The WTR24 is a 100 Volt line transformers for impedance
1
matching between low impedance loudspeakers (8 Ohm) and
100 Volt amplifiers. Using the WTR24 line transformer, low
impedance loudspeakers can be applied to any 100 Volt public
address system where long cable runs can be used. The WTR24
has a maximum output power of 24 Watt and different power
taps for 24 Watt, 12 Watt and 6 Watt. The housing is designed
to be water- and dustproof, while making it possible to be
hidden at any location such as above false ceilings, in wall
junction boxes, in hollow places inside walls, ... The primary
connection (100V side) is performed using a special designed
waterproof AWX 5 connector whereby the desired power tap
can be selected depending on the rotation of the connector.
The secondary connection (8 Ohm side) is performed using a
waterproof cable gland. A connection cable with a length of 0.5
meter is provided on both sides of the transformer. The over
dimensioned core of the transformer limits the saturation to a
minimum and gives a remarkable improvement of the sound
reproduction, especially in the low frequency range. All these
features make these transformers comply to an Ingress
Protection rating of IP66.
WTR24
Waterproof transformer 24W 100V
System specifications:
Line Transformer Tappings 1 24 W / 417 Ω
2 12 W / 833 Ω
3 6 W / 1667 Ω
Inputs Connector AWX5 Connector (0.5 m Cable) (100 V)
Outputs Impedance 8 Ω
Connector Waterproof cable gland (0.5 m Cable) (8 Ω)
Product Features:
Construction ABS
Colours Black
Dimensions 58 x 58 x 82 mm (W x H x D)
Weight 0.375 kg
AUDAC - WTR24 - 28/05/2020 11:05 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
