Owner’s Manual
ECS-204
20A Power Conditioner & Sequencer
ECS-204
20A Power Conditioner & Sequencer
Detailed Product Information
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
– 1 – AtlasSound.com
Specifications are subject to change without notice.
ECS-204
Owner’s Manual
20A Power Conditioner & Sequencer
Table of Contents
Important Safety Instructions ................................................................................................................. 3
Introduction ........................................................................................................................................... 5
Key Features .......................................................................................................................................... 6
Applications ........................................................................................................................................... 6
Front Panel ............................................................................................................................................. 7
Rear Panel ............................................................................................................................................ 10
Installation ............................................................................................................................................. 13
AC Power Cord Retainer System ......................................................................................................... 14
Troubleshooting ..................................................................................................................................... 15
Specifications ........................................................................................................................................ 16
Warranty ................................................................................................................................................ 20
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AtlasSound.com – 2 –
Specifications are subject to change without notice.
Owner’s Manual
ECS-204
20A Power Conditioner & Sequencer
Important Safety Instructions
The lightning flash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage “ within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this device near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other device that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they
exit from the device.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the device. When a cart is used,
use caution when moving the cart/device combination to avoid injury from tip-over.
13 This product is equipped with a three-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only fit into a
grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
14. Unplug this device during lightning storms or when unused for long periods of time.
15. Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled, or objects have fallen into the device, the device has been exposed
to rain or moisture, does not operate normally, or has been dropped.
16. WARNING: To reduce the risk of fire or electric shock, this device should not be exposed to rain or moisture and objects filled with
liquids, such as a vase, should not be placed on this device.
17. To completely disconnect this equipment from the mains, disconnect the power supply cord plug from the receptacle.
18. The mains plug of the power supply cord shall remain readily operable.
19. Protective earthing terminal. The apparatus should be connected to a mains socket with a protective earthing connection.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
– 3 – AtlasSound.com
Specifications are subject to change without notice.
ECS-204
20A Power Conditioner & Sequencer
Owner’s Manual
When The Device Is In Use
• To prevent electric shock, do not remove the product cover as there are high voltage components inside. Refer all servicing to
Atlas Sound.
• Should any of the following irregularities occur during use, immediately switch off the power, disconnect the power cord from the
AC outlet and contact Atlas Sound. Do not to attempt to continue operation with the product as this may cause fire or electric shock:
• Smoke or strange smell coming from the unit.
• If the product falls or the case is damaged.
• If water or any metallic objects falls into the product.
• If the power supply cord is damaged in any way.
• If the unit is malfunctioning.
• Do not insert or drop metallic objects or flammable materials into the ventilation holes of the product's cover, as this may result in
electric shock or fire.
• Do not place any containers with liquid or metallic objects on the top of the product. If any liquid spills into the unit, fire or electric
shock may result.
• Never operate this product or touch the power supply cord during an electrical storm, electric shock may result.
• Never exceed the power rating on the product when connecting equipment. Fire and/or property damage may result.
• Operate the product only with the voltage specified on the unit. Fire and/or electric shock may result if a higher voltage is used.
• Do not modify, kink, or cut the power cord. Do not place the power cord in close proximity to heaters and do not place heavy objects
on the power cord, including the product itself, doing so may result in fire or electrical shock.
• Ensure that the safety ground terminal is connected to a proper ground. Never connect the ground to a gas pipe as a catastrophic
disaster may result.
• Be sure the installation of the product is stable, avoid slanted surfaces as the product may fall and cause injury or property damage.
When Installing The Product
• Installation of this product must be done by a certified electrician for a permanently connected apparatus provided neither with an
all-pole mains switch nor an all-pole circuit breaker. A readily accessible disconnect device shall be incorporated in the building
installation power wiring. The installation shall be carried out in accordance with all applicable installation rules in accordance with all
applicable federal, state, and local laws, regulations, and safety codes and ordinances.
• Never install this product in humid or dusty locations, nor in direct sunlight, near sources of heat, or in areas where sooty smoke or
steam are present. Fire and electric shock may result.
