Installation

You must install and charge
the battery before using the
telephone.

Install the telephone base close to a telephone jack and a power outlet not
controlled by a wall switch. The telephone base can be placed on a flat surface
or vertically mounted on the wall. For optimum range and better reception,
place the telephone base in a central and open location.

If you subscribe to high-speed Internet service (digital subscriber line ­DSL) through your telephone line, you must install a DSL filter between
the telephone line cord and the telephone wall jack (see page 3). The filter
prevents noise and caller ID problems caused by DSL interference. Please
contact your DSL service provider for more information about DSL filters.

Your product may be shipped with a protective sticker covering the handset or
telephone base display - remove it before use.

For customer service or product information, visit our website at

STOP!

See pages 5-6
for easy instructions.

www.telephones.att.com or call 1 [phone]. In Canada, dial
1 [phone].

Avoid placing the telephone base too close to:

Communication devices such as: television sets, VCRs, or other cordless

•
telephones.

Excessive heat sources.

•
Noise sources such as a window with traffic outside, motors, microwave

•
ovens, refrigerators, or fluorescent lighting.

Excessive dust sources such as a workshop or garage.

•
Excessive moisture.

•
Extremely low temperature.

•
Mechanical vibration or shock such as on top of the washing machine or

•
workbench.

1

Backup batteries installation and use

In the event of a power failure, your telephone can still operate with limited
functions if there are backup batteries (purchased separately) installed in the
telephone base. If a power failure happens during a call on the corded handset,
the call continues (at the lowest volume) until you hang up; while a call on the
cordless handset or speakerphone disconnects immediately.

During a power failure, you can still make and answer calls using the corded
handset. However, you cannot make or answer calls on the cordless handset or
speakerphone.

If power resumes while you are on a call, the call continues and the telephone
resets once you hang up.

Follow the steps below to install backup batteries.

1. Make sure the telephone line cord
and power adapter cord are not
connected to the telephone base.

2. Press the tab on the base battery
cover (on the bottom of the
telephone base) toward the cover
and swing open the battery door.

3. Insert three new AAA alkaline
batteries, matching the + and

- signs engraved on the telephone
base.

4. Replace the backup battery cover
onto the telephone base; the
cover clicks into place when it is

Battery compartment tab

attached properly.

During a power failure, if the backup batteries are installed, the telephone
base displays CHECK AC POWER.

BASE

CHECK AC POWER

NOTES:

1. With backup batteries, the base ringer and the handset listening volume will be at the lowest setting.

2. We recommend changing the batteries every nine months.

2

Telephone base installation

Install the telephone base as shown below.
The telephone base is ready for tabletop use. If you want to change to wall

mounting, see the user’s manual for details.

7. Plug the large end
of the power adapter
into a power outlet
not controlled by a
wall switch.

6. Plug the other
end of the
telephone line
cord into a
telephone jack or
a DSL filter.

5. Raise the
antenna.

If you have DSL high
speed Internet service,
a DSL filter (not
included) is required.

1. Plug the small end of the
power adapter into the
power jack on the bottom
of the telephone base.

2. Plug one end of the
telephone line cord
into the telephone
jack on the bottom of
the telephone base.

3. Plug the other
end of the coiled
handset cord
into the jack at
the left of the
telephone base.

4. Place the cords into
the channels.
