Techn olo gie s
Atop Technologies, Inc.
Industrial Wireless Serial Device Server
SW550xC Series
Hardware Installation Guide
Version 1.1
Updated on Feb,2014
F.G
ANT1
Good
Fair
Poor
P2P
Tx Rx
COM1
WLAN
COM
RUN
LAN
V+
Good
Fair
SAB
Poor
ON
12 3
P2P
P2P
COM
Tx Rx
COM1
ON
1 2 3
COM2
WLAN
RUN
COM
RUN
LAN
Reset
Tel: 886-3-5508137
Fax: 886-3-5508131
www.atop.com.tw
P/N: 89900469G
V-
ANT1
P2P
RUN
Reset
F.G
V-
V+
SAB
ON
12 3
COM1
ON
1 2 3 4 5 6
COM2
Installation Overview
The device’s appearance is as in the figure below.
If you have purchased the wall mount kit, proceed
1.
to place the screws on the back of the device as
shown in (Fig. 1).
Although internal grounding has been done
2.
inside, in order to ensure overall maximum
performance and protect your device it is still
strongly advised to link this point to the ground as
well; hazardous ESD can come into contact with
it and damage your equipment.
On the power terminal block, there is a terminal
for Frame Ground, you can choose whether to
connect it to the grounding or you may opt to
connect to the grounding screw next to the
terminal block (the one chosen should be
connected at all times) (Fig. 2)
Proceed then to fix the antenna to the female
3.
RP-SMA connectors deemed to, (Fig. 3)
You can then choose whether to plug in the I/O
ports at this point or do it later depending on the
actual location of the device or level of comfort for
performing such operation.
Once the plate has been firmly put in place,
4.
proceed to mount the whole device as shown in
(Fig. 4).
ANT1
Good
Fair
SAB
Poor
ON
P2P
P2P
COM
Tx Rx
COM1
WLAN
RUN
COM
RUN
LAN
Reset
(Fig. 3)
F.G
V-
V+
123
ON
1 2 3
Proceed to (Fig. 5) if you want to
remove the device from DIN-Rail.
Next we can then proceed to
5.
(Fig. 4) (Fig. 5)
connect the device to the LAN
(switch or PC, depending on the case), take care on using the RJ-45
connector; after this we can then proceed to the device’s settings.
SW5501C provides one serial port with D-sub(M) or 5-pin terminal
6.
block, please select one of them.
■
The openings to the sides are for the
device’s heat dissipation, please never
obstruct or cover them with any objects.
■
SW550xC’s factory IP by default is
10.0.50.100 you can access the device by
its Web UI once it is connected to a
physical network (or using Serial Manager,
for more information on Serial Manager,
please refer to its user’s manual). Please
be aware that the PC needed for this
procedure needs to be in the same
subnet, or you may refer yourself to the
User’s Manual.
(Fig. 1)
(Fig. 2)
F.G.
V-
V+
Field Maintenance and Service
If the device requires servicing of any kind, you may need to disconnect
and remove it from its mounting. The initial installation should be done
in a way that makes this as convenient as possible.
■
Voltage/Power lines should be properly insulated as well as other
cables. Be careful when handling them so as to not trip over.
■
Do not under any circumstance insert foreign objects of any kind into
the heat dissipation holes located in the different faces of the device.
This may not only harm the internal layout but might cause harm to
you as well.
■
Do not under any circumstance open the device for any reason.
Please contact your dealer for any repair needed or follow the
instructions on section of your User’s manual.
Pin Assignments
9-pin D-sub Connector for RS-232/422/485
1 2 3 4 5
6 7 8 9
Pin RS-232
DCD
1
RXD
2
TXD
3
DTR
4
SG
5
DSR
6
RTS
7
CTS
8
RI
9
RS-422 / 4-Wire RS485
(Full Duplex)
N/A
TXD+
RXD+
N/A
SG
N/A
RXD-
TXD-
N/A
5-pin Terminal Block for RS-232/422/485
5 4 3 2 1
Pin RS-232
SG
1
RTS
2
TxD
3
CTS
4
RxD
5
RS-422 / 4-Wire RS485
(Full Duplex)
SG
R-
R+
T-
T+
P2P Button
Pressing seconds
Working mode
1~3(s)
Restart connection
RS-485 / 2-Wire RS485
(Half Duplex)
N/A
N/A
DATA+
N/A
SG
N/A
DATA-
N/A
N/A
RS-485 / 2-Wire RS485
(Half Duplex)
SG
DATA-
DATA+
N/A
N/A
4~7(s)
AP
8~(s)
AP client
Package Check List
Inside the package you will find the following items:
Descriptions DescriptionsQty
Industrial W ireless Serial Device Server SW550x C
3dBi antenna
3-Pin 5.08mm Lockable Terminal Block
5-Pin 5.08mm Lockable Terminal Block
5-Pin 5.08mm Lockable Terminal Block
(for SW550C2 -TB / SW550C2-Sis)
Din Rail Kit
1 1
(Already moun ted to the de vice)
1
Installation Guide
Warranty Card
1
1
CD (User’s Manual / Insta llation
Guide / Serial Manager Utili ty)
2
Optional Accessories
Item Description
