The PC3000 is a flush mount wall program selector for 100V PA
1
installations. It is compatible with AUDAC, Niko, Legrand and
other standard 45 x 45 mm installation materials. The output
can be selected out of 5 different sources using the rotatable
dial. Due to it’s slim and good looking design, these program
selectors will blend into all kinds of different environments or
interiors. The construction of the PC3000 is made with sturdy
ABS and therefore suitable for big projects in industrial
buildings to the standard installation into home design
interiors. The connections are made at the rear side, using
screw terminal blocks. Matching coverplates for the PC3000 are
separately available (CP45CF). Available in Black (/B) and White
(/W).
Applications:
Corporate spaces•
Residential•
PC3000
Program selector 45 x 45 mm
Product Features:
Dimensions 45 x 45 x 60 mm (W x H x D)
Weight 0.100 kg
Construction ABS
Mounting 45 x 45 mm
Colours Black (RAL9005) (PC3000/B)
White (RAL9010) (PC3000/W)
Variants:
PC3000/B - Black version•
PC3000/W - White version•
Shipping & Ordering:
Packaging Cardboard box
Shipping weight & volume 0.055 kg - 0.00009 Cbm
AUDAC - PC3000 - 25/05/2020 12:09 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