• Keep all sides of the unit at least 31⁄2" away from objects that may obstruct air flow to prevent the unit's internal temperature rise.
WARNING
CAUTION
When The Product Is In Use
• Never place heavy objects on the product, causing it to fall and/or break, resulting in personal injury and property damage. In
addition, the product itself may fall and cause injury and property damage.
• Contact Atlas Sound for instructions on cleaning the inside of the unit. Large accumulations of dust inside the unit may result in heat
buildup and fire.
• Ensure that the power supply plug is securely plugged into the wall outlet. Never allow dust to accumulate on the power plug or
inside the wall outlet.
• When cleaning the unit or the unit is not to be operated for an extended period, unplug the power cord from the wall.
CAUTION
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AtlasSound.com – 4 –
Specifications are subject to change without notice.
Owner’s Manual
ECS-204
20A Power Conditioner & Sequencer
Introduction
Thank you for purchasing the Atlas Sound ECS-204 AC Power Sequencer and Conditioner. The ECS-204 has been designed to meet
most installation requirements for AC power distribution and equipment power protection. The 20A compact 1 RU unit features four
internal sequential timing sections, three on the unit and one to trigger an external device. All can be activated via the unit locally or
remotely. Front panel activation is via a momentary switch, while rear activation can be accomplished via a remote momentary switch,
latching switch, or by 5-24VDC. AC Mains Voltage can be monitored via the front panel from the precision Digital Volt Meter. The ECS-
204 has incorporated dual front panel USB charge ports that can be used to charge devices such as cell phones or music players. To
light the rack this charge port also supports an optional USB gooseneck lamp. The rear of the rack can be illuminated by the optional
Atlas Power 16" gooseneck LED lamp (AP-GNL) connected via an XLR style socket.
If a 20A AC Mains power source is not enough to meet the amperage demand of your system, the ECS-204 provides a sequenced
12VDC or contact closure output (Seq 4) that can be used to trigger other devices such as the Atlas Sound ECM-20SH 20A standalone
AC power module. Also, up to 3 ECS-204 can be linked together to give you 12 sequenced outputs. Sequence timing selection is made
by a rear panel switch selection. There are four choices that range from 3 seconds to 2 minutes.
The ECS-204 incorporates an Emergency Power Down (EPD) feature. The EPD may be required by the local fire code to pass site
inspection. This port when activated turns Off all channels at once. Unstable AC Mains voltage is one of the main reasons for
equipment failure. AC Spikes, or Transients, are commonly caused by lightning storms or utility power plant grid switchovers. The
amount of energy that can be injected into the power system can be immense with voltages reaching 6kV or amperage peaks of
3000A. These spikes are very fast and usually only last for a very short period of time. To protect against this potential problem, the
ECS-204 features Dual Clamping Suppression technology (DCS). If a spike intrudes the AC system, the ECS-204 incoming AC Mains
has special suppression circuitry to eliminate the unwanted energy and in the unlikely event of any energy getting passed the first
stage, each sequenced output section has redundant DCS circuitry clamping the unwanted energy. This circuitry is very fast and can
suppress unwanted energy within a nanosecond, while sustaining the suppression up to 2 milliseconds, thus ensuring virtually trouble
free protection.
The ECS-204 also features noise filtering for unwanted Radio Frequency Interference (RFI) that is commonly introduced into the AC
lines by nearby radio transmitters or wireless products. EMI filters are incorporated to reduce noise from Electromagnetic Interference
(EMI) from items such as electric motors, switching power supplies and lightning. The benefit of these filters can be seen on video
products or audibly by reduced static pops and external signal interference.
