AUDIAL
WC0875 27022018
Bluetooth Speaker
Instruction Manual
Model Ref: WC0875
INTRODUCTION
Congratulations on choosing to buy an Audial product. All
products brought to you by Audial are manufactured to the
highest standards of performance and safety.
Before use, please read this manual carefully. It gives important
instructions about safety, use and maintenance of your bluetooth
speaker.
We hope you enjoy using your purchase for many years to come.
Remove all packaging material. You may wish to keep the
packaging for future use or storage of your bluetooth speaker.
Alternatively, dispose of accordingly.
CONTENTS
Introduction ........................................................ 1
Important Safety Information
Product Overview
Functions
........................................................... 5
Charging the speaker
Product Specications
Troubleshooting
Disposal Information
.............................................. 4
........................................ 6
....................................... 7
................................................. 8
.......................................... 9
............................. 2
01
IMPORTANT SAFETY INFORMATION
This handbook contains basic safety precautions and
instructions for use. Please read the manual carefully before
using the bluetooth speaker to reduce the risk of product
damage and personal injury.
• DO NOT expose the bluetooth speaker to high
temperatures, direct sunlight, moisture, rain or a highly
dusty environment.
• DO NOT use the bluetooth speaker in prohibited areas
(ie; airplanes).
• DO NOT use the bluetooth speaker whilst driving or
walking.
• DO NOT dispose of the bluetooth speaker in a re to
avoid explosion.
• DO NOT disconnect the bluetooth speaker from the USB
power supply by pulling on the cord.
• DO NOT attempt to disassemble the product, or use
alcohol, thinners or benzene to clean the Bluetooth
speaker as this will cause damage to the unit.
• DO NOT disassemble, repair or modify the Bluetooth
speaker by yourself. Refer servicing to qualied
personnel only.
• Never subject any heavy impact on the bluetooth
speaker such as dropping or shaking.
• Keep away from magnetic sources.
• It is not recommended to use the speaker at a high
volume for an extended period of time as this may cause
damage to your hearing.
• Once the casing has been tampered with the company
shall not be liable for any resulting damages or faults.
• Clean with a dry cloth only. Make sure the bluetooth
speaker is turned o before and do not use liquid or
02
abrasive cleansers.
• Only use this bluetooth speaker for its intended domestic
use. JDW will not accept any liability if the bluetooth
speaker is subject to improper use or failure to comply
with these instructions.
• Keep the bluetooth speaker and its power supply
cord away from heat or sharp edges that could cause
damage.
• Use of an extension cord with the bluetooth speaker is
not recommended.
• This bluetooth speaker should not be operated by means
of an external timer or separate remote control system.
• Keep the bluetooth speaker away from ammable
materials.
• Avoid dropping the Bluetooth Speaker.
• The company reserves the right to improve the product
specication and design. The information is subject to
changes without prior notice.
• This Bluetooth speaker has no waterproof function.
• All pictures in this manual are just for your reference
only.
• Kindly read this user manual before using the bluetooth
speaker carefully, and keep it for future reference.
03
PRODUCT OVERVIEW
1
Volume Increase
2
Next Track
3
Previous Track
4
Volume Decrease
5
Call & Play/Pause
6
3.5mm Aux Input
7
On/O Switch
8
Micro USB Charging Port
9
TF/SD Card Slot
1
3
4
2
5
6
7 8 9
In the box:
1. Bluetooth Speaker x 1
2. Micro USB Charging Cable x 1
3. 3.5mm AUX cable x 1
4. User Manual x 1
3.5mm
AUX cable
Micro USB
Charging Cable
04
FUNCTIONS
TF/SD CARD
• Insert the micro SD/TF card into the micro SD/TF card slot
(9). When switched on with the SD/TF card in place, the
speaker will announce “now you are in TF mode”. Audio will
automatically play. WAV and MP3 media are supported.
