Rack mounting set for half rackspace 1u enclosures
4
The MBS310 rack mounting set is designed to safely and
effectively mount half rackspace devices into 19” or 10.5” racks.
The flowing configurations are possible with this set:
One half rackspace device in to a 19” rack (1 HE)
Two half rackspace devices in to a 19” rack (1 HE)
One half rackspace device in to a 10.5” rack (1 HE)
The set contains:
1 x single mounting ear
2 x double mounting ears
2 x couplers
8 x screws M4 x 6mm
MBS310
AUDAC - MBS310 - 27/05/2020 10:05 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
Page 1 of
Page 2
Technical drawings:
241,5
113
43,7
9
31,75
Product description:
Weight: Outer dimensions: Unit height:
(w x h x d)
MBS310
Single ear (1x)
TBA 241,5 x 43,7 x 113 1 HE
RACK MOUNTING SET FOR HALF
RACKSPACE 1U ENCLOSURES - SINGLE EAR
4
AUDAC - MBS310 - 27/05/2020 10:05 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
Page 2 of
Page 3
24
113
43,7
9
31,75
Product description:
Weight: Outer dimensions: Unit height:
(w x h x d)
MBS310
Double ear (2x)
TBA 24 x 43,7 x 113 1 HE
RACK MOUNTING SET FOR HALF RACKSPACE
1U ENCLOSURES - DOUBLE EAR
4
AUDAC - MBS310 - 27/05/2020 10:05 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
Page 3 of
Page 4
69,5
29,5
2,5
Product description:
Weight: Outer dimensions: Unit height:
(w x h x d)
MBS310
Coupler (2x)
TBA 69,5 x 29,5 x 2,5 N/A
RACK MOUNTING SET FOR HALF
RACKSPACE 1U ENCLOSURES - COUPLER
4
AUDAC - MBS310 - 27/05/2020 10:05 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
Page 4 of
