Quick Reference Guide For
Partner II R2 – System Programming
System Programming – From extension 10 (MLS-12D or MLS-34D) dial Feature 00,
then press the Left Intercom button 2 times to enter System Programming. The
numbers in parentheses after the program item heading are the factory default values. To
end the System Programming session dial Feature 00.
System Date (010100) System Day (1)
Dial #101 Dial #102
Dial date (MMDDYY) Dial day (1-7, 1=Sun, 7=Sat)
System Time (0000) Number of Outside Lines
Dial #103 Dial #104
Dial time (HHMM) in 24-hour format Dial number of lines (01-24)
Transfer Return Rings (4) PBX Dial-Out Code (9)
Dial #105 Dial #106
Dial return rings (0-9), 0=No return Dial dial-out code (0-9)
Recall Timer (18=450msec) Rotary Dial Timeout (2)
Dial #107 Dial #108
Dial recall interval (01-80) 1=4 sec, 2=8 sec, 3=12 sec
Each increment of 1 = 25msec
Outside Conference Denial (1) Dial Mode (1)
Dial #109 Dial #201
1=Allowed, 2=Disallowed Dial line number (01-24)
1=Touchtone, 2=Rotary
Hold Disconnect Timer (1) Line Assignment
Dial #203 Dial #301
Dial line number (01-24) Dial extension (10-57)
1=Long (450msec), 2=Short (50ms) Dial line number (01-24)
1=Assigned, 2=Not assigned
3=Select button
Line Access Restriction Language (1)
Dial #302 Dial #303
Dial extension (10-57) 1=English, 2=Spanish, 3=French
Dial line number (01-24)
1=No restriction, 2=Out only,
3=In only, 4=No access
Page 1 of 6
Quick Reference Guide For
Partner II R2 – System Programming
Automatic Extension Privacy (2) Abbreviated Ring (1)
Dial #304 Dial #305
Dial extension (10-57) Dial extension (10-57)
1=Assigned, 2=Not assigned 1=Active, 2=Not active
Transfer Return Extension(*) Copy Settings
Dial #306 Dial #399
Dial extension (10-57) Dial source extension (10-57)
Dial extension to which a transferred Dial target extension (10-57)
call will be returned (10-57)
* = Extension transferring call
Outgoing Call Restriction (1) Toll Call Prefix (1)
Dial #401 Dial #402
Dial extension (10-57) 1= 0/1 + Area Code,
1=No restriction, 2=Inside only, 3=Local only 2=Area Code only
System Password Disallowed Phone Number List
Dial #403 Dial #404
Dial 4 digits to set password Dial list number (1-4)
Dial list entry (01-10)
Dial phone number (12 digits max.)
Press Enter
Disallowed List Assignment (2) Emergency Phone Number List
Dial #405 Dial #406
Dial extension (10-57) Dial list entry (01-10)
Dial list number (1-4) Dial phone number (12 digits max.)
1=Assigned, 2=Not assigned Press Enter
Allowed Phone Number List Allowed List Assignment (2)
Dial #407 Dial #408
Dial list number (1-4) Dial extension (10-57)
Dial list entry (01-10) Dial list number (1-4)
Dial phone number (12 digits max.) 1=Assigned, 2=assigned
Press Enter
Pickup Group Extensions (2) Calling Group Extensions (2)
Dial #501 Dial #502
Dial extension (10-57) Dial extension (10-57)
1=Assigned, 2=Not assigned 1=Assigned, 2=Not assigned
Page 2 of 6
Quick Reference Guide For
Partner II R2 – System Programming
Night Service Button (Extension 10 Only) (2) Night Service Group (2)
Dial #503 Dial #504
1=Assigned to next available button w/lights Dial extension (10-57)
2=Not assigned 1=Assigned, 2=Not assigned
3=Press a button with lights to custom assign
Fax Extension (2) Music-On-Hold (1)
Dial #601 Dial #602
Dial extension (10-57) 1=Active, 2=Not active
1=Assigned, 2=Not assigned
Hotline Doorphone 1 Extension
Dial #603 Dial #604
Dial hotline extension (11-57) Dial extension (12-15, 18-21, 24-27,
Dial alerted extension (10-57, or 70 for page) 30-33, 36-39, 42-45, 48-51, 54-57)
Doorphone 2 Extension Doorphone Alert Extensions (1)
Dial #605 Dial #606
Dial extension (12-15, 18-21, 24-27, Dial extension (10-57)
30-33, 36-39, 42-45, 48-51, 54-57) 1=No Alert, 2=Door 1 Alert,
3=Door 2 Alert, 4=Door 1&2 Alert
Attendant/VMS Extensions (2) SMDR Record Type (1)
Dial #607 Dial #608
Dial extension (10-57) 1=All calls, 2= Outgoing calls only
1=Assigned, 2=Not assigned
SMDR Top Of Page System Reset
Dial #609 Dial #728
All calls disconnected,
All programming saved
System Initialization
Dial #989
Display “Restart – Defaults”
Dial 25327 (CLEAR)
System returned to factory default
Page 3 of 6
Quick Reference Guide For
Partner II R2 – Centralized Programming
Centralized Programming – From extension 10 (MLS-12D or MLS-34D) dial Feature
00, press the Left Intercom button 2 times, then press the Right Intercom button 1 time
to enter Centralized Programming. The following station features can only be changed
in Centralized Programming. To program another extension, press the Right Intercom
button. Dial Feature 00 to end the programming session.
