteries. The handset is charged with the keypad facing outwards.
Please dispose of any batteries in a responsible and environmentally friendly manner.
Turning the Handset On/Off
Press and hold the l button for a few seconds to turn the handset off or on.
When the handset is turned off, no calls can be made or received. It is not
necessary to turn the handset off over night, however we do recommend turning
the handset off if it is not to be used for a prolonged period of time, e.g. during
a holiday. If the battery runs low, the handset will automatically turn off due
to inadequate voltage.
6 www.doro.com
English
Installation
Battery Charge Indicator
The indicator in the display shows when it is time to recharge the battery.
The symbol has three segments, which disappear as the battery charge decreases.
When the battery is almost out, the symbol will appear in the display and
a warning tone will be heard. If the handset is not recharged at this time, the
phone will cease to function until it is recharged.
Range
The range of the telephone varies depending on various factors in the
surrounding environment. The radio waves transmitting the call may be
hindered by obstructions, reducing the range.
Specied ranges require an unobstructed transmission between the handset and
the base unit. In such ideal conditions, the telephone range can be up to 300
metres. In a densely populated area, house, apartment, etc. the range of the
telephone will be reduced. Try to get the best range by relocating the base unit.
The ideal location for the base unit is a high and unobstructed place.
Out of range warning
If during a call the handset is carried too far from the base unit the sound
quality will deteriorate, a warning tone (if selected) will be heard from the
handset. Unless the handset is moved closer to the base unit within a few
seconds, the call will be lost.
www.doro.com 7
English
Installation
The Display
Indicator Function
Indicates that a handset is connected (during a call).
EXT External call.
INT Intercom Function.
p
Settings.
Battery charge indicator.
Shown within range of the base unit. Flashes when out of range.
b
Phone Book.
Key Lock.
ID New number/s in Caller ID log.
Base Unit Indicator
Q/5
On when a call is connected, ashes on incoming calls, or to
indicate that new numbers have been received and stored in
memory.
8 www.doro.com
English
Operation
Making a Call
1. Enter the required telephone number. Mistakes can be erased using C.
2. Press Q, the telephone number will now be dialled.
3. Press l to terminate the call.
Receiving a Call
1. Wait for the handset to ring.
2. Press Q to answer the call.
3. Press l to terminate the call.
Please note!
If the telephone cannot connect to a line, a warning tone will be heard. The problem may be
due to the batteries running low, the handset being too far from the base unit or all of the
transmission channels being engaged.
Redial Button
The ten most recently dialled numbers can easily be redialled using r/{.
1. Press and release the { button. Scroll to the required telephone number
using {/}.
2. Press Q to dial the telephone number.
Volume Control
The earpiece volume may be adjusted during a call using {/}. There are ve
settings, 1 = low, 5 = high.
Mute Button
The handset microphone can be muted during a call by pressing the mute button
z
. Press the mute button again to re-activate the microphone.
The display shows MUTE for as long as the function is active.
www.doro.com 9
English
Operation
Paging
Pressing j on the base unit will activate the paging signal of the handset. This
function is used to help locate the handset or to page the person carrying the
handset. The signal will stop automatically after a while or if the L button
on the handset is pressed. The page can also be cancelled by pressing j on
the base again.
Key Lock
This function locks the keypad on the handset to prevent unintentional usage.
1. Press and release the 0 and * buttons. The display will show .
2. To remove the key lock again press the 0 and * buttons.
Calls can still be received, even if the key lock is active. When the call is nished,
the handset returns to locked mode.
Timer
Within approximately 5 seconds after the connection of a call, a timer will be
shown on the display. The timer helps you keep track of how long the call lasts.
Recall
Access to additional network services can be gained by using the R button.
Contact your network operator for more information.
Press the R button followed by the extension number to transfer a call when
connected to a PBX (TBR only).
10 www.doro.com
