Features
• High Performance, Low Power AVR
– 210 DMIPS throughput at 150 MHz
– 16 KB instruction cache and 16 KB data caches
– Memory Management Unit enabling use of operating systems
– Single-cycle RISC instruction set including SIMD and DSP instructions
– Java Hardware Acceleration
• Multimedia Co-Processor
– Vector Multiplication Unit for video acceleration through color-space conversion
(YUV<->RGB), image scaling and filtering, quarter pixel motion compensation
• Multi-hierarchy bus system
– High-performance data transfers on separate buses for increased performance
• Data Memories
– 32KBytes SRAM
• External Memory Interface
– SDRAM, DataFlash™, SRAM, Multi Media Card (MMC), Secure Digital (SD),
– Compact Flash, Smart Media, NAND Flash
• Direct Memory Access Controller
– External Memory access without CPU intervention
• Interrupt Controller
– Individually maskable Interrupts
– Each interrupt request has a programmable priority and autovector address
• System Functions
– Power and Clock Manager
– Crystal Oscillator with Phase-Lock-Loop (PLL)
– Watchdog Timer
– Real-time Clock
• 6 Multifunction timer/counters
– Three external clock inputs, I/O pins, PWM, capture and various counting
capabilities
• 4 Universal Synchronous/Asynchronous Receiver/Transmitters (USART)
– 115.2 kbps IrDA Modulation and Demodulation
– Hardware and software handshaking
• 3 Synchronous Serial Protocol controllers
– Supports I2S, SPI and generic frame-based protocols
• Two-Wir e Inte rfac e
– Sequential Read/Write Operations, Philips’ I2C© compatible
• Liquid Crystal Display (LCD) interface
– Supports TFT displays
– Configurable pixel resolution supporting QCIF/QVGA/VGA/SVGA configurations.
• Image Sensor Interface
– 12-bit Data Interface for CMOS cameras
• Universal Serial Bus (USB) 2.0 High Speed (480 Mbps) Device
– On-chip Transceivers with physical interface
• 16-bit stereo audio DAC
– Sample rates up to 50 kHz
• On-Chip Debug System
– Nexus Class 3
– Full speed, non-intrusive data and program trace
– Runtime control and JTAG interface
• Package/Pins
– AT32AP7002: 196-ball CTBGA
• Power supplies
– 1.65V to1.95V VDDCORE
– 3.0V to 3.6V VDDIO
®
32 32-Bit Microcontroller
AVR®32 32-bit
Microcontroller
AT32AP7002
Preliminary
Summary
32054AS-AVR32-02/07
1. Part Description
The AT32AP7002 is a complete System-on-chip application processor with an AVR32 RISC
processor achieving 210 DMIPS running 150 MHz. AVR32 is a high-performance 32-bit RISC
microprocessor core, designed for cost-sensitive embedded applications, with particular emphasis on low power consumption, high code density and high application performance.
AT32AP7002 implements a Memory Management Unit (MMU) and a flexible interrupt controller
supporting modern operating systems and real-time operating systems. The processor also
includes a rich set of DSP and SIMD instructions, specially designed for multimedia and telecom
applications.
AT32AP7002 incorporates SRAM memories on-chip for fast and secure access. For applications requiring additional memory, external 16-bit SRAM is accessible. Additionally, an SDRAM
controller provides off-chip volatile memory access as well as controllers for all industry standard
off-chip non-volatile memories, like Compact Flash, Multi Media Card (MMC), Secure Digital
(SD)-card, SmartCard, NAND Flash and Atmel DataFlash™.
The Direct Memory Access controller for all the serial peripherals enables data transfer between
memories without processor intervention. This reduces the processor overhead when transferring continuous and large data streams between modules in the MCU.
The Timer/Counters includes three identical 16-bit timer/counter channels. Each channel can be
independently programmed to perform a wide range of functions including frequency measurement, event counting, interval measurement, pulse generation, delay timing and pulse width
modulation.
AT32AP7002
AT32AP7002 also features an onboard LCD Controller, supporting single and double scan
monochrome and color passive STN LCD modules and single scan active TFT LCD modules.
On monochrome STN displays, up to 16 gray shades are supported using a time-based dithering algorithm and Frame Rate Control (FRC) method. This method is also used in color STN
displays to generate up to 4096 colors.
The LCD Controller is programmable for supporting resolutions up to 2048 x 2048 with a pixel
depth from 1 to 24 bits per pixel.
A pixel co-processor provides color space conversions for images and video, in addition to a
wide variety of hardware filter support
The media-independent interface (MII) and reduced MII (RMII) 10/100 Ethernet MAC modules
provides on-chip solutions for network-connected devices.
Synchronous Serial Controllers provide easy access to serial communication protocols, audio
standards like AC'97, I2S, I2C© and various SPI modes. The modules support frame-based protocols, like VoIP SIP protocols.
The Java hardware acceleration implementation in AVR32 allows for a very high-speed Java
byte-code execution. AVR32 implements Java instructions in hardware, reusing the existing
RISC data path, which allows for a near-zero hardware overhead and cost with a very high
performance.
The Image Sensor Interface supports cameras with up to 12-bit data buses and connects
directly to the LCD interface through a separate bus.
32054AS-AVR32-02/07
PS2 connectivity is provided for standard input devices like mice and keyboards.
2
AT32AP7002
AT32AP7002 integrates a class 3 Nexus 2.0 On-Chip Debug (OCD) System, with non-intrusive
real-time trace, full-speed read/write memory access in addition to basic runtime control.
The C-compiler is closely linked to the architecture and is able to utilize code optimization features, both for size and speed.
32054AS-AVR32-02/07
3
2. Blockdiagram
Figure 2-1. Blockdiagram
TRST_N
TCK
TDO
TDI
TMS
EVTI_N
D+
D-
DATA[11..0]
HSYNC
VSYNC
PCLK
PA
PB
PC
PD
PE
XIN32
XOUT32
XIN0
XOUT0
XIN1
XOUT1
PLL0
PLL1
OSCEN_N
Parallel Input/Output Controllers
RESET_N
A
D
D
A
A
D
T
D
T
A
C
CMD
DATA[7..0]
C
S
S
S
S
S
32 KHz
OSC
OSC0
OSC1
PLL0
PLL1
G
K
L
C
INTERFACE
MCKO
MDO[5..0]
MSEO[1..0]
EVTO_N
INTERFACE
SENSOR
INTERFACE
INTRAM0
INTRAM1
0
T
A
1
A
T
N
0
A
A
N
1
L
K
K
L
D
I
C
N
Y
O
D
3
[
]
0
.
.
JTAG
USB
DMA
PB
DMA CONTROLLER
AUDIO BITSTREAM
DAC
MULTIMEDIA CARD
INTERFACE
AC97 CONTROLLER
POWER
MANAGER
CLOCK
GENERATOR
CLOCK
CONTROLLER
SLEEP
CONTROLLER
RESET
CONTROLLER
NEXUS
CLASS 3
PBB
S
M
M
S
HSB
HSB-PB
BRIDGE
B
OCD
MEMORY MANAGEMENT UNIT
INSTR
CACHE
M
M
HIGH SPEED
BUS MATRIX
S
SMM
CONFIGURATION REGISTERS BUS
S
HSB
HSB-PB
BRIDGE A
PB
PBA
DMA
DMA
DMA
AP CPU
DATA
CACHE
HSB-HSB BRIDGE
PERIPHERAL
CONTROLLER
PDC
PERIPHERAL
PDC
INTERFACE 0/1
SYNCHRONOUS
PDC
CONTROLLER 0/1/2
TWO-WIRE
INTERFACE
PS2 INTERFACE
REAL TIME
COUNTER
WATCHDOG
M
M
DMA
USART0
USART1
USART2
USART3
SERIAL
SERIAL
TIMER
AT32AP7002
PIXEL COPROCESSOR
VSYNC,
HSYNC,
DATA[22..0],
NANDOE,
NANDWE,
SDCKE,
NCS[3,1,0],
ADDR[22..0]
NCS[5,4,2]
CFRNW,
CFCE1,
CONTROLLER & ECC)
CFCE2,
ADDR[23..25]
DATA[31..16]
RXD
TXD
CLK
RTS, CTS
SCK
MISO, MOSI
NPCS0
NPCS[3..1]
TX_DATA
RX_DATA
SCL
SDA
CLOCK[1..0]
DATA[1..0]
PWR,
PCLK,
MODE,
DVAL,
CC,
GPL[7..0]
RAS,
CAS,
SDWE,
SDCK,
NWE3,
NWE1,
NWE0,
NRD,
NWAIT
SDCS,
DATA[15..0]
PA
PB
PC
PD
PE
Parallel Input/Output Controllers
LCD
CONTRO
LLER
S
M
DMA
S
(SDRAM & STATIC MEMORY
EXTERNAL BUS INTERFACE
TX_CLOCK, TX_FRAME_SYNC
RX_CLOCK, RX_FRAME_SYNC
32054AS–AVR32–02/07
A
B
CLK[2..0]
X
E
T
K
P
NMI_N
.
