Audio line transformer 24W 100V
1
The TR1000 series are 100 Volt line transformers, designed for
impedance matching between loudspeakers and amplifiers.
They are used for converting low impedance speakers allowing
them to be used in 100V PA installations where long cableruns
can be used. The transformers have an over-dimensioned core,
which limits saturation to a minimum and gives remarkable
improvement of the sound reproduction quality, especially in
the low frequencies. There are several power tappings available
for 100V, and depending of the transformer that’s used, the
output impedance can also be selected.
System specifications:
Line Transformer Tappings 1 24 W / 416 Ω
2 12 W / 833 Ω
3 6 W / 1600 Ω
TR1024F
Outputs Impedance 8 Ω
Product Features:
Dimensions 52 x 60 x 56 mm (W x H x D)
Weight 0.360 kg
Shipping & Ordering:
Shipping weight & volume 0.360 kg - 0.0017 Cbm
AUDAC - TR1024F - 27/05/2020 09:03 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