High and low AC Main line voltages are another major contributor to equipment failures. High line is also known as surges. Surges
usually are a slower steady state rise in voltages ranging from 128VAC and up. They can be caused by fluctuations in the utility
company’s power lines or industrial equipment turning On and Off and is on the same power leg of the building’s incoming AC. Low
line is also known as brownouts. This happens when the AC Mains drops below 107VAC. Most of the time it is caused by the utility
company not being able to supply enough power during heavy utility consumption time periods, such as heat waves. Another factor
would be from voltage drops in AC lines due to long transmissions. The ECS-204 will not only inform you if one of these conditions
occurs, but under extreme variances in the AC Mains, it will shut the power to the equipment Off. The Abnormal Voltage indicator on
the front panel will flash if the AC Mains is between 128VAC and 132VCA or 107VAC and 101VAC. This is to inform you that a surge
occurred and may have damaged voltage sensitive equipment. If an extreme voltage swing occurs above 132VAC or below 101VAC,
the ECS-204 Extreme Voltage Shutdown (EVS) protection circuit will automatically activate and turn all outlets Off until it is manually
reset or the voltage is stable.
The ECS-204 offers sequenced power management control, along with noise filtering and spike/surge protection making it the most
compact, effective power management protection system on the market today.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
– 5 – AtlasSound.com
Specifications are subject to change without notice.
ECS-204
Owner’s Manual
20A Power Conditioner & Sequencer
Key Features
• 9 Total 20A Outlets
• 2 Front Panel Unswitched Outlets
• 1 Rear Panel Unswitched Outlets
• 6 Rear Panel Outlets are Sequenced in Three Stages
• Sequenced Output Trigger for an ECM-15SH, ECM-20SH or an additional ECS-204
• Selectable Sequence Times from 3 Seconds to 2 Minutes
• Linkable up to 3 ECS-204 Units
• Radio Frequency (RFI) and Electromagnetic Interference (EMI) Filters
• Dual Clamping Spike & Surge Suppression, DCS Circuitry
• Front Panel Digital AC Mains Voltmeter
• Emergency Power Down (EPD)
• Extreme Voltage Shutdown (EVS) Below 102V or Above 132V AC Line with Selectable Auto or Manual Reset
• External Switch Sequence Trigger Activation, Momentary or Latching Switch
• External DCV Sequence Trigger Activation 5-24VDC
• Circuit Breaker Protection @ 20 Amps Indicated by “Breaker Open” Indicator
• AC Fault, Wiring Fault, and Abnormal Voltage Indicators
• Dual Front Panel USB Charge Ports for Charging USB Devices or Gooseneck Style Lamps
• Rear Panel XLR Receptacle for the Optional AP-GNL Gooseneck Lamp
• Front Panel Mains Power Switch Security Cover
• Optional Remote Key Switch
• AC Power Cord Retainer
Applications
The ECS-204 was designed to be flexible with features that allow it to be used in a variety of applications. The sequenced outputs
allow the turning of equipment On and Off in a particular order, to eliminate an in rush of current and audible pops that often occur
with non-sequenced power strips. It also can be used solely for protection against lightning strikes or voltage surges. If fuzzy video
or frequent static pops occur, the AC power conditioning will eliminate or reduce those inconveniences. The following are just a few
examples of applications the ECS-204 can be used:
• Restaurants
• Houses of Worship
• Schools
• Home Theaters
• Office Buildings
• Sports Bars
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AtlasSound.com – 6 –
Specifications are subject to change without notice.
Owner’s Manual
ECS-204
20A Power Conditioner & Sequencer
Front Panel Features
1 2 3 4
1. Unswitched AC Outlets – The two 120VAC outlets are always “Live” when the ECS-204 power cord is plugged into an AC mains
power source and voltage is present. If voltage is present at the outlets, it will be displayed on the AC Mains Voltage Meter.
Note: The AC mains power switch or sequencer section does not affect the Unswitched AC Outlets. The Unswitched Outlets are
protected by the surge protection circuitry, but will not be shut Off by the EVS circuit.
2. AC Mains Breaker – The 20A rated breaker will open if the combined draw of all AC outlets exceeds 20A.
Note: The breakers are designed to exceed their rating for a short period of time. If the breaker is tripped, to reset you must first
remove the load from the ECS-204 and push the center button on the breaker.
3. System Activation Switch – To turn the ECS-204 On or Off, press the momentary switch once. To make the unit tamper proof
a security cover is included that will cover the Front Panel Activation Switch. Two screws are provided to secure the cover.
4. USB Charge Port – Two USB charge ports, 5V 1A maximum. These ports can be used to charge cell phones or other devices.