.
0
]
[
2
2
[
0
]
.
.
T
I
N
S
[
7
TIMER/COUNTER 0/1
.
0
]
.
[
7
.
0
.
]
EXTERNAL
INTERRUPT
CONTROLLER
INTERRUPT
CONTROLLER
PULSE WIDTH
MODULATION
CONTROLLER
PWM0
PWM1
PWM2
PWM3
4
2.1 Processor and architecture
2.1.1 AVR32AP CPU
•
32-bit load/store AVR32B RISC architecture.
– Up to 15 general-purpose 32-bit registers.
– 32-bit Stack Pointer, Program Counter and Link Register reside in register file.
– Fully orthogonal instruction set.
– Privileged and unprivileged modes enabling efficient and secure Operating Systems.
– Innovative instruction set together with variable instruction length ensuring industry leading
code density.
– DSP extention with saturating arithmetic, and a wide variety of multiply instructions.
– SIMD extention for media applications.
• 7 stage pipeline allows one instruction per clock cycle for most instructions.
– Java Hardware Acceleration.
– Byte, half-word, word and double word memory access.
– Unaligned memory access.
– Shadowed interrupt context for INT3 and multiple interrupt priority levels.
– Dynamic branch prediction and return address stack for fast change-of-flow.
– Coprocessor interface.
• Full MMU allows for operating systems with memory protection.
• 16Kbyte Instruction and 16Kbyte data caches.
– Virtually indexed, physically tagged.
– 4-way associative.
– Write-through or write-back.
• Nexus Class 3 On-Chip Debug system.
– Low-cost NanoTrace supported.
AT32AP7002
2.1.2 Pixel Coprocessor (PiCo)
Coprocessor coupled to the AVR32 CPU Core through the TCB Bus.
•
• Three parallel Vector Multiplication Units (VMU) where each unit can:
– Multiply three pixel components with three coefficients.
– Add the products from the multiplications together.
– Accumulate the result or add an offset to the sum of the products.
• Can be used for accelerating:
– Image Color Space Conversion.
•Configurable Conversion Coefficients.
• Supports packed and planar input and output formats.
• Supports subsampled input color spaces (i.e 4:2:2, 4:2:0).
– Image filtering/scaling.
• Configurable Filter Coefficients.
• Throughput of one sample per cycle for a 9-tap FIR filter.
• Can use the built-in accumulator to extend the FIR filter to more than 9-taps.
• Can be used for bilinear/bicubic interpolations.
– MPEG-4/H.264 Quarter Pixel Motion Compensation.
• Flexible input Pixel Selector.
– Can operate on numerous different image storage formats.
• Flexible Output Pixel Inserter.
– Scales and saturates the results back to 8-bit pixel values.
32054AS–AVR32–02/07
5
– Supports packed and planar output formats.
• Configurable coefficients with flexible fixed-point representation.
2.1.3 Debug and Test system
IEEE1149.1 compliant JTAG and boundary scan
•
• Direct memory access and programming capabilities through JTAG interface
• Extensive On-Chip Debug features in compliance with IEEE-ISTO 5001-2003 (Nexus 2.0) Class 3
• Auxiliary port for high-speed trace information
• Hardware support for 6 Program and 2 data breakpoints
• Unlimited number of software breakpoints supported
• Advanced Program, Data, Ownership, and Watchpoint trace supported
2.1.4 DMA controller
2 HSB Master Interfaces
•
• 3 Channels
• Software and Hardware Handshaking Interfaces
– 11 Hardware Handshaking Interfaces
• Memory/Non-Memory Peripherals to Memory/Non-Memory Peripherals Transfer
• Single-block DMA Transfer
• Multi-block DMA Transfer
– Linked Lists
– Auto-Reloading
– Contiguous Blocks
• DMA Controller is Always the Flow Controller
• Additional Features
– Scatter and Gather Operations
– Channel Locking
Bus Locking
–
– FIFO Mode
– Pseudo Fly-by Operation
AT32AP7002
2.1.5 Peripheral DMA Controller
Transfers from/to peripheral to/from any memory space without intervention of the processor.
•
• Next Pointer Support, forbids strong real-time constraints on buffer management.
• Eighteen channels
– Two for each USART
– Two for each Serial Synchronous Controller
– Two for each Serial Peripheral Interface
2.1.6 Bus system
HSB bus matrix with 10 Masters and 8 Slaves handled
•
– Handles Requests from the CPU Icache, CPU Dcache, HSB bridge, HISI, USB 2.0 Controller,
LCD Controller, DMA Controller 0, DMA Controller 1, and to internal SRAM 0, internal SRAM 1,
PB A, PB B, EBI and, USB.
32054AS–AVR32–02/07
6
AT32AP7002
– Round-Robin Arbitration (three modes supported: no default master, last accessed default
master, fixed default master)
– Burst Breaking with Slot Cycle Limit
– One Address Decoder Provided per Master
• 2 Peripheral buses allowing each bus to run on different bus speeds.
– PB A intended to run on low clock speeds, with peripherals connected to the PDC.
– PB B intended to run on higher clock speeds, with peripherals connected to the DMAC.
• HSB-HSB Bridge providing a low-speed HSB bus running at the same speed as PBA
– Allows PDC transfers between a low-speed PB bus and a bus matrix of higher clock speeds
An overview of the bus system is given in Figure 2-1 on page 4. All modules connected to the
same bus use the same clock, but the clock to each module can be individually shut off by the
Power Manager. The figure identifies the number of master and slave interfaces of each module
connected to the HSB bus, and which DMA controller is connected to which peripheral.
32054AS–AVR32–02/07
7
2.2 Package and PinoutAVR32AP7002
Figure 2-2. 196 CTBGA Pinout
TOP VIEW BOTTOM VIEW
Ball A1
1413121110987654321 1413121110 9 8 7 6 5 4 3 2 1
AT32AP7002
A
B
C
D
E
F
G
H
J
K
L
M
N
P
AVR32
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Table 2-1. CTBGA196 Package Pinout A1..T8
12345678
PX49 PX48 PX47 AVDDPLL PC28 PC23 PC20 PB22
A
PX50 GND VDDIO PLL0 PLL1 XIN32 PC22 PB23
B
PX51 PD01 PX05 GND AGNDPLL XOUT32 PC29 PC21
C
PX32 PD00 VDDIO PX02 XIN0 XOUT0 AGNDOSC PC30
D
PX33 PX00 PX04 GND PD07 AVDDOSC OSCEN_N PC31
E
PX01 PX03 VDDCORE PD04 PD09 TDI RESET_N VDDCORE
F
PD05 PD08 PD06 TDO PA04 PA02 PA08 PX22
G
TMS TRST_N TCK EVTI_N PB24 PA10 PA14 PX38
H
PA 01 PA0 3 PA 0 0 V D D IO G ND PA 0 9 PA 1 8 G N D
J
PA 05 PA1 1 PA 1 2 PA 1 6 G ND G N D PA 2 6 WA K E _N
K
PB25 PA21 PA19 GND VDDIO VDDIO PA25 PA29
L
PA13 PA22 PA23 PD17 AVDDUSB VDDCORE VBG PA30
M
PA15 PA20 PD12 PD15 PD16 AGNDUSB FSDP HSDP
N
PA17 PA24 PD13 PD14 XIN1 XOUT1 FSDM HSDM
P
32054AS–AVR32–02/07
8
AT32AP7002
Table 2-2. CTBGA196 Package Pinout A9..T16
9 1011121314
PB18 PB16 PB11 PB08 PB05 PB04
A
PB21 PB17 PB12 PB09 PB06 PB03
B
PA06 PB19 PB14 PB10 PB07 PB02
C
VDDIO PB20 PB15 PB13 GND PB01
D
PA07 GND PB00 PX44 VDDIO PX45
E
PX42 GND GND PX43 PX46 PX40
F
PX30 PX25 PX31 VDDIO VDDCORE PX39
G
PA28 PX20 PX28 PX29 VDDCORE PX26
H
PB27 PX37 PX23 PX27 PX21 PX24
J
PB28 PX15 PX36 PX19 PX34 PX18
K
PX41 GND PX07 VDDIO GND PX35
L
PX53 PX06 PX11 PX12 PX17 PX14
M
PB26 VDDIO PX09 PB29 PX16 PX13
N
PA27 PA31 PX52 PX08 PX10 PB30
P
32054AS–AVR32–02/07
9
AT32AP7002
3. Signals Description
The following table gives details on the signal name classified by peripheral. The pinout multiplexing of these signals is given in the Peripheral Muxing table in the Peripherals chapter.
