AuCom MVS User Manual

Download
CONTENTS
Contents
Section 1 Caution Statements ................................................................................................................................................................ 3
Section 2 General Description ............................................................................................................................................................... 5
Section 3 Specifications............................................................................................................................................................................... 8
Section 4 Installation .................................................................................................................................................................................. 11
Section 5 Keypad and Feedback ......................................................................................................................................................... 19
Section 6 Programming Menu ............................................................................................................................................................. 22
Section 7 Commissioning ....................................................................................................................................................................... 41
Section 8 Maintenance Tools ............................................................................................................................................................... 45
Section 9 Operation .................................................................................................................................................................................. 47
Section 10 Troubleshooting ..................................................................................................................................................................... 54
710-13019-00A MVS User Manual Page 1
CONTENTS
Section 11 Appendix ................................................................................................................................................................................... 59
Page 2 MVS User Manual 710-13019-00A
Section 1 Caution Statements
This symbol is used throughout this manual to draw attention to topics of special importance to the installation and operation of MVS Series soft starters.
Caution Statements cannot cover every potential cause of equipment damage but can highlight common causes of damage. It is the installer's responsibility to read and understand all instructions in this manual prior to installing, operating or maintaining the soft starter, to follow good electrical practice including applying appropriate personal protective equipment and to seek advice before operating this equipment in a manner other than as described in this manual.
Read and understand the entire manual before installing operating, or maintaining the starter. Follow all
The examples and diagrams in this manual are included solely for illustrative purposes. The information contained in this manual is subject to change at any time and without prior notice. In no event will responsibility or liability be accepted for direct, indirect or consequential damages resulting from the use or application of this equipment.
applicable local and national codes.
Apply appropriate personal protective equipment (PPE) and follow safe electrical work practices. Use only electrically insulated tools and clothing and insulated protective gear when working around electrical
equipment.
Disconnect all power and ensure that the starter is de-energised before servicing the starter. Do not rely on visual indications such as switch position or fuse removal for determining a de-energised
condition. Always assume that a terminal is energised until it is checked with a properly rated meter to ensure that a terminal is de-energised and grounded.
Isolate the soft starter completely from the power supply before attempting any work on the starter or motor. Always use a properly rated voltage sensing device to confirm power is off. Before servicing the starter, ensure that all static charge has been discharged by grounding it with an appropriate
grounding device.
Metal swarf in the cabinet can cause equipment failure. Do not apply voltage to the control input terminals. These are active 24 VDC inputs and must be controlled
with potential free contacts.
Contacts or switches operating the control inputs must be suitable for low voltage, low current switching (ie gold
flash or similar).
Cables to the control inputs must be segregated from mains voltage and motor cabling. Some electronic contactor coils are not suitable for direct switching with PCB mount relays. Consult the
contactor manufacturer/supplier to confirm suitability.
WARNING - ELECTRICAL SHOCK HAZARD MVS soft starters contain dangerous voltages when connected to mains voltage. Only a qualified electrician should carry out the electrical installation. Improper installation of the motor or the soft starter may cause equipment failure, serious injury or death. Follow this manual and local electrical safety codes.
CAUTION STATEMENTS
SHORT CIRCUIT MVS soft starters are not short circuit proof. After severe overload or short circuit, the operation of the soft starter should be fully tested by an authorised service agent.
GROUNDING AND BRANCH CIRCUIT PROTECTION It is the responsibility of the user or person installing the soft starter to provide proper grounding and branch circuit protection according to local electrical safety codes.
ARC FLASH HAZARD Soft starters have a potential risk of arc flash. When insulation or isolation between electrified conductors is breached or can no longer withstand the applied voltage, a short circuit occurs through the air. This may cause a phase-to-ground and/or a phase-to-phase fault.
AuCom soft starters have been designed to mitigate an arc fault, however it is the responsibility of the site engineer to ensure that personnel are protected from serious injury that may result from an arc fault.
Although unlikely, arc fault can be caused by:
Contamination in the insulation caused by deterioration over time
710-13019-00A MVS User Manual Page 3
CAUTION STATEMENTS
t
Inadequate insulation system on cable terminals Overvoltage Incorrect protection coordination settings Overheating of the contact area, due to incorrect tightening of connections Introduction of foreign matter, including swarf, vermin, tools or maintenance equipment left in the starter
STORAGE The starter must be stored in its original packaging in a clean and dry environment. The starter should be unpacked only after the equipment room is ready for installation. Particular care should be taken to avoid exposure of the electronics to cement and/or concrete dust.
© 2011 AuCom Electronics Ltd. All Rights Reserved.
As AuCom is continuously improving its products it reserves the right to modify or change the specification of its products at any
ime without notice. The text, diagrams, images and any other literary or artistic works appearing in this document are protected
by copyright. Users may copy some of the material for their personal reference but may not copy or use material for any other
purpose without the prior consent of AuCom Electronics Ltd. AuCom endeavours to ensure that the information contained in
this document including images is correct but does not accept any liability for error, omission or differences with the finished
product.
Page 4 MVS User Manual 710-13019-00A
Section 2 General Description
2.1 Overview
The MVS provides compact and robust soft start solutions for control of medium voltage motors. MVS soft starters provide a complete range of motor and system protection features and have been designed for reliable performance in the most demanding installation situations.
Each MVS soft starter comprises two elements:
a power assembly a controller module
The power assembly and controller module are supplied as a pair and share the same serial number. Care should be taken during installation to ensure the correct controller and power assembly are used together.
Each MVS is also supplied with two fibre-optic cables, to connect the controller module to the power assembly, and three non-conduction lead assemblies, allowing the soft starter to be tested with a low-voltage motor (< 500 VAC).
2.2 Feature List
GENERAL DESCRIPTION
Starting
Constant current Current ramp
Stopping
Coast to stop Soft stop
Protection
Under/ Overvoltage Mains frequency Phase sequence Shorted SCR Motor overload (thermal model) Instantaneous overcurrent (two stages) Time-overcurrent Ground fault Undercurrent Current imbalance Motor thermistor Excess start time Power circuit Auxiliary trip
Extensive input and output options
Remote control inputs
(3 x fixed, 2 x programmable)
Relay outputs
(3 x fixed, 3 x programmable)
Analog output
(1 x programmable)
Serial port (with module)
Comprehensive feedback
Starter status LEDs Date and time stamped event logging Operational counters (starts, hours-run, kWh) Performance monitoring (current, voltage, power factor,
kWh)
User-programmable monitoring screen Multi-level password protection Emergency stop push button
Power Connection
50 A to 600
A, nominal
2300 VAC to 7200 VAC
Accessories (optional)
DeviceNet, Modbus or Profibus communication modules Synchronous motor control PC Software Overvoltage protection Control supply transformer MV/LV Control transformer
710-13019-00A MVS User Manual Page 5
GENERAL DESCRIPTION
2.3 Key Features
MVS soft starters offer several special functions to ensure ease of use and to provide optimal motor control in all environments and applications.
Customisable Protection
The MVS offers comprehensive protection to ensure safe operation of the motor and soft starter. The protection characteristics can be customised extensively to match the exact requirements of the installation.
Use parameter group 4 on page 28 to set the conditions in which each protection mechanism will activate.
Example: use parameter 4C
Undercurrent Delay
Use parameter group 16 on page 39 to select the soft starter's response when a protection mechanism activates. Each protection can be set to trip the starter, activate a warning flag, or be ignored. All protection activations are recorded in the event log, regardless of the protection class setting.
Example: Use parameter 16C
Advanced Thermal Modelling
to log). The default response is trip.
NOTE MVS soft starters have built-in trip points to ensure operation remains within the soft starter's capability. These internal trips cannot be overridden. Certain faults within the MVS will also prevent the soft starter from operating. Refer to
Undercurrent
to set the level for an undercurrent trip and parameter 4D
to set a delay on the trip.
Undercurrent
to select the response for an undercurrent trip (trip, warn or write
Troubleshooting
on page 54 for details.
Intelligent thermal modelling allows the soft starter to predict whether the motor can successfully complete a start. The MVS uses information from previous starts to calculate the motor's available thermal capacity, and will only permit a start which is predicted to succeed.
This feature can be enabled or disabled using parameter 4N
Motor Temperature Check
.
Comprehensive Event and Trip Logging
The MVS has a 99-place event log to record information on soft starter operation. A separate trip log stores detailed information about the last eight trips.
Informative Feedback Screens
A digital display screen allows the MVS to display important information clearly. Comprehensive metering information, details of starter status and last start performance allow easy monitoring of the starter's performance at all times.
Dual Parameter Set
The MVS can be programmed with two separate sets of operating parameters. This allows the soft starter to control the motor in two different starting and stopping configurations.
The secondary motor settings (parameter groups 9 and 10) are ideal for dual speed motors or conventional (squirrel-cage) motors which may start in two different conditions (such as loaded and unloaded conveyors).
NOTE MVS soft starters are not suitable for controlling two separate motors. The secondary parameter set should only be used for a secondary configuration of the primary motor.
The MVS will use the secondary motor settings to control a start when instructed via a programmable input (refer to parameters 6A and 6F
Input A or B Function
).
Fibre Optics
The MVS uses two-line fibre optic connections between the low voltage control module and the high voltage power assembly for electrical isolation. This fibre optic link simplifies installation of chassis mount MVS starters into custom panels.
Page 6 MVS User Manual 710-13019-00A
2.4 Model Code
MVS
–
–
Control Supply Voltage
C12 = 110~130 Vac & 220~240 Vac
Supply Voltage
V02 = 2300 Vac 50/60 Hz V03 = 3300 Vac 50/60 Hz V04 = 4160 Vac 50/60 Hz V06 = 6600 Vac 50/60 Hz V07 = 7200 Vac 50/60 Hz
Current Rating
0080 = 80 A @ AC53b 4-20 : 1780 0159 = 159 A @ AC53b 4-20 : 1780 0230 = 230 A @ AC53b 4-20 : 1780 0321 = 321 A @ AC53b 4-20 : 1780 0500 = 500 A @ AC53b 4-20 : 1780 0600 = 600 A @ AC53b 4-20 : 1780
GENERAL DESCRIPTION
710-13019-00A MVS User Manual Page 7
SPECIFICATIONS
Section 3 Specifications
3.1 Dimensions and Weights
A
a
e
b
B
Front view Side view Phase arm extended
A B C a b c d e Weight
MVSxxxx-V02 MVSxxxx-V03 MVSxxxx-V04 MVSxxxx-V06 MVSxxxx-V07
mm
(inch)
772
(30.4)
832
(32.8)
* For models MVSxxxx-V02 to MVSxxxx-V04, these dimensions apply up to 321 A. For the same models with current ratings of 500 and 600 A, the MVSxxxx-V06 dimensions apply.
NOTE In addition to the dimensions of the soft starter power assembly, an enclosure must allow space for the following required components:
MVS soft starters must always be installed with a main contactor and bypass contactor. Models with current ratings 500 A and above require forced air ventilation when installed in an enclosure.
3.2 Low Voltage Section
mm
(inch)
669
(26.3)
875
(34.5)
c C
mm
(inch)
667
(26.3)
817
(32.2)
mm
(inch)
750
(29.5)
810
(31.9)
mm
(inch)
658
(25.9)
864
(34.0)
mm
(inch)
650
(25.6)
800
(31.5)
d
mm
(inch)
1302
(51.3)
1559
(61.4)
mm
(inch)
531
(20.9)
551
(21.7)
kg (lb)
165
(363.8)
217
(478.4)
1 Access for LV wiring 2 Control voltage terminal block 3 Gate firing fibre optic connectors 4 Access hole for CT wiring 5 Fibre connections to controller 6 Fibre optic indication LEDs 7 Non-conduction readback fibre optic connectors 8 Ground current CT
Page 8 MVS User Manual 710-13019-00A
3.3 Controller
The Controller is suitable for use with all MVS soft starters.
220.0(8.66)
1
START STOP RESET INPUT A INPUT B
Run Trip LocalReady
LCL
Reset
StopStart
RMT
Menu
Exit
Store
Alt
Logs
Tool s
1 Control input LEDs 2 Keypad
SPECIFICATIONS
340.0
(13.39)
Dimensions are shown in mm (inch).
Weight: 2.1 kg (4.63 lb)
3.4 Key Components
1 2
3
3.5 General Technical Data
80.0
(3.15)
5
1 Control transformer 2 Control voltage terminal block 3 Power interface PCB 4 Phase arm (x3) 5 Power assembly
03993.C
Supply
Mains Voltage
MVSxxxx-V02 .......................................................................................................................................................................... 2.3 kV Phase-phase
MVSxxxx-V03 .......................................................................................................................................................................... 3.3 kV Phase-phase
MVSxxxx-V04 .......................................................................................................................................................................... 4.2 kV Phase-phase
MVSxxxx-V06 .......................................................................................................................................................................... 6.6 kV Phase-phase
MVSxxxx-V07 .......................................................................................................................................................................... 7.2 kV Phase-phase
Rated Frequency (fr) ............................................................................................................................................................................................. 50/60 Hz
Rated lightning impulse withstand voltage (U
p
)
MVSxxxx-V02 ~ 04 ............................................................................................................................................................................................ 45 kV
MVSxxxx-V06 ~ V07 ........................................................................................................................................................................................ 45 kV
Rated power frequency withstand voltage (U
)
d
MVSxxxx-V02 ~ V04 .................................................................................................................................................................................... 11.5 kV
MVSxxxx-V06 ~ V07 ........................................................................................................................................................................................ 20 kV
Rated normal current (l
)
r
MVS0080-Vxx .......................................................................................................................................................................................................... 80 A
MVS0159-Vxx ....................................................................................................................................................................................................... 159 A
MVS0230-Vxx ....................................................................................................................................................................................................... 230 A
MVS0321-Vxx ....................................................................................................................................................................................................... 321 A
MVS0500-Vxx ....................................................................................................................................................................................................... 500 A
MVS0600-Vxx ......................................................................................................................................................................................................... 600 A
Rated short-time withstand current (asymmetrical RMS peak) (l
) ................................................................................................. 48 kA 1
k
Form Designation ...................................................................................................................... Bypassed semiconductor motor starter form 1
710-13019-00A MVS User Manual Page 9
SPECIFICATIONS
Control Inputs
Start (Terminals C23, C24) ................................................................................................................................................. 24 VDC, 8 mA approx
Stop (Terminals C31, C32) ................................................................................................................................................. 24 VDC, 8 mA approx
Reset (Terminals C41, C42) ............................................................................................................................................... 24 VDC, 8 mA approx
Input A (Terminals C53, C54) .......................................................................................................................................... 24 VDC, 8 mA approx
Input B (Terminals C63, C64) ........................................................................................................................................... 24 VDC, 8 mA approx
Motor Thermistor (Terminals B4, B5) ..................................................................................................................................... Trip point > 2.4 k
NOTE All control inputs are potential free. Do not apply external voltage to these inputs.
