User Manual
RS232 Extender over cat5 up to 1000ft
AT-RS232SRS
Toll free: 1-877-536-3976
Local: 1-408-962-0515
www.atlona.com
TABLE OF CONTENTS
1. Introduction .................................................. 2
2. Application .................................................. 2
3. Package Contents .................................................. 2
4. System require .................................................. 2
5. Hardware Installation .................................................. 2
6. Features .................................................. 3
7. Specification .................................................. 3
8. Connection Diagram .................................................. 4
9. Safety Information .................................................. 5
10. Warranty .................................................. 6
11. Atlona Product Registration .................................................. 7
Toll free: 1-877-536-3976
Local: 1-408-962-0515
1
www.atlona.com
INTRODUCTION
Atlona Technologies’ extender unit is an affordable solution providing control of any RS-232 protocol device.
With regular RS-232 devices you are limited to an immediate area of control while this Atlona unit extends control over 250 meters. Atlona’s RS-232 extender also provides full duplex transmission and hardware handshake
signals, with no need for configuration.
APPLICATION
• System installation.
• System controlling.
PACKAGE CONTENTS
• Unit Transmitter.
• Unit Receiver.
• 5V DC power adaptor.
• Operation Manual.
SYSTEM REQUIRE
Input PC/laptop equipment, RS-232 (DB 9) female to male cable x 2, CAT 5 cable and output source device.
HARDWARE INSTALLATION
1 2 3
Transmitter
1. Connect to PC/laptop’s main control system with RS232 (DB 9) female to male cable for sending protocol
to source device.
2. Connect with CAT 5 cable up to 250M and link to Receiver’s CAT 5 connector.
3. Connect the 5V DC power adaptor into the unit and plug the adaptor to an AC wall outlet.
Note: Only one adaptor is needed for both Transmitter and Receiver.