Table 3-1. Signal Description List
Active
Signal Name Function Type
Power
AVDDPLL PLL Power Supply Power 1.65 to 1.95 V
AVDDUSB USB Power Supply Power 1.65 to 1.95 V
AVDDOSC Oscillator Power Supply Power 1.65 to 1.95 V
VDDCORE Core Power Supply Power 1.65 to 1.95 V
VDDIO I/O Power Supply Power 3.0 to 3.6V
AGNDPLL PLL Ground Ground
AGNDUSB USB Ground Ground
Level Comments
AGNDOSC Oscillator Ground Ground
GND Ground Ground
Clocks, Oscillators, and PLL’s
XIN0, XIN1, XIN32 Crystal 0, 1, 32 Input Analog
XOUT0, XOUT1,
XOUT32
PLL0, PLL1 PLL 0,1 Filter Pin Analog
TCK Test Clock Input
TDI Test Data In Input
TDO Test Data Out Output
TMS Test Mode Select Input
TRST_N Test Reset Input Low
MCKO Trace Data Output Clock Output
Crystal 0, 1, 32 Output Analog
JTAG
Auxiliary Port - AUX
MDO0 - MDO5 Trace Data Output Output
MSEO0 - MSEO1 Trace Frame Control Output
EVTI_N Event In Input Low
32054AS-AVR32-02/07
10
Table 3-1. Signal Description List
Active
Signal Name Function Type
EVTO_N Event Out Output Low
Power Manager - PM
GCLK0 - GCLK4 Generic Clock Pins Output
OSCEN_N Oscillator Enable Input Low
RESET_N Reset Pin Input Low
WAKE_N Wake Pin Input Low
External Interrupt Module - EIM
EXTINT0 - EXTINT3 External Interrupt Pins Input
NMI_N Non-Maskable Interrupt Pin Input Low
AC97 Controller - AC97C
Level Comments
AT32AP7002
SCLK AC97 Clock Signal Input
SDI AC97 Receive Signal Output
SDO AC97 Transmit Signal Output
SYNC AC97 Frame Synchronization Signal Input
DAC - DAC
DATA0 - DATA1 D/A Data Out Output
DATAN0 - DATAN1 D/A Inverted Data Out Output
External Bus Interface - EBI
ADDR0 - ADDR25 Address Bus Output
CAS Column Signal Output Low
CFCE1 Compact Flash 1 Chip Enable Output Low
CFCE2 Compact Flash 2 Chip Enable Output Low
CFRNW Compact Flash Read Not Write Output
DATA0 - DATA31 Data Bus I/O
NANDOE NAND Flash Output Enable Output Low
NANDWE NAND Flash Write Enable Output Low
NCS0 - NCS5 Chip Select Output Low
NRD Read Signal Output Low
32054AS-AVR32-02/07
11
Table 3-1. Signal Description List
Active
Signal Name Function Type
NWAIT External Wait Signal Input Low
NWE0 Write Enable 0 Output Low
NWE1 Write Enable 1 Output Low
NWE3 Write Enable 3 Output Low
RAS Row Signal Output Low
SDA10 SDRAM Address 10 Line Output
SDCK SDRAM Clock Output
SDCKE SDRAM Clock Enable Output
SDCS SDRAM Chip Select Output Low
SDWE SDRAM Write Enable Output Low
Level Comments
AT32AP7002
Image Sensor Interface - ISI
DATA0 - DATA11 Image Sensor Data Input
HSYNC Horizontal Synchronization Input
PCLK Image Sensor Data Clock Input
VSYNC Vertical Synchronization Input
Mulitmedia Card Interface - MMCI
CLK Multimedia Card Clock Output
CMD0 - CMD1 Multimedia Card Command I/O
DATA0 - DATA7 Multimedia Card Data I/O
Parallel Input/Output 2 - PIOA, PIOB, PIOC, PIOD, PIOE
PA0 - PA31 Parallel I/O Controller PIOA I/O
PB0 - PB30 Parallel I/O Controller PIOB I/O
PC0 - PC31 Parallel I/O Controller PIOC I/O
PD0 - PD17 Parallel I/O Controller PIOD I/O
PE0 - PE26 Parallel I/O Controller PIOE I/O
PS2 Interface - PSIF
CLOCK0 - CLOCK1 PS2 Clock Input
DATA0 - DATA1 PS2 Data I/O
32054AS-AVR32-02/07
12
Table 3-1. Signal Description List
Active
Signal Name Function Type
Serial Peripheral Interface - SPI0, SPI1
MISO Master In Slave Out I/O
MOSI Master Out Slave In I/O
NPCS0 - NPCS3 SPI Peripheral Chip Select I/O Low
SCK Clock Output
Synchronous Serial Controller - SSC0, SSC1, SSC2
RX_CLOCK SSC Receive Clock I/O
RX_DATA SSC Receive Data Input
RX_FRAME_SYNC SSC Receive Frame Sync I/O
TX_CLOCK SSC Transmit Clock I/O
Level Comments
AT32AP7002
TX_DATA SSC Transmit Data Output
TX_FRAME_SYNC SSC Transmit Frame Sync I/O
DMA Controller - DMAC
DMARQ0 - DMARQ3 DMA Requests Input
Timer/Counter - TIMER0, TIMER1
A0 Channel 0 Line A I/O
A1 Channel 1 Line A I/O
A2 Channel 2 Line A I/O
B0 Channel 0 Line B I/O
B1 Channel 1 Line B I/O
B2 Channel 2 Line B I/O
CLK0 Channel 0 External Clock Input Input
CLK1 Channel 1 External Clock Input Input
CLK2 Channel 2 External Clock Input Input
Two-wire Interface - TWI
SCL Serial Clock I/O
SDA Serial Data I/O
Universal Synchronous Asynchronous Receiver Transmitter - USART0, USART1, USART2, USART3
32054AS-AVR32-02/07
13
Table 3-1. Signal Description List
Signal Name Function Type
CLK Clock I/O
CTS Clear To Send Input
RTS Request To Send Output
RXD Receive Data Input
TXD Transmit Data Output
Pulse Width Modulator - PWM
PWM0 - PWM3 PWM Output Pins Output
Universal Serial Bus Device - USB
DDM USB Device Port Data - Analog
DDP USB Device Port Data + Analog
AT32AP7002
Active
Level Comments
VBG USB bandgap Analog
Connected to a 6810 Ohm ± 0.5%
resistor to gound and a 10 pF
capacitor to ground.
32054AS-AVR32-02/07
14
4. Power Considerations
4.1 Power Supplies
The AT32AP7002 has several types of power supply pins:
•
VDDCORE pins: Power the core, memories, and peripherals. Voltage is 1.8V nominal.
• VDDIO pins: Power I/O lines. Voltage is 3.3V nominal.
• VDDPLL pin: Powers the PLL. Voltage is 1.8V nominal.
• VDDUSB pin: Powers the USB. Voltage is 1.8V nominal.
• VDDOSC pin: Powers the oscillators. Voltage is 1.8V nominal.
The ground pins GND are common to VDDCORE and VDDIO. The ground pin for VDDPLL is
GNDPLL, and the GND pin for VDDOSC is GNDOSC.
See ”Electrical Characteristics” on page 928 for power consumption on the various supply pins.
4.2 Power Supply Connections
Special considerations should be made when connecting the power and ground pins on a PCB.
Figure 4-1 shows how this should be done.
Figure 4-1. Connecting analog power supplies
AT32AP7002
AVDDUSB
AVDDPLL
AVDDOSC
AGNDUSB
AGNDPLL
AGNDOSC
VDDCORE
3.3uH
C54
0.10u
VCC_1V8
C56
0.10u
C55
0.10u
32054AS–AVR32–02/07
15
5. I/O Line Considerations
5.1 JTAG pins
The TMS, TDI and TCK pins have pull-up resistors. TDO is an output, driven at up to VDDIO,
and have no pull-up resistor. The TRST_N pin is used to initialize the embedded JTAG TAP
Controller when asserted at a low level. It is a schmitt input and integrates permanent pull-up
resistor to VDDIO, so that it can be left unconnected for normal operations.
5.2 WAKE_N pin
The WAKE_N pin is a schmitt trigger input integrating a permanent pull-up resistor to VDDIO.
5.3 RESET_N pin
The RESET_N pin is a schmitt input and integrates a permanent pull-up resistor to VDDIO. As
the product integrates a power-on reset cell, the RESET_N pin can be left unconnected in case
no reset from the system needs to be applied to the product.
5.4 EVTI_N pin
The EVTI_N pin is a schmitt input and integrates a non-programmable pull-up resistor to VDDIO.
AT32AP7002
5.5 TWI pins
5.6 PIO pins
When these pins are used for TWI, the pins are open-drain outputs with slew-rate limitation and
inputs with inputs with spike-filtering. When used as GPIO-pins or used for other peripherals, the
pins have the same characteristics as PIO pins.