Low Voltage Supply
Rated Voltage ...................................................................................................................................................................... 110 ~130 or 220 ~ 240 V
Rated Frequency ..................................................................................................................................................................................................... 50/60 Hz
Typical power consumption ....................................................................................................................................................... 70 W
3
continuous
Outputs
Relay Outputs ..................................................................................................................................................................... 10 A @ 250 VAC resistive
.............................................................................................................................................................................................. 6 A @ 250 VAC 15 p.f. 0.3
................................................................................................................................................................................................. 10 A @ 30 VDC resistive
Outputs on interface PCB
Main Contactor (13, 14) ............................................................................................................................................................ Normally Open
Bypass Contactor (23, 24) ........................................................................................................................................................ Normally Open
Run Output/ PFC (33, 34) ........................................................................................................................................................ Normally Open
Outputs on Controller
Output Relay A (43, 44) ............................................................................................................................................................ Normally Open
Output Relay B (51, 52, 54) .......................................................................................................................................................... Changeover
Output Relay C (61, 62, 64) ............................................................................................................................................................ Changeover
Analog Output (B10, B11) ..................................................................................................................................................... 0-20 mA or 4-20 mA
Environmental
Degree of Protection
Power Assembly ...................................................................................................................................................................................................... IP00
Controller .......................................................................................................................................................................................... IP54/ NEMA 12
Operating Temperature ..................................................................................................... - 10 ˚C to + 60 ˚C, above 40˚C with derating
Storage Temperature ..................................................................................................................................................................... - 25 ˚C to + 80 ˚C
Humidity ........................................................................................................................................................................ 5% to 95% Relative Humidity
Pollution Degree ................................................................................................................................................................................ Pollution Degree 3
Vibration ........................................................................................................................................................................................ Designed to IEC 60068
EMC Emission
Equipment Class (EMC) .......................................................................................................................................................................................... Class A
Conducted Radio Frequency Emission ....................................................................................... 10 kHz to 150 kHz: < 120 - 69 dB µV
............................................................................................................................................................................ 0.15 MHz to 0.5 MHz: < 79 dB µV
................................................................................................................................................................................ 0.5 MHz to 30 MHz: < 73 dB µV
Radiated Radio Frequency Emission ....................................................................................... 0.15 MHz to 30 MHz: < 80-50 dB µV/m
................................................................................................................................................................. 30 MHz to 100 MHz: < 60-54 dB µV/m
.................................................................................................................................................................. 100 MHz to 2000 MHz: < 54 dB µV/m
This product has been designed as Class A equipment. Use of this product in domestic environments may cause radio interference, in which case the user may be required to employ additional mitigation methods. EMC Immunity
Electrostatic Discharge .................................................................................................................. 6 kV contact discharge, 8 kV air discharge
Radio Frequency Electromagnetic Field ..................................................................................................... 80 MHz to 1000 MHz: 10 V/m
Fast Transients 5/50 ns (main and control circuits) .......................................................................... 2 kV line to earth, 1 kV line to line
Surges 1.2/50 µs (main and control circuits) .................................................................................. 2 kV line to earth, 1 kV line to line
Voltage dip and short time interruption (safe shutdown) .......................................................... 5000 ms (at 0% nominal voltage)
Standards Approvals
C ....................................................................................................................................................................................................... EMC requirements
CE .......................................................................................................................................................................................................... EMC EU Directive
1
Short circuit current, with appropriate R rated fuses fitted.
2
It is critical that the circuit breaker and associated protection relay are set to trip <150 ms. Failure to do so could result
in SCR rupture and subsequent arc fault.
3
Excludes contactors and/or circuit breakers.
Page 10 MVS User Manual 710-13019-00A
Section 4 Installation
NOTE The MVS soft starter should only be installed in a restricted access location suitable for electrical equipment.
NOTE Ensure that the equipment room is clean and relatively dust-free before unpacking and installing the MVS soft starter. In particular, beware of concrete dust as it may cause corrosion.
4.1 Mounting Instructions - Power Assembly
All MVS models are rated IP00 and must be installed inside an enclosure.
No clearance is required below or at the sides. The power assembly should be installed with 100 mm clearance above for isolation.
min 100 mm (3.93 inch)
INSTALLATION
NOTE Models with current ratings 500 A and above require forced air ventilation when installed in an enclosure.
Mounting Points
The power assembly is mounted in place using four M12 bolts. One bolt is required through each corner at the base of the unit, tightened to a torque of 40 Nm. Individual phase arms are secured within the frame using one M10 nut and two M10 high tensile grade 8.8 bolts complete with Belleville washers, all tightened to a torque of 28 ~ 30 Nm.
1
Plan View
Front of unit
C
B
2
3
710-13019-00A MVS User Manual Page 11
A
10130.A
INSTALLATION
1 M10 bolts with belleville washers 2 M10 nut 3 M12 mounting holes
Model
A
mm (inch) MVSxxxx-V02 636 513 68.5 MVSxxxx-V03 (25.0) (20.0) (2.7) 28~30 Nm 40 Nm MVSxxxx-V04 MVSxxxx-V06 842 663 68.5 28~30 Nm 40 Nm MVSxxxx-V07 (33.1) (26.1) (2.7)
* For models MVSxxxx-V02 to MVSxxxx-V04, these dimensions apply up to 321 A. For the same models with current ratings of 500 and 600 A, the MVSxxxx-V06 dimensions apply.
4.2 Mounting Instructions - Controller
The Controller is secured into place using ten M4 nuts, affixed to the studs on the back of the controller.
B
mm (inch)
C
mm (inch)
Torque
(phase arms)
Torque
(base)
220 (8.66)
196 (7.72)
186 (7.32)
03263.B
112 (4.41)
300 (11.81)
310 (12.20)
340 (13.39)
80.0 (3.15)
To mount the controller, make a 186 mm x 300 mm cutout at the desired mounting location. Ensure adequate clearance (>85 mm) is available behind the mounting location.If you intend to use a communication module, allow for a minimum clearance of 120 mm behind the mounting panel.
Drill 5 mm holes to accommodate the studs on the controller. Fit the controller through the cutout and tighten the nuts onto the studs.
NOTE Before installation, always ensure that you are using the correct controller for the soft starter. This can be checked by comparing the serial number on the back of the controller with the serial number on the front of the power assembly.
1 Serial number
1
MVS0321-V04-C12
INPUTRATING: 4160 VAC50/60 Hz OUTPUTRATING: 321A:AC53b4-201780 AUXILIARY CONTACTS: 8A, 30 VDC resistive / 10 A, 250 VAC 360 VA WITHSTAND CURRENT: 20 kA WITHSTAND VOLTAGE: 45000 VAC Cat III AUXILIARY CONTACT S : #24-#14AWG,0 .2 -2 .5 mm2 (0.5 NM, 4.4 lb-in)
AUCOM
O/C: MVS032 1-411 S/N: 197803-459
IND. CONT. EQ. 32 AN
Z79
MAIN CONTROL MODULE
MVS-0321-V04-C12
S/N: 197803-459
IND. CONT.E Q. 32 AN
Z79
03530.E
Page 12 MVS User Manual 710-13019-00A
4.3 Power Terminations
T1
T1B
L1
INSTALLATION
T2B, T2, L2
T3B, T3, L3
25
(0.98)
13
(0.51)
6
(0.24)
Use only M10 high tensile grade 8.8 threaded fasteners for all terminations. Use a pre-load torque setting between 28 ~ 30 Nm. Use only Belleville washers.
Side View Top View
10131.A
03217.C
a b c d e f g h i
MVSxxxx-V02* MVSxxxx-V03* MVSxxxx-V04* MVSxxxx-V06 MVSxxxx-V07
mm
(inch)
228
(8.98)
228
(8.98)
mm
(inch)
79
(3.11)
79
(3.11)
mm
(inch)
744
(29.29)
804
(31.65)
mm
(inch)
79
(3.11)
107
(4.19)
mm
(inch)
129
(5.08)
164
(6.46)
mm
(inch)
179
(7.05)
222
(8.72)
mm
(inch)
200
(7.87)
268
(10.55)
mm
(inch)
200
(7.87)
268
(10.55)
mm
(inch)
200
(7.87)
268
(10.55)
* For models MVSxxxx-V02 to MVSxxxx-V04, these dimensions apply up to 321 A. For the same models with current ratings of 500 and 600 A, the MVSxxxx-V06 dimensions apply.
710-13019-00A MVS User Manual Page 13
INSTALLATION
4.4 Earth Terminations
A 10 mm earth stud is located on each side of the power assembly, at the rear of the unit. Use only M10 high tensile grade
8.8 threaded fasteners for all terminations. Use a pre-load torque setting between 28 ~ 30 Nm. Use only Belleville washers.
4.5 Control Terminations
On the control voltage terminal block, control wiring is secured in place by 3 mm spring terminals. Use a screwdriver to open the terminal clamp, then insert the wire into the terminal cage. Release the clamp by removing the screwdriver.
B
A
C
4.6 Control Wiring
The soft starter can be controlled in three ways:
using the buttons on the Controller via remote inputs via a serial communication link
The LCL/RMT button controls whether the MVS will respond to local control (via the Controller) or remote control (via the remote inputs).
The Local LED on the Controller is on when the soft starter is in local control mode and off when the soft starter is in remote control mode.
Control via the serial communication network is always enabled in local control mode, and can be enabled or disabled in remote control mode (refer to parameter 6R). Control via the serial communication network requires an optional communication module.
The STOP button on the Controller is always enabled.
The MVS has three fixed inputs for remote control. These inputs should be controlled by contacts rated for low voltage, low current operation (gold flash or similar).
A
(mm)
3 2.5 3
C
B
(mm2) C (mm)
Page 14 MVS User Manual 710-13019-00A
1
C23 C24
A B
C
C31 C32 C41 C42
A
B
C
2
C23 C24 C31 C32 C41 C42
3
A
B
C
C23 C24 C31 C32 C41 C42
03943.D
1 Two-wire control 2 Three-wire control
3 Four-wire control A Start B Stop C Reset
INSTALLATION
CAUTION Do not apply voltage to the control input terminals. These are active 24 VDC inputs and must be controlled with potential free contacts.
Cables to the control inputs must be segregated from mains voltage and motor cabling.
The reset input can be normally open or normally closed. Use parameter 6M to select the configuration.
NOTE Reset input is normally closed by default.
4.7 Terminal Block (Controller)
Terminations on the Controller use plug-in terminals. Unplug the terminal blocks, complete the wiring, then re-plug the terminal blocks into the controller.
Control
OutputC
Supply
24VAC/DC
Relay Outputs
OutputA
OutputB
4.8 Power Circuits
Overview
MVS soft starters are designed to operate as part of a system including other components. A main contactor and bypass contactor are required in all installations. MVS models V02 ~ V07 must be installed with fuses.
The following additional components may also be required:
Control Inputs
Start
Analog Output
Motor
Stop
Reset
ProgA
Prog B
Thermistor
Fibre Optic Connection
To Power Assembly
03948.B
main isolator/ earth switch power factor correction line inductors transient/ overvoltage protection MV/LV control supply transformer
Main Contactor
The MVS must always be installed with a main contactor. Select a contactor with an AC3 rating greater than or equal to the full load current rating of the connected motor or there is an option for a circuit breaker above 7.2 kV.
The main contactor is associated with terminals L1, L2, L3 on the supply side of the soft starter. The coil is associated with output terminals 13, 14 of the MVS (refer to
Power Circuit Configuration
).
To ensure that the potentially dangerous medium voltage area is isolated from the low voltage control area, power is supplied to the main contactor coil from the control voltage terminal block (refer to
Internal Wiring
).
Bypass Contactor
The MVS must always be installed with a bypass contactor. Select a contactor with an AC1 rating greater than or equal to the full load current rating of the connected motor or there is an option for a circuit breaker above 7.2 kV.
710-13019-00A MVS User Manual Page 15
INSTALLATION
The bypass contactor is associated with terminals L1, L2, L3 on the supply side of the soft starter, and bypass terminals T1B, T2B, T3B on the motor side. The coil is associated with output terminals 23, 24, and the auxiliary Normally Open contact is associated with input terminals C73, C74 of the soft starter (refer to
To ensure that the potentially dangerous medium voltage area is isolated from the low voltage control area, power is supplied to the bypass contactor coil from the control voltage terminal block (refer to
Power Circuit Configuration
Internal Wiring
).
).
Page 16 MVS User Manual 710-13019-00A
INSTALLATION
Power Circuit Configuration
MVS power circuit with main contactor, bypass contactor, main isolator/ earth switch, R Rated fuses and control supply. Configured for four-wire start/ stop control. Models V02 to V07 must be installed with backup/R-rated fuses (refer to R-Rated Protection Fuses)
1
2
A2 A3
110-130 VAC
220-240 VAC
+10
-15 +10
-15
A1 A2
3
A3 13
C73 C74
14 23 24 33 34
KM1
KM2
A4
A5
A11 A12
A11 A12
C23 C24 C31 C32 C41 C42
C53 C54 C63 C64
B4 B5
TX RX
(Bk)(Wh)
(Wh)(Bk)
RX TX
43 44 54 52
51
5
64 62
61
B10
+
B11
-
03223.E
A1 Power assembly A4 Controller
1 3 Phase 50/60 Hz Supply 5 Remote control inputs Q1 Main isolator/Earth switch F1 R-Rated protection fuses KM1 Main contactor KM2 Bypass contactor (external)
2 To motor
C23~C24 Start C31~C32 Stop C41~C42 Reset C53~C54 Programmable input A C63~C64 Programmable input B
A2 Control voltage terminals 6 Programmable outputs
3 Control supply A3 Power interface PCB
4 Relay outputs
43, 44 Programmable Relay output A 51, 52, 54 Programmable Relay output B
61, 62, 64 Programmable Relay output C C73~C74 Bypass contactor feedback signal 7 Motor thermistor input 13~14 Main contactor KM1 8 Analog output 23~24 Bypass contactor KM2 A5 Communications module (optional) 33~34 Run output (PFC)
(refer to
Internal Wiring
).
710-13019-00A MVS User Manual Page 17
INSTALLATION
4.9 Internal Wiring
A5
A3
3
1
A2
4
5
2
6
A4
03221.F
KM1 Main contactor KM2 Bypass contactor (external) KM3 PFC contactor (optional) 1 COM. Connect to:
A2-1(1) for 110 or 220 VAC coil A2-2(1) for 120 or 230 VAC coil A2-3(1) for 130 or 240 VAC coil A4 Controller
A2 Control voltage terminal block
A3 Power interface PCB 3 Bypass feedback 4 Main contactor output 5 Bypass contactor output 6 Run (PFC) output 7 Power supply
8 Fibre optic cables (supplied, but must be connected at
site)
2 Feed connected to A1 or A3 must be
externally fused.
A5 Gate drive PCBs
NOTE The control voltage terminal section (A2) has links fitted for 110 VAC external control and contactor coil voltages. For other voltages, remove these links and refit as indicated.
External control supply
Contactor coil supply (KM1 - KM3) Voltage Connect into Link from Voltage Link from 110 VAC
A2(2) to A2-1(2) 110 VAC 120 VAC A1 and A2 A2(2) to A2-2(2) 120 VAC A1(2) to 13(2) 130 VAC 220 VAC
A2(2) to A2-3(2) 130 VAC
A2(2) to A2-1(2) 220 VAC 230 VAC A3 and A2 A2(2) to A2-2(2) 230 VAC A3(2) to 13(2) 240 VAC
A2(2) to A2-3(2) 240 VAC
Page 18 MVS User Manual 710-13019-00A
Section 5 Keypad and Feedback
5.1 The Controller
Exits the menu or parameter, or cancels a
Enters a menu or parameter, or saves a
5.2 Displays
status and programming details.
NOTE When the Controller is powered up, the Ready LED flashes for 5 seconds as part of the initialisation routine.
