Audeo PFE O22, PFE 012 Perfect Bass User Manual

Phonak AG
Laubisrütistrasse 28
CH-8712 Stäfa
Switzerland
www.audeoworld.com

User Guide

Audéo PFE 022 + mic Perfect Bass

029-0231-02/V1.00/2010-07/cu © Phonak AG All rights reserved

Thank you for choosing the Audéo Perfect Fit Earphones (PFE)
from Phonak, the world’s leading designer and manufacturer of
hearing systems.

Audéo PFE intensifies the listening experience thanks to the
fusion of design, perfect fit, and rich sound. They are the perfect
earphones for those who want to enjoy music without limits.

Reduced volume or no sound? The audio filter might be blocked.
Please replace the audio filters! (For details, consult the user
guide.)

Cable

Earphone
“leg"

Silicone ear tips

Sound tube

Descriptions

Microphone

Multifunction button

Please read this manual carefully before using
your earphones.

1. Package content

a. Earphone with microphone and green audio filters for Perfect

Bass (already mounted)

b. Silicone ear tips – 1 pair S, 1 pair M, 1 pair L

b.

b. c.

a.

a.

Original accessories can be purchased from authorized Phonak
dealers or on the www.audeoworld.com website (available in
selected countries).

2. Additional accessories available for your Audéo PFE
Perfect Bass

a. Audio filters:

I

Set with 8 audio filters grey for emphasis of mid-frequencies

I

Set with 8 audio filters black for emphasis of trebble and bass

I

Set with 8 audio filters green for Perfect Bass

b. ComplyTMfoam ear tips:

I

Set with 3 pairs small + 1 cleaning tool

I

Set with 3 pairs medium + 1 cleaning tool

I

Set with 3 pairs big + 1 cleaning tool

c. Ear guides

I

Set with 3 pairs silicone ear guides

3. Important information

PREVENTION OF HEARING LOSS

CAUTION: Permanent hearing loss may occur if earphones are
used at high volumes for prolonged periods of time.
NOTE: For France, these earphones have been tested to comply
with the Sound Pressure Level requirement stipulated in
French article L. 5232-1.

In order to protect your hearing, we recommend
the following:

I

Always listen to the lowest possible volume for limited periods
of time.

I

You should immediately stop listening if you experience ringing
in your ears or other pain or discomfort.

I

Ideally, do not exceed 50% of the maximum volume of an MP3
player and do not listen for more than 1 hour a day.

I

In order to avoid dangerous sound bursts, always turn the
volume of the sound source down before connecting your
Audéo PFE to it.

i

Warnings

I

Do not use this product in other ways than described in
this manual.

I

Since the earphones block out ambient noise, never use them
while operating machinery or driving any kind of vehicle,
walking, biking, jogging or during any other activity where
failure to hear outside sounds or alerts can be dangerous.

I

Keep this product and its accessories out of the reach of
children. Handling or use by children may pose a threat of
death or serious injury. This product contains small parts and
a cord that may pose a risk of choking or strangulation.

I

If an ear tip or an audio filter becomes lodged in your ear, seek
medical assistance to remove the ear tip or audio filter. If
removal is performed without proper medical assistance, the ear
may be damaged.

I

Before inserting the earphones, make sure that the ear tips are
attached firmly to the sound tube.

I

If the earphones cause discomfort or irritation, stop using
them. Consult a physician or audiologist if needed.

I

Handle the earphones with care.

I

Do not expose the earphones to extreme temperatures or to
strong magnetic fields. Do not immerse them in liquid. Avoid
sharp blows to the earphones.

I

Keep these instructions and recommendations so you can
review them in the future.

i

a. Wearing the earphones

Audéo PFE deliver amazing sound if correctly inserted in the ears
and if an absolute seal is achieved. To experience their best
performance, proceed as follows:

4. How to use

Only use Audéo PFE with original parts. Never use accessories
from other manufacturers. They may not be compatible with
Audéo PFE and can modify the frequency response of your
earphones, damage them or even cause injury!