All the I/O lines integrate a programmable pull-up resistor. Programming of this pull-up resistor is
performed independently for each I/O line through the PIO Controllers. After reset, I/O lines
default as inputs with pull-up resistors enabled, except when indicated otherwise in the column
“Reset State” of the PIO Controller multiplexing tables.
32054AS–AVR32–02/07
16
6. Memories
6.1 Embedded Memories
• 32 Kbyte SRAM
– Implemented as two 16Kbyte blocks
– Single cycle access at full bus speed
6.2 Physical Memory Map
The system bus is implemented as an HSB bus matrix. All system bus addresses are fixed, and
they are never remapped in any way, not even in boot. Note that AT32AP7002 by default uses
segment translation, as described in the AVR32 Architecture Manual. The 32 bit physical
address space is mapped as follows:
Table 6-1. AT32AP7002 Physical Memory Map
Start Address Size Device
0x0000_0000 64 Mbyte EBI SRAM CS0
0x0400_0000 64 Mbyte EBI SRAM CS4
AT32AP7002
0x0800_0000 64 Mbyte EBI SRAM CS2
0x0C00_0000 64 Mbyte EBI SRAM CS3
0x1000_0000 256 Mbyte EBI SRAM/SDRAM CS1
0x2000_0000 64 Mbyte EBI SRAM CS5
0x2400_0000 16 Kbyte Internal SRAM 0
0x2400_4000 16 Kbyte Internal SRAM1
0xFF00_0000 4 Kbyte LCDC configuration
0xFF20_0000 1 KByte DMAC configuration
0xFF30_0000 1 MByte USB Data
0xFFE0_0000 1 MByte PBA
0xFFF0_0000 1 MByte PBB
Accesses to unused areas returns an error result to the master requesting such an access.
The bus matrix has the several masters and slaves. Each master has its own bus and its own
decoder, thus allowing a different memory mapping per master. The master number in the table
below can be used to index the HMATRIX control registers. For example, MCFG2 is associated
with the HSB-HSB bridge.
32054AS–AVR32–02/07
17
AT32AP7002
Table 6-2. HSB masters
Master 0 CPU Dcache
Master 1 CPU Icache
Master 2 HSB-HSB Bridge
Master 3 ISI DMA
Master 4 USB DMA
Master 5 LCD Controller DMA
Master 6 Ethernet MAC0 DMA
Master 7 Ethernet MAC1 DMA
Master 8 DMAC Master Interface 0
Master 9 DMAC Master Interface 1
Each slave has its own arbiter, thus allowing a different arbitration per slave. The slave number
in the table below can be used to index the HMATRIX control registers. For example, SCFG3 is
associated with PBB.
Table 6-3. HSB slaves
Slave 0 Internal SRAM 0
Slave 1 Internal SRAM1
Slave 2 PBA
Slave 3 PBB
Slave 4 EBI
Slave 5 USB data
Slave 6 LCDC configuration
Slave 7 DMAC configuration
32054AS–AVR32–02/07
18
7. Peripherals
7.1 Peripheral address map
Table 7-1. Peripheral Address Mapping
Address Peripheral Name Bus
AT32AP7002
0xFF000000
0xFF200000
0xFF300000
0xFFE00000
0xFFE00400
0xFFE00800
0xFFE00C00
0xFFE01000
0xFFE01400
0xFFE01800
LCDC LCD Controller Slave Interface - LCDC HSB
DMAC DMA Controller Slave Interface- DMAC HSB
USB USB 2.0 Slave Interface - USB HSB
SPI0 Serial Peripheral Interface - SPI0 PB A
SPI1 Serial Peripheral Interface - SPI1 PB A
TWI Two-wire Interface - TWI PB A
USART0
USART1
USART2
USART3
Universal Synchronous Asynchronous Receiver
Transmitter - USART0
Universal Synchronous Asynchronous Receiver
Transmitter - USART1
Universal Synchronous Asynchronous Receiver
Transmitter - USART2
Universal Synchronous Asynchronous Receiver
Transmitter - USART3
PB A
PB A
PB A
PB A
32054AS–AVR32–02/07
0xFFE01C00
0xFFE02000
0xFFE02400
0xFFE02800
0xFFE02C00
0xFFE03000
0xFFE03400
SSC0 Synchronous Serial Controller - SSC0 PB A
SSC1 Synchronous Serial Controller - SSC1 PB A
SSC2 Synchronous Serial Controller - SSC2 PB A
PIOA Parallel Input/Output 2 - PIOA PB A
PIOB Parallel Input/Output 2 - PIOB PB A
PIOC Parallel Input/Output 2 - PIOC PB A
PIOD Parallel Input/Output 2 - PIOD PB A
19
Table 7-1. Peripheral Address Mapping (Continued)
Address Peripheral Name Bus
AT32AP7002
0xFFE03800
0xFFE03C00
0xFFF00000
0xFFF00400
0xFFF00800
0xFFF00C00
0xFFF01000
0xFFF01400
0xFFF02000
0xFFF02400
PIOE Parallel Input/Output 2 - PIOE PB A
PSIF PS2 Interface - PSIF PB A
SM System Manager - SM PB B
INTC Interrupt Controller - INTC PB B
HMATRIX HSB Matrix - HMATRIX PB B
TC0 Timer/Counter - TC0 PB B
TC1 Timer/Counter - TC1 PB B
PWM Pulse Width Modulation Controller - PWM PB B
DAC DAC - Audio DAC PB B
MCI Mulitmedia Card Interface - MCI PB B
0xFFF02800
0xFFF02C00
0xFFF03000
0xFFF03400
0xFFF03800
0xFFF03C00
AC97C AC97 Controller - AC97C PB B
ISI Image Sensor Interface - ISI PB B
USB USB 2.0 Configuration Interface - USB PB B
SMC Static Memory Controller - SMC PB B
SDRAMC SDRAM Controller - SDRAMC PB B
ECC Error Correcting Code Controller - ECC PB B
7.2 Interrupt Request Signal Map
The various modules may output interrupt request signals. These signals are routed to the Interrupt Controller (INTC). The Interrupt Controller supports up to 64 groups of interrupt requests.
Each group can have up to 32 interrupt request signals. All interrupt signals in the same group
share the same autovector address and priority level. Refer to the documentation for the individual submodules for a description of the semantic of the different interrupt requests.
32054AS–AVR32–02/07
20
AT32AP7002
The interrupt request signals in AT32AP7002 are connected to the INTC as follows:
Table 7-2. Interrupt Request Signal Map
Group Line Signal
0 0 COUNT-COMPARE match
1 Performance Counter Overflow
1 0 LCDC EOF
1 LCDC LN
2 LCDC LSTLN
3 LCDC MER
4 LCDC OWR
5 LCDC UFLW
2 0 DMAC BLOCK
1 DMAC DSTT
2DMAC ERR
3 DMAC SRCT
4DMAC TFR
3 0 SPI 0
4 0 SPI 1
50TWI
6 0 USART0
7 0 USART1
8 0 USART2
9 0 USART3
10 0 SSC0
11 0 SSC1
12 0 SSC2
13 0 PIOA
14 0 PIOB
15 0 PIOC
16 0 PIOD
17 0 PIOE
18 0 PSIF
19 0 EIM0
1EIM1
2EIM2
3EIM3
20 0 PM
32054AS–AVR32–02/07
21 0 RTC
21
Table 7-2. Interrupt Request Signal Map
Group Line Signal
22 0 TC00
1TC01
2TC02
23 0 TC10
1TC11
2TC12
24 0 PWM
27 0 DAC
28 0 MCI
29 0 AC97C
30 0 ISI
31 0 USB
32 0 EBI
AT32AP7002
7.3 DMAC Handshake Interface Map
The following table details the hardware handshake map between the DMAC and the peripherals attached to it: :
Table 7-3. Hardware Handshaking Connection
Request Hardware Handshaking Interface
MCI RX 0
MCI TX 1
DAC TX 2
AC97C CHANNEL A RX 3
AC97C CHANNEL A TX 4
AC97C CHANNEL B RX 5
AC97C CHANNEL B TX 6
EXTERNAL DMA REQUEST 0 7
EXTERNAL DMA REQUEST 1 8
EXTERNAL DMA REQUEST 2 9
EXTERNAL DMA REQUEST 3 10
32054AS–AVR32–02/07
22
7.4 Clock Connections
7.4.1 Timer/Counters
Each Timer/Counter channel can independently select an internal or external clock source for its
counter:
Table 7-4. Timer/Counter clock connections
Timer/Counter Source Name Connection
0 Internal TIMER_CLOCK1 clk_slow
1 Internal TIMER_CLOCK1 clk_slow
AT32AP7002
TIMER_CLOCK2 clk_pbb / 4
TIMER_CLOCK3 clk_pbb / 8
TIMER_CLOCK4 clk_pbb / 16
TIMER_CLOCK5 clk_pbb / 32
External XC0 See Section 7.7
XC1
XC2
TIMER_CLOCK2 clk_pbb / 4
TIMER_CLOCK3 clk_pbb / 8
7.4.2 USARTs
TIMER_CLOCK4 clk_pbb / 16
TIMER_CLOCK5 clk_pbb / 32
External XC0 See Section 7.7
XC1
XC2
Each USART can be connected to an internally divided clock:
Table 7-5. USART clock connections
USART Source Name Connection
0 Internal CLK_DIV clk_pba / 8
1
2
3
32054AS–AVR32–02/07
23
7.4.3 SPIs
Each SPI can be connected to an internally divided clock:
Table 7-6. SPI clock connections
SPI Source Name Connection
0 Internal CLK_DIV clk_pba / 32
1
7.5 External Interrupt Pin Mapping
External interrupt requests are connected to the following pins::
Table 7-7. External Interrupt Pin Mapping
Source Connection
NMI_N PB24
EXTINT0 PB25
EXTINT1 PB26
EXTINT2 PB27
AT32AP7002
EXTINT3 PB28
7.6 Nexus OCD AUX port connections
If the OCD trace system is enabled, the trace system will take control over a number of pins, irrespectively of the PIO configuration. Two different OCD trace pin mappings are possible,
depending on the configuration of the OCD AXS register. For details, see the AVR32 AP Techni-
cal Reference Manual.