Four-line display for
Status LEDs
Menu navigation buttons:
parameter change.
parameter change.
KEYPAD AND FEEDBACK
Soft starter local control buttons
Menu navigation buttons. Scroll to the next or previous menu or parameter, or change the setting of the current parameter.
Shortcut buttons for quick access to common tasks.
Alt button. Use with F1 or F2 to open performance logs or commissioning tools.
The Controller displays a wide range of performance information about the soft starter. The top half of the screen shows real-time information on current or motor power (as selected in parameter 8D). Use the and buttons to select the information shown on the bottom half of the screen.
Starter status User programmable screen Motor temperature Current Motor power Voltage Last start information Date and time Performance graphs SCR conduction
Refer to
5.3 Menus
Commissioning Menu
The Commissioning Menu provides access to commissioning and testing tools.
To open the Commissioning Menu, press ALT then F2 (Tools) while viewing the metering screens.
Refer to
Programming Menu
Operating feedback
on page 51, for further details.
Commissioning Menu
on page 41, for further details.
The Programming Menu lets you view and change programmable parameters that control how the MVS operates.
To open the Programming Menu, press the MENU button while viewing the monitoring screens.
You can access the Programming Menu at any time, including while the soft starter is running. Any changes to the start profile take effect immediately.
To navigate through the Programming Menu:
710-13019-00A MVS User Manual Page 19
KEYPAD AND FEEDBACK
to scroll through parameter groups, press the or button. to open a submenu, press the button. to view the parameters in a group, press the button. to return to the previous level, press the button. to close the Programming Menu, press repeatedly
Menu Shortcuts
The F1 and F2 buttons offer keyboard shortcuts to the Auto-Stop menu. Use parameters 8B and 8C (
on page 35) to select the shortcut target.
Action
F1 and F2 Button
Adjustment Lock
You can lock the Programming Menu to prevent users from altering parameter settings. The adjustment lock can be turned on and off using parameter 15B.
To lock the programming menu:
1. Open the Programming Menu.
2. Open the Extended Menu.
3. Select 'Advanced'
4. Enter the Access Code
5. Select parameter 15B Adjustment Lock.
6. Select and store 'Read Only'
If a user attempts to change a parameter value when the adjustment lock is active, an error message is displayed:
Access Denied Adj Lock is On
Altering Parameter Values
To change a parameter value:
scroll to the appropriate parameter in the Programming Menu and press to enter edit mode. to alter the parameter setting, use the and buttons. Pressing or once will increase or decrease
the value by one unit. If the button is held for longer than five seconds, the value will increase or decrease at a faster rate.
to save changes, press STORE. The setting shown on the display will be saved and the Controller will return to
the parameter list.
to cancel changes, press EXIT. The Controller will ask for confirmation, then return to the parameter list
without saving changes.
Access Code
Critical parameters (parameter group 15 and higher) are protected by a four-digit security access code, preventing unauthorised users from viewing or modifying parameter settings.
When a user attempts to enter a restricted parameter group, the Controller prompts for an access code. The access code is requested once for the programming session, and authorisation continues until the user closes the menu.
To enter the access code, use the and buttons to select a digit, and the and buttons to change the value. When all four digits match your access code, press STORE. The Controller will display an acknowledgement message before continuing.
Enter Access Code 0###
STORE Access Allowed
SUPERVISOR
To change the access code, use parameter 15A.
The simulation tools and counter resets are also protected by the security access code.
The default access code is 0000.
Page 20 MVS User Manual 710-13019-00A
KEYPAD AND FEEDBACK
Logs Menu
The Logs Menu provides information on events, trips and starter performance.
To open the Logs Menu, press ALT then F1 (LOGS).
Refer to
Logs Menu
on page 45, for further details.
710-13019-00A MVS User Manual Page 21
PROGRAMMING MENU
Section 6 Programming Menu
You can access the Programming Menu at any time, including while the soft starter is running. Any changes to the start profile take effect immediately.
The Programming Menu contains three sub-menus:
Standard Menu The Standard Menu provides access to commonly used parameters, allowing you to
configure the MVS to suit your application.
Extended Menu The Extended Menu provides access to all the MVS's programmable parameters, allowing
experienced users to take advantage of advanced features.
Load/Save Settings Load/Save Settings lets you save the current parameter settings to a file, load parameters
6.1 Standard Menu
The standard menu provides access to commonly used parameters, allowing the user to configure the MVS as required for the application. For details of individual parameters, refer to
1 Motor Data-1
2 Start/Stop Modes-1
3 Auto-Start/Stop
4 Protection
6 Inputs
7 Outputs
1A
2A 2B 2C 2D 2H 2I
3C 3D
4A 4C 4D 4E 4F 4G
6A 6B 6C 6D 6E 6F 6G 6H 6I 6J
7A 7B 7C 7D 7E 7F 7G 7H 7I 7M 7N
from a previously saved file, or reset all parameters to default values.
Motor Full Load Current
Start Mode Start Ramp Time Initial Current Current Limit Stop Mode Stop Time
Auto-Stop Type Auto-Stop Time
Excess Start Time Undercurrent Undercurrent Delay Instantaneous Overcurrent Instantaneous Overcurrent Delay Phase Sequence
Input A Function Input A Name Input A Trip Input A Trip Delay Input A Initial Delay Input B Function Input B Name Input B Trip Input B Trip Delay Input B Initial Delay
Relay A Function Relay A On Delay Relay A Off Delay Relay B Function Relay B On Delay Relay B Off Delay Relay C Function Relay C On Delay Relay C Off Delay Low Current Flag High Current Flag
Parameter Descriptions
on page 26.
Page 22 MVS User Manual 710-13019-00A
7O
8 Display
8A 8B 8C 8D 8E 8F 8G 8H
6.2 Extended Menu
The extended menu gives access to all of the MVS's programmable parameters.
1 Motor Data-1
2 Start/Stop Modes-1
3 Auto-Start/Stop
4 Protection
1A 1B 1C 1D
2A 2B 2C 2D 2E 2F 2G 2H 2I
3A 3B 3C 3D
4A 4B 4C 4D 4E 4F 4G 4H 4I 4J 4K 4L 4M 4N 4O 4P 4Q 4R 4S 4T 4U 4V
Motor Temperature Flag
Language F1 Button Action F2 Button Action Display A or kW User Screen - Top Left User Screen - Top Right User Screen - Bottom Left User Screen - Bottom Right
Motor Full Load Current Locked Rotor Time Locked Rotor Current Motor Service Factor
Start Mode Start Ramp Time Initial Current Current Limit Reserved Kickstart Time Kickstart Level Stop Mode Stop Time
Reserved Reserved Auto-Stop Type Auto-Stop Time
Excess Start Time Excess Start Time-2 Undercurrent Undercurrent Delay Instantaneous Overcurrent Instantaneous Overcurrent Delay Phase Sequence Current Imbalance Current Imbalance Delay Frequency Check Frequency Variation Frequency Delay Restart Delay Motor Temperature Check Ground Fault Level Ground Fault Delay Undervoltage Undervoltage Delay Overvoltage Overvoltage Delay Instantaneous Overcurrent S2 Instantaneous Overcurrent Delay S2
PROGRAMMING MENU
710-13019-00A MVS User Manual Page 23
PROGRAMMING MENU
5 Auto-Reset Trips (Reserved)
5A
6 Inputs
6A 6B 6C 6D 6E 6F 6G 6H 6I 6J 6K 6L 6M 6N 6O 6P 6Q 6R
7 Outputs
7A 7B 7C 7D 7E 7F 7G 7H 7I 7J 7K 7L 7M 7N 7O 7P 7Q 7R 7S 7T 7U 7V 7W
8 Display
8A 8B 8C 8D 8E 8F 8G 8H 8I 8J 8K 8L
Reserved
Input A Function Input A Name Input A Trip Input A Trip Delay Input A Initial Delay Input B Function Input B Name Input B Trip Input B Trip Delay Input B Initial Delay Reserved Reserved Remote Reset Logic Reserved Reserved Reserved Local/Remote Comms in Remote
Relay A Function Relay A On Delay Relay A Off Delay Relay B Function Relay B On Delay Relay B Off Delay Relay C Function Relay C On Delay Relay C Off Delay Reserved Reserved Reserved Low Current Flag High Current Flag Motor Temperature Flag Analog Output A Analog A Scale Analog A Maximum Adjustment Analog A Minimum Adjustment Reserved Reserved Reserved Reserved
Language F1 Button Action F2 Button Action Display A or kW User Screen - Top Left User Screen - Top Right User Screen - Bottom Left User Screen - Bottom Right Graph Data Graph Timebase Graph Maximum Adjustment Graph Minimum Adjustment
Page 24 MVS User Manual 710-13019-00A
8M 8N 8O
Current Calibration Mains Reference Voltage Voltage Calibration
PROGRAMMING MENU
9 Motor Data-2
9A 9B 9C 9D 9E
Reserved Motor FLC-2 Reserved Reserved Reserved
10 Start/Stop Modes-2
11
10A 10B 10C 10D 10E 10F 10G 10H 10I
11A
Start Mode-2 Start Ramp-2 Initial Current-2 Current Limit-2 Reserved Kickstart Time-2 Kickstart Level-2 Stop Mode-2 Stop Time-2
RTD/PT100 (Reserved)
Reserved
12 Slip-Ring Motors
12A 12B 12C 12D
Motor Data-1 Ramp Motor Data-2 Ramp Changeover Time Slip Ring Retard
15 Advanced
15A 15B 15C
Access Code Adjustment Lock Emergency Run
16 Protection Action
16A 16B 16C 16D 16E 16F 16G 16H 16I 16J 16K 16L 16M 16N 16O 16P 16Q 16R 16S 16T 16U 16V 16W
Motor Overload Excess Start Time Undercurrent Instantaneous Overcurrent Current Imbalance Frequency Input A Trip Input B Trip Motor Thermistor Starter Communication Network Communication Reserved Battery/Clock Ground Fault Reserved Reserved Reserved Reserved Reserved Reserved Reserved Undervoltage Overvoltage
710-13019-00A MVS User Manual Page 25
PROGRAMMING MENU
6.3 Load/Save Settings
The Load/Save Settings menu requires an access code and allows users to:
Load the MVS's parameters with default values Reload previously saved parameter settings from an internal file Save the current parameter settings to an internal file
In addition to the factory default values file, the MVS can store two user-defined parameter files. These files contain default values until a user file is saved.
To load or save settings:
1. Open the Programming Menu
2. Scroll to Load/Save Settings and press the button.
3. Scroll to the required function and press the button. Enter the access
code when prompted.
4. At the confirmation prompt, select YES to confirm or NO to cancel and
then STORE to load/save the selection.
When the action has been completed, the screen will briefly display a confirmation message, then return to the Load/Save Settings screen
6.4 Parameter Descriptions
1 Motor Data-1
The parameters in Motor Data-1 configure the soft starter to match the connected motor. These parameters describe the motor's operating characteristics and allow the soft starter to model the motor's temperature.
1A – Motor FLC
Range: 5-1000A Default: 100A Description: Matches the starter to the connected motor's full load current. Set to the full load current
1B – Locked Rotor Time
Range: 0:01 - 2:00 (minutes:seconds) Default: 10 seconds Description: Sets the maximum length of time the motor can sustain locked rotor current from cold before
1C – Locked Rotor Current
Range: 400% - 1200% FLC Default: 600% Description: Sets the locked rotor current of the connected motor, as a percentage of full load current.
1D – Motor Service Factor
Range: 100% - 130% Default: 105% Description: Sets the motor service factor used by the thermal model. If the motor runs at full load
2 Start/Stop Modes-1
(FLC) rating shown on the motor nameplate.
reaching its maximum temperature. Set according to the motor datasheet.
Set according to the motor datasheet.
current, it will reach 100%. Set according to the motor datasheet.
Load Defaults Load Backup Load User Set 1
Load Defaults No Yes
2A – Start Mode
Options: Constant Current (Default) Description: Selects the soft start mode.
2B – Start Ramp Time
Range: 0:01 - 3.00 (minutes:seconds) Default: 1 second
Page 26 MVS User Manual 710-13019-00A
Description: Sets the ramp time for current ramp starting (from the initial current to the current limit).
PROGRAMMING MENU
2C – Initial Current
Range: 100% - 600% FLC Default: 400% Description: Sets the initial start current level for current ramp starting, as a percentage of motor full load
current. Set so that the motor begins to accelerate immediately after a start is initiated. If current ramp starting is not required, set the initial current equal to the current limit.
2D – Current Limit
Range: 100% - 600% FLC Default: 400% Description: Sets the current limit for constant current and current ramp soft starting, as a percentage of
motor full load current.
2E – Reserved
Description: This parameter is reserved for future use.
2F, 2G – Kickstart
Parameter 2F
Kickstart Time
Range: 0 – 2000 milliseconds Default: 0000 milliseconds Description: Sets the kickstart duration. A setting of 0 disables kickstart.
Parameter 2G
Kickstart Level
Range: 100% - 700% FLC Default: 500% Description: Sets the level of the kickstart current.
CAUTION Kickstart subjects the mechanical equipment to increased torque levels. Ensure the motor, load and couplings can handle the additional torque before using this feature.
2H – Stop Mode
Options: Coast To Stop (Default)
TVR Soft Stop
Description: Selects the stop mode.
2I – Stop Time
Range: 0:00 - 4:00 (minutes:seconds) Default: 0 seconds Description: Sets the time for soft stopping the motor using timed voltage ramp.
If a main contactor is installed, the contactor must remain closed until the end of the stop time.
3 Auto-Stop
The MVS can be programmed to stop automatically, after a specified delay or at a specified time of day.
WARNING This function should not be used in conjunction with remote two-wire control. The soft starter will still accept start and stop commands from the remote inputs or serial communication network. To disable local or remote control, use parameter 6Q.
3A, 3B – Reserved
Description: These parameters are reserved for future use.
3C, 3D – Auto-Stop
Parameter 3C
Auto-Stop Type
Options: Off (Default) The soft starter will not auto-stop.
Timer The soft starter will auto-stop after a delay from the next
start, as specified in parameter 3D.
Clock The soft starter will auto-stop at the time programmed in
parameter 3D. Description: Selects whether the soft starter will auto-stop after a specified delay, or at a time of day. Parameter 3D
Auto-Stop Time
Range: 00:01 - 24:00 (hours:minutes) Default: 1 minute
710-13019-00A MVS User Manual Page 27
PROGRAMMING MENU
Description: Sets the time for the soft starter to auto-stop, in 24 hour clock format.
4 Protection Settings
These parameters determine when the soft starter's protection mechanisms will activate. The activation point for each protection mechanism can be set to suit the installation.
The soft starter responds to protection events by tripping, warning, or writing the event to the event log. The response is determined by the Protection Action settings (parameter group 16). The default response is a trip.
CAUTION The protection settings are vital for safe operation of the soft starter and motor. Defeating the protection may compromise the installation and should only be done in the case of emergency.
4A, 4B – Excess Start Time
4C, 4D – Undercurrent
4E, 4F – Instantaneous Overcurrent
Excess start time is the maximum time the MVS will attempt to start the motor. If the motor does not transition to Run mode within the programmed limit, the starter will trip. Set for a period slightly longer than required for a normal healthy start. A setting of 0 disables excess start time protection.
