Atlona Technologies AT-UHD-CAT-2 Datasheet

4K/UHD

HDMI to HDBaseT Distribution Amplier

TM

Introduction

The Atlona AT-UHD-CAT-2 is a 4K/UHD HDMI to HDBaseT distribution amplier featuring pass-through HDMI input
connections, two HDBaseT outputs and display control capability. Each output transmits AV and control signals
up to 230 ft. (70 m) @ 1080p and 130 ft. (40 m) @ 4K/UHD. Features include 4K/UHD @ 60 Hz with 4:2:0 color
subsampling, HDCP 2.2 compliance, EDID management, and PoE for powering remote receivers. A wide variety
of consumer displays may be controlled by the UHD-CAT-2 using CEC. Designed for commercial distribution
applications, the UHD-CAT-2 is control system-friendly and integrates with any TCP/IP, RS-232, or IR control system
and features a 1U, half-rack width enclosure with external, international power supply. Compatible Atlona receiver:
AT-UHD-EX-70C-RX.

Signal distribution applications increasingly require compatibility with HDCP 2.2, 4K/UHD @ 60 Hz support with 4:2:0
color subsampling to ensure images reach displays with compatible copy protection and with the pristine digital
image quality of the original signal, without artifacts resulting from inferior image distribution systems. HDBaseT
distribution ensures reliable, long-distance transmission of high resolution audio and video signals.
These core features along with added display control provide additional exibility. Power over Ethernet not only
provides compatibility with Atlona Extender products but enables HDBaseT Certication.

Applications

• Retail, restaurant, and entertainment environments that need long distance signal extension of high-impact
messages and program information.

• TV showrooms that demand the highest quality signal be delivered to each 4K television to entice customers to
make an immediate purchase decision.

• Any single image/multi-screen environment that requires display control.

AT-UHD-CAT-2

1

Key Features

4K/UHD

TM

HDMI to HDBaseT Distribution Amplier

HDMI distribution amplier with built-in HDBaseT

transmission

• Combines signal distribution and long distance
transmission into a single enclosure; eliminates
several devices and power supplies.

• Reduces overall system costs, speeds installation,
and prevents compatibility issues.

• HDMI input with pass-through.

Two HDBaseT outputs for transmission of HDMI,
power, and control up to 230 feet (70 meters)

• Long distance, 230 foot (70 m) outputs oer
bidirectional extension of both RS-232 and IR control
plus remote receiver power.

• Compatible receiver: AT-UHD-EX-70C-RX.

• RS-232 and IR insertion ports for each HDBaseT
output.

• Reduces multiple, separate cable runs down to a

single category cable per display, shrinking cable
bundles and required conduit capacity to reduce
cost of installation.

4K/UHD capability with HDCP 2.2 copy protection

• Compatible with ultra-high denition sources and
displays; adheres to latest content protection
specication.

• Ensures AV distribution systems are ready for 4K/
UHD streaming services and playback devices.

Power over Ethernet (PoE) for HDBaseT receivers

• Supplies industry standard IEEE 802.3af PoE over
HDBaseT to the UHD-EX-70C-RX or compatible
HDBaseT receivers.

• Allows convenient receiver installation at a display or
projector without the need for local AC power.

EDID management

• Manages EDID communications with the source
through a display’s EDID or internally stored EDID.

• Ensures desired audio formats and video resolutions
are provided to the AV system.

Intuitive GUI-based conguration using integrated
web server

• Oers menu-based conguration of network
settings, RS-232 settings, EDID, and HDCP
management.

• Allows fast conguration of internal product settings
and troubleshooting from a mobile device or PC in
the eld.

TCP/IP, RS-232, and IR control

• Flexible control options for compatibility with the
Atlona Velocity™ control system, as well as other

third-party control systems.

• Reduces integration time and costs.

Easy to congure and manage with AMS (Atlona
Management System)

• Centralized, network-based conguration and
management of Atlona IP-controllable products and

systems.