Table 7-8. Nexus OCD AUX port connections
Pin AXS=0 AXS=1
EVTI_N EVTI_N EVTI_N
MDO[5] PB09 PC18
MDO[4] PB08 PC14
MDO[3] PB07 PC12
MDO[2] PB06 PC11
MDO[1] PB05 PC06
MDO[0] PB04 PC05
EVTO_N PB03 PB28
MCKO PB02 PC02
MSEO[1] PB01 PC01
32054AS–AVR32–02/07
MSEO[0] PB00 PC00
24
7.7 Peripheral Multiplexing on IO lines
The AT32AP7002 features five PIO controllers, PIOA to PIOE, that multiplex the I/O lines of the
peripheral set. Each PIO Controller controls up to thirty-two lines.
Each line can be assigned to one of two peripheral functions, A or B. The tables in the following
pages define how the I/O lines of the peripherals A and B are multiplexed on the PIO
Controllers.
Note that some output only peripheral functions might be duplicated within the tables.
7.7.1 PIO Controller A Multiplexing
Table 7-9. PIO Controller A Multiplexing
I/O Line Peripheral A Peripheral B
PA00 SPI0 - MISO SSC1 - RX_FRAME_SYNC
PA01 SPI0 - MOSI SSC1 - TX_FRAME_SYNC
PA02 SPI0 - SCK SSC1 - TX_CLOCK
PA03 SPI0 - NPCS[0] SSC1 - RX_CLOCK
PA04 SPI0 - NPCS[1] SSC1 - TX_DATA
PA05 SPI0 - NPCS[2] SSC1 - RX_DATA
PA06 TWI - SDA USART0 - RTS
PA07 TWI - SCL USART0 - CTS
PA08 PSIF - CLOCK USART0 - RXD
PA09 PSIF - DATA USART0 - TXD
PA10 MCI - CLK USART0 - CLK
PA11 MCI - CMD TC0 - CLK0
PA12 MCI - DATA[0] TC0 - A0
PA13 MCI - DATA[1] TC0 - A1
PA14 MCI - DATA[2] TC0 - A2
PA15 MCI - DATA[3] TC0 - B0
PA16 USART1 - CLK TC0 - B1
PA17 USART1 - RXD TC0 - B2
PA18 USART1 - TXD TC0 - CLK2
PA19 USART1 - RTS TC0 - CLK1
PA20 USART1 - CTS SPI0 - NPCS[3]
PA21 SSC0 - RX_FRAME_SYNC PWM - PWM[2]
PA22 SSC0 - RX_CLOCK PWM - PWM[3]
PA23 SSC0 - TX_CLOCK TC1 - A0
PA24 SSC0 - TX_FRAME_SYNC TC1 - A1
PA25 SSC0 - TX_DATA TC1 - B0
PA26 SSC0 - RX_DATA TC1 - B1
PA27 SPI1 - NPCS[3] TC1 - CLK0
PA28 PWM - PWM[0] TC1 - A2
AT32AP7002
32054AS–AVR32–02/07
25
Table 7-9. PIO Controller A Multiplexing
PA29 PWM - PWM[1] TC1 - B2
PA30 SM - GCLK[0] TC1 - CLK1
PA31 SM - GCLK[1] TC1 - CLK2
7.7.2 PIO Controller B Multiplexing
Table 7-10. PIO Controller B Multiplexing
I/O Line Peripheral A Peripheral B
PB00 ISI - DATA[0] SPI1 - MISO
PB01 ISI - DATA[1] SPI1 - MOSI
PB02 ISI - DATA[2] SPI1 - NPCS[0]
PB03 ISI - DATA[3] SPI1 - NPCS[1]
PB04 ISI - DATA[4] SPI1 - NPCS[2]
PB05 ISI - DATA[5] SPI1 - SCK
PB06 ISI - DATA[6] MCI - CMD[1]
PB07 ISI - DATA[7] MCI - DATA[4]
PB08 ISI - HSYNC MCI - DATA[5]
PB09 ISI - VSYNC MCI - DATA[6]
PB10 ISI - PCLK MCI - DATA[7]
PB11 PSIF - CLOCK[1] ISI - DATA[8]
PB12 PSIF - DATA[1] ISI - DATA[9]
PB13 SSC2 - TX_DATA ISI - DATA[10]
PB14 SSC2 - RX_DATA ISI - DATA[11]
PB15 SSC2 - TX_CLOCK USART3 - CTS
PB16 SSC2 - TX_FRAME_SYNC USART3 - RTS
PB17 SSC2 - RX_FRAME_SYNC USART3 - TXD
PB18 SSC2 - RX_CLOCK USART3 - RXD
PB19 SM - GCLK[2] USART3 - CLK
PB20 DAC - DATA[1] AC97C - SDO
PB21 DAC - DATA[0] AC97C - SYNC
PB22 DAC - DATAN[1] AC97C - SCLK
PB23 DAC - DATAN[0] AC97C - SDI
PB24 NMI_N DMAC - DMARQ[0]
PB25 EXTINT0 DMAC - DMARQ[1]
PB26 EXTINT1 USART2 - RXD
PB27 EXTINT2 USART2 - TXD
PB28 EXTINT3 USART2 - CLK
PB29 SM - GCLK[3] USART2 - CTS
PB30 SM - GCLK[4] USART2 - RTS
AT32AP7002
32054AS–AVR32–02/07
26
7.7.3 PIO Controller C Multiplexing
Table 7-11. PIO Controller C Multiplexing
I/O Line Peripheral A Peripheral B
PC20 LCDC - HSYNC
PC21 LCDC - PCLK
PC22 LCDC - VSYNC
PC23 LCDC - DVAL
PC28 LCDC - DATA[2]
PC29 LCDC - DATA[3]
PC30 LCDC - DATA[4]
PC31 LCDC - DATA[5]
AT32AP7002
7.7.4 PIO Controller D Multiplexing
PIO Controller D Multiplexing
Table 7-12. PIO Controller D Multiplexing
I/O Line Peripheral A Peripheral B
PD00 LCDC - DATA[6]
PD01 LCDC - DATA[7]
PD04 LCDC - DATA[10]
PD05 LCDC - DATA[11]
PD06 LCDC - DATA[12]
PD07 LCDC - DATA[13]
PD08 LCDC - DATA[14]
PD09 LCDC - DATA[15]
PD12 LCDC - DATA[18]
PD13 LCDC - DATA[19]
PD14 LCDC - DATA[20]
PD15 LCDC - DATA[21]
PD16 LCDC - DATA[22]
PD17 LCDC - DATA[23]
32054AS–AVR32–02/07
27
AT32AP7002
7.7.5 IO Pins Without Multiplexing
Many of the external EBI pins are not controlled by the PIO modules, but directly driven by the
EBI. These pins have programmable pullup resistors. These resistors are controlled by Special
Function Register 4 (SFR4) in the HMATRIX. The pullup on the lines multiplexed with PIO is
controlled by the appropriate PIO control register.
This SFR can also control CompactFlash, SmartMedia or NandFlash Support, see the EBI chapter for details
7.7.5.1 HMatrix SFR4 EBI Control Register
Name: HMATRIX_SFR4
Access Type: Read/Write
31 30 29 28 27 26 25 24
––––––––
23 22 21 20 19 18 17 16
––––––––
15 14 13 12 11 10 9 8
–––––––EBI_DBPUC
76543210
– – EBI_CS5A EBI_CS4A EBI_CS3A – EBI_CS1A -
• CS1A: Chip Select 1 Assignment
0 = Chip Select 1 is assigned to the Static Memory Controller.