1. Turn the volume of the sound
source to a minimum before
connecting the earphones.

2. Identify the left and right
earphones.

L

R

L

3. Attach the silicone ear guides to the
cables and pull through to the
earphones. The ear guides route the
wires comfortably around the ears
and ensure a perfect fit and reduced
cable noise. The snug fit is especially
great during exercise because the
earphones stay firmly in place. Use
of the ear guides is optional.

4. If you are using ComplyTMfoam tips,
compress them with your fingers.

5. Hold each earphone by the "leg",
with the cable pointing up, and
the ear tips towards your head.

6. Place the cable behind the ear and
insert the ear tips into your ear
canal with a gentle push. Do not
force the earphones into the ears!
If the ear tips are too big, try a
smaller size.

7. The cables hang behind the ears
and then "down the back" or "on
the chest". With the ear guides
attached, the cable is routed
perfectly around your ear.

8. The ear tips should seal the
ear canal and fit without any
discomfort. Rotate the earphones
so that the "leg" points diagnally
towards the top of the ear.

If you feel that the ear tips are too loose (insufficient seal) or too
tight (discomfort), try using another size.
To remove the earphones from the ears, hold them by the "leg"
and pull them out gently with a small rotation in order to break
the seal.

Do not pull on the cable to remove the earphones from your ear.

b. Ear tips

The silicone ear tips are washable and better for use during
exercise. The ComplyTMfoam ear tips are better at filtering out
ambient noise, making them the best choice for travel or use in
noisy surroundings.
To change the ear tips (foam or silicone), grab the ear tip in the
middle and pull it slowly until it comes loose. Do not use
your fingernails or any other sharp object to remove the ear tips,
as otherwise they could be damaged.

L

c. Audio filters

The audio filters have an essential acoustic function for the frequency
response of the Audéo PFE. The purpose of this filter is to deliver sound
that matches what one perceives when listening with non-occluded
ears. Different kinds of audio filters are available for Audéo PFE: The grey
filter is for enhanced perception of the mid-frequencies, the black audio
filter for enhanced bass and treble and the green filters for Perfect Bass.
The green audio filter for Perfect Bass is mounted on the Audéo PFE by
default. Because each individual's perception of sound is unique, Audéo
PFE allows you to choose the filter that suits your personal preferences.
Another function of the audio filter is to prevent dirt from entering the
sound tube.

I

Make sure that the audio filters are in place before using
the Audéo PFE. Audéo PFE only function correctly if the audio filters
are inserted in the output tube.

I

Replace the audio filters when they become dirty or clogged and the
sound of the Audéo PFE is affected.

I

Always use audio filters having the same color for both the right
and left earphone.

To replace the audio filters
proceed as follows:

1. To change the ear tips (foam
or silicone), grab the ear tip in
the middle and pull it slowly
until it comes loose.

2. Gently push and twist the
"threaded end" of the
changing tool into the used
audio filter.

L

3. Do not overtwist the tool;
stop when you feel a slight
resistance (about 1 rotation)
or you could damage the
audiofilter. Pull the used
audio filter out.

4. So you can reuse the audio
filter, insert it in an empty slot
in the audio filter box; turn
and remove the changing
tool. Dispose of any soiled or
damaged audio filters.

5. Proceed with placing a new audio
filter in the earphones. Make sure
that the audio filter is sitting in
the dispenser with the open side
facing upwards.

6. Press the "flat end" of the
changing tool into the filter
ring and pull out vertically.

7. Push the new audio filter into
the sound tube of your
earphones. Tip the changing
tool sideways to release it.

d. Microphone

The Audéo PFE earphone microphone features a multifunction
button. This allows you to listen to music on your iPhoneTMor other
mobile phone, and if a call comes in, you can answer it immediately
without having to take off the Audéo PFE. The microphone is
compatible with the iPhoneTMand other music-enabled phones that
are equipped with a 3.5 mm/4-contact stereo jack socket.

Microphone

Multifunction button

The multifunction button offers you the following options with
the iPhoneTM:

I

To pause the music or the video, press the button once.

I

To resume the music or video playback, press the button again.

I

To skip a track, press the button twice quickly.

I

To jump to the previous track, press the button three
times quickly.