Note: Will not charge devices that require priority charging circuits. To light the front of a rack we suggest using an optional USB
gooseneck lamp.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
– 7 – AtlasSound.com
Specifications are subject to change without notice.
ECS-204
Owner’s Manual
20A Power Conditioner & Sequencer
Front Panel Features
5 5 5 5 6 7 8 9
11 12 13 10
5. Sequence Indicator – There are four green LED active sequence outlet indicators labeled “SEQ 1”, “SEQ 2”, “SEQ 3”and
“SEQ 4”. Their sequence timing depends on the customer set settings, see the Sequence Settings Rear Panel section. When the
LED is illuminated, the corresponding AC outlet section on the rear of the chassis will be active or “Live”. Turned “On”, the order
of the trigger sequence is SEQ 1, SEQ 2, SEQ 3, SEQ 4. Turned “Off”, the order is SEQ4, SEQ 3, SEQ 2, SEQ 1.
6. AC Mains Wiring Polarity Fault Indicator – The Red LED will illuminate if the AC Mains Power Cord is plugged into an AC Mains
outlet that is wired incorrectly, such as when the AC Hot and the AC Neutral are wired backwards.
7. AC Mains Breaker Indicator – This Red LED will illuminate if the maximum unit current draw is exceeded. The breaker rating is
15A, but will handle higher peaks for a short period of time. The LED will illuminate until the AC Mains Breaker is reset.
8. AC Fault Indicator – Although the Dual Clamping Suppression (DCS) circuit virtually assures protection from most transient voltage
spikes and surges, nature has a way of occasionally creating electrical forces that are beyond the capabilities of any device to
absorb without some degree of damage. In the rare instance that this occurs and the DCS circuit has been damaged, the Red
“AC Fault” LED indicator will illuminate and an internal buzzer will sound. The ECS-204 will also shut off permanently until the unit
is repaired. Note: If the AC Fault LED is illuminating it is important to have all equipment that was connected to that AC Mains Line
inspected for proper operation.
9. AC Mains Abnormal Voltage Indicator – This LED flashes under several AC Mains fault situations that are listed below. Normal
operating voltages for AC Mains voltage is considered to be between 108VAC and 125VAC. Any voltages exceeding those
parameters are considered a risk to damage equipment plugged into the ECS-204.
10. AC Mains Voltage Indicator Meter – When the ECS-204 is plugged into an AC mains source, the precision voltage meter will
Indicate the reading within 2%. The unit does not have to be Sequenced On for the unit to display the AC Mains volt reading.
Below are reading conditions and fault codes.
• High AC Line Mains – The Abnormal Voltage LED will flash between 128VAC and 132VAC indicating possible damage may
occur to equipment due to high AC Mains voltage. The ECS-204 outlets will remain active but the LED will stay flashing even if
the voltage returns to a normal operating range. To stop the LED from flashing the system activation switch must be cycled
“Off”. Note: It is recommended prior to proceeding to have the AC Mains inspected by an electrician.
• Low AC Line Mains – The Abnormal Voltage LED will flash between 101VAC and 107VAC indicating possible damage may
occur to equipment due to low AC Mains voltage. The ECS-204 outlets will remain active but the LED will stay flashing even if
the voltage returns to a normal operating range. To stop the LED from flashing the System Activation Switch must be cycled
“Off”. Note: It is recommended prior to proceeding to have the AC Mains inspected by an electrician.
• Extreme High AC Line Mains – If the AC Mains reach 132VAC, the EVS (Extreme Voltage Shutdown) circuit will be triggered
to shut off the AC outlets while activating the Abnormal Voltage LED. The Red LED will illuminate steady and the AC Mains
Voltage Meter will flash HI (High Voltage) during this mode. The ECS-204 EVS circuit can be set to either Auto Reset or Manual
Reset mode. Read below how to select and set the proper reset mode for your installation. Note: If the EVS is activated, it is
recommended prior to proceeding to have the AC Mains inspected by an electrician.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AtlasSound.com – 8 –
Specifications are subject to change without notice.