1 = Chip Select 1 is assigned to the SDRAM Controller.
• CS3A: Chip Select 3 Assignment
0 = Chip Select 3 is only assigned to the Static Memory Controller and NCS3 behaves as
defined by the SMC.
1 = Chip Select 3 is assigned to the Static Memory Controller and the NAND Flash/SmartMedia
Logic is activated.
• CS4A: Chip Select 4 Assignment
0 = Chip Select 4 is assigned to the Static Memory Controller and NCS4, NCS5 and NCS6
behave as defined by the SMC.
1 = Chip Select 4 is assigned to the Static Memory Controller and the CompactFlash Logic is
activated.
• CS5A: Chip Select 5 Assignment
0 = Chip Select 5 is assigned to the Static Memory Controller and NCS4, NCS5 and NCS6
behave as defined by the SMC.
32054AS–AVR32–02/07
1 = Chip Select 5 is assigned to the Static Memory Controller and the CompactFlash Logic is
activated.
28
AT32AP7002
Accessing the address space reserved to NCS5 and NCS6 may lead to an unpredictable
outcome.
• EBI_DBPUC: EBI Data Bus Pull-up Control
0: EBI D[15:0] are internally pulled up to the VDDIO power supply.
enabled after reset.
1: EBI D[15:0] are not internally pulled up.
Table 7-13. IO Pins without multiplexing
I/O Line Function
PX00 EBI - DATA[0]
PX01 EBI - DATA[1]
PX02 EBI - DATA[2]
PX03 EBI - DATA[3]
PX04 EBI - DATA[4]
PX05 EBI - DATA[5]
PX06 EBI - DATA[6]
PX07 EBI - DATA[7]
PX08 EBI - DATA[8]
PX09 EBI - DATA[9]
PX10 EBI - DATA[10]
PX11 EBI - DATA[11]
PX12 EBI - DATA[12]
PX13 EBI - DATA[13]
PX14 EBI - DATA[14]
PX15 EBI - DATA[15]
PX16 EBI - ADDR[0]
PX17 EBI - ADDR[1]
PX18 EBI - ADDR[2]
PX19 EBI - ADDR[3]
PX20 EBI - ADDR[4]
PX21 EBI - ADDR[5]
PX22 EBI - ADDR[6]
PX23 EBI - ADDR[7]
PX24 EBI - ADDR[8]
PX25 EBI - ADDR[9]
PX26 EBI - ADDR[10]
PX27 EBI - ADDR[11]
PX28 EBI - ADDR[12]
PX29 EBI - ADDR[13]
PX30 EBI - ADDR[14]
PX31 EBI - ADDR[15]
The pull-up resistors are
32054AS–AVR32–02/07
29
Table 7-13. IO Pins without multiplexing (Continued)
PX32 EBI - ADDR[16]
PX33 EBI - ADDR[17]
PX34 EBI - ADDR[18]
PX35 EBI - ADDR[19]
PX36 EBI - ADDR[20]
PX37 EBI - ADDR[21]
PX38 EBI - ADDR[22]
PX39 EBI - NCS[0]
PX40 EBI - NCS[1]
PX41 EBI - NCS[3]
PX42 EBI - NRD
PX43 EBI - NWE0
PX44 EBI - NWE1
PX45 EBI - NWE3
PX46 EBI - SDCK
PX47 EBI - SDCKE
PX48 EBI - RAS
PX49 EBI - CAS
PX50 EBI - SDWE
PX51 EBI - SDA10
PX52 EBI - NANDOE
PX53 EBI - NANDWE
AT32AP7002
32054AS–AVR32–02/07
30
7.8 Peripheral overview
7.8.1 External Bus Interface
Optimized for Application Memory Space support
•
• Integrates Three External Memory Controllers:
– Static Memory Controller
– SDRAM Controller
– ECC Controller
• Additional Logic for NAND Flash/SmartMedia
– SmartMedia support: 8-bit as well as 16-bit devices are supported
– CompactFlash support: all modes (Attribute Memory, Common Memory, I/O, True IDE) are
supported but the signals _IOIS16 (I/O and True IDE modes) and _ATA SEL (True IDE mode)
are not handled.
• Optimized External Bus:
– 16- or 32-bit Data Bus
– Up to 26-bit Address Bus, Up to 64-Mbytes Addressable
– Optimized pin multiplexing to reduce latencies on External Memories
• Up to 6 Chip Selects, Configurable Assignment:
– Static Memory Controller on NCS0
– SDRAM Controller or Static Memory Controller on NCS1
– Static Memory Controller on NCS2
– Static Memory Controller on NCS3, Optional NAND Flash/SmartMedia
– Static Memory Controller on NCS4 - NCS5, Optional CompactFlash
7.8.2 Static Memory Controller
TM
and CompactFlashTM Support
TM
AT32AP7002
TM
Support
Support
•
• 64-Mbyte Address Space per Chip Select
• 8-, 16- or 32-bit Data Bus
• Word, Halfword, Byte Transfers
• Byte Write or Byte Select Lines
• Programmable Setup, Pulse And Hold Time for Read Signals per Chip Select
• Programmable Setup, Pulse And Hold Time for Write Signals per Chip Select
• Programmable Data Float Time per Chip Select
• Compliant with LCD Module
• External Wait Request
• Automatic Switch to Slow Clock Mode
• Asynchronous Read in Page Mode Supported: Page Size Ranges from 4 to 32 Bytes
7.8.3 SDRAM Controller
•
• Programming Facilities
6 Chip Selects Available
Numerous Configurations Supported
– 2K, 4K, 8K Row Address Memory Parts
– SDRAM with Two or Four Internal Banks
– SDRAM with 16- or 32-bit Data Path
– Word, Half-word, Byte Access
– Automatic Page Break When Memory Boundary Has Been Reached
– Multibank Ping-pong Access
– Timing Parameters Specified by Software
– Automatic Refresh Operation, Refresh Rate is Programmable
32054AS–AVR32–02/07
31
• Energy-saving Capabilities
– Self-refresh, Power-down and Deep Power Modes Supported
– Supports Mobile SDRAM Devices
• Error Detection
– Refresh Error Interrupt
• SDRAM Power-up Initialization by Software
• CAS Latency of 1, 2, 3 Supported
• Auto Precharge Command Not Used
7.8.4 Error Corrected Code Controller
Hardware Error Corrected Code (ECC) Generation
•
– Detection and Correction by Software
• Supports NAND Flash and SmartMedia
• Supports NAND Flash/SmartMedia with Page Sizes of 528, 1056, 2112 and 4224 Bytes, Specified
by Software
7.8.5 Serial Peripheral Interface
Supports communication with serial external devices
•
– Four chip selects with external decoder support allow communication with up to 15
peripherals
– Serial memories, such as DataFlash™ and 3-wire EEPROMs
– Serial peripherals, such as ADCs, DACs, LCD Controllers, CAN Controllers and Sensors
– External co-processors
• Master or slave serial peripheral bus interface
– 8- to 16-bit programmable data length per chip select
– Programmable phase and polarity per chip select
– Programmable transfer delays between consecutive transfers and between clock and data
per chip select
– Programmable delay between consecutive transfers
– Selectable mode fault detection
• Very fast transfers supported
– Transfers with baud rates up to MCK
– The chip select line may be left active to speed up transfers on the same device
7.8.6 Two-wire Interface
™
Devices with 8- or 16-bit Data Path.
AT32AP7002
32054AS–AVR32–02/07
Compatibility with standard two-wire serial memory
•
• One, two or three bytes for slave address
• Sequential read/write operations
32
7.8.7 USART
Programmable Baud Rate Generator
•
• 5- to 9-bit full-duplex synchronous or asynchronous serial communications
– 1, 1.5 or 2 stop bits in Asynchronous Mode or 1 or 2 stop bits in Synchronous Mode
– Parity generation and error detection
– Framing error detection, overrun error detection
– MSB- or LSB-first
– Optional break generation and detection
– By 8 or by-16 over-sampling receiver frequency
– Hardware handshaking RTS-CTS
– Receiver time-out and transmitter timeguard
– Optional Multi-drop Mode with address generation and detection
– Optional Manchester Encoding
• RS485 with driver control signal
• ISO7816, T = 0 or T = 1 Protocols for interfacing with smart cards
– NACK handling, error counter with repetition and iteration limit
• IrDA modulation and demodulation
– Communication at up to 115.2 Kbps
• Test Modes 46
– Remote Loopback, Local Loopback, Automatic Echo
7.8.8 Serial Synchronous Controller
AT32AP7002
•
• Contains an independent receiver and transmitter and a common clock divider
• Offers a configurable frame sync and data length
• Receiver and transmitter can be programmed to start automatically or on detection of different
• Receiver and transmitter include a data signal, a clock signal and a frame synchronization signal
7.8.9 AC97 Controller
•
• Capable to Interface with a Single Analog Front end
• Three independent RX Channels and three independent TX Channels
• Time Slot Assigner allowing to assign up to 12 time slots to a channel
• Channels support mono or stereo up to 20 bit sample length - Variable sampling rate AC97 Codec
Provides serial synchronous communication links used in audio and telecom applications (with
CODECs in Master or Slave Modes, I2S, TDM Buses, Magnetic Card Reader, etc.)