• Manage conguration and rmware updates for AV

devices spanning a facility, building, enterprise, or

residence.

• Available as a cost-eective server appliance, or a

free software download.

CEC display control

• Sends CEC display power on/o control over
HDBaseT.

• Enables control of displays connected to UHD-

EX-70C-RX receivers (as supported by the display
manufacturer).

• CEC control can be triggered by using either the
front-panel button as well as using IP or RS-232

control commands.

AT-UHD-CAT-2

2

4K/UHD

HDMI to HDBaseT Distribution Amplier

TM

Specications

Video

HDMI Specication HDMI 1.4, HDCP 2.2

UHD/HD 4096×2160 (DCI)@60/50

9.97/30/50/59.94/60 Hz, 1080i@25/29.97/30 Hz, 720p@30/50/59.94/60 Hz

VESA 2560×2048, 2560×1600, 2048×1536, 1920×1200, 1680×1050, 1600×1200, 1600×900, 1440×900,

1400×1050, 1366×768, 1360×768, 1280×1024, 1280×800 1280×768, 1152×768, 1024×768, 800×600,
640×480

Color Space YUV, RGB

Chroma Subsampling 4:4:4, 4:2:2, 4:2:0

Color Depth 8-bit, 10-bit, 12-bit

Audio

Pass-through PCM 2Ch, LPCM 5.1, LPCM 7.1, Dolby® Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, Dolby

Atmos®, DTS®, DTS-HD Master Audio™, DTS:X

Sample Rate 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz

Bit Depth Up to 24-bit

(1)

/30/25/24 Hz, 3840×2160(UHD)@60/50

(1)

/24/25/30 Hz, 1080p@23.98/24/25/2

Protocols

Addressing DHCP, static

Management HTTP, Telnet

Control

CEC Supported from control systems

RS-232 Device control and conguration; supports baud rates from 2400 to 115200

IR Pass-through from control system to sink device

Connectors

HDMI IN 1 - Type A, 19-pin female

HDMI OUT 1 - Type A, 19-pin female

FW 1 - mini-USB

HDBaseT OUT 2 - RJ45

LAN 1 - RJ45, 10/100/1000 Mbps

RS-232 / IR 3 - captive screw, 5-pin; master RS-232 / IR, and pass-through on port 2 and 3

DC 48V 1 - 3-pin DIN

Indicators and Controls

Control Buttons:

POWER, EDID

LED Indicators:

HDMI IN/OUT, HDBaseT (1,2), LOCK,
INT, LEARN

Bidirectional pass-through from control system to sink device

Pass-through from viewing location to source

2 - momentary, tact-type

7 - LED, blue

AT-UHD-CAT-2

3

4K/UHD

HDMI to HDBaseT Distribution Amplier

TM

Resolution / Distance 4K/UHD - Feet / Meters 1080p - Feet / Meters

HDMI IN/OUT 15 5 30 10

CAT5e/6 115 35 200 60

CAT6a/7 130 40 230 70

Power

Consumption 52.8 W

Idle Consumption 12.6 W

External Power Supply Input: 100 - 240 V AC, 50/60 Hz

Safety CE, FCC, Level IV, cULus, RoHS, RCM, CCC

Environmental

Operating Temperature +32 to +122 °F

Storage Temperature -4 to +140 °F

Operating Humidity (RH) 20% to 95%, non-condensing

Output: 48 V DC, 3.125 A

0 to +50 °C

-20 to +60 °C

Chassis

Dimensions (H x W x D) 1.73 in x 8.75 in x 10.28 in

Weight 3.70 lbs / 1.66 kg

Safety CE, RoHS, FCC

(1) 4096x2160 @ 50/60 Hz and 3840x2160 @ 50/60 Hz only supports 4:2:0 8-bit chroma subsampling.

44 mm x 222 mm x 261 mm
