Page 1
PA601 COMMERCIAL AMPLIFIER
F7,&'7cfb_\_[h
OWNER'S MANUAL
Signal PowerPeak
Power
Master
PA601 Commercial Amplifi er
On
Off
Specifications are subject to change without notice
AtlasSound.com
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
Page 2
PA601 COMMERCIAL AMPLIFIER
OWNER'S MANUAL
TABLE OF CONTENTS
Safety Instructions.............................................................………………………………….………………….2
Introduction, Features, and Applications......................................................................……………………...3
Safety Precautions......................................................................……………………...…………………........4
Front Panel Description......................................................................…………………………………..…….6
Rear Panel Description......................................................................…………………………………...........7
Wiring the PA601 and Security Cover Option…………………………………………………………………....9
Rack Mount Options…………………………………………………………………………………………........10
Block Diagram………………………………………………………………………………………………….......11
Specifi cations..........................................................................................…………………………………….12
Warranty................................................................................................……………………………………...16
SAFETY INSTRUCTIONS
Please Read Carefully Before Installing Or Operating This Product
Many Safety Messages Are Included In This Manual, Please Be Sure To Observe These As They Are
Important
We Recommend That You Keep This Manual Close By For Future Reference
• Do not install this device in dusty or humid locations, or in direct exposure to sunlight. In addition,
locations that have steam or sooty conditions are not to be used, as this may result in fi re or electric
shock.
• Prevent the power cord from damage, pinching, or from being walked on, in particular the plug and
where the cord attaches to the product.
• Do not defeat the polarized or grounding feature of the power cord plug. If the plug will not fi t in your
outlet, consult a licensed electrician.
• Use only the specifi ed accessories and attachments specifi ed in this manual.
• Disconnect the power cord during electrical storms or when the product will be unused for long
periods.
• Have servicing done only by qualifi ed personnel. Servicing will be required when the product is
damaged in any way, when the power cord is damaged, when liquid has been spilled or objects have
fallen into the device. Servicing will also be required when this device has been exposed to rain, does
not operate normally, or has been dropped.
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
2
Page 3
PA601 COMMERCIAL AMPLIFIER
OWNER'S MANUAL
#!54)/.
2)3+/&%,%#42)#3(/#+
$/./4/0%.
!44%.4)/.
4/2%$5#%4(%2)3+/&&)2%/2%,%#42)#3(/#+
$/./4%80/3%4()3!00,)!.#%4/2!)./2-/)3452%
2)315%$%$%#(!2'%%,%#42)15%
|
.%0!3/562)2
7!2.).'
4HELIGHTINGFLASHWITHARROWHEADWITHINA
TRIANGLEISINTENDEDTOTELLTHEUSERTHAT
PARTSINSIDETHEPRODUCTAREARISKOF
ELECTRICSHOCKTOPERSONS
4HEEXCLAMATIONPOINTWITHINATRIANGLEIS
INTENDEDTOTELLTHEUSERTHATIMPORTANT
OPERATINGANDSERVICINGINSTRUCTIONSARE
INTHEPAPERSWITHTHEAPPLIANCE
INTRODUCTION
Congratulations and thank you for purchasing the Atlas Sound PA601 amplifi er. This new and innovative
professional grade product has been designed from the ground up to include the important features that
professional installation personnel require to meet or exceed their customer’s expectations. Small and
compact, and engineered for reliability, the Atlas Sound PA601 will provide years of service and fl exibility in
today’s background music and paging applications.
FEATURES
• 1 Channel @60W Into 70.7V, 100V, and 8Ω Loads
• One Balanced Line Input
• 1 Mono Unbalanced RCA Input
• 1 Unbalanced Line Output
• Loudness Contour Switch
• Selectable AC Mains
• IEC AC Mains Power Connect
• Terminal Block Speaker Output
APPLICATIONS
The Atlas Sound PA601 is the perfect choice for distributed business paging and background music (BGM)
systems, small to medium speech privacy systems and in applications where additional amplifi cations is
required.
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
3
Page 4
PA601 COMMERCIAL AMPLIFIER
OWNER'S MANUAL
SAFETY PRECAUTIONS
• Read the instructions very carefully before using this product.
• Observe the instructions in this manual as conventions of safety; symbols and messages regarded as
important precautions are included.
• Retain this manual for future reference.
Message Conventions and Safety Symbols
Before installing and operating this product, read this manual so you are fully aware of the potential
safety hazards and understand the safety symbols and messages. The safety symbols and messages
shown below are used in this manual to prevent bodily injury and property damage from mishandling.
WARNING
CAUTION
WARNING
• Do not expose the product to rain or in an environment where it may be exposed to water or other
liquids, which may result in fi re or electric shock.