event on the frame sync signal
Compatible with AC97 Component Specification V2.2
– One RX and one TX channel dedicated to the AC97 Analog Front end control
– One RX and one TX channel for data transfers, connected to the DMAC
– One RX and one TX channel for data transfers, connected to the DMAC
Interface (48KHz and below)
32054AS–AVR32–02/07
33
7.8.10 Audio DAC
Digital Stereo DAC
•
• Oversampled D/A conversion architecture
– Oversampling ratio fixed 128x
– FIR equalization filter
– Digital interpolation filter: Comb4
– 3rd Order Sigma-Delta D/A converters
• Digital bitstream outputs
• Parallel interface
• Connected to DMA Controller for background transfer without CPU intervention
7.8.11 Timer Counter
Three 16-bit Timer Counter Channels
•
• Wide range of functions including:
– Frequency Measurement
– Event Counting
– Interval Measurement
– Pulse Generation
– Delay Timing
– Pulse Width Modulation
– Up/down Capabilities
• Each channel is user-configurable and contains:
– Three external clock inputs
– Five internal clock inputs
– Two multi-purpose input/output signals
• Two global registers that act on all three TC Channels
7.8.12 Pulse Width Modulation Controller
AT32AP7002
4 channels, one 16-bit counter per channel
•
• Common clock generator, providing Thirteen Different Clocks
– A Modulo n counter providing eleven clocks
– Two independent Linear Dividers working on modulo n counter outputs
• Independent channel programming
– Independent Enable Disable Commands
– Independent Clock
– Independent Period and Duty Cycle, with Double Bufferization
– Programmable selection of the output waveform polarity
– Programmable center or left aligned output waveform
32054AS–AVR32–02/07
34
7.8.13 Multimedia Card Interface
2 double-channel Multimedia Card Interface, allowing concurrent transfers with 2 cards
•
• Compatibility with MultiMedia Card Specification Version 2.2
• Compatibility with SD Memory Card Specification Version 1.0
• Compatibility with SDIO Specification Version V1.0.
• Cards clock rate up to Master Clock divided by 2
• Embedded power management to slow down clock rate when not used
• Each MCI has two slot, each supporting
– One slot for one MultiMediaCard bus (up to 30 cards) or
–One SD Memory Card
• Support for stream, block and multi-block data read and write
7.8.14 PS/2 Keyboard Interface
Peripheral Bus slave
•
• PS/2 Host
• Receive and transmit capability
• Parity generation and error detection
• Overrun error detection
7.8.15 USB Device Port
AT32AP7002
7.8.16 LCD Controller
USB V2.0 high-speed compliant, 480 Mbits per second
•
• Embedded USB V2.0 high-speed transceiver
• Embedded dual-port RAM for endpoints
• Suspend/Resume logic
• Ping-pong mode (two memory banks) for isochronous and bulk endpoints
• Six general-purpose endpoints
– Endpoint 0, Endpoint 3: 8 bytes, no ping-pong mode
– Endpoint 1, Endpoint 2: 64 bytes, ping-pong mode
– Endpoint 4, Endpoint 5: 256 bytes, ping-pong mode
Single and Dual scan color and monochrome passive STN LCD panels supported
•
• Single scan active TFT LCD panels supported
• 4-bit single scan, 8-bit single or dual scan, 16-bit dual scan STN interfaces supported
• Up to 24-bit single scan TFT interfaces supported
• Up to 16 gray levels for mono STN and up to 4096 colors for color STN displays
• 1, 2 bits per pixel (palletized), 4 bits per pixel (non-palletized) for mono STN
• 1, 2, 4, 8 bits per pixel (palletized), 16 bits per pixel (non-palletized) for color STN
• 1, 2, 4, 8 bits per pixel (palletized), 16, 24 bits per pixel (non-palletized) for TFT
• Single clock domain architecture
• Resolution supported up to 2048x2048
• 2D-DMA Controller for management of virtual Frame Buffer
– Allows management of frame buffer larger than the screen size and moving the view over this
virtual frame buffer
• Automatic resynchronization of the frame buffer pointer to prevent flickering
• Configurable coefficients with flexible fixed-point representation.
32054AS–AVR32–02/07
35
•
7.8.17 Image Sensor Interface
•
ITU-R BT. 601/656 8-bit mode external interface support
• Support for ITU-R BT.656-4 SAV and EAV synchronization
• Vertical and horizontal resolutions up to 2048 x 2048
• Preview Path up to 640*480
• Support for packed data formatting for YCbCr 4:2:2 formats
• Preview scaler to generate smaller size image 50
• Programmable frame capture rate
AT32AP7002
32054AS–AVR32–02/07
36
8. Boot Sequence
This chapter summarizes the boot sequence of the AT32AP7002. The behaviour after power-up
is controlled by the Power Manager.
8.1 Starting of clocks
After power-up, the device will be held in a reset state by the Power-On Reset circuitry, until the
power has stabilized throughout the device. Once the power has stabilized, the device will use
the XIN0 pin as clock source. XIN0 can be connected either to an external clock, or a crystal.
The OSCEN_N pin is connected either to VDD or GND to inform the Power Manager on how the
XIN0 pin is connected. If XIN0 receives a signal from a crystal, dedicated circuitry in the Power
Manager keeps the part in a reset state until the oscillator connected to XIN0 has settled. If XIN0
receives an external clock, no such settling delay is applied.
On system start-up, the PLLs are disabled. All clocks to all modules are running. No clocks have
a divided frequency, all parts of the system recieves a clock with the same frequency as the
XIN0 clock.
8.2 Fetching of initial instructions
After reset has been released, the AVR32AP CPU starts fetching instructions from the reset
address, which is 0xA000_0000. This address lies in the P2 segment, which is non-translated,
non-cacheable, and permanently mapped to the physical address range 0x0000_0000 to
0x2000_0000. This means that the instruction being fetched from virtual address 0xA000_0000
is being fetched from physical address 0x0000_0000. Physical address 0x0000_0000 is
mapped to EBI SRAM CS0. This is the external memory the device boots from.
AT32AP7002
The code read from the SRAM CS0 memory is free to configure the system to use for example
the PLLs, to divide the frequency of the clock routed to some of the peripherals, and to gate the
clocks to unused peripherals.
32054AS–AVR32–02/07
37
AT32AP7002
9. Ordering Information
Figure 9-1. Ordering Information
Temperature
Ordering Code Package Package Type Packing
AT32AP7002-CTUR CTBGA196 Green Reel Industrial (-40°C to 85°C)
AT32AP7002-CTUT CTBGA196 Green Tray Industrial (-40°C to 85°C)
Operating Range
32054AS–AVR32–02/07
38
10. Errata
10.1 Rev. C
AT32AP7002
1. SPI FDIV option does not work
Selecting clock signal using FDIV = 1 does not work as specified.
Fix/Workaround
Do not set FDIV = 1.
2. SPI Chip Select 0 BITS field overrides other Chip Selects
The BITS field for Chip Select 0 overrides BITS fields for other Chip selects.
Fix/Workaround
Update Chip Select 0 BITS field to the relevant settings before transmitting with Chip Selects
other than 0.
3. SPI LASTXFER may be overwritten
When Peripheral Select (PS) = 0, the LASTXFER-bit in the Transmit Data Register (TDR)
should be internally discared. This fails and may cause problems during DMA transfers.
Transmitting data using the PDC when PS=0, the size of the transferred data is 8- or 16-bits.
The upper 16 bits of the TDR will be written to a random value. If Chip Select Active After
Transfer (CSAAT) = 1, the behavior of the Chip Select will be unpredictable.
Fix/Workaround
- Do not use CSAAT = 1 if PS = 0
- Use GPIO to control Chip Select lines
- Select PS=1 and store data for PCS and LASTXFER for each data in transmit buffer.
4. SPI LASTXFER overrides Chip Select
The LASTXFER bit overrides Chip Select input when PS = 0 and CSAAT is used.
Fix/Workaround
- Do not use the CSAAT
- Use GPIO as Chip Select input
- Select PS = 1. Transfer 32-bit with correct LASTXFER settings.
5. MMC data drite operation with less than 12 bytes is impossible.
The Data Write operation with a number of bytes less than 12 is impossible
Fix/Workaround
The PDC counters must always be equal to 12 bytes for data transfers lower than 12 bytes.
The BLKLEN or BCNT field are used to specify the real count number.
6. MMC SDIO interrupt only works for slot A
If 1-bit data bus width and on other slots than slot A, the SDIO interrupt can not be captured.
