Highlights:
3
4 x 2" high-quality broadband speakers•
The LINO series are column speaker series designed for a wide
variation of general-purpose applications in acoustic difficult
environments, ranging from speech and announcement
applications to background music systems. Typical applications
are houses of worship, auditoria, presentation rooms, public
transportation hubs, … and many more. They are solidly
constructed using solid aluminum materials and finished
through a rigid finely perforated front grill. Mounting is done
through an L-shaped bracket on top and bottom, offering
optimal flexibility for fixation and directional placement.
Connections are made through terminal block connections.
The LINO4 column speaker consists of 4 x 2” low/mid-frequency
drives with a 1” central positioned tweeter for the high
frequencies. It reaches a power handling of 20 Watt, while a
multi-tapping line transformer allows it to be connected in
70V/100V public address systems with power taps for 20W,
10W and 5W.
LINO4
Column speaker 4 x 2"
Applications:
Education•
Public facilities•
Corporate spaces•
Houses of worship•
System specifications:
Drivers 4 x 2”
Connectors 5-pin Euro Terminal Block
Speaker type Column speaker
Max. Power 40 W
RMS Power 20 W
Frequency Response (± 3 dB) 170 Hz - 15 kHz
Sound Pressure (Max. W/1m) 91 dB
AUDAC - LINO4 - 21/05/2020 09:59 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
Page 1 of
Page 2
Product Features:
3
Colours Black & White
Construction Aluminum
Front finish Aluminium grill
AUDAC - LINO4 - 21/05/2020 09:59 UTC
We reserve the right to change specifications without notice, this is part of our policy to continually improve our products.
Page 2 of
Page 3
Technical drawings:
424,6
72
101,3
354
23x7
Product description:
Weight: Outer dimensions: Unit height:
(w x h x d)
LINO4
TBA 72 x 424,6 x 101,3 N/A
SLIM COLUMN SPEAKER 20 W - 70V/100V
3