• Operate the product only with the voltage specifi ed on the unit. Fire and/or electric shock may result if
a higher voltage is used.
• Do not modify, kink, or cut the power cord. Do not place the power cord in close proximity to heaters
and do not place heavy objects on the power cord, including the product itself, doing so may result in
fi re or electric shock.
• Replace the protective cover over the speaker terminals after installation. Do not touch the 70V
speaker terminals as electric shock may result.
• Ensure that the safety ground terminal is connected to a proper ground. Never connect the ground to
a gas pipe as a catastrophic disaster may result.
• Be sure the installation of the product is stable, avoid slanted surfaces as the product may fall and
cause injury or property damage.
Indicates a potentially hazardous situation which, if mishandled, could result
in death or serious injury.
Indicates a potentially hazardous situation which, if mishandled, could result
in moderate or minor personal injury, and/or property damage.
WHEN INSTALLING THE PRODUCT
WARNING
• To prevent electric shock, do not remove the product cover as there are high voltage components
inside. Refer all servicing to Atlas Sound.
• Should any of the following irregularities occur during use, immediately switch off the power,
disconnect the power cord from the AC outlet and contact Atlas Sound. Do not to attempt to continue
operation with the product as this may cause fi re or electric shock:
• Smoke or strange smell coming from the unit.
• If the product falls or the case is damaged.
Specifications are subject to change without notice
WHEN THE DEVICE IS IN USE
AtlasSound.com
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
4
Page 5
PA601 COMMERCIAL AMPLIFIER
• If water or any metallic objects falls into the product.
• If the power supply cord is damaged in any way.
• If the unit is malfunctioning.
• Do not insert or drop metallic objects or fl ammable materials into the ventilation holes of the product's
cover, as this may result in electric shock or fi re.
• Do not place any containers with liquid or metallic objects on the top of the product. If any liquid spills
into the unit, fi re or electric shock may result.
• Never operate this product or touch the power supply cord during an electrical storm, electric shock
may result.
• Never exceed the wattage on the product when connecting equipment. Fire and/or property damage
may result.
OWNER'S MANUAL
CAUTION
• Plugging in or unplugging the power cord with wet hands may result in electric shock.
• Never move the unit with the power cord plugged into the wall, as damage to the power cord may
result. When unplugging the cord from the wall, grasp the plug, NOT the cord.
• Never block the panel vents in the product's cover. Heat buildup may result inside the unit and fi re may
result.
• Never install this product in humid or dusty locations, nor in direct sunlight, near sources of heat, or in
areas where sooty smoke or steam are present. Fire and electric shock may result.
CAUTION
• When powering the product up for the fi rst time, ensure that the volume controls are turned down.
Unexpected high sound pressure levels may be present at the speakers and result in hearing loss.
• Never place heavy objects on the product, causing it to fall and/or break, resulting in personal injury
and property damage. In addition, the product itself may fall and cause injury and property damage.
• Never operate the product for extended periods with the sound in a distorted condition. This is an
indication of a malfunction, which may result in excessive heat being generated and causing a fi re.
• Contact Atlas Sound for instructions on cleaning the inside of the unit. Large accumulations of dust
inside the unit may result in heat buildup and fi re.
• Ensure that the power supply plug is securely plugged into the wall outlet. Never allow dust to
accumulate on the power plug or inside the wall outlet.
• When cleaning the unit or the unit is not to be operated for an extended time period, unplug the power
cord from the wall.
WHEN INSTALLING THE PRODUCT
WHEN THE PRODUCT IS IN USE
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
5
Page 6
PA601 COMMERCIAL AMPLIFIER
OWNER'S MANUAL
FRONT PANEL DESCRIPTION
F7,&'7cfb_\_[h
Signal PowerPeak
4
3
2
Power
On
Off
Master
5
1. Power Switch
This push on/off switch supplies power to the PA601 amplifi er.
2. Power LED
This LED illuminates when the power switch is turned on.
3. Peak LED Indicator
The Peak LED will illuminate if the PA601 inputs are being over driven or when the input gain controls
are turned up too high. Check that the proper signal level is being fed into the inputs and/or turn the
input gain down until the LED is turned off.
1
4. Signal LED
When the Signal LED illuminates, this indicates that input signals connected to the amplifi er are
capable of driving the PA601 to full power.
5. Input 1 Gain
Input 1 rotary control varies the amplitude of the signal fed into the amplifi er. Turn clockwise to increase
and counter-clockwise to decrease the signal level.