Owner’s Manual
ECS-204
20A Power Conditioner & Sequencer
Front Panel Features
• Extreme Low AC Line Mains – If the AC Mains lowers to 100VAC, the EVS (Extreme Voltage Shutdown) circuit will be
triggered to shut Off the AC outlets while activating the Abnormal Voltage LED. The Red LED will illuminate steady and the
AC Mains Voltage Meter will flash LO (Low Voltage), The ECS-204 EVS circuit can be set to either Auto Reset or Manual Reset
mode. Read below how to select and set the proper reset mode for your installation. Note: If the EVS is activated, it is
recommended prior to proceeding to have the AC Mains inspected by an electrician.
11. External Trigger Indicator – If an External Trigger Voltage or Switch is applied, the Exterior Trigger Mode LED will be illuminated.
12. System ON Indicator – When the ECS-204 is activated the system ON LED will be illuminated.
13. Slave Mode Indicator – If the ECS-204 is selected to be a slave unit, the Slave Mode LED will illuminate indicating that there
is more than one ECS-204 connected to the trigger sequencing. Up to three ECS-204 units can be connected in series. Refer to
the Rear Panel Dip Switch Settings and the Line In / Out section for more details.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
– 9 – AtlasSound.com
Specifications are subject to change without notice.
20A Power Conditioner & Sequencer
Rear Panel Features
14 6 16 15
ECS-204
Owner’s Manual
4 5
1. AC Mains Input – Connect the 12-gauge 9' (3m) power cord to a 20A 120VAC outlet to provide power to the ECS-204.
2. Unswitched AC Outlet – This 120VAC outlet is always “Live” when the ECS-204 power cord is plugged into an AC Mains power
source and voltage is present. If voltage is present at the outlets it will be displayed on the AC Mains Voltage Meter.
Note: The AC Mains power switch or sequencer section does not affect the Unswitched AC Outlets. The Unswitched Outlets are
protected by the surge protection circuitry but will not be shut Off by the EVS circuit.
3. Sequence 1 AC Outlets – The three AC outlets are “Live” when the Sequence 1 section is activated. These outlets are
recommended for products such as computers, modems, routers, DSP processors, Cable/SAT, DVD, or TV’s. These outlets
have a special filter circuit that is optimized to reduce interference to your Digital and Analog components. The total maximum draw
for this sequential section is 15A and the total current draw for the ECS-204 is 20A.
Note: It does not harm high current audio components to be connected to the Sequential Section 1 digital filter outlets.
4. Sequence 2 AC Outlets – The two AC outlets are “Live” when the Sequence 2 section is activated. These outlets are
recommended for Analog and Digital type products such as audio receivers, tape decks, mixers, or video equipment. These outlets
have a special filter circuit that is optimized to reduce interference to your analog type components. The total maximum draw for
this sequential section is 16A and the total current draw for the ECS-204 is 20A.
Note: It does not harm high current audio components to be connected to the Sequential Section 2 filter outlets.
5. Sequence 3 AC Outlet – The single high current non filtered AC outlet is “Live” when Sequence 3 section is activated. This outlet
is designed to deliver maximum current to power hungry components like amplifiers and projectors. It does not harm low power
consuming components when connected to the Sequential Section 3 Analog filter outlets. If more high power outlets are needed
or if 16A is not enough current to support your power requirements you can use the SEQ 4 12VDC or Latching Switch contacts
trigger to activate an additional power outlet such as the ECM-20SH. Contact Atlas Sound for AC outlet options.
6. Sequence 4 Output – The ECS-204 can handle 20A of current before the breaker opens. If 20A is not enough current to support
the power requirements, this output can be used to activate an additional power outlet such as the ECM-20SH. This triggered
12VDC output voltage or the Hard Switched contacts works in conjunction with Sequence 4 timing section. Contact Atlas Sound for
AC outlet options.
Note: This DC output can also be used to power an LED indicator for a remote activation switch such as the Atlas ECS-KSW3,
WPD or other wall plates.
1237 12 98 10 1113
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AtlasSound.com – 10 –
Specifications are subject to change without notice.
Owner’s Manual
Using DCV
+
–
From External DC Source
Note: Overrides Front Panel Activation Switch.