Range: 0:00 - 4:00 (minutes:seconds) Default: 20 seconds Description: Parameter 4A sets the time for the primary motor and parameter 4B (
The MVS can be configured to trip if the average current of all three phases drops below a specified level while the motor is running.
Parameter 4C
Range: 0% - 100% Default: 20% Description: Sets the trip point for undercurrent protection, as a percentage of motor full load current.
Parameter 4D
Range: 0:00 - 4:00 (minutes:seconds) Default: 5 seconds Description: Slows the MVS's response to undercurrent, avoiding trips due to momentary fluctuations.
The MVS can be configured to trip if the average current of all three phases exceeds a specified level while the motor is running.
Parameter 4E
Range: 80% - 600% FLC Default: 400% Description: Sets the trip point for instantaneous overcurrent protection, as a percentage of motor full load
Parameter 4F
Range: 0:00 - 1:00 (minutes:seconds) Default: 0 seconds Description: Slows the MVS's response to overcurrent, avoiding trips due to momentary overcurrent
Excess Start Time-2
sets the time for the secondary motor.
Undercurrent
Set to a level between the motor's normal working range and the motor's magnetising (no load) current (typically 25% to 35% of full load current). A setting of 0% disables undercurrent protection.
Undercurrent Delay
Instantaneous Overcurrent
current.
Instantaneous Overcurrent Delay
events.
)
NOTE This protection is only active during run and must be coordinated with
(parameters 4U, 4V).
2
Instantaneous Overcurrent Stage
4G – Phase Sequence
Range: Any sequence (Default)
Positive only Negative only
Description: Selects which phase sequences the soft starter will allow at a start. During its pre-start
checks, the starter examines the sequence of the phases at its input terminals and trips if the
Page 28 MVS User Manual 710-13019-00A
actual sequence does not match the selected option.
PROGRAMMING MENU
4H, 4I – Current Imbalance
The MVS can be configured to trip if the currents on the three phases vary from each other by more than a specified amount. The imbalance is calculated as the difference between the highest and lowest currents on all three phases, as a percentage of the highest current.
Current imbalance detection is desensitised by 50% during starting and soft stopping.
Parameter 4H
Current Imbalance
Range: 10% - 50% Default: 30% Description: Sets the trip point for current imbalance protection. Parameter 4I
Current Imbalance Delay
Range: 0:00 - 4:00 (minutes:seconds) Default: 3 seconds Description: Slows the MVS's response to current imbalance, avoiding trips due to momentary fluctuations.
4J, 4K, 4L – Frequency Trip
The MVS monitors mains frequency throughout operation, and can be configured to trip if the frequency varies beyond a specified tolerance.
Parameter 4J
Frequency Check
Range: Do Not Check
Start Only Start/Run (Default)
Run Only Description: Determines when and if the starter will monitor for a frequency trip. Parameter 4K
Frequency Variation
Range: ± 2 Hz
± 5 Hz (Default)
± 10 Hz
± 15 Hz Description: Selects the soft starter's tolerance for frequency variation. Parameter 4L
Frequency Delay
Range: 0:01 - 4:00 (minutes:seconds) Default: 1 second Description: Slows the MVS's response to frequency disturbances, avoiding trips due to momentary
fluctuations.
NOTE If the mains frequency drops below 35 Hz or rises above 75 Hz, the starter will trip immediately, irrespective of the settings for Frequency Trip parameters.
4M – Restart Delay
Range: 00:01 - 60:00 (minutes:seconds) Default: 10 seconds Description: The MVS can be configured to force a delay between the end of a stop and the beginning of
4N – Motor Temp Check
Range: Do Not Check (Default)
Description: Selects whether the MVS will verify the motor has sufficient thermal capacity for a successful
4O, 4P – Ground Fault Level
The MVS can be configured to trip if ground fault exceeds a specified level while the motor is running. Ground fault is a dynamic trip based on phase current measurements every half-cycle.
Parameter 4O
Ground Fault Level
Range: 1 A - 40 A Default: 10 A Description: Sets the trip point for ground fault protection.
the next start. During the restart delay period, the display shows the time remaining before
another start can be attempted.
Check
start. The soft starter compares the motor's calculated temperature with the temperature
rise from the last motor start and only operates if the motor is cool enough to start
successfully.
710-13019-00A MVS User Manual Page 29
PROGRAMMING MENU
Parameter 4P
Range: 0:01 - 4:00 (minutes:seconds) Default: 3 seconds Description: Slows the starter's response to ground fault variation, avoiding trips due to momentary
4Q, 4R – Undervoltage
The MVS can be configured to trip if the average voltage on all three phases of the mains supply falls below a specified level while the motor is running.
Parameter 4Q
Range: 100 – 18000 V Default: 100 V Description: Sets the trip point for undervoltage protection. Set as required. Parameter 4R
Range: 0:00 – 4:00 (minutes:seconds) Default: 5 seconds Description: Slows the MVS's response to undervoltage, avoiding trips due to momentary fluctuations.
4S, 4T – Overvoltage
The MVS can be configured to trip if the average voltage on all three phases of the mains supply exceeds a specified level while the motor is running.
Parameter 4S
Range: 100 – 18000 V Default: 7200 V Description: Sets the trip point for overvoltage protection.
Parameter 4T
Range: 0:00 – 4:00 (minutes:seconds) Default:5 seconds Description: Slows the MVS's response to overvoltage, avoiding trips due to momentary fluctuations.
4U, 4V – Instantaneous Overcurrent Stage 2
The MVS has two instantaneous trip functions, stage 1 and 2. These protection functions are configured to be complementary.
Stage 1 must be configured to protect the SCR. When Stage 1 triggers, the SCRs continue to conduct current for some time and the starter performs a controlled stop. Stage 1 should trigger at lower current/higher time values than Stage 2.
Stage 2 must be configured to protect the main switching device. When Stage 2 triggers, the starter opens the main switching device.
If the main switching element is a contactor (protected by a fuse), then this function must be coordinated with the fuse to ensure that the contactor does NOT open until the fuse ruptures.
If the main switching element is a breaker, then the delay must be minimised to provide the best possible protection to the SCR.
Parameter 4U
Range: 30 A – 4400 A Default: 4400 A Description: Sets the trip point for instantaneous overcurrent stage 2 protection in amperes. Set as
Parameter 4V
Range: 10 – 1000 ms Default: 10 milliseconds Description: Sets the duration required for current to exceed the level set in parameter 4U before a trip
Ground Fault Trip Delay
fluctuations.
Undervoltage Level
Undervoltage Trip Delay
Overvoltage Level
Set as required.
Overvoltage Trip Delay
Instantaneous Overcurrent S2
required.
Instantaneous Overcurrent Delay S2
occurs. Set as required.
NOTE This protection is active during starting, running and stopping. It must be coordinated with
Overcurrent
(parameters 4E, 4F).
Instantaneous
Page 30 MVS User Manual 710-13019-00A
PROGRAMMING MENU
Example: Contactor and Fuse
Instantaneous Overcurrent Delay Stage 1 (4F)
1
Motor start time
2
Instantaneous Overcurrent Delay Stage 2 (4V)
3
FLC
4
Motor start current
5
Instantaneous Overcurrent Stage 1 (4E)
6
Instantaneous Overcurrent Stage 2 (4U) to trip
7
external upstream breaker
1
Time
2
8
3
9
10
SCR
8
Fuse
9
Thermal model curve
10
4
Current
6 75
07248.D
Shaded area indicates motor operation
Example: Circuit Breaker
1 2 3 4 5 6 7
8
Time
9
C
Current
Shaded area indicates motor operation
5 Auto-Reset Trips (Reserved)
Instantaneous Overcurrent Delay Stage 1 (4F) Motor start time Instantaneous Overcurrent Delay Stage 2 (4V) FLC Motor start current Instantaneous Overcurrent Stage 1 (4E) Instantaneous Overcurrent Stage 2 (4U) to trip
main breaker SCR Thermal model curve
This parameter group is reserved for future use.
6 Inputs
The MVS has two programmable inputs, which allow remote control of the soft starter.
6A – Input A Function
710-13019-00A MVS User Manual Page 31
Options: Motor Set Select (Default) The MVS can be configured with two separate sets of motor
data. To use the secondary motor data, parameter 6A must be set to Mo tor Set Select and C53, C5 4 must be closed when a s ta rt command is given. The MVS checks which motor data to use at a start, and will use that motor data for the entire start/stop cycle.
PROGRAMMING MENU
Description: Selects the function of Input A.
6B – Input A Name
Options: Input Trip (Default) No Flow
Description: Selects a message for the Controller to display when Input A is active.
6C, 6D, 6E – Input A Trip
Parameter 6C
Input Trip (N/O) Input A can be used to trip the soft starter. When parameter
6A is set to Input Trip (N/O), a closed circuit across C53, C54 trips the soft starter. (Refer to parameters 6C, 6D, 6E)
Input Trip (N/C) When parameter 6A is set to Input Trip (N/C), an open circuit
across C53, C54 trips the soft starter. (Refer to parameters 6C, 6D, 6E)
Local/Remote Select Input A can be used to select between local and remote
control, instead of using the LCL/RMT button on the Controller. When the input is open, the starter is in local mode and can be controlled via the Controller. When the input is closed, the starter is in remote mode. The START and LCL/RMT buttons are disabled, and the soft starter will ignore any Local/Remote select command from the serial communications network. To use Input A to select between local and remote control, parameter 6Q must be set to LCL/RMT Anytime or LCL/RMT when Off.
Emergency Run In emergency run the soft starter continues to run until
stopped, ignoring all trips and warnings (refer to parameter 15C for details). Closing the circuit across C53, C54 activates emergency run. Opening the circuit ends emergency run and the MVS stops the motor.
Emergency Stop The MVS can be commanded to emergency stop the motor,
ignoring the soft stop mode set in parameter 2H. When the circuit across C53, C54 is opened, the soft starter allows the motor to coast to stop.
Low Pressure Emergency Stop
High Pressure Controller
Pump Fault PLC
Low Level Vibration Alarm
High Level
Input A Trip
Options: Always Active (Default) A trip can occur at any time when the soft starter is receiving
power.
Operating Only A trip can occur while the soft starter is running, stopping or
starting.
Run Only A trip can only occur while the soft starter is running. Description: Selects when an input trip can occur. Parameter 6D
Input A Trip Delay
Range: 0:00 - 4:00 (minutes:seconds) Default: 0 seconds Description: Sets a delay between the input activating and the soft starter tripping. Parameter 6E
Input A Initial Delay
Range: 00:00 - 30:00 (minutes:seconds) Default: 0 seconds Description: Sets a delay before an input trip can occur, after the soft starter has entered the state selected
in 6C.
6F, 6G, 6H, 6I, 6J – Input B Trip
Parameters 6F~6J configure the operation of Input B, in the same way as parameters 6A~6E configure Input A. Refer to Input A for details.
Input B Function
6F 6G
Page 32 MVS User Manual 710-13019-00A
Input B Name
(Default: Input Trip N/O)
(Default: Input Trip)
6H 6I 6J
Input B Trip
(Default: Always Active)
Input B Trip Delay Input B Initial Delay
(Default: 0:00)
(Default: 0:00)
PROGRAMMING MENU
6K, 6L – Reserved
These parameters are reserved for future use.
6M – Remote Reset Logic
Options: Normally Closed (Default)
Normally Open
Description: Selects whether the MVS's remote reset input (terminals C41, C42) is normally open or
normally closed.
6N, 6O, 6P – Reserved
These parameters are reserved for future use.
6Q – Local/Remote
Options: LCL/RMT Anytime (Default) LCL/RMT selection is always enabled.
LCL/RMT When Off LCL/RMT selection is enabled when the starter is off. Local Control Only The LCL/RMT button and all remote inputs are disabled. Remote Control Only Local control buttons (START, RESET, LCL/RMT) are disabled.
Description: Selects when the LCL/RMT button can be used to switch between local and remote control,
and enables or disables the local control buttons and remote control inputs. The STOP button on the Controller is always enabled.
CAUTION The STOP button on the Controller is always enabled. When using two-wire remote control, the soft starter will restart if the remote start/stop and reset inputs are still active.
6R – Comms in Remote
Options: Disable Ctrl in RMT
Enable Ctrl in RMT (Default)
Description: Selects whether the starter will accept Start, Stop and Reset commands from the serial
communication network when in Remote mode. The Force Comms Trip and Local/Remote commands are always enabled.
7 Outputs
The MVS has three programmable outputs, which can be used to signal different operating conditions to associated equipment.
7A – Relay A Function
Options: Off Relay A is not used.
Main Contactor (DEFAULT) The relay closes when the MVS receives a start command, and
remains closed as long as the motor is receiving voltage. Run The relay closes when the starter changes to run state. Trip The relay closes when the starter trips (refer to parameter 16A
to 16U). Warning The relay closes when the starter issues a warning (refer to
parameter 16A to 16U).
710-13019-00A MVS User Manual Page 33
Low Current Flag The relay closes when the low current flag activates (refer to
parameter 7M
Low Current Flag
, while the motor is running).
High Current Flag The relay closes when the high current flag activates (refer to
parameter 7N
High Current Flag
, while the motor is running).
Motor Temp Flag The relay closes when the motor temperature flag activates
INPUT A TRIP INPUT B TRIP MOTOR OVERLOAD CURRENT IMBALANCE UNDERCURRENT
(refer to parameter 7O
Motor Temperature Flag
The relay closes when Input A activates to trip the soft starter.
The relay closes when Input B activates to trip the soft starter.
The relay closes when the starter trips on Motor Overload.
The relay closes when the starter trips on Current Imbalance.
The relay closes when the starter trips on Undercurrent.
).
PROGRAMMING MENU
Description: Selects the function of Relay A (normally open).
7B, 7C – Relay A Delays
The MVS can be configured to wait before opening or closing Relay A.
Parameter 7B
Range: 0:00 - 5:00 (minutes:seconds) Default: 0 seconds Description: Sets the delay for closing Relay A. Parameter 7C
Range: 0:00 - 5:00 (minutes:seconds) Default: 0 seconds Description: Sets the delay for re-opening Relay A.
7D~7I – Output Relays B and C
Parameters 7D~7I configure the operation of Relays B and C in the same way as parameters 7A~7C configure Relay A. Refer to Relay A for details.
Relay B is a changeover relay.
INST OVERCURRENT
FREQUENCY GROUND FAULT HEATSINK OVERTEMP PHASE LOSS MOTOR THERMISTOR CHANGEOVER CONTACTOR
UNDERVOLTAGE
Relay A On Delay
Relay A Off Delay
The relay closes when the starter trips on Instantaneous
Overcurrent.
The relay closes when the starter trips on Frequency.
The relay closes when the starter trips on Ground Fault.
Not applicable to this product.
The relay closes when the starter trips on Phase Loss.
The relay closes when the starter trips on Motor Thermistor.
The relay closes when the high rotor resistance current ramp
has reached full voltage, allowing use with a slip-ring motor.
The relay closes when the mains voltage drops below the level
set in parameter 4Q.
7D 7E 7F
Relay B Function Relay B On Delay Relay B Off Delay
Default: Run
Default: 0 seconds Default: 0 seconds
Relay C is a changeover relay.