Specifications are subject to change without notice
AtlasSound.com
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
6
Page 7
PA601 COMMERCIAL AMPLIFIER
REAR PANEL DESCRIPTION
120V/230V-240V
OWNER'S MANUAL
F7,&'
7jbWiIekdZ7cfb_\_[h
Unbalanced
Loudness
LineIn
LineOut
Balanced
Line Input
G–+
FUSE
0.8A/250V FOR 230V~240V
1.5A/250V FOR 120V
Speaker Output 60W
70V 100V
4
COM
¡
CLASS 2 WIRING
£Ид£К>VКV>ЮКЫ`°]КГ]К/8КЗx££К
nдд®КnЗИООООКМ>Г-Х`°V
On
Off
67891011
6. Balanced Input
Balanced line level signals connect to the (+), (–), and (G) terminals. Note if you are connecting an
unbalanced line level input, tie (short) the (G) and (–) terminals together with an insulated jumper
wire.
7. Line In
The Line In connector is useful for receiving a -6dBV mono unbalanced line level signal from a
playback system such as a CD player.
8. Line Out
Line Out connector is useful for providing unbalanced line level signal to another amplifier or other
external device.
9. Loudness Contour EQ
This switch, when in the ON position, provides +4dB of boost at 100Hz and 8kHz. Use of this EQ is
suggested to enhance music playback at low levels.
10. Output Terminal Strip
For loudspeaker connections, connect as follows or proceed to the setup section for typical wiring
schemes.
COM - Speaker common or negative connection
4Ω - Connect to direct coupled loudspeakers
70V - Connect to transformer coupled, 70.7V loudspeakers with a total load impedance of 83Ω
100V - Connect to transformer coupled, 100V loudspeakers with a total load impedance of 167Ω
11. IEC AC Receptacle
Prior to connecting a grounded power cord the proper selection of the AC Line switch and fuse must be
made. For 120VAC use the 1.6A/250V fuse and for 230~240VAC use the 1A250V fuse.
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
7
Page 8
PA601 COMMERCIAL AMPLIFIER
120V/230V-240V
OWNER'S MANUAL
F7,&'
7jbWiIekdZ7cfb_\_[h
Unbalanced
Loudness
LineIn
LineOut
FUSE
0.8A/250V FOR 230V~240V
1.5A/250V FOR 120V
Speaker Output 60W
70V 100V
4
COM
¡
CLASS 2 WIRING
£Ид£К>VКV>ЮКЫ`°]КГ]К/8КЗx££К
nдд®КnЗИООООКМ>Г-Х`°V
On
Off
1312
13. AC Mains Voltage Select
Match the voltage selection to the required voltage.
14. Ground Terminal
Connect this terminal to electrical ground as required by local codes.
Balanced
Line Input
–+
G
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
8
Page 9
PA601 COMMERCIAL AMPLIFIER
OWNER'S MANUAL
WIRING THE PA601
Speaker Outputs - Use 2 conductor unshielded wire of the appropriate gauge. If you are unsure about
this, contact Atlas Sound Tech Support at 1-800-876-3333. Make sure you know how many speakers you
need and what tap value you intend to use.
Balanced Input - Use 2 conductor w/shield for low level signals (20-22 gauge is best). Maintain the
proper polarity, + to +, – to –, and shield to ground.
Unbalanced Inputs and Outputs - Pre-made RCA cables can be purchased from vendors to simplify
interconnection to external devices.
SECURITY COVER OPTION
In order to prevent unauthorized operation of the PA601, optional security covers are available which take
the place of the front panel knob. After the PA601 has been installed and is operating as desired, grasp
the front panel knob and pull straight out from the front panel. Replace the knob with a security cover,
Atlas part number AAVCC-5.
F7,&'7cfb_\_[h
Signal PowerPeak
On
Off
Master
or
Front Panel
Knob
Security Cover
Specifications are subject to change without notice
Power
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
9
Page 10
PA601 COMMERCIAL AMPLIFIER
OWNER'S MANUAL
RACK MOUNTING OPTION
Rack mount ears are available through Atlas for installing the PA601 into equipment racks. If multiple units
are being rack mounted, install Atlas 1RU (SVP19-1-052) vented panels between amplifiers, in order to
aid cooling.
