1 x 10 Component Video with Stereo and
Digital Audio Distribution Amplifier
over CAT5/6 compatible with AT-COMP300RL
AT-COMP10SS
Toll free: 1-877-536-3976
Local: 1-408-962-0515
User Manual
www.atlona.com
TABLE OF CONTENTS
1. Introduction 2
2. Features 2
3. Package Contents 2
4. Specifications 3
5. Connection and Operation 3
6. RJ45 Pin Configuration 4
7. Troubleshooting 4
8. LED Indicators 5
9. DIP Switch 5
10. Safety Information 6
11. Warranty 7
12. Atlona Product Registration 8
Toll free: 1-877-536-3976
Local: 1-408-962-0515
1
www.atlona.com
INTRODUCTION
The Atlona AT-COMP10SS is 1 x 10 Component Video with Stereo and Digital Audio Distribution Amplifier
designed to accept a video and audio feed from Component Video source such as DVD player, Cable/Sat Box,
media player or digital signage player and distribute the same feed to 10+ locations. The COMP10SS is featured with 1 x Component/Audio input and 10 x CAT5/6/7 outputs which could be connected with Atlona
AT-COMP300RL receiving modules up to 1000ft away.
The COMP10SS is also featured with local Component and audio outputs, meant to either connect to a local
display for monitoring or daisy chaining to another COMP10SS amplifier.
Note: Receiving models AT-COMP300RL are required accessories.
FEATURES
• Transmits Component with Stereo Audio and Digital Audio (optical and S/PDIF) (up to 1000ft away to 10+
locations)
• Supports Full HD Video with resolutions up to 1080p
• Compatible with AT-COMP300RL – receiving module
• Local Component/Audio output for local monitoring display or daisy chaining ability to go to another
AT-COMP10SS
• Extension Distance up to 1000ft: 1080p @1000ft; 1080i/720p @ 1250ft; 480p @1400ft
• Rack Mountable – 1U
PACKAGE CONTENTS
• 1 x AT-COMP10SS (transmitter module)
• 1 x 5v Power supplies (Universal 110/240V)
• 1 x Set of Wall Mounting Ears
• 1 x Instructions manual