7G 7H 7I
Relay C Function
Relay C On Delay
Relay C Off Delay
Default: Trip
Default: 0 seconds Default: 0 seconds
The following parameters are reserved for future use:
7J ~ 7L
Reserved
7M, 7N – Low Current Flag and High Current Flag
The MVS has low and high current flags to give early warning of abnormal operation. The current flags can be configured to indicate an abnormal current level during operation, between the normal operating level and the undercurrent or instantaneous overcurrent trip levels. The flags can signal the situation to external equipment via one of the programmable outputs. The flags clear when the current returns within the normal operating range by 10% of the programmed motor full load current.
Parameter 7M
Low Current Flag
Range: 1% - 100% FLC Default: 50% Description: Sets the level at which the low current flag operates, as a percentage of motor full load
current.
Parameter 7N
High Current Flag
Range: 50% - 600% FLC Default: 100% Description: Sets the level at which the high current flag operates, as a percentage of motor full load
current.
7O – Motor Temperature Flag
The MVS has a motor temperature flag to give early warning of abnormal operation. The flag can indicate that the motor is operating above its normal operating temperature but lower than the overload limit. The flag can signal the situation to external equipment via one of the programmable outputs.
Page 34 MVS User Manual 710-13019-00A
PROGRAMMING MENU
Range: 0% - 160% Default: 80% Description: Sets the level at which the motor temperature flag operates, as a percentage of the motor's
thermal capacity.
7P, 7Q, 7R, 7S – Analog Output A
The MVS has an analog output, which can be connected to associated equipment to monitor motor performance.
Parameter 7P
Analog Output A
Options: Current (% FLC) (Default) Current as a percentage of motor full load current.
Motor Temp (%) Motor temperature as a percentage of the motor rated
current (calculated by the soft starter's thermal model).
Motor kW (%) Motor kilowatts. 100% is motor FLC (parameter 1A)
multiplied by mains reference voltage (parameter 8N). Power factor is assumed to be 1.0.
3 . V . I
FLC
. pf 1000 Motor kVA (%) Motor kilovolt amperes. 100% is motor FLC (parameter
1A) multiplied by mains reference voltage (parameter 8N).
3 . V . I
FLC
1000 Motor pf Motor power factor, measured by the soft starter. Voltage (% Mains) The average voltage measured on three phases as a
percentage of the mains reference voltage parameter 8N. Description: Selects which information will be reported via Analog Output A. Parameter 7Q
Analog A Scale
Options: 0-20 mA
4-20 mA (Default) Description: Selects the range of the analog output. Parameter 7R
Analog A Maximum Adjustment
Range: 0% - 600% Default: 100% Description: Calibrates the upper limit of the analog output to match the signal measured on an external
current measuring device. Parameter 7S
Analog A Minimum Adjustment
Range: 0% - 600% Default: 0% Description: Calibrates the lower limit of the analog output to match the signal measured on an external
current measuring device.
7T~7W – Reserved
These parameters are reserved for future use.
8 Display
These parameters allow the Controller to be tailored to individual users' requirements.
8A – Language
Options: English (Default)
Chinese Description: Selects which language the Controller will use to display messages and feedback.
8B, 8C – F1 and F2 Button Action
Options: None
Setup Auto-Start/Stop Menu Description: Selects the function of the F1 and F2 buttons on the Controller.
8B
710-13019-00A MVS User Manual Page 35
8C
F1 Button Action
F2 Button Action
Default: SetupAuto-Start/Stop Menu
Default: None
PROGRAMMING MENU
8D – Display A or kW
Options: Current (Default)
Description: Selects whether the MVS will display current (amperes) or motor kilowatts on the main
8E, 8F, 8G, 8H – User-Programmable Screen
Options: Blank Displays no data in the selected area, allowing long messages to be shown
Description: Selects which information will be displayed on the programmable monitoring screen.
Motor kW
monitoring screen.
without overlapping.
Starter State The starter's operating state (starting, running, stopping or tripped). Only
available for top left and bottom left positions on the screen. Motor Current The average current measured on three phases. Motor pf The motor's power factor, measured by the soft starter. Mains Frequency The average frequency measured. Motor kW The motor's running power in kilowatts. Motor HP The motor's running power in horsepower. Motor Temp The motor's temperature, calculated by the thermal model. kWh The number of kilowatt hours the motor has run via the soft starter. Hours Run The number of hours the motor has run via the soft starter. Analog Input Not applicable to this product. Mains Voltage The average voltage measured on three phases.
8E
User Screen - Top Left
8F
User Screen - Top Right
8G 8H
User Screen - Bottom Left User Screen - Bottom Right
8I, 8J, 8K, 8L – Performance Graphs
The MVS has a real-time performance graph to report the behaviour of critical operating parameters.
Parameter 8I
Graph Data
Options: Current (% FLC) (Default) Current as a percentage of motor full load current.
Motor Temp (%) Motor temperature as a percentage of the motor rated current
Motor kW (%) Motor kilowatts. 100% is motor FLC (parameter 1A) multiplied
1000 Motor kVA (%) Motor kilovolt amperes. 100% is motor FLC (parameter 1A)
1000 Motor pf Motor power factor, measured by the soft starter. Voltage (% Mains) The average voltage measured on three phases as a percentage
Description: Selects which information the graph will display. Parameter 8J
Graph Timebase
Options: 10 seconds (Default)
30 seconds 1 minute 5 minutes 10 minutes 30 minutes
1 hour Description: Sets the graph time scale. The graph will progressively replace the old data with new data. Parameter 8K
Graph Maximum Adjustment
Range: 0% – 600% Default: 400% Description: Adjusts the upper limit of the performance graph.
Default: Starter State
Default: Blank
Default: kWh
Default: Hours Run
(calculated by the soft starter's thermal model).
by mains reference voltage (parameter 8N). Power factor is assumed to be 1.0.
multiplied by mains reference voltage (parameter 8N).
of the mains reference voltage parameter 8N.
3 . V . I
3 . V . I
FLC
. pf
FLC
Page 36 MVS User Manual 710-13019-00A
Parameter 8L
Graph Minimum Adjustment
PROGRAMMING MENU
Range: 0% – 600% Default: 0% Description: Adjusts the lower limit of the performance graph.
8M – Current Calibration
Range: 85% - 115% Default:100% Description: Calibrates the soft starter's current monitoring circuits to match an external current metering
device.
Use the following formula to determine the necessary adjustment:
Calibration (%) = Current shown on MVS display Current measured by external device
eg 102% = 66A
65A
NOTE This adjustment affects all current-based functions and protections.
8N – Mains Ref Volt
Range: 100 – 14000 V Default: 400 V Description: Provides the reference voltage for the analog output and performance graphs.
8O – Voltage Calibration
Range: 85% – 115% Default: 100% Description: Adjusts the soft starter's voltage monitoring circuits. The MVS is factory-calibrated with an
accuracy of ± 5%. This parameter can be used to adjust the voltage readout to match an
external voltage metering device. Set as required, using the following formula:
Calibration (%) = Voltage shown on soft starter display
Voltage measured by external device
eg 90% 6000
6600
NOTE This adjustment affects all voltage-based functions.
9 Motor Data-2
The MVS can support two different starting and stopping motor data sets.
To select the secondary motor data set, a programmable input must be configured to parameter set selection (parameters 6A and 6F) and the input must be active when the soft starter receives a start signal.
NOTE You can only choose which motor data set to use while the soft starter is stopped.
9A ~ 9E – Secondary Motor Settings
Parameter 9A
Reserved
This parameter is reserved for future use.
Parameter 9B
Motor FLC-2
Range: 5 - 1000 A Default:100 A Description: Sets the secondary motor's full load current. Parameter 9C
Reserved
Description: This parameter is reserved for future use.
Parameter 9D
Reserved
This parameter is reserved for future use.
710-13019-00A MVS User Manual Page 37
PROGRAMMING MENU
Parameter 9E
This parameter is reserved for future use.
10 Start/Stop-2
10A ~ 8N – Start/Stop-2
Refer to Start/Stop-1 (parameters 2A~2I) for details.
Parameter 10A
Options: Constant Current (Default) Description: Selects the soft start mode. Parameter 10B
Range: 0:01 - 3.00 (minutes:seconds) Default: 1 second Description: Sets the ramp time for current ramp starting (from the initial current to the current limit). Parameter 10C
Range: 100% - 600% Default: 400% Description: Sets the initial start current level for current ramp starting, as a percentage of motor full load
Parameter 10D
Range: 100% - 600% FLC Default: 400% Description: Sets the current limit for constant current and current ramp soft starting, as a percentage of
Parameter 10E
Description: This parameter is reserved for future use. Parameter 10G
Range: 0 - 2000 (milliseconds) Default: 0000 milliseconds Description: Sets the kickstart duration. A setting of 0 disables kickstart. Parameter 10F
Range: 100% - 700% FLC Default: 500% Description: Sets the level of the kickstart current. Parameter 10H
Options: Coast To Stop (Default)
Description: Selects the stop mode. Parameter 8N
Range: 0:00 - 4:00 (minutes:seconds) Default: 0 seconds Description: Sets the stop time.
11 RTD/PT100 (Reserved)
Reserved
Start Mode-2
Start Ramp Time-2
Initial Current-2
current. Set so that the motor begins to accelerate immediately after a start is initiated.
If current ramp starting is not required, set the initial current equal to the current limit.
Current Limit-2
motor full load current.
Reserved
Kickstart Time-2
Kickstart Level-2
Stop Mode-2
TVR Soft Stop
Stop Time-2
This parameter group is reserved for future use.
12 Slip-Ring Motors
These parameters allow the soft starter to be configured for use with a slip-ring motor.
12A, 12B – Motor Data-1 and Motor Data-2 Ramp
Options: Single Ramp (Default)
Dual Ramp Description: Selects whether to use a single or dual current ramp profile for soft starting. Set to single
ramp for non-slip ring induction motors, or dual ramp for slip-ring induction motors.
Parameter 12A selects the ramp configuration for the primary motor and parameter 12B
12C – Changeover Time
Range: 100 - 500 (milliseconds) Default: 150 milliseconds
Page 38 MVS User Manual 710-13019-00A
selects the ramp configuration for the secondary motor.
PROGRAMMING MENU
Description: Sets the delay between the rotor resistance relay closing and the low resistance current ramp
starting. Set so that the contactor has enough time to close, but the motor does not slow
down.
Parameter 12C only applies if parameter 12A or 12B is set to 'Dual Ramp', and an output
relay is set to 'Changeover Contactor'.
12D – Slip-Ring Retard
Range: 10% - 90% Default: 50% Description: Sets the level of conduction while the rotor resistor closes, as a percentage of full conduction.
Set so that no current pulse occurs, but the motor retains enough speed to start correctly.
15 Advanced
15A – Access Code
Range: 0000 - 9999 Default: 0000 Description: Sets the access code to control access to restricted sections of the menus.
Use the and buttons to select which digit to alter and use the and buttons to
change the value. After the last digit is set press STORE.
NOTE In the event of a lost access code, contact your supplier for master access code that allows you to re-program a new access code.
15B – Adjustment Lock
Options: Read & Write
Allows users to alter parameter values in the Programming Menu. (Default) Read Only Prevents users altering parameter values in the Programming Menu.
Parameter values can still be viewed.
Description: Selects whether the Controller will allow parameters to be changed via the Programming
Menu.
15C – Emergency Run
Options: Disable (Default)
Enable
Description: Selects whether the soft starter will permit emergency run operation. In emergency run, the
soft starter will start (if not already running) and continue to operate until emergency run ends, ignoring stop commands and trips. Emergency run is controlled using a programmable input.
16 Protection Action
These parameters define how the soft starter will respond to different protection events. The soft starter can trip, issue a warning, or ignore different protection events as required. All protection events are written to the event log. The default action for all protections is to trip the soft starter.
CAUTION Defeating the protection may compromise the starter and motor, and should only be done in the case of emergency.
16A~16W – Protection Actions
Options: Trip Starter (Default)
Warning & Log Log Only
Description: Selects the soft starter's response to each protection.
16A 16B 16C 16D 16E 16F 16G 16H
710-13019-00A MVS User Manual Page 39
Motor Overload
Excess Start Time
Undercurrent
Instantaneous Overcurrent
Current Imbalance
Frequency
Input A Trip Input B Trip
PROGRAMMING MENU
20 Restricted
These parameters are restricted for Factory use and are not available to the user.
16I 16J 16K 16L 16M 16N
Motor Thermistor Starter Communication
Network Communication
Reserved
Battery/Clock Ground Fault
16O~16U 16V 16W
Undervoltage
Overvoltage
Reserved
Page 40 MVS User Manual 710-13019-00A
Section 7 Commissioning
7.1 Commissioning Menu
The Commissioning Menu provides access to commissioning and testing tools.
To open the Commissioning Menu, press ALT then F2 (Tools) while viewing the metering screens.
The Commissioning Menu is protected by the access code.
The default access code is 0000.
To navigate through the Commissioning Menu:
to scroll to the next or previous item, press the or button. to open an item for viewing, press the button. to return to the previous level, press the button. to close the Commissioning Menu, press repeatedly.
Set Date and Time
To set the date and time:
1. Open the Commissioning Menu.
2. Scroll to the date/time screen.
3. Press the button to enter edit mode.
4. Press the and buttons to select which part of the date or time to edit.
5. Use the and buttons to change the value.
6. To save changes, press the button. The MVS will confirm the changes.
To cancel changes, press the button.
Simulation Tools
COMMISSIONING
Software simulation functions let you test the soft starter's operation and control circuits without connecting the soft starter to mains voltage. The MVS has three simulation modes:
The run simulation simulates a motor starting, running and stopping to confirm that the soft starter and
associated equipment have been installed correctly.
The protection simulation simulates activation of each protection mechanism to confirm that the soft starter and
associated control circuits are responding correctly.
The output signal simulation simulates output signalling to confirm that outputs and associated control circuits
are operating correctly.
The simulation tools are accessed via the Commissioning Menu. The simulations are only available when the soft starter is in Ready state, control voltage is available and the Controller is active.
NOTE Access to the simulation tools is protected by the security access code. The default access code is 0000.
Run Simulation
To use the run simulation:
1. Open the Commissioning Menu.
2. Scroll to Run Simulation and press .
3. Press START or activate the start input.
The MVS simulates its pre-start checks and closes the main contactor (if installed). The Run LED flashes.
NOTE If the Mains voltage is connected an error message is shown. Remove the Mains voltage and proceed to next step.
Run Simulation Ready Apply Start Signal
Run Simulation Pre-Start Checks STORE to Continue
Run Simulation ATTENTION! Remove Mains Volts STORE to Continue
710-13019-00A MVS User Manual Page 41
COMMISSIONING
4. Press . The MVS simulates starting. The Run LED flashes.
5. Press . The MVS simulates running. The Run LED stays on without
flashing and the bypass contactor closes (if installed)
6. Press STOP or activate the stop input. The MVS simulates stopping. The
Run LED flashes and the bypass contactor opens (if installed)
7. Press . The Ready LED flashes and the main contactor opens (if installed)
8. Press to return to the commissioning menu.
.
Protection Simulation
NOTE Run simulation can be exited at any stage by pressing the .
Run Simulation Starting X:XXs STORE to Continue
Run Simulation Running Apply Stop Signal
Run Simulation Stopping X:XXs STORE to Continue
Run Simulation Stopped STORE to Continue
The protection simulation simulates activation of each protection mechanism to confirm that the soft starter and associated control circuits are responding correctly.
To use the protection simulation:
1. Open the Commissioning Menu.
2. Scroll to Protection Simulation and press .
3. Use the and buttons to select the protection you want to
simulate.