Rack Mount for Single Amplifi er
Rack Mount for Two Amplifi ers
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
10
Page 11
PA601 COMMERCIAL AMPLIFIER
BLOCK DIAGRAM
BALANCED
INPUT
OWNER'S MANUAL
UNBALANCED
AC115V/230V
60Hz /50Hz
+
-
LINE IN
LINE OUT
AC IN
1.6A/250VFOR230V
3.15A/250VFOR115V
FUSE
L
N
LOUDNESS
ON
MIX BUS AMP
POWER SW
WHT
CHASSIS
GROUND
RED
POWER SW
WHT
RED
VOL SEL SW
115V
230V
37
OFF
PEAK LED
SIGNAL LED
100Hz
8kHz
+4dB
PWR AMP 60W
LIMITER
32:(5
4Ω
100V
70V
COM
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
11
Page 12
PA601 COMMERCIAL AMPLIFIER
OWNER'S MANUAL
SPECIFICATIONS
POWER OUTPUT
Max. Average Power @ 50Hz-20kHz with .5% THD
(10-80kHz fi lter)
8Ω, 1kHz, 0.5% THD 60W RMS
TRANSFORMER OUTPUTS
4Ω 60W RMS
70V 60W RMS
100V 60W RMS
FREQUENCY RESPONSE
50Hz-20kHz
THD+N
.5% or less, at 1kHz, rated output
.1% or less, at 1kHz, 5W output
SENSITIVITY
Balanced Line (Phoenix) 500mV (–6dBV) 20kΩ
Unbalanced (RCA) 500mV (–6dBV) 20kΩ
OUTPUTS
Main Transformer coupled, balanced, 4Ω, 70.7V, and 100V
Line Out Unbalanced 600Ω
OUTPUT REGULATION
Less than 2dB, no load to full load
SIGNAL TO NOISE RATIO
Balanced Line >55dB
Unbalanced >75dB
EQ LOUDNESS CONTOUR
Bass ≥ +4dB @ 100Hz
Treble ≥ +4dB @ 8kHz
INDICATORS
Power, signal, peak
POWER CONSUMPTION
120VA
DIMENSIONS
8.27" x 3.66" x 14" (210mm x 93mm x 357mm)
WEIGHT
14 lbs (6.58kg)
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
12
Page 13
PA601 COMMERCIAL AMPLIFIER
NOTES:
OWNER'S MANUAL
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
13
Page 14
PA601 COMMERCIAL AMPLIFIER
NOTES:
OWNER'S MANUAL
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
14
Page 15
PA601 COMMERCIAL AMPLIFIER
NOTES:
OWNER'S MANUAL
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
15
Page 16
PA601 COMMERCIAL AMPLIFIER
OWNER'S MANUAL
Limited Warranty
All products manufactured by Atlas Sound are warranted to the original dealer/installer, industrial or
commercial purchaser to be free from defects in material and workmanship and to be in compliance with
our published specifi cations, if any. This warranty shall extend from the date of purchase for a period
of three years on all Atlas Sound products, including SOUNDOLIER brand, and ATLAS SOUND brand
products except as follows: one year on electronics and control systems; one year on replacement parts;
and one year on Musician Series stands and related accessories. Additionally, fuses and lamps carry no
warranty. Atlas Sound will solely at its discretion, replace at no charge or repair free of charge defective
parts or products when the product has been applied and used in accordance with our published operation
and installation instructions. We will not be responsible for defects caused by improper storage, misuse
(including failure to provide reasonable and necessary maintenance), accident, abnormal atmospheres,
water immersion, lightning discharge, or malfunctions when products have been modifi ed or operated in
excess of rated power, altered, serviced or installed in other than a workman like manner. The original
sales invoice should be retained as evidence of purchase under the terms of this warranty. All warranty
returns must comply with our returns policy set forth below. When products returned to Atlas Sound do
not qualify for repair or replacement under our warranty, repairs may be performed at prevailing costs for
material and labor unless there is included with the returned product(s) a written request for an estimate of
repair costs before any nonwarranty work is performed. In the event of replacement or upon completion of
repairs, return shipment will be made with the transportation charges collect.
EXCEPT TO THE EXTENT THAT APPLICABLE LAW PREVENTS THE LIMITATION OF
CONSEQUENTIAL DAMAGES FOR PERSONAL INJURY, ATLAS SOUND SHALL NOT BE LIABLE IN
TORT OR CONTRACT FOR ANY DIRECT, CONSEQUENTIAL OR INCIDENTAL LOSS OR DAMAGE
ARISING OUT OF THE INSTALLATION, USE OR INABILITY TO USE THE PRODUCTS. THE ABOVE
WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES INCLUDING BUT NOT LIMITED TO
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Atlas Sound does not assume, or does it authorize any other person to assume or extend on its behalf,
any other warranty, obligation, or liability. This warranty gives you specifi c legal rights and you may have
other rights which vary from state to state.
SERVICE
Should your PA601 amplifi er require service, please contact the Atlas Sound warranty department at 1-
877-689-8055, ext. 277 to obtain an RA number.
Atlas Sound Tech Support can be reached at 1-800-876-3333.
Visit our website at www.AtlasSound.com to see other Atlas products.
Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3333 • FAX: (800) 765-3435
©2006 ATLAS SOUND LP Printed in U.S.A. 00106 ATS002264 RevA 01/06 PP
16
Loading...
