Atmos Chair 21 P Operating Instructions Manual

ATMOS
Chair 21 P

ATMOS MedizinTechnik
GmbH & Co. KG

Ludwig-Kegel-Str. 16
79853 Lenzkirch / Germany

Tel. +49 7653 - 6 89-0
Fax +49 7653 - 6 89-190

[e-mail]
www.atmosmed.com

Operating Instructions

English

503.0730.B

503.0700.B
2011-06 Index: 04

MedizinTechnik

2

ATMOS

Telefon: + 49 7653 689-0

Fax:
+ 49 7653 689-190
+ 49 7653 689-292 (Service Center)

E-Mail: [e-mail]
Internet: http://www.atmosmed.com

MedizinTechnik GmbH & Co. KG
Ludwig-Kegel-Str.16
79853 Lenzkirch
Germany

page

1.0 Introduction .......................................................... 3 - 5

1.1 Notes on operating instructions ................................... 3

1.2 Function ...................................................................... 4

1.3 Intended use ............................................................... 4

1.4 Scope of supply ........................................................... 5

1.5 Transport and storage .................................................5

1.6 Explanation of symbols ............................................... 5

2.0 For your safety .......................................................... 6

3.0 Installation and start-up ......................................7 - 8

3.1 Operating elements .....................................................7

3.2 Fixing the ATMOS Chair 21 P .....................................7

3.3 Mounting the foot rest ................................................. 8

3.4 Fixation of the back rest .............................................. 8

3.5 Adjusting the head rest ............................................... 8

3.6 Removing the head rest .............................................. 8

4.0 Operation ................................................................... 9

4.1 Adjusting the seat height .............................................9

4.2 Rotating the upper part ............................................... 9

4.3 Adjusting the backrest .................................................9

5.0 Cleaning and care ................................................... 10

6.0 Maintenance and service ........................................ 11

7.0 Troubleshooting ...................................................... 11

8.0 Options and spare parts .........................................12

8.1 Options ......................................................................12

8.2 Spare parts ................................................................ 12

9.0 Technical data ......................................................... 13

10.0 Testing / Disposal ....................................................14

10.1 Checking ATMOS devices ......................................... 14

10.2 Disposal .................................................................... 14

11.0 Notes on EMC ..........................................................14

Declaration of Conformity

ATMOS General Standard Terms and Conditions

Table of contents

3

1.0 Introduction

These operating instructions contain important notes on how to operate the ATMOS Chairo 21 P or
safely, correctly and effectively. Their reading helps to avoid risks, and also to reduce repair costs
and down-time. That increases, amongst other things, the reliability and service-life of the device.

These operating instructions serve not only for new operating personnel to be instructed in its use,
but also for use as a reference manual.

These operating instructions must always be kept available near the device.

Care and safety inspections in conjunction with professional execution provide for operational safety
and readiness for use of your ATMOS Chair 21 P and are therefore a must besides regular cleaning.
Repair work and safety inspections may be carried out only by expert personnel authorised by
ATMOS. By applying only original spare parts you will have the guarantee that operational safety,
readiness for work and the value of your ATMOS Chair 21 P will be preserved..

● The product ATMOS Chair 21 P bears CE marking CE according to the EC
Directive of the council for medical products 93/42/EEC, Directive 2007/47/EC dd.
05 September 2007 and meets the basic requirements of annex I of this directive.

● The quality management system applied at ATMOS has been certifi ed according to international

standards EN ISO 9001 and EN ISO 13485.

● Prior to start-up please peruse chapter 2.0 „For your safety“, in order to be prepared for any
possible dangerous situations.

Please store this document near the device for later use!

These operating instructions are valid for the following devices:

• ATMOS Chair 21 P REF 503.0730.0

Colour: white-dove blue

• ATMOS Chair 21 P REF 503.0700.0

Coulor: basic-dove blue

• ATMOS Chair 21 P REF 503.0701.0

Special colour

1.1 Notes on operating instructions

4

1.2 Function

 The ATMOS Chair 21 P (for patients) guarantees a

comfortable deportment for the patient (seating or
half-lying position) at optimum examination position.

 The ATMOS Chair 21 P is equipped with a mechanical

height adjustment. The seat height can be varied

between 46 - 66 cm.

 The upper part of the chair is easily rotary around 360°

and can be arrested in every height and rotary position by

a fi xing brake.

 The inclination of the backrest is infi nitely variable from

approx. -5° forward to 45° backward.

1.3 Intended use

Main function

This patient chair enables the optimum positioning of the patient
with regard to height and the position (seating position or half-

lying position)

Application

For treatment of human beings (=positioning)

Specifi cation of the main function

• Height adjustment of the seat by mechanical hydraulics

pump from

approx. 46 cm up to approx. 66 cm

• 360° rotation

• Can be arrested in every height and every rotary position

• Backrest can be inclined from –5° up to 45° by gas com-

pression spring

• Height-adjustable head-rest

Intended use
Movement of the patient

Application durability
Temporarily (up to 60 minutes)

Application environment
In hospitals and practices of ENT doctors and phoniatricians

Application limitations

• Not as swivel chair resp. swivel-swing chair for the nystag-

mus examination

• Not for patients with a weight of more than 150 kg

• Backrest inclination only with chairs which are screwed
tightly on the fl oor

1.0 Introduction

5

1.4 Scope of supply

Prior to dispatch, this ATMOS device was subjected to an extensive functional test and has been carefully packed.
Nevertheless, please compare the contents of the shipment on completeness immediately upon receipt (see delivery note)

1.6 Explanation of symbols

Warning,
especial diligent notice!

Serial number

Order number

Creation date

The CE sign shows that this
product meets the appropriate
requirements of the
EC Directive.

Important information!

1.0 Introduction

● Ambient conditions:

Transport/Storage: -20...+50 °C;

5...90 % air humidity
non-condensing
at air pressure 700...1060 hPa

Operation and

battery charging: +5...+35 °C;

20...80 % air humidity
non-condensing
at air pressure 700...1060 hPa

Graduierter
Sekretbehälter (1l)

Sekretbehälter­deckel mit 3facher
Übersaugsicherheit

REF

SN

1.5 Transport and storage

● The transport of the device may be effected only in a

dispatch carton upholstered and offering suffi cient protec-

tion.

● Please document and report damages in transit imme­diately. For complaints or return deliveries, please use
the enclosed form QD 434.

The form QD 434 can also be downloaded from the
internet www.atmosmed.de.

● The unit must be allowed to stand for up to six hours at

room temperature prior to starting up for the fi rst time

following transport at temperatures below freezing. The
unit may not be operated if it has not acclimatised as this

might damage its diaphragms.