AUX Mode
• Insert into the aux input slot (6). When switched on with the
micro SD/TF card in place, the speaker will announce “now
you are in Aux mode”. Use your bluetooth speaker to play
music through the speaker using the provided AUX cable.
Battery
• When the battery is running low, the speaker will announce
“Battery low, please recharge”. When charging, a red light will
illuminate above the charging port when charging.
USB mode
• When connected to a PC with the micro USB cable, the
speaker will announce “USB Bluetooth speaker”. Here you
can charge the speaker or access your les stored on an
inserted micro SD/TF Card.
Bluetooth mode
• You can wirelessly connect and control the media you are
playing through the speaker.
• When turning on, the Bluetooth speaker will automatically
enter Bluetooth mode. The speaker will announce “the
Bluetooth bluetooth speaker is ready to pair”. At this point the
green LED light at the back of the unit will ash.
• Connect a bluetooth bluetooth speaker to the bluetooth
speaker by pairing with the code WC0875.
• Once connected successfully, the speaker will announce “the
Bluetooth bluetooth speaker is connected successfully”. At
this point the green LED light at the back of the unit will be a
stable light.
• When audio is being played through the speaker, the green
05
indicator light will ash blue and green.
Phone
• When a mobile phone is connected to the speaker, it can
play audio through the speaker of the phone call. To answer
the call, press the “call & play/pause button (5)” on top of the
Bluetooth speaker to answer the call.
• During the ring process, the speaker will read out the number
that is currently calling.
• To hang up, simply press the “call & play/pause button (5)”
located on the top of the Bluetooth speaker.
CHARGING THE SPEAKER
To charge the Bluetooth speaker, connect the supplied micro USB
cable to the micro USB charging port (8) and the other end to
your computer or USB charging bluetooth speaker.
Make sure you charge your Bluetooth speaker for at least 4 hours
before using it for the rst time.
06
PRODUCT SPECIFICATIONS
Bluetooth® Version V 4.2.
Working Distance Up to 10 meters in open space.
Speaker Output 5W * 2
Frequency
Response
Charging Input DC 5 V
Playback Time Approx. 3-4 hours
Charging Time Approx. 4-5 hours
Rechargeable
Battery
Unit Size 196 x 79 x 79mm
Note: Battery life & charging time may vary, based on
usage & types of bluetooth speakers used. The product
design and specications may be changed subject of
without prior
notice.
100Hz - 20kHz
2000mAh
07
TROUBLESHOOTING
Problem Solution
Make sure your speaker has not
Speaker will not
turn on.
Pairing is
unsuccessful after
multiple attempts
Playback Time
run out of battery. Connect it to a
power source via the included USB
cable.
Check if the green ashing
bluetooth indicator light is on. If the
indicator light is o, please switch
the power button to turn on the unit
If the Bluetooth light still doesn’t
come on after switching the power
button to ON, please charge the
unit.
Unplug any micro SD/TF memory
cards/ Auxiliary cables.
Ensure that the speaker is not
already connected to another
bluetooth speaker.
Interference or
static during
playback
Restart your pairing bluetooth
speaker.
Avoid using the speaker between
concrete or other building
structures that may interfere with
the signal.
Please check the battery level of
the unit (via the paired bluetooth
speaker) and charge if necessary.
08
DISPOSAL INFORMATION
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF
THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE
2002/96/EC.
At the end of its working life, the product must not be disposed
of as urban waste. It must be taken to a special local authority
dierentiated waste collection centre or to a dealer providing this
service.
Disposing of a house hold product seperately avoids possible
negative consequences for the environment and health deriving
from inappropriate disposal and enables the constituent materials
to be recovered to obtain signicant savings in energy and
resources. As a reminder of the need to dispose of products
seperately, the product is marked with a crossed-out wheeled
dustbin.
2011/65/EU
09
AUDIAL
Wellington Grove,
Stockport, SK2 6RH