4. Press and hold to simulate the selected protection.
5. The screen is displayed momentarily. The soft starter's response
depends on the Protection Action setting (parameter group 16).
0.0A Tripped Selected Protection
6. Use or to select another simulation, or press to return to
the commissioning menu.
NOTE If the protection trips the soft starter, reset before simulating another protection. If the protection action is set to 'Warning & Log', no reset is required.
If the protection is set to 'Warning & Log', the warning message can be viewed only while the STORE button is pressed.
If the protection is set to 'Log only', nothing appears on the screen but an entry will appear in the log.
Output Signal Simulation
The output signal simulation simulates output signalling to confirm that outputs and associated control circuits are operating correctly.
NOTE To test operation of the flags (motor temperature and low/high current), set an output relay to the appropriate function and monitor the relay's behaviour.
To use the output signal simulation:
Page 42 MVS User Manual 710-13019-00A
1. Open the Commissioning Menu.
2. Scroll to Output Signalling Simulation and press .
3. Use the and buttons to select a function to simulate, then press
.
4. Use the and buttons to turn the signal on and off.
To confirm correct operation, monitor the state of the output.
5. Press to return to the simulation list.
COMMISSIONING
Prog Relay A Off On
Analog Output Simulation
The analog output simulation uses the and buttons to change the analog output current at terminals B10, B11 of the Controller.
Analog Output 0% 4 mA
Attach an external current measuring device to terminals B10, B11 of the Controller. Use the or button to adjust the percentage value in the lower left hand corner of the display. The current measuring device should indicate the same level of current as shown at the lower right corner of the display.
Temperature Sensors State
This screen shows the state of the motor thermistors and RTD/PT100s.
Temp Sensors State Thermistor: O
RTDs A–>G:OOOOOOO
NOTE The use of RTDs is not supported by this product and this screen will always indicate Open = o.
Digital I/O State
This screen shows the current status of the digital inputs and outputs.
S = shrt H=hot C=cld O=opn
Digital I/O State Inputs: 1000000
The top line of the screen shows the start, stop, reset and programmable inputs A and B, then '00'. The screen shows input C23~C24 closed with all other inputs open.
The bottom line of the screen shows programmable output A, the fixed Run output, programmable outputs B and C, then '000'. The screen shows all outputs open.
Analog I/O State
Outputs: 0000000
This screen shows the current status of the Analog I/O
Analog I/O State Input: - - - - %
NOTE Input is not supported by this product and this screen will always indicate Input: - - - - %
Reset Thermal Models
The MVS's advanced thermal modelling software constantly monitors the motor's performance. This allows the MVS to calculate the motor's temperature and ability to start successfully at any time.
The thermal model for the active motor can be reset if required.
1. Open the Commissioning Menu..
2. Scroll to Reset Thermal Models and press .
3. At the confirmation prompt press STORE to confirm or to
cancel the action. You may have to enter your access code.
710-13019-00A MVS User Manual Page 43
Reset Thermal Models M1 X% M2 X%
Output A: 04.0mA
COMMISSI
O
Whe
f
w
o
Whe
then
a
l
a
O
n
m
-
-
t
s
h
t
r
t
t
t
t
p
t
s
t
n WARN
o
a
V
f
T
a
r
n
a
r
u
n
h
e
o
C
C
s
g
f
e
k
t
s
a
n
d
a
o
o
p
u
s
e
s
e
u
c
o
m
n
o
r
b
i
h
o
o
u
f
t
t
d
e
t
p
nt
s
o
r
n
a
m
m
t
p
p
o
g
s
s
e
r
n
e
e
a
r
e
s
0
r
d
t
e
t
y
b
e
e
e
o
o
h
t
n
e
o
A
3
e
d
NING
4.
con
7.2 Lo
1.
2.
Select Reset Selecting Do
en the therma
irmation mess
CAUTI Resetti emerge
Voltage
Clip asse non non
he of t (on arm The fron Pass
hro
he it to grad the
he
he
nd press .
Not Reset ret
model has be
ge then retur
N
g the motor t
ncy.
Test Mod
one end of th
bly to the b conduction P conduction P
ide of the pha
e long round he left hand si
when viewed
e is a small ste of the PCB. the other end
ugh the phase
hree grading r
the steel brac
ing resistor on
hase arm (thi
ame as the br
on-conductio
rns to previo
en reset, the s
to the previ
ermal model
resistor
lt on the
B. The B is located o
e arm, at the t
rading resisto
de of the phas
rom the back)
el bracket just
of the assem
arm, in front o
sistors, and cl
et in front of t
he other side
bracket looks
cket in front PCB).
s screen.
reen will displ
us screen.
may compro
n
p
e
.
in
ly
f
ip
e
f
f
Res
ay a
ise motor life
Store to Res
t Thermal M
Do Not Rese
Reset
nd should onl
t
odels
y be done in t
e case of
perate the M
To
1.
Isolate the so Connect one
2.
Connect T1,
3.
of the soft st Set paramete
4.
Switch on co
5.
Controller or Stop and rest
6.
en testing is co
remove cont
After l phase assemb
ING
w voltage mo rm before con lies remain on
S in low volt
t starter from non-conducti
2, T3 of the s
rter to three
1A
Motor F
trol and main via the remot
rt the motor
mplete, isolate
ol voltage. R
e testing, ens
necting the so
he phase arm
ge test mode:
he motor an
n resistor ass
ft starter to a
hase mains su
ll Load Curre
supply, and u
input. Monito
everal times t
the soft starte
move the no
re that the no
t starter to a
s, the soft star
the mains su
mbly to each
hree phase m
ply with volta
to the value e the MVS to r the soft start
confirm cor
r from the mai
-conduction r
n-conduction
edium voltag
er may suffer
ply.
hase arm. tor with full lo
e less than 5
hown on the
tart the moto
r's display an
ect and consis
s supply. Dis
sistor assemb
esistor assem
motor. If th
evere damag
ad current of 5 0 VAC (frequ
motor name p
. The start c verify the line ent operation.
onnect the s
ly from each p
ly is removed
non-conduc
.
~ 20 A. Co
ncy 50 Hz or late. mmand can b
current and v
ft starter from
hase arm.
from each
ion resistor
nect L1, L2, L
60 Hz).
sent from th ltage readings
the motor an
.
Page 44
MVS User Manu
l
710-13019-00
Section 8 Maintenance Tools
8.1 Logs Menu
The Logs Menu provides information on events, trips and starter performance.
To open the Logs Menu, press ALT then F1 (LOGS) while viewing the metering screens.
To navigate through the Logs Menu:
to open a log, press the button. to scroll through the entries in each log, press the and buttons.
to view details of a log entry, press the button. to return to the previous level, press the button. to close the Logs Menu, press repeatedly.
Trip Log
Logs
MAINTENANCE TOOLS
ALT
Alt
Tools
F1 (LOGS)
The Trip Log stores details of the eight most recent trips, including the date and time the trip happened. Trip 1 is the most recent and trip 8 is the oldest stored trip.
To open the Trip Log:
1. Open the Logs Menu.
2. Scroll to Trip Log and press .
3. Use the and buttons to select a trip to view, and press to display details.
4. Use the and buttons to scroll through available details.
To close the log and return to the main display, press repeatedly.
Event Log
The Event Log stores time-stamped details of the starter's 99 most recent events (actions, warnings and trips), including the date and time of the event. Event 1 is the most recent and event 99 is the oldest stored event.
To open the Event Log:
1. Open the Logs Menu.
2. Scroll to Event Log and press .
3. Use the and buttons to select an event to view, and press to display details.
To close the log and return to the main display, press repeatedly.
Performance Counters
The performance counters store statistics on the starter's operation:
Hours run (lifetime and since counter last reset) Number of starts (lifetime and since counter last reset) Motor kWh (lifetime and since counter last reset) Number of times the thermal model has been reset
The resettable counters (hours run, starts and motor kWh) can only be reset if the Adjustment Lock (parameter 15B) is set to Read & Write.
To view the counters:
1. Open the Logs Menu.
2. Scroll to Counters and press .
3. Use the and buttons to scroll through the counters. Press to view details.
710-13019-00A MVS User Manual Page 45
MAINTENANCE TOOLS
4. To reset a counter, press STORE (enter access code if required) then use the button to select Reset. Press
STORE to confirm the action.
To close the counters and return to the main display, press the repeatedly.
Page 46 MVS User Manual 710-13019-00A
Section 9 Operation
CAUTION We recommend testing the soft starter's setup on a low voltage motor before beginning operation on a medium voltage motor. This allows the operator to test that the soft starter is correctly connected to the auxiliary equipment.
9.1 Using the Soft Starter to Control a Motor
To soft start the motor, press the START button on the Controller or activate the Start remote input. The motor will start using the start mode selected in parameter 2A.
To stop the motor, press the STOP button on the Controller or activate the Stop remote input. The motor will stop using the stop mode selected in parameter 2H.
To reset a trip on the soft starter, press the RESET button on the Controller or activate the Reset remote input.
To emergency stop the motor, press the local STOP and RESET buttons at the same time. Alternatively, one of the programmable inputs can be configured for emergency stop (parameters 6A and 6F). The soft starter will remove power from the motor and open the main contactor, and the motor will coast to stop.
9.2 Using the MVS to Control a Slip-Ring Motor
The MVS can be used to control a slip-ring motor, using rotor resistance.
1
t1 t2 t3
OPERATION
2
V1
V2
3
S
1
S2 S3 S4
P1 P2 P3
1 Sub-states 3 States t1 Main contactor close time t2 Rotor resistance contactor close time t3 Bypass contactor close time 2 Output voltage
S1 Ready S2 Pre-start tests S3 Starting
S4 Running V1 100% voltage 4 Phases of operation V2 Slip-ring retard voltage
P1 Start command
P2 Rotor resistance current ramp
P3 Shorted rotor current ramp
Commissioning
03986.C
1. Configure the MVS as follows:
Parameter settings:
Parameter 7A
Relay A Function
Select 'Changeover Contactor'
Parameter 7B
Relay A On Delay
Set this to the maximum time (5m:00s).
Parameter 12A
Motor Data-1 Ramp
Select 'Dual Ramp' (for slip-ring induction motor control)
Parameter 12C
710-13019-00A MVS User Manual Page 47
Changeover Time
OPERATION
S
d
2. Start the motor under normal load conditions and record the time it takes to reach a constant speed with external
3. Start the motor under normal load conditions and monitor the motor speed behaviour and motor current when the
Default setting is 150 milliseconds. Set this to a value just greater than the changeover contactor (KM3)
pole closing time.
Parameter 12D
Slip Ring Retard
Default setting is 50%. Set this parameter to a value which is high enough to cause the motor to instantly
accelerate once the rotor resistance (R1) has been bridged out and low enough to avoid a motor current pulse.
rotor resistance (R1) in the circuit. Stop the motor soon after a constant speed has been reached. Change parameter 7B to the recorded time value.
changeover contactor (KM3) switches in to short-out the rotor resistance (R1) If the motor does not start to accelerate immediately after changeover, increase the setting of parameter 12D. If there is a pulse in motor current immediately after changeover, reduce the setting of parameter 12D.
1 R1 Constant Speed
2 First ramp 3 Second ramp
3
4 Run mode (I < 120% FLC) 5 Parameter 7B 6 KM3 closes 7 Parameter 12C
pee
Time
NOTE For this installation to function correctly, only use the primary motor settings. Only use the constant current start method (parameter 2A
Start Mode
).
Page 48 MVS User Manual 710-13019-00A
OPERATION
Slip-Ring Motor Connection
KM2
KM1
1
220~240VAC
+10
-15
A1
L1
L2
L3 E
A3A2
A1 A2
3
A3
F1
A11 A12
A11 A12
C23 C24 C31
S1
S2
C32 C41 C42
C53 C54 C63 C64
B4 B5
A4
6
5
7 8
4
TX RX
RX TX
T1
T1B
T2
T2B
T3
T3B
C73 C74
KM2
13
14 23 24 33 34
(Bk)(Wh)
(Wh)(Bk)
43 44 54
KM3
52
51 64 62
61
B10
+
B11
-
3
M
2
R1
KM3
A1 Power assembly A4 Controller
1 3 Phase 50/60 Hz Supply 5 Remote control inputs KM1 Main contactor KM2 Bypass contactor
2 To motor R1 Rotor Resistance KM3 Changeover contactor
C23~C24 Start C31~C32 Stop C41~C42 Reset C53~C54 Programmable input A C63~C64 Programmable input B
A2 Control voltage terminals 6 Programmable outputs
3 Control supply
43, 44 Output Relay A functionality = rotor resistance
changeover
A3 Power interface PCB
4 Relay outputs
51, 52, 54 Programmable Relay output B
61, 62, 64 Programmable Relay output C C73~C74 Bypass contactor feedback signal 7 Motor thermistor input 13~14 Main contactor KM1 8 Analog output 23~24 Bypass contactor KM2 33~34 Run output contactor
710-13019-00A MVS User Manual Page 49
OPERATION
9.3 Operating States
Start and Run States
The MVS soft starter has six operating states, and performs the following actions in each state:
a d
b
c fe
321 4 65
1 2
7717.A
State Starter actions
1 Not ready Control power is on and the starter performs system checks. The starter may be waiting
for the motor to cool before allowing a start. 2 Ready The starter is initialised and waiting for a start command. 3 Pre-start checks A start command has been received (a). The main contactor closes (b) and the starter
performs connection checks. 4 Starting The starter ramps the SCRs up to full conduction and closes the bypass contactor (c). 5 Running The motor is running normally. 6 Stopping A stop command has been received (d). The starter opens the bypass contactor (e), ramps
the SCRs down to no conduction, then opens the main contactor (f).
Trip States
The starter's response to a trip depends on the starter's state when the trip occurs.
Trip while starting (bypass contactor not yet closed)
State Function Not Ready Perform system checks. Ready Wait for start command. Start command received Main contactor closes. Pre-start checks Perform connection checks. Starting Ramp up SCR firing angles. Trip command Turn SCRs off then open main contactor. Tripped Wait for reset command. Reset command received Trip cleared and starter returns to Not Ready state or Ready state.
Trip while running (bypass contactor closed)
State Starter action Not Ready Perform system checks. Ready Wait for start command. Start command received Main contactor closes. Pre-start checks Perform connection checks. Starting Ramp up SCR firing angles. Full conduction SCRs at 100% conduction. Verify current is < 120% FLC then close bypass contactor. Running Normal motor run state (bypassed mode). Trip command Open bypass contactor. Turn SCRs off then open main contactor. Tripped Wait for reset command. Reset command received Trip cleared and starter returns to Not Ready or Ready state.
Instantaneous Overcurrent Stage 2 trip
The main contactor opens immediately, regardless of the starter's state.
Page 50 MVS User Manual 710-13019-00A
9.4 Motor Protection
Motor, System and Soft Starter Protection Mechanisms
The MVS incorporates extensive protection features to ensure safe operation of the motor, system and soft starter. Most protection features can be customised to suit the installation. Use parameter group 4 to control the situation where the protections will activate and parameter group 16 to select the soft starter's response. The default response is to trip the soft starter.
Protection Coordination
Check protection settings on the supply side of the starter to ensure correct discrimination with the soft starter.