AD17-24C (US-Y)
Power Adapter
AD17-24D (EU-Y)
Power Adapter
ADP-DB9(F)-TB5
Y-Type power adaptor,100-240VAC input,
0.6A @ 24VDC output, US plug
Y-Type power adaptor,100-240VAC input,
0.6A @ 24VDC output, EU plug
Female DB9 to Female 3.81mm TB5 Converter
WMK-454-Black Black Aluminum Wall Mount Kit
DIP Switch
SW5501C
COM
COM1
SW5502C
COM
COM1
COM2
Dip Function SW Ω
3
2
1
Pull High
Pull Low
Termination
On
Off
On
Off
On
Off
Dip Function SW Ω
6
5
4
3
2
1
Pull High
Pull Low
Termination
Pull High
Pull Low
Termination
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
Qty
1
1
1
1K
100K
1K
100K
120
N/A
1K
100K
1K
100K
120
N/A
1K
100K
1K
100K
120
N/A
LED Indicators
Name
COM
LAN
WLAN
RUN
P2P
Color
Green
Orange
Green
Green
Green
Orange
Green
Status
Blinking
Off
Blinking
On
Off
Blinking
On
Off
On
Blinking
Off
Off
Blinking Steadily
Blinking Rapidly
On
Blinking
On
Blinking
Signal LEDs
Operations
Searching for an AP
Connecting
Connected
Cannot connected to the AP
No IP provided by the DHCP
Server
Poor Signal Strength 30%
Fair Signal Strength(31-60%)
Good Signal Strength(61-100%)
Description
Data transmitting on the serial port
Data is not transmitting on the serial port
Data is transmitting on Ethernet
Ethernet is connected on 100Mbps
Ethernet is disconnected on 100Mbps
Data is transmitting on Ethernet
Ethernet is connected on 10Mbps
Ethernet is disconnected on 10Mbps
Wireless Radio is enabled
Wireless Radio is enabled and data is transmitting
Wireless Radio is disabled
System is not powered on
AP firmware is running normally
AP firmware is not running
WPS connected
WPS is connecting at Wi-Fi Direct Go mode
WPS connected
WPS is connecting at client mode
off ●on ☼blinking
○
Poor Fair Good
☼
☼
☼
☼
☼
☼
●
●
●
●
●
●
Device Dimensions,
Physical Appearance and Mounting
Proceed to mount the SW550xC in a dry location free from dirt and
corrosive vapors, for more questions on environmental limitations
please refer to the User’s manual.
■
Unit Dimensions and Layout (unit=mm)
The Industrial Wireless Serial Device Server and dimensions are
shown below.
Front View
SW5501C
F.G.
V-
V+
Left Side View Right Side View
SW5502C-TB SW5502C
Rear ViewTop and Bottom View
Warranty Policy
Warranty Conditions
Products supplied by Atop Technologies are covered in this warranty for
sub-standard performance or defective workmanship. The warranty is
not, however, extended to goods damaged in the following
circumstances:
(a) Excessive forces or impacts
(b) War or an Act of God: wind storm, fire, flood, electric shock,
earthquake
(c) Use of unqualified power supply, connectors, or unauthorized
parts/kits
(d) Replacement with unauthorized parts
RMA and Shipping Costs Reimbursement
Customers shall always obtain an authorized "RMA" number from Atop
before shipping the goods to be repaired to Atop. When in normal use,
a sold product shall be replaced with a new one within 3 months after
purchase. The shipping cost from the customer to Atop will be
reimbursed by Atop.
After 3 months and still within the warranty period, it is up to Atop
whether to replace the unit with a new one; normally, as long as a
product is under warranty, all parts and labor are free of charge to the
customers.
After the warranty period, the customer shall cover the cost for parts
and labor.Three months after purchase, the shipping cost from the
customer to Atop will not be reimbursed, but the shipping cost from
Atop to the customer will be paid by Atop.
Limited Liability
Atop shall not be held responsible for any consequential losses from
using Atop’s product.
Warranty Period
Product Categories
Ethernet Switches
Wireless
Serial Device Servers
Modbus Gateways
Embedded Device Servers
DIN-Rail Power Supplies
Power Adaptors
Antennas
Other Accessories
Warranty
5 Years
3 Years
1 Year
The warranty certification will not be effective until an authorized stamp
issued by Atop’s overseas agents.
Purchase Date: / / (yyyy/mm/dd)
Serial Number:
Atop Customer Services and Supports
1. Please contact your local dealers or Atop Technical Support Center at
the following numbers.
+ 886-3-550-8137 (Atop Taiwan)
+ 86-21-6495-6232 (Atop China)
2. Please report the defected problems via Atop’s Web site or E-mail
account
Web Site：www.atop.com.tw, e-mail：service@atop.com.tw
Web Site：www.atop.com.cn, e-mail：service@atop.com.cn
─ Any changes to this material will be announced on Atop website. ─