I

To accept an incoming call while you are listening to music,
press the button once: playback stops automatically.

I

To end a call, press the button once: your music resumes
automatically.

I

To decline an incoming call, keep the button depressed for
about two seconds: two low beeps confirm that the call has
been declined.

iPhoneTMis a registered trademark of Apple Inc.

e. Maintenance

To extend the lifetime of your earphones, keep them clean and
follow the recommendations below.

I

The cleaning tool is for the tube of the ear tips (silicone or
foam) and serves to remove earwax build-up.

I

Never use the cleaning tool for the earphone sound tube!

R

I

The silicone ear tips should be cleaned regularly with water
and mild soap, or with an antiseptic wipe. Always make sure
that the ear tips are dry before reusing.

I

ComplyTMfoam tips cannot be cleaned. They should be replaced
when they become soiled.

I

After extended us, the ComplyTMfoam tips may no longer seal
properly because they lose their elasticity. Please replace them
with new ComplyTMfoam tips.

I

The earphones can be cleaned with an antiseptic wipe.

5. Technical characteristics

Driver: high precision balanced armature
Sensitivity: 107 dB SPL / mW, 1 kHz
Impedance: 32 Ohm, 1 kHz
Frequency range: 5 Hz – 17 kHz
Cord length: 3.6 ft/110 cm
Weight: 0.5 oz/14 g
Connector: ⅛ inch/ 3.5 mm

gold-plated stereo jack

6. Certification

© 2010 Phonak. All rights reserved. Audéo and the Audéo Logo
are trademarks of Phonak. Swiss design.
Audéo earphones conform to EMC Directive 2004/108/EC and
have been tested according to European Standards EN
55022:2006 and EN 55024:1998.
Audéo earphones meet applicable criteria listed in European
Standard EN 50332-2:2003.
ComplyTMis a registered trademark of Hearing Components.
iPhoneTMis a registered trademark of Apple Inc.
Manufactured under Hearing Components U.S. patent number
4,880,076 and 5,002,151 and international equivalents.
Audéo PFE should not be discarded in a trash receptacle. To
discard Audéo PFE, take them to an approved collection site.

7. Audéo PFE: limited warranty

Phonak AG warrants that this product will be free from defects
in materials or workmanship for a period of two (2) years from
the date of original retail purchase. This warranty is available only
to the original retail purchaser, and only if the product was
purchased through the official Webshop or an authorized retailer.
Upon a breach of this warranty, Phonak AG will, at its sole
discretion, replace or repair the product. If Phonak AG replaces
the product, you are entitled to a replacement of equal or at least
equivalent quality and technical functionality. When we replace
the product, the replaced product becomes the property of
Phonak and the new product becomes your property.

Repair or replacement shall be your sole remedy upon any
breach of this warranty. In particular, Phonak AG shall not be
responsible or liable to you for any money damages, including
for any special, incidental or consequential damages, even if

Phonak AG was aware of the possibility of such categories
of damages.
If your product evidences a defect within the warranty
period, you may make a warranty claim, by presenting the
defective product and valid proof of purchase from one
of our authorized retailers or the Webshop.
If you ordered the product through the Webshop, you
can return it to the address on your invoice. You must return
a copy of the proof of purchase with the product.
This warranty applies only to the external shell of the
product and all internal components. The ear tips,
cleaning tool, audio filters (incl. dispenser and replacement
tool), ear guides, carrying case and adapters for mobile
telephones are not covered by this warranty.

This warranty is available to you only if the product was
handled properly, subject to normal use, and used solely for the
purpose intended. This warranty does not cover normal wear
and tear, damage caused by acts of God or misuse. In addition,
this warranty does not apply if the product or individual
components were repaired or modified by anyone other
than Phonak.

This warranty is in lieu of all other standard implied warranties
if the law allows, or if not, only to the extent the laws allows.

WITHOUT LIMITING THE GENERALITY OF THE PRIOR
SENTENCE, PHONAK AG HEREBY DISCLAIMS ALL IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. In some countries, implied warranties

cannot be limited. Under certain conditions, these limitation
or exclusions may therefore not apply to you.
This warranty replaces all other warranties for this product.
