The OPT2 is a fiber interconnection interface for the R2 and M2
1
Digital Multi-Zone & Multi-Media Matrix Systems. This module
makes it possible to transfer up to 16 digital audio signals over
one single fiber conductor (8 stereo channels) for covering large
distances.A duplex 62.5 / 125 µm multimode glass fiber
terminated with ST/PC connectors should be used for linking
the devices with each other.The wiring of the entire system
needs to be done according to a closed loop principle where
the output is connected to the input of the next device in the
chain and the last device gives feedback to the input of the first
device.Multiple devices (up to 15 pcs) can be cascaded through
series linking with a maximum distance of 1000 meters
between two devices. The especially developed protocol for this
purpose guarantees an accurate signal transmission with
maximal speed and reliability. The OPT2 includes all software
and accessories (except the fiber) which are necessary to
control and configure the system. The selection of the signals to
be transferred and the zone assignment can be made in the
user interface of the system.Recommended fiber to be used in
combination with OPT2 is ‘PROCAB FBS125 Duplex Fiber Optic
ST/PC to ST/PC 62.5/125µm’. This optic transmitter is
compatible with 50/125 μm, 62.5/125 μm, 100/140 μm, and
200 μm HCS® Fiber.
OPT2
Optical fiber kit
System specifications:
Used cable 62.5 / 125 μm multimode glass
Connectors ST/PC Connectors
Wavelength 820 nm
Max. length 1000 m
Outputs Power -10.5 dBm peak
Product Features:
Dimensions 70 x 30 x 12 mm (W x H x D)
Accessories Optional Procab FBS125 Duplex fiber connection cable ST/PC
AUDAC - OPT2 - 25/05/2020 11:59 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
