ATN MO-3 User Manual
AMERICAN
TECHNOLOGIES
NET WORK
CORP.
u s e r ` s g u i d e
MO-3
The information in this manual furnished for information use only, is subject to change without notice, is not to be
construed as a commitment by ATN Corp.
ATN Corp. assumes no responsibility or liability for any errors or inaccuracies that may appear in this book.
©2001 ATN Corp. All right reserved.
Optional 90mm
lens
Standard 35mm
lens
Any “C” mount lens
Optional 90mm
lens
Standard 35mm lens
Any “C” mount lens
Doubler
Long Range IR illuminator
Video
Camera
adapter
35 mm Camera
Optional focal length doubler
gives the NightStar
increased magnification, in
just seconds, without any
tools.
Builtin infra-red illuminator
1’ to Infinity focus
35mm F 1.2 lens
for maximum
clarity
One 3 volt battery
Master power
5 Diopter
Camera
adapter
2
APPLICATION
The MO3-2 Night Vision Monocular is a complex opticoelectronic system for individual use.
The device consists of (see above figure) the objective lens assembly, eyepiece and the body.
The body contains a 2nd Gen. D-grade image intensifier tube assembly with an integrated
high voltage power source and the three volt battery housing. D-grade tubes are tubes that did
not pass our tube certification test typically do to too many cosmetic imperfections on the tube.
These imperfections are normally seen as black spots in the viewing area. These blemishes
do not affect the light gain, or lifespan of the tube.
The MO3-2 is equipped with a built-in infra-red illuminator for total darkness viewing. Plus,
with numerous accessories available (90mm lens and doubler for 4x and 8x magnification,
Universal camera and camcorder adapter, Long Range and IR-450 infra red illuminators) the
MO3-2D is one of the most versatile least expensive 2nd generation units on the market.
Objective lens protective cover (not shown) is intended to protect the objective lens from dust
and scratches. It also will act as a daylight filter, allowing you to test the scope in daylight or
other bright light situations. The pinhole in the center of the protective cover allows the user to
check the operation ability of the device in daylight conditions.
NOTE: Do not test the scope in daylight conditions even with the daylight filter/lens cap on for
more than ten (10) minutes.
The device is powered up by sliding the switch on the side of the unit labeled “PWR”.
FEATURES
• Great for hunting, camping, boating or surveillance
• Total darkness technology
• Automatic brightness control
• Built-in IR illuminator
• Manual focus
• Adjustable eyepiece
• High res. 2nd Gen. D-grade image intensifier tube
• Rugged and versatile design
• Light weight and comfortable
• Water and dust resistant
• Single switch button operation
• Superb 1X lens system
• Optional Doubler & Lens allows 2X to 8X magnification
• Soft case
• Two years warranty (optional extended warranty)
SPECIFICATIONS
Magnification ....................... 1X (Optional 2X, 4X, 8X)
Intensifier tube ...................... High res. 2nd Gen. D-grade
Lens System.......................... 35 mm; F1.4
Field of view........................... 20°
Resolution ............................. 40lp/mm
Range of Focus..................... 1’ to ?
Power Supply......................... 3 volt lithium
Battery Life ............................ 10-20 hours
Operating Temp. .................. -30°F to +110°F
Dimensions............................ 140 X 85 X 60 mm (5.5” X 3.5” X 2.5”
Weight..................................... 0.4 kg (9.5 oz)
