4K / HDR
Eight-Output HDMI Distribution Amplifer
Introduction
The Atlona Rondo™ 448 (AT-RON-448) is a 1x8 HDMI distribution amplier for high dynamic range (HDR) formats.
It is HDCP 2.2 compliant and supports 4K/UHD video @ 60 Hz with 4:4:4 chroma sampling, as well as HDMI data
rates up to 18 Gbps. The Rondo 448 is ideal for applications requiring the latest as well as emerging 4K/UHD and
HDR sources and displays. It is compatible with all video resolutions, audio formats, and color space formats
supported in the HDMI 2.0b specication, plus the ability to pass metadata for HDR content. This Rondo Series
HDMI distribution amplier includes EDID management features, front panel LED indicators for power and signal
status, audio de-embedding to analog and coaxial S/PDIF audio outputs, and the capability to cascade several units
without compromising performance.
Applications
• Residential installations
The Rondo 448 is designed for AV systems with the latest UHD and HDR sources such as Ultra HD Blu-ray
players, plus compatible televisions and projectors.
• TV showrooms
The Rondo 448 can be used for reliable content distribution to televisions, to properly demonstrate the quality
and appeal of 4K and HDR programming.
• Professional AV applications
Atlona 4K HDR products are ideal for full-motion, highly detailed 4K graphics presentations for visualization,
3D renderings, simulations, and more.
AT-RON-448
1
4K / HDR
Eight-Output HDMI Distribution Amplifer
Key Features
1x8 HDMI distribution amplier
• Delivers high performance, reliable HDMI signal distribution.
• Easy to install and deploy in commercial and residential applications.
4K/UHD capability @ 60 Hz with 4:4:4 chroma sampling, plus support for HDR formats
• Ideal for new and emerging 4K/UHD and HDR-capable sources and displays.
• Fully supports video resolutions, audio formats, and color space formats in the HDMI 2.0b specication.
HDCP 2.2 compliant
• Adheres to latest specication for High-bandwidth Digital Content Protection.
• Allows protected content stream to pass between devices.
EDID management
• Manages EDID communications with the source through a display’s EDID or internally stored EDID.
• Ensures desired audio formats and video resolutions are provided to the AV system.
Supports cascading up to eight units
• Combine multiple Rondo 448 and other Rondo Series distribution ampliers without compromising performance
or reliability.
• System designs and congurations can easily be adapted or modied as needed.
HDMI audio de-embedding
• Extracts HDMI two-channel PCM audio to the unbalanced analog stereo output, and two-channel PCM or multichannel bitstream audio to the coaxial S/PDIF digital output.
• Provides an additional integration option for AV receivers and whole-house audio systems.
Front panel power and signalstatus LEDs
• LED indicators provide power and HDMI input / output signal status information.
• Provides easy setup and troubleshooting.
AT-RON-448
2
4K / HDR
Eight-Output HDMI Distribution Amplifer
Specications
Video
HDMI Specication HDMI 2.0, HDCP 2.2
Maximum TMDS Clock 600 MHz
UHD/HD 4096×2160(DCI)@60/30/24 Hz, 3840×2160(UHD)@60/50/24/25/30 Hz, 1080p@23.98/24/25/29.97/30/5
VESA 2560×2048, 2560×1600, 2048×1536, 1920×1200, 1680×1050, 1600×1200, 1600×900, 1440×900,
Color Space YUV, RGB
Chroma Subsampling 4:4:4, 4:2:2, 4:2:0
Color Depth 8-bit, 10-bit, 12-bit
HDR HDR10 , Hybrid Log-Gamma (HLG), and Dolby® Vision™ @ 60Hz
0/59.94/60 Hz, 1080i@25/29.97/30 Hz, 720p@30/50/59.94/60 Hz
1400×1050, 1366×768, 1360×768, 1280×1024, 1280×800 1280×768, 1152×768, 1024×768, 800×600,
640×480
Audio
Pass-through PCM 2Ch, LPCM 5.1, LPCM 7.1, Dolby® Digital, DTS® 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD
Sample Rate 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Bit Depth Up to 24-bit
Connectors
HDMI IN 1 - Type A, 19-pin female
HDMI OUTPUT 8 - Type A, 19-pin female
ANALOG OUTPUT 1 - captive screw, 5-pin
SPDIF OUTPUT 1 - RCA-type, female
FW 1 - Mini-USB, Type-A
MAIN 1 - locking connector, female
BACKUP 1 - locking connector, female
Indicators and Controls
Power LED indicators 2 - LED, red (M, B)
Output LED indicators 8 - LED, blue ( 1 - 8)
EDID LED indicators 2 - LED, blue (INT, LEARN)
EDID 1 - momentary, tact-type
Resolution / Distance 4K/UHD - Feet / Meters 1080p - Feet / Meters
HDMI IN/OUT 15 5 30 10
Master Audio™, Dolby Atmos®, DTS:X
Power
Power Input: AC100-240V ~ 50/60Hz
Output: DC 5V
Consumption 6.75 W
Safety CE, FCC, cULus
AT-RON-448
3
4K / HDR
Eight-Output HDMI Distribution Amplifer
Environmental
Operating Temperature 32 to +122 °F
Storage Temperature -4 to +140 °F
Operating Humidity (RH) 20% to 90%, non-condensing
Chassis
Dimensions (H x W x D) 1.73 in x 17.07 in x 10.03 in
Weight 5.7 lbs / 2.61 kg
Safety CE, RoHS, FCC
0 to +50 °C
-20 to +60 °C
44 mm x 433.8 mm x 255 mm