When using fuse and main contactors, set the breaker current parameters to coordinate with the fuse and contactor. The contactor must not open if the current is above its maximum value. The fuse must act first or the upstream breakers instantaneous trip level must be less than the contactor's fault break current level.
If using breakers only, set breaker so that the maximum instantaneous trip time is < 150 ms.
Voltage must not be continuously maintained on the phase arms while the motor is off. Short circuit protective equipment must be installed in all cases.
Motor Overload Protection
The MVS offers thermal model motor overload protection which monitors the performance of the motor and calculates its temperature in all states. This protection is based on the motor information programmed in parameter groups 1 and 9, and the thermal model adjusts itself according to the motor's recent operating history (including temperature rise from previous operation).
OPERATION
3
4
Time
04013.C
1
Current
Motor Thermal Model Protection Set-up
To enable motor and starter protection using the motor thermal model, the soft starter must be programmed with accurate information on the motor's characteristics.
1. Set parameters 1B
Locked Rotor Time
motor datasheet.
2. Use instantaneous overcurrent protection (parameters 4E, 4F) to provide protection for locked rotor situations.
Refer to individual parameters for details.
3. Use instantaneous overcurrent protection stage 2 (parameters 4U, 4V) to trip circuit breaker or main contactor in the
event of extreme overcurrent situations.
9.5 Operating Feedback
5
1: Motor service factor 2: Locked rotor current 3: Motor failure curve 4: Motor thermal model protection curve 5: Typical motor operating current
2
, 1C
Locked Rotor Current
and 1D
Motor Service Factor
according to the
Displays
The Controller displays a wide range of performance information about the soft starter. The top half of the screen shows real-time information on current or motor power (as selected in parameter 8D). Use the and buttons to select the information shown on the bottom half of the screen.
Starter status User programmable screen
710-13019-00A MVS User Manual Page 51
OPERATION
Starter Status
The starter status screen shows details of the starter's operating status, including motor current, power and temperature..
Motor temperature Current Motor power Voltage Last start information Date and time Performance graphs SCR conduction
NOTE Screens shown here are with the default settings.
0A Ready M1 000% 00000kW
Programmable screen
The MVS's user-programmable screen can be configured to show the most important information for the particular application. Use parameters 8E to 8H to select which information to display.
0A Ready 0A 00000 kWh 00000hrs
Motor Temperature
The temperature screen shows which motor data set is in use, and the temperature of the motors as a percentage of total thermal capacity.
0A Primary Motor Set
M1 000% M2 000%
NOTE M2 xxx% temperature is not applicable to this product.
Current monitoring screen
The current screen shows real-time line current on each phase.
0A Phase currents (Gnd Crnt XX.XA) 0000A 0000A 0000A
Motor Power
The motor power screen shows motor power (kW, HP and kVA) and power factor.
0A 00000kW 00000HP 00000kVA -. - - pf
Voltage
The voltage screen shows real-time line voltage across each phase.
Page 52 MVS User Manual 710-13019-00A
OPERATION
0A Line Voltages 00000 00000 00000
Last Start Information
The last start information screen shows details of the most recent successful start:
start duration (seconds) maximum start current drawn (as a percentage of motor full load current) calculated rise in motor temperature
0A Last start 000 s
000 % FLC Temp 0%
Date and Time
The date/time screen shows the current system date and time (24 hour format). For details on setting the date and time, refer to
Set Date and Time
0A
on page 41.
YYYY MMM DD HH:MM:SS
Performance Graph
The performance graph provides a real-time display of operating performance. Use parameters 8I~8L to select which information to display.
0000 A 0%-400%
SCR Conduction Bargraph
The SCR conduction bargraph shows the level of conduction on each phase.
L1 Cond
L2 Cond
L3 Cond
10166.A
710-13019-00A MVS User Manual Page 53
TROUBLESHOOTING
Section 10 Troubleshooting
The MVS provides extensive information to help the operator diagnose and remedy any operating difficulties.
In addition to the motor and load protection features already described, the MVS reports in detail on the starter's own state. Any internal failure will cause the soft starter to trip, and full details will be recorded in the trip log and event log.
10.1 Protection Responses
When a protection condition is detected, the MVS will write this to the event log and may also trip or issue a warning. The soft starter's response to some protections may depend on the Protection Action settings (parameter group 16).
Some protection responses cannot be adjusted by the user. These trips are usually caused by external events (such as phase loss) or by a fault within the soft starter. These trips do not have associated parameters and cannot be set to Warn or Log.
If the MVS trips you will need to identify and clear the condition that triggered the trip, then reset the soft starter before restarting. To reset a the starter, press the RESET button on the Controller or activate the Reset remote input.
If the MVS has issued a warning, the soft starter will reset itself once the cause of the warning has been resolved.
10.2 Trip Messages
This table lists soft starter's protection mechanisms and the probable cause of the trip. Some of these can be adjusted using parameter group 4 protections and cannot be set or adjusted.
Protection Settings
and parameter group 16
Protection Action
, other settings are built-in system
Error Message Possible cause/Suggested solution
Assy Power Low
Control voltage to the power interface PCB has dropped below the required level. Check that the control voltage transformer and control circuit fuses are healthy, and that voltage is present at the terminal block (terminals A1-A2 or A2-A3) within the specified range. This trip is not adjustable.
Battery/clock
A verification error has occurred on the real time clock, or the backup battery voltage is low. If the battery is low and the power is off, date/time settings will be lost. Reprogram the date and time. Related parameters: 16M
Bypass fail (bypass contactor)
The bypass contactor has welded closed or is not operating correctly. There may be a problem with the control circuit or the contactor coil. Check the condition of the bypass contactor's main poles. Check the operation of the contactor control circuitry and contactor coil. This trip is not adjustable.
NOTE You can use the Run Simulation to check the bypass contactor's operation without mains voltage connected.
Cond 1 Invalid Cond 2 Invalid Cond 3 Invalid
There is a problem with the SCR firing or feedback system.
Check that the fibre-optic cables between the power interface PCB and the gate drive
adaptor PCBs are properly connected.
The value of the grading resistor may not be suitable for the nominal mains voltage. If you
are using a low voltage motor for testing purposes, contact your local supplier for advice.
This trip is not adjustable.
Control Volts Low
Control voltage to the Controller has dropped below the required level. Check that the control voltage transformer and control circuit fuses are healthy, and that voltage is present at terminals A11, A12 within the specified range. This trip is not adjustable.
Current imbalance
Current imbalance can be caused by problems with the motor, the environment or the installation, such as:
An imbalance in the incoming mains voltage A problem with the motor windings A light load on the motor A phase loss on input terminals L1, L2 or L3 during Run mode An SCR that has failed open circuit. A failed SCR can only be definitely diagnosed by
replacing the SCR and checking the starter's performance. If you have recently replaced or repaired a phase arm, the connector at the back of the phase arm may not be securely plugged into the connector on the body of the power assembly.
Page 54 MVS User Manual 710-13019-00A
Remove the securing bolts and slide the phase arm out, then slide it back in firmly. Ensure
the connectors on the PCBs meet properly then retighten the bolts. There may be an open circuit SCR gate lead, or damage to the SCR gate.
Check the SCR gate connections (check at the SCRs and at the firing PCB). Consult your
local supplier for details of the SCR gate testing procedure. Related parameters: 4H, 4I, 16E
Current Reading
Excess start time
Frequency (Mains supply)
Gate Drive Fail
Ground fault
Input A trip
Input B trip
Instantaneous overcurrent
Int Comms Fail
Internal fault X
L1 phase loss L2 phase loss L3 phase loss
There is an error in the current monitoring circuit. Check the connections between the power interface PCB and the current transformers. If the connections are all sound, there may be a fault in the power interface PCB. Contact your local supplier for advice. This trip is not adjustable.
The motor was unable to accelerate to full speed in the time allowed. Excess start time trip can occur in the following conditions:
parameter 1A parameter 2D parameter 2B
setting
The motor may have experienced an abnormal increase in loading or might be jammed.
Related parameters: 1A, 2A-2D, 4A, 16B The mains frequency has gone beyond the specified range.
Check for other equipment in the area that could be affecting the mains supply (particularly variable speed drives and switch mode power supplies (SMPS). If the MVS is connected to a generator set supply, the generator may be too small or could have a speed regulation problem. Related parameters: 4J, 4K, 4L, 16F
There is a problem with the SCR gate drive.
Check that the fibre-optic cables are properly connected between:
1. the power interface PCB and the gate drive adaptor PCBs and
2. the gate drive PCB and gate current firing PCBs.
Check the supply to the gate drive adaptor PCBs, gate drive PCB and gate circuit firing PCBs. There may be a fault with the gate drive adaptor PCBs, gate drive PCB or gate circuit firing
PCBs. Contact your local supplier for advice. This trip is not adjustable.
Ground current (monitored through a dedicated current transformer) has exceeded the selected level. Test the insulation of the output cables and the motor. Identify and resolve the cause of any ground fault. Related parameters: 4O, 4P, 16N
Identify and resolve the condition which caused Input A to activate. Related parameters: 6A, 6B, 6C, 6D, 6E, 16G
Identify and resolve the condition which caused Input B to activate. Related parameters: 6F, 6G, 6H, 6I, 6J, 16H
The motor has experienced a sharp rise in motor current, probably caused by a locked rotor condition (shearpin) while running. This may indicate a jammed load. A trip may also occur when a medium level fault current has been detected. This may indicate a system short circuit. Related parameters: 4E, 4F, 4U, 4V, 16D
Communication has failed between the Controller and the power interface PCB.
Check that the Controller is receiving control voltage within the specified range (terminals
A11, A12).
Check that the fibre-optic cables between the Controller and the interface PCB are firmly
connected.
Check that each fibre-optic cable is emitting light at the Rx end.
This trip is not adjustable. The MVS has tripped on an internal fault. Contact your local supplier with the fault code (X).
Related parameters: None During pre-start checks the starter has detected a phase loss as indicated.
In run state, the starter has detected that the current on the affected phase has dropped below
3.3% of the programmed motor FLC for more than 1 second, indicating that either the incoming phase or connection to the motor has been lost. Check the supply and the input and output connections at the starter and at the motor end.
Motor Full Load Current
Current Limit
Start Ramp Time
is not appropriate for the motor
has been set too low
has been set greater than the setting for 4A
TROUBLESHOOTING
Excess Start Time
710-13019-00A MVS User Manual Page 55
TROUBLESHOOTING
L1-T1 shorted L2-T2 shorted L3-T3 shorted
Motor connection
Motor overload (thermal model)
Motor thermistor
Network communication (between module and network)
Overvoltage
Parameter out of Range
Phase sequence
Power loss
Starter communication (between module
Phase loss can also be caused by a failed SCR, particularly an SCR that has failed open circuit. A failed SCR can only be definitely diagnosed by replacing the SCR and checking the starter's performance. Related parameters: None
During prestart checks the starter has detected a shorted power assembly or a short within the bypass contactor as indicated. This trip is not adjustable.
There is a problem with the soft starter's connection to the motor. If only one phase is affected, the error message will indicate which phase (T1, T2, T3).
Ensure the motor is connected to terminals T1, T2, T3 using in-line (three wire) connection.
The MVS does not support inside delta (six wire) connection.
Check that the fibre-optic cables between the power interface PCB and the gate drive
adaptor PCBs are firmly connected.
Check each output phase of the soft starter for power circuit continuity.
This trip will also occur when there is a phase imbalance across the soft starter’s input terminals L1, L2, L3. Related parameters: None
The motor has reached its maximum thermal capacity. Overload can be caused by:
The soft starter protection settings not matching the motor thermal capacity Excessive starts per hour Excessive throughput Damage to the motor windings
Resolve the cause of the overload and allow the motor to cool. If you think the soft starter has tripped incorrectly, check the parameter settings. Related parameters: 1A, 1B, 1C, 1D, 9B, 16A
The external resistance across the motor thermistor input (terminals B4, B5) has exceeded 2.4 kΩ.
If the starter tripped at power-up, no thermistor is present at terminals B4, B5. If you are not
using a thermistor, you must attach a link across terminals B4-B5.
If the starter tripped during operation, the temperature of the motor winding has increased.
Resolve the cause of the overheating. Related parameters: 16I
The network master has sent a trip command to the starter, or there may be a network communication problem. Check the network for causes of communication inactivity. Related parameters: 16K
There has been a voltage surge on the mains. Causes can include problems with a transformer tap regulator or off-loading of a large transformer load.
Check that the starter is configured appropriately for local conditions. Monitor the mains voltage to determine the cause of the voltage fluctuation, and resolve the
cause. Related parameters: 4S, 4T, 16W
An error occurred loading data from the EEPROM to RAM when the Controller powered up. The parameter set or values in the Controller do not match the parameters in the starter. "Load User Set" has been selected but no saved file is available.
Reset the fault and then reload the default settings. If the problem persists, contact your local distributor. Related parameters: None
The phase sequence on the soft starter's input terminals (L1, L2, L3) is not valid. Check the phase sequence on L1, L2, L3 and ensure the setting in parameter 4G is suitable for the installation. Related parameters: 4G
The starter is not receiving mains supply on one or more phases when a Start Command is given.
Check that the main contactor closes when a start command is given, and remains closed until
the end of a soft stop.
Check MVS fuses and confirm that all three mains supply phases are present.
This trip is not adjustable. There could be a problem with the connection between the soft starter and the optional
communications module. Remove and reinstall the module. If the problem persists, contact your local distributor. The communications module has been powered down while the soft starter remains powered up.
Page 56 MVS User Manual 710-13019-00A
and soft starter) Synch A Missing
Synch B Missing
Related parameters: 16J The voltage detection system has failed. The voltage dividing resistors (located between L1, L2,
L3 and the power interface PCB) have failed or the power interface PCB may be faulty. Contact your local supplier for advice.
TROUBLESHOOTING
This trip is not adjustable.
Undercurrent
The motor has experienced a sharp drop in current, caused by loss of load. Causes can include broken components (shafts, belts or couplings), or a pump running dry. Related parameters: 4C, 4D, 16C
Undervoltage
Mains voltage has fallen below the level selected in parameter 4Q. Causes can include an undersized supply or adding a large load to the system.
Check that the starter is configured appropriately for local conditions. Monitor the mains voltage to determine the cause of voltage fluctuation.
Related parameters: 4Q, 4R, 16V
Unsupported Option
Contact your local supplier for advice.
LED locations
The non-conduction and firing LEDs are located on the power interface PCB. The non-conduction LEDs should dim during starting, and should be off when the bypass contactor closes. The firing LEDs should be on during starting, and off just before the bypass contactor closes and the soft starter enters run mode.
The gate drive adaptor, gate drive and gate drive firing PCBs are located on individual phase arm power assemblies.
1 Firing LEDs (Red)
2 Non-conduction LEDs (Green)
10.3 General Faults
This table describes situations where the soft starter does not operate as expected but does not trip or give a warning.
Symptom Probable Cause Starter "Not Ready"
The soft starter does not respond to the START or RESET button on the Controller.
1
2
03994.D
3
3 Gate Drive PCB's, Gate Drive Adaptor PCB's and Gate
Drive Firing PCB's
Check Input A (C53, C54). The emergency stop function may be active. If
parameter 6A or 6F is set to Emergency Stop and there is an open circuit on the corresponding input, the MVS will not start.
The soft starter may be in Remote control mode. When the soft starter is in
Remote control mode, the Local LED on the starter is off. Press the LCL/RMT button once to change to Local control.
