Atlas Sound VP14 User Manual

Leave Would-be Perpetrators
Powerless

The VP14 vandal resistant, slanted wall mount
baffle, finished in attractive, neutral beige, is
ideal for use in high-security areas such as
schools and correctional facilities. Its sturdy,
14-gauge baffle construction and specially
designed protective labyrinth screen protects
the enclosed speaker assembly against abuse.
Each package contains a high-quality 8"
diameter loudspeaker with a 10-ounce ceramic
magnet complete with factory assembled
25V/70.7V transformer including four power
taps (.5, 1, 2 & 4 Watts). The VP14 exhibits a
wide frequency response with low distortion.

More and more jobs in secured facilities are
using surface mount raceways due to continu­al building expansions and retrofits. To accom­modate for this, the VP14 includes an adapter
to comply with Wiremold 500 and 700 series
conduit. This adapter can be installed securely
through any of the standard

3

⁄4" knockouts that
are included on all four sides of the VP14. This
provides for a cleaner installation where sur­face mount raceways are required. All knock­outs are finished completely flush before the
enclosure is painted making them invisible to
any would-be perpetrator.

Features

• Attractive Design is Suitable for Use in a Variety
of Surface-Mount Vandal Proof Applications

• Wire Mold 500 & 700 Series Compatible

• Durable All-steel Construction

• Impermeable Security Grille Protects Speaker

• Attractive Finish

• 9.5° Sloped Design Offers Directional Sound
Projection

• Includes High-Quality 8" Loudspeaker with 25V/70.7V
Line Transformer

VP14

VP14

Shown with wire mold

adapter included

AAttllaass SSoouunndd..ccoomm 8800 00..887766 ..33333333

VP14 Vandal-Proof

Speaker System

1601 Jack McKay Blvd.
Ennis,TX 75119

AtlasSound.com

Tech Support 800.876.3333

Printed in the USA
Specifications are subject to change without notice.

©Atlas Sound LP. Atlas Sound is a trademark of Atlas Sound LP. All rights reserved.

• Five Year Limited Warranty •

ATS001154 RevA 3/02

000302

484202

WD Series

Attractive surface mounting loudspeaker packages
with 10 oz. magnet and choice of transformer are
mounted in a sloped baffle with black fabric grille.
Models with (V) suffix include volume control option

WD417-72 System

SPECIFICATIONS

Model VP14 WD417-25 WD417-72 WD417-72V
SPEAKER TYPE 8" Dual Cone 8" Dual Cone 8" Dual Cone 8" Dual Cone
MAGNET WEIGHT 10 oz (226g) 10 oz (226g) 10 oz (226g) 10 oz (226g)
FREQUENCY RESPONSE 50Hz to 15kHz 50Hz to 15kHz 50Hz to 15kHz 50Hz to 15kHz
SENSITIVITY (1W/1M) 96dB 96dB 96dB 96dB
WATTS-PROGRAM 15 15 15 15
TRANSFORMER 25V/70.7V 25V/70.7V 25V/70.7V 25V/70.7V
TRANSFORMER T APS 1/2W,1W,2W, 4W 1/2W,1W,2W, 4W 1/2W,1W,2W, 4W 1/2W,1W,2W, 4W
50 OHM POT No No No Yes
BAFFLE MATERIAL 14 Gauge CRS NA NA NA
ENCLOSURE MATERIAL 16 Gauge CRS MDF MDF MDF
FINISH "Wiremold" Beige Simulated Oak Simulated Oak Simulated Oak

DIMENSIONS:
LENGTH (Rear of Enclosure) 11.4" (290mm) 10.47" (266mm) 10.47" (266mm) 10.47" (266mm)
WIDTH 11.75" (298mm) 9.48" (241mm) 9.48" (241mm) 9.48" (241mm)
HEIGHT (Bottom of Enclosure) 2.876" (73mm) 3.75" (95mm) 3.75" (95mm) 3.75" (95mm)
HEIGHT (Top of Enclosure) 5.29" (134mm) 5.43" (138 mm) 5.43" (138 mm) 5.43" (138 mm)