32054AS–AVR32–02/07
Fix/Workaround
Use slot A.
39
AT32AP7002
7. PSIF TXEN/RXEN may disable the transmitter/receiver
Writing a '0' to RXEN will disable the receiver. Writing '0' to TXEN will disable the transmitter.
Fix/Workaround
When accessing the PS/2 Control Register always write '1' to RXEN to keep the receiver
enabled, and write '1' to TXEN to keep the transmitter enabled.
8. PSIF TXRDY interrupt corrupts transfers
When writing to the Transmit Holding Register (THR), the data will be transferred to the data
shift register immediately, regardless of the state of the data shift register. If a transfer is
ongoing, it will be interrupted and a new transfer will be started with the new data written to
THR.
Fix/Workaround
Use the TXEMPTY-interrupt instead of the TXRDY-interrupt to update the THR. This
ensures that a transfer is completed.
9. LCD memory error interupt does not work
Writing to the MERIT-bit in the LCD Interrupt Test Register (ITR) does not cause an interrupt
as intended. The MERIC-bit in the LCD Interrupt Clear Register (ICR) cannot be written.
This means that if the MERIS-bit in ISR is set, it cannot be cleared.
Fix/Workaround
Memory error interrupt should not be used.
10. PWN counter restarts at 0x0001
The PWN counter restarts at 0x0001 and not 0x0000 as specified. Because of this the first
PWM period has one more clock cycle.
Fix/Workaround
- The first period is 0x0000, 0x0001, ..., period
- Consecutive periods are 0x0001, 0x0002, ..., period
11. PWM channel interrupt enabling triggers an interrupt
When enabling a PWM channel that is configured with center aligned period (CALG=1), an
interrupt is signalled.
Fix/Workaround
When using center aligned mode, enable the channel and read the status before channel
interrupt is enabled.
12. PWM update period to a 0 value does not work
It is impossible to update a period equal to 0 by the using the PWM update register
(PWM_CUPD).
Fix/Workaround
Do not update the PWM_CUPD register with a value equal to 0.
32054AS–AVR32–02/07
13. PWM channel status may be wrong if disabled before a period has elapsed
Before a PWM period has elapsed, the read channel status may be wrong. The CHIDx-bit
for a PWM channel in the PWM Enable Register will read '1' for one full PWM period even if
the channel was disabled before the period elapsed. It will then read '0' as expected.
40
10.2 Rev. B
10.3 Rev. A
AT32AP7002
Fix/Workaround
Reading the PWM channel status of a disabled channel is only correct after a PWM period
14. TWI transfer error without ACK
If the TWI does not receive an ACK from a slave during the address+R/W phase, no bits in
the status register will be set to indicate this. Hence, the transfer will never complete.
Fix/Workaround
To prevent errors due to missing ACK, the software should use a timeout mechanism to terminate the transfer if this happens.
Not sampled.
Not sampled.
32054AS–AVR32–02/07
41
11. Datasheet Revision History
Please note that the referring page numbers in this section are referred to this document. The
referring revision in this section are referring to the document revision.
11.1 Rev. A 02/07
1. Initial revision.
AT32AP7002
32054AS–AVR32–02/07
42
Table of Contents
AT32AP7002
1 Part Description ....................................................................................... 2
2 Blockdiagram ........................................................................................... 4
2.1 Processor and architecture ......................................................................................5
3 Package and Pinout ................................................................................. 8
4 Signals Description ............................................................................... 10
5 Power Considerations ........................................................................... 16
5.1 Power Supplies ......................................................................................................16
5.2 Power Supply Connections ....................................................................................16
6 I/O Line Considerations ......................................................................... 17
6.1 JTAG pins ............................................................................................................... 17
6.2 WAKE_N pin .......................................................................................................... 17
6.3 RESET_N pin ......................................................................................................... 17
6.4 EVTI_N pin .............................................................................................................17
6.5 TWI pins .................................................................................................................17
6.6 PIO pins ..................................................................................................................17
7 Memories ................................................................................................ 19
7.1 Embedded Memories .............................................................................................19
7.2 Physical Memory Map ............................................................................................ 19
8 Peripherals ............................................................................................. 21
8.1 Peripheral address map .........................................................................................21
8.2 Interrupt Request Signal Map ................................................................................. 23
8.3 DMAC Handshake Interface Map ........................................................................... 25
8.4 Clock Connections .................................................................................................25
8.5 External Interrupt Pin Mapping ............................................................................... 26
8.6 Nexus OCD AUX port connections ........................................................................ 27
8.7 Peripheral Multiplexing on IO lines .........................................................................27
8.8 Peripheral overview ................................................................................................ 34
9 Boot Sequence ....................................................................................... 40
32054AS–AVR32–02/07
9.1 Starting of clocks .................................................................................................... 40
9.2 Fetching of initial instructions .................................................................................40
10 Ordering Information ............................................................................. 41
i
11 Revision History ..................................................................................... 42
11.1 Rev. D 04/06 ........................................................................................................42
11.2 Rev. C 04/06 ........................................................................................................42
ii
AT32AP7002
32054AS–AVR32–02/07
Atmel Corporation Atmel Operations
2325 Orchard Parkway
San Jose, CA 95131, USA
Tel: 1(408) 441-0311
Fax: 1(408) 487-2600
Regional Headquarters
Europe
Atmel Sarl
Route des Arsenaux 41
Case Postale 80
CH-1705 Fribourg
Switzerland
Tel: (41) 26-426-5555
Fax: (41) 26-426-5500
Asia
Room 1219
Chinachem Golden Plaza
77 Mody Road Tsimshatsui
East Kowloon
Hong Kong
Tel: (852) 2721-9778
Fax: (852) 2722-1369
Japan
9F, Tonetsu Shinkawa Bldg.
1-24-8 Shinkawa
Chuo-ku, Tokyo 104-0033
Japan
Tel: (81) 3-3523-3551
Fax: (81) 3-3523-7581
Memory
2325 Orchard Parkway
San Jose, CA 95131, USA
Tel: 1(408) 441-0311
Fax: 1(408) 436-4314
Microcontrollers
2325 Orchard Parkway
San Jose, CA 95131, USA
Tel: 1(408) 441-0311
Fax: 1(408) 436-4314
La Chantrerie
BP 70602
44306 Nantes Cedex 3, France
Tel: (33) 2-40-18-18-18
Fax: (33) 2-40-18-19-60
ASIC/ASSP/Smart Cards
Zone Industrielle
13106 Rousset Cedex, France
Tel: (33) 4-42-53-60-00
Fax: (33) 4-42-53-60-01
1150 East Cheyenne Mtn. Blvd.
Colorado Springs, CO 80906, USA
Tel: 1(719) 576-3300
Fax: 1(719) 540-1759
Scottish Enterprise Technology Park
Maxwell Building
East Kilbride G75 0QR, Scotland
Tel: (44) 1355-803-000
Fax: (44) 1355-242-743
RF/Automotive
Theresienstrasse 2
Postfach 3535
74025 Heilbronn, Germany
Tel: (49) 71-31-67-0
Fax: (49) 71-31-67-2340
1150 East Cheyenne Mtn. Blvd.
Colorado Springs, CO 80906, USA
Tel: 1(719) 576-3300
Fax: 1(719) 540-1759
Biometrics/Imaging/Hi-Rel MPU/
High Speed Converters/RF Datacom
Avenue de Rochepleine
BP 123
38521 Saint-Egreve Cedex, France
Tel: (33) 4-76-58-30-00
Fax: (33) 4-76-58-34-80
Literature Requests
www.atmel.com/literature
Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any
intellectual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN ATMEL’S TERMS AND CONDI-
TIONS OF SALE LOCATED ON ATMEL’S WEB SITE, ATMEL ASSUMES NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY
WARRANTY RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, OR NON-INFRINGEMENT. IN NO EVENT SHALL ATMEL BE LIABLE FOR ANY DIRECT, INDIRECT, CONSEQUENTIAL, PUNITIVE, SPECIAL OR INCIDENTAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, OR LOSS OF INFORMATION) ARISING OUT
OF THE USE OR INABILITY TO USE THIS DOCUMENT, EVEN IF ATMEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Atmel makes no
representations or warranties with respect to the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications
and product descriptions at any time without notice. Atmel does not make any commitment to update the information contained herein. Unless specifically provided
otherwise, Atmel products are not suitable for, and shall not be used in, automotive applications. Atmel’s products are not intended, authorized, or warranted for use
as components in applications intended to support or sustain life.
© 2007 Atmel Corporation. All rights reserved. AT ME L®, logo and combinations thereof, Everywhere You Are®, AVR®, AVR Studio®, and oth-
ers, are registered trademarks or trademarks of Atmel Corporation or its subsidiaries. Other terms and product names may be trademarks of others.
32054AS–AVR32–02/07
Loading...