710-13019-00A MVS User Manual Page 57
TROUBLESHOOTING
The soft starter does not respond to commands from the control inputs.
The soft starter does not respond to a start command from either the local or remote controls.
Motor does not reach full speed.
Erratic motor operation.
Soft stop ends too quickly.
Remote start/stop command is overriding Auto Start/Stop settings when using remote 2-wire control.
Parameter settings cannot be stored.
The soft starter may be in Local control mode. When the soft starter is in
Local control mode, the Local LED on the starter is on. Press the LCL/RMT button once to change to Remote control.
The control wiring may be incorrect. Check that the remote start, stop and
reset inputs are configured correctly (refer to
Control Wiring
for details).
The signals to the remote inputs may be incorrect. Test the signalling by
activating each input signal in turn. The appropriate remote control input LED should activate on the starter.
The soft starter will only execute a start command from the remote inputs if
the remote stop and reset inputs are closed.
The soft starter may be waiting for the restart delay to elapse. The length of
the restart delay is controlled by parameter 4M
Restart Delay
The motor may be too hot to permit a start. If parameter 4N
Temperature Check
is set to Check, the soft starter will only permit a start
.
Motor
when it calculates that the motor has sufficient thermal capacity to complete the start successfully. Wait for the motor to cool before attempting another start.
The emergency stop function may be active. If parameter 6A or 6F is set to
Emergency Stop and there is an open circuit on the corresponding input, the MVS will not start. If the emergency stop situation has been resolved, close the circuit on the input.
NOTE Parameter 6Q
Local/Remote
controls when the LCL/RMT button is
enabled.
If the start current is too low, the motor will not produce enough torque to
accelerate to full speed. The soft starter may trip on excess start time.
NOTE Make sure the motor starting parameters are appropriate for the application and that you are using the intended motor starting profile. If parameter 6A or 6F is set to Motor Set Select, check that the corresponding input is in the expected state.
The load may be jammed. Check the load for severe overloading or a locked
rotor situation.
The SCRs in the MVS require at least 5 A of current to latch. If you are testing
the soft starter on a motor with full load current less than 5 A, the SCRs may not latch correctly.The SCRs in the MVS require at least 5 A of current to latch. If you are testing the soft starter on a motor with full load current less than 5 A, the SCRs may not latch correctly.
The soft stop settings may not be appropriate for the motor and load.
Review the settings of parameters 2H, 2I, 10H and 10I.
If the motor is very lightly loaded, soft stop will have limited effect. Auto Start/Stop function should only be used in Remote mode, 3 and 4-wire
control.
Make sure you are saving the new value by pressing the STORE button after
adjusting a parameter setting. If you press EXIT, the change will not be saved.
Check that the adjustment lock (parameter 15B) is turned off. If the
adjustment lock is on, settings can be viewed but not changed. You need to know the security access code to change the adjustment lock setting.
The EEPROM may be faulty on the Controller. A faulty EEPROM will also trip
the soft starter, and the Controller will display the message Parameter Out Of Range. Contact your local supplier for advice.
Page 58 MVS User Manual 710-13019-00A
Section 11 Appendix
11.1 Parameter Defaults
If you require assistance from your supplier or a service technician, please note all parameter settings in the table below.
1 Primary Motor Settings User Set 1 User Set 2 Default 1A 1B 1C 1D 2 Start/Stop Modes-1 2A 2B 2C 2D 2E 2F 2G 2H 2I 3 Auto-Start/Stop 3A 3B 3C 3D 4 Protection Settings 4A 4B 4C 4D 4E 4F 4G 4H 4I 4J 4K 4L 4M 4N 4O 4P 4Q 4R 4S 4T 4U 4V 5 Auto-Reset Trips (Reserved) 5A 6 Inputs 6A 6B 6C 6D 6E 6F 6G
Motor Full Load Current Locked Rotor Time Locked Rotor Current Motor Service Factor
Start Mode Start Ramp Time Initial Current Current Limit Reserved Kickstart Time Kickstart Level Stop Mode Stop Time
Reserved Reserved Auto-Stop Type Auto-Stop Time
Excess Start Time Excess Start Time-2 Undercurrent Undercurrent Delay Instantaneous Overcurrent Instantaneous Overcurrent Delay Phase Sequence Current Imbalance Current Imbalance Delay Frequency Check Frequency Variation Frequency Delay Restart Delay Motor Temperature Check Ground Fault Level Ground Fault Delay Undervoltage Undervoltage Delay Overvoltage Overvoltage Delay Instantaneous Overcurrent S2 Instantaneous Overcurrent Delay S2
Reserved
Input A Function Input A Name Input A Trip Input A Trip Delay Input A Initial Delay Input B Function Input B Name
100 A 00m:10s 600% FLC 105%
Constant current 00m:01s 400% FLC 400% FLC
0 ms 500% FLC Coast to stop 00m:00s
Off 00h:01m
00m:20s 00m:20s 20% FLC 00m:05s 400% FLC 00m:00s Any sequence 30% 00m:03s Start/Run ±5 Hz 00m:01s 00m:10s Do not check 10 A 00m:03s 100 V 00m:05s 7200 V 00m:05s 4400 A 10 ms
Motor set select Input trip Always active 00m:00s 00m:00s Input trip (N/O) Input trip
APPENDIX
710-13019-00A MVS User Manual Page 59
APPENDIX
6H 6I 6J 6K 6L 6M 6N 6O 6P 6Q 6R
Input B Trip Input B Trip Delay Input B Initial Delay Reserved Reserved Remote Reset Logic Reserved Reserved Reserved Local/Remote Comms in Remote
7 Outputs 7A 7B 7C 7D 7E 7F 7G 7H 7I 7J 7K 7L 7M 7N 7O 7P 7Q 7R 7S 7T 7U 7V 7W
Relay A Function Relay A On Delay Relay A Off Delay Relay B Function Relay B On Delay Relay B Off Delay Relay C Function Relay C On Delay Relay C Off Delay Reserved Reserved Reserved Low Current Flag High Current Flag Motor Temperature Flag Analog Output A Analog A Scale Analog A Maximum Adjustment Analog A Minimum Adjustment Reserved Reserved Reserved Reserved
8 Display 8A 8B 8C 8D 8E 8F 8G 8H 8I 8J 8K 8L 8M 8N 8O
Language F1 Button Action F2 Button Action Display A or kW User Screen - Top Left User Screen - Top Right User Screen - Bottom Left User Screen - Bottom Right Graph Data Graph Timebase Graph Maximum Adjustment Graph Minimum Adjustment Current Calibration Mains Reference Voltage Voltage Calibration
9 Motor Data-2 9A 9B 9C 9D 9E
Reserved Motor FLC-2 Reserved Reserved Reserved
Always active 00m:00s 00m:00s
Normally closed (N/C)
LCL/RMT anytime Enable control in
remote
Main contactor 00m:00s 00m:00s Run 00m:00s 00m:00s Trip 00m:00s 00m:00s
50% FLC 100% FLC 80% Current (%FLC) 4-20 mA 100% 0%
English Setup auto-start/stop None Current Starter state Blank kWh Hours run Current (%FLC) 10 seconds 400% 0% 100% 400 V 100%
100 A
Page 60 MVS User Manual 710-13019-00A
10 Start/Stop Modes-2 10A 10B 10C 10D 10E 10F 10G 10H 10I
Start Mode-2 Start Ramp-2 Initial Current-2 Current Limit-2 Reserved Kickstart Time-2 Kickstart Level-2 Stop Mode-2 Stop Time-2
11 RTD/PT100 (Reserved) 11A
Reserved
12 Slip-Ring Motors 12A 12B 12C 12D
Motor Data-1 Ramp Motor Data-2 Ramp Changeover Time Slip Ring Retard
15 Advanced 15A 15B 15C
Access Code Adjustment Lock Emergency Run
16 Protection Actions 16A 16B 16C 16D 16E 16F 16G 16H 16I 16J 16K 16L 16M 16N 16O 16P 16Q 16R 16S 16T 16U 16V 16W 20 Restricted
Motor Overload Excess Start Time Undercurrent Instantaneous Overcurrent Current Imbalance Frequency Input A Trip Input B Trip Motor Thermistor Starter Communication Network Communication Reserved Battery/Clock Ground Fault Reserved Reserved Reserved Reserved Reserved Reserved Reserved Undervoltage Overvoltage
11.2 Accessories
Constant current 00m:01s 400% FLC 400% FLC
0 ms 500% FLC Coast to stop 00m:00s
Single ramp Single ramp 150 ms 50%
0000 Read and write Disable
Trip starter Trip starter Trip starter Trip starter Trip starter Trip starter Trip starter Trip starter Trip starter Trip starter Trip starter
Trip starter Trip starter
Trip starter Trip starter
APPENDIX
Communication Modules
MVS soft starters support network communication using the Profibus, DeviceNet, Modbus RTU and USB protocols, via an easy-to-install communications module.
Installing Communication Modules
Communication modules attach to the back of the Controller:
710-13019-00A MVS User Manual Page 61
APPENDIX
Modbus Module
Part Number: PIM-MB-01
The Modbus Module enables control and monitoring via a Modbus RTU network.
Refer to the Modbus Module Instructions for further details.
Profibus Module
Part Number: PIM-PB-01
The Profibus Module enables control and monitoring via a Profibus network.
Refer to the Profibus Module Instructions for further details.
DeviceNet Module
Part Number: PIM-DN-01
The DeviceNet Module enables control and monitoring via a DeviceNet network.
Refer to the DeviceNet Module Instructions for further details.
USB Module
Part Number: PIM-USB-01
The USB Module enables connectivity to the WInMaster software suite.
Refer to the USB Module Instructions for further details.
Trip Codes (Serial Communication Network)
Description Profibus
Modbus RTU DeviceNet
DP Excess start time 1 1 101 Motor overload 2 2 20 Motor thermistor 3 3 75 Current imbalance 4 4 26 Frequency 5 5 55 Phase sequence 6 6 54 Instantaneous overcurrent 7 7 28 Power loss 8 8 50 Undercurrent 9 9 29 Motor connection 11 11 102 Input A trip 12 12 11 Starter communication (between module and soft starter) 15 15 113 Network communication (between module and network) 16 16 114 Internal error 17 17 104 Overvoltage 18 18 52 Undervoltage 19 19 51 Ground fault 20 20 27
Page 62 MVS User Manual 710-13019-00A
APPENDIX
EEPROM fail 23 23 62 Input B trip 24 24 110 Bypass fail 25 25 105 L1 phase loss 26 26 23 L2 phase loss 27 27 24 L3 phase loss 28 28 25 L1-T1 shorted 29 29 115 L2-T2shorted 30 30 116 L3-T3 shorted 31 31 117 Battery/Clock 35 35 121 Miscellaneous n/a n/a 70 No trip 255 255 0
PC Software
WinMaster is a purpose-designed software suite for control and monitoring a soft starter. WinMaster is compatible with all AuCom soft starter ranges and is ideal for parameter management during commissioning. WinMaster has the following features:
Operational control (Start, Stop, Reset, Quick Stop) Starter status monitoring (Ready, Starting, Running, Stopping, Tripped) Performance monitoring (motor current, motor temperature) Upload parameter settings Download parameter settings
To use WinMaster with the MVS, the soft starter must be fitted with a USB Module (PIM-USB-01) or a Modbus Module (PIM-MB-01).
Other MVS Accessories
Other accessories available to enhance your MVS starter include:
RTD protection relay Motor protection relay (external to MVS) Power meter Indication lamps Start, stop and reset pushbuttons Local/remote selector switch Internal panel light for low voltage section Panel heater Power supply and contactor for motor heater Control transformers Metering VT MV/LV control supply transformer
NOTE Other accessories may be available on request.
R Rated Protection Fuses
If specified, R Rated protection fuses can be installed on the supply side of the soft starter to provide Type 2 coordination and short circuit protection for the motor branch circuit. The appropriate fuse should be selected from the table below, based on the motor's rated full load current. MVS models V02 ~ V07 must be installed with fuses.
Fuse ratings:
Starter Rated FLC Fuse
80 A 6R 159 A 12R 230 A 18R 321 A 24R
710-13019-00A MVS User Manual Page 63
APPENDIX
500 A –­600 A 400RC315*
* two fuses in parallel
Fuse type code formats:
System Voltage
2.3 kV
System Voltage
3.3 ~ 4.2 kV
System Voltage
6 ~ 7.2 kV
Ferraz A240Rrr A480Rrr-1 A072xxDxRO-rr
Bussmann JCK-x-rr JCL-x-rr JCR-x-rr
Siba – 400RC315* 400RC315*
* two fuses in parallel rr = R rating of the fuse x = physical format of the fuse (select according to installation requirements)
Examples:
6R fuse for 2.3 kV: A240R6R or JCK-A-6R 12R fuse for 3.3 kV: A480R12R-1 or JCL-B-12R 18R fuse for 6.6 kV: A072B1DARO-18R or JCR-B-18R
Power Factor Correction
NOTE Do not connect power factor correction capacitors to the output of MVS soft starters. If static power factor correction is employed, it must be connected to the supply side of the soft starter.
Power factor correction capacitors should be selected based on the motor data and the required final power factor.
If power factor correction capacitors are being used, select a contactor according to the required kVAr. The contactor must be connected on the supply side of the soft starter. The power factor correction capacitor contactor coil is associated with output terminals 33, 34 of the soft starter's Interface PCB.
Line Inductors
Output line inductors are required if the cable run between the soft starter and the motor is greater than 200 m. Line inductors should be installed outside the panel, between the soft starter output (terminals T1, T2, T3) and the motor. Contact your local supplier for selection details.
Transient/ Overvoltage Protection
Overvoltage protection should be installed if there is a risk of high voltage transients at the installation. Contact your local supplier for details.
Control Supply Transformer (PT/VT)
The MVS requires a low voltage control supply. If low voltage is not available, a transformer is required. Use a transformer with primary voltage matching the MV mains voltage, and secondary voltage to suit the MVS starter. Use a single phase 500 VA transformer with protection fuses on both the primary and secondary sides.
11.3 Maintenance
Maintenance Schedule
The table below lists the minimum maintenance requirements. Your maintenance program may include more frequent maintenance. In certain environmental conditions (such as dusty or humid environments), increase the frequency of maintenance to every year.
Part Instructions Timing Control terminals Check tightness Every 2 years Earthing terminals Check tightness Every 2 years Cable lugs Check tightness Every 2 years General MVS Cleanliness Every 2 years
Tools required
MVS starters can be serviced with the following tools:
Page 64 MVS User Manual 710-13019-00A
APPENDIX
Allen keys (standard metric) 16 mm spanners 16 mm socket Torque wrench <20 Nm Torx drive screwdriver #20 Small flat bladed screwdriver 3 mm Multimeter MV Insulation tester
Thermal Image
After completing commissioning of the MVS and after the motor has been running fully loaded, take a thermal image of the bus bars and other critical parts.
As part of the maintenance program, compare a recent thermal image with the post-commissioning image.
Perform the usual inspection for dust and debris.
710-13019-00A MVS User Manual Page 65
APPENDIX
Page 66 MVS User Manual 710-13019-00A
APPENDIX
710-13019-00A MVS User Manual Page 67
APPENDIX
Page 68 MVS User Manual 710-13019-00A
7 1 0 - 1 3 0 1 9 - 0 0 A
È710-13019-00A%ËÍ
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
