AVR1016: AVR Training QTouch Xplained
Prerequisites
• Knowledge level: Intermediate
• PC Platform: Windows® 2000, XP, Vista
• Hardware requirements:
- JTAG ICE mkII
- Xplain Kit
- Atmel
• Software requirements:
- Atmel
- (Atmel QTouch Studio, Optional)
- Latest version of WinAVR
- Atmel QTouch
• Time consumption: ~3 hours
Introduction
The purpose of this training is to get familiar with the Atmel QTouch Library 4.0 and
how to use it in your own applications.
This hands-on consist of a number of tasks. The first task shows how to connect
everything and assure that your hardware is working properly. The second task
explains how to set up a project and configure simple Atmel QTouch buttons. The
next task show how to configure a more advanced sensor and how to use the
debug interface in order to take advantage of the live debugging features of
QTouch Studio.
®
QTouch® Xplained board
®
AVR Studio® 4 (latest version)
®
Library (latest version)
8-bit
Microcontrollers
Application Note
Basics for Atmel AVR Studio, WinAVR or tools use are not covered.