Automatic Line Selection (Do this procedure first before programming other features)
Dial extension (10-57)
Dial **
Touch line buttons in the order of desired selection. (To select intercom dial tone, touch
the Left Intercom button first, then touch line buttons in the order of desired selection.)
Dial ** to end
Line Ringing
Dial extension (10-57)
Observe the green lights for each line assigned to the extension.
Immediate Ring = Steady light
Delayed Ring = Slow flashing light
No Ring = Fast fluttering light
Press each line button until the desired ring option is set.
Page 4 of 6
Quick Reference Guide For
Partner II R2 – Station Features
To program a feature to a station button follow one of the following procedures:
Station Programming (At the station being programmed)
Dial Feature 00
Press the button to be programmed
Press the Feature button, then dial a feature code listed below
Program another button, or Dial Feature 00 to end
Centralized Programming (At extension 10 only)
Dial extension (10-57) to be programmed
Press the button to be programmed
Press the Feature button, then dial a feature code listed below
Program another button, or dial Feature 00 to end
Feature Codes
*Do Not Disturb = 01
Exclusive Hold = 02
Recall (Flash) = 03
Saved Number Redial = 04
Last Number Redial = 05
Conference Drop = 06
*Privacy = 07
Touchtone Enable = 08
Message Light On = 09
Message Light Off = 10
**Call Forwarding/Call Follow Me = 11
* = Requires a button with lights
** = Button with lights recommended
Additional Features
Enter Station Programming, or Centralized Programming
Press button to be programmed
Call Pickup Individual = Press Left Intercom, dial 6, dial extension (10-57)
Call Pickup Group = Press Left Intercom, dial 66, dial group (1-4)
Direct Line Pickup – Active Line = Press Left Intercom, dial 68
Direct Line Pickup – Idle Line = Press Left Intercom, dial 8
Group Calling - Ring (Internal) = Press Left Intercom, dial 7, dial group (1-4)
Group Hunting – Ring = Press Left Intercom, dial 77, dial hunt group (1-6)
Group Hunting – Voice = Press Left Intercom, dial *77, dial hunt group (1-6)
Group Paging – Voice (Internal) = Press Left Intercom, dial *7, dial group (1-4)
Loudspeaker Paging = Press Left Intercom, dial 70
Page 5 of 6
Quick Reference Guide For
Partner II R2 – Auto/Speed Dialing
Auto Dial – Inside (Station DSS/BLF)
Enter Station Programming, or Centralized Programming
Press the button to be programmed
Press the Left Intercom button
Dial an extension (10-57)
Note: Dial * before the extension to make this a voice call instead of a ringing call
Auto Dial – Outside
Enter Station Programming, or Centralized Programming
Press the button to be programmed
Dial outside phone number (Up to 20 digits including special dialing characters)
Personal Speed Dial
Enter Station Programming, or Centralized Programming
Press the Feature button
Dial a 2-Digit Code (80-99)
Dial outside phone number (Up to 20 digits including special dialing characters.)
System Speed Dial (Note: NOT Done In System Programming)
At extension 10, Dial Feature 00
Press Feature followed by a 2-digit speed dial code (20-79)
Dial phone number (Up to 20 digits including special dialing characters.
Special Dialing Characters
Touchtone Enable = Press Transfer button
Stop Dialing = Press Mic button
Pause (1.5 seconds) = Press Hold button
Recall (Flash) = Press Spkr button
Restriction Override = Dial * before the phone number
Dial Feature 00 to end
J & J Communications
770-795-5462 or 888-552-6665
www.jandjcommunications.com
Page 6 of 6