GND
RMT V IN
5-24V
EPD
Emergency Power Down
Remote Latching (CC) Contact Closure Switch
Note: When Control Port Pins are Shorted,
All Outputs Turn Off Together.
Release and Start a New Sequence.
(Front)
Rear Panel Features
ECS-204
20A Power Conditioner & Sequencer
System Configuration Switch Settings
0
1
1SW 2 3 4 5
7. Switch Configuration Settings – There are 5 Dip Switches that control Sequence Delay Timing, System link combining of 2 or 3
ECS-204 units together and the EVS Reset mode. Follow the chart in the manual or the chart located on the top cover of the unit
for operation settings. Zero (0) indicates the “UP” position and One (1) indicates the “DOWN” position. Note: After changing a Dip
Switch setting, the unit power must be reset for the changed setting to take effect.
A. Sequence Delay Settings – The ECS-204 has four timing settings between each sequence. Follow the chart for the settings
for Switches 1 & 2. When daisy chaining multiple units together each unit’s settings only relate to that individual unit.
Therefore, each unit can be different or all can have the same setting. Follow the chart in the manual or the chart located on
the top cover of the unit for operation settings. Note: After changing a Dip Switch setting, the unit power must be reset for the
changed setting to take effect.
B. System Link Settings Master or Slave Unit – Determine if you daisy chaining two or three units together. Choose the
position of the sequence in perspective to the equipment you are activating. The first unit will be known as the Master Unit, all
others are Slave Units. Switches 3 & 4 determine the position of the unit and sequence timing. Follow the chart for the settings
for Switches 3 & 4. When a unit is selected as a Slave Unit the Front Panel Slave Mode LED will illuminate. Also follow the
System Control Port section below for unit daisy chain connection. Note: After changing a Dip Switch setting, the unit power
must be reset for the changed setting to take effect.
C. Extreme Voltage Shutdown (EVS) Settings – There are two settings to meet your install requirements. Dip Switch 5 assigns
the ECS-204 to be in EVS Auto Reset or Manual Reset mode. Note: After changing a Dip Switch setting, the unit power
must be reset for the changed setting to take effect.
• Auto Reset – Place Dip Switch 5 in the UP (0) position. When set to Auto Reset the EVS circuit will shut Off Sequence
1-4. The AC Outlets will auto reset back on when the AC Mains voltage has stabilized between 107V and 128V.
Note: After changing a Dip Switch setting, the unit power must be reset for the changed setting to take effect.
• Manual Reset – Place Dip Switch 5 in the Down (1) position. When set to Manual Reset the EVS circuit will shut Off
Sequence 1-4. The AC Outlets will not turn back on until back on until the AC Mains voltage has stabilized between
107V and 128V and a new sequence has been manually activated. Note: After changing a Dip Switch setting, the unit
power must be reset for the changed setting to take effect.
Seq 1
Seq 2
Seq 3
Seq 4
Sequence Delay SW 1,2
00
6 Sec
3 Sec
3 Sec
3 Sec
01
15 Sec
6 Sec
6 Sec
6 Sec
10
1 Min
9 Sec
9 Sec
9 Sec
System Link
11
2 Min
15 Sec
15 Sec
15 Sec
SW 3
SW 4
SW 5
SW 501
Master
0
0
EVS (Extreme Voltage Shutdown)
Slave 1
1
0
Auto Reset
Manual Reset
Slave 2
1
1
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
– 11 – AtlasSound.com
Specifications are subject to change without notice.
ECS-204
Remote Activation Wiring Chart
Parallel to Front Panel Activation Switch.
Using Latching (CC) Contact Closure
Remote Latching (CC) Contact Closure Switch
Note: Overrides Front Panel Activation Switch.
+12VDC
RMT
V IN
Using DCV
+
–
From External DC Source
Note: Overrides Front Panel Activation Switch.
GND
RMT V IN
5-24V
EPD
Emergency Power Down
Remote Latching (CC) Contact Closure Switch
Note: When Control Port Pins are Shorted,
(Front)
ECS-204 - Silk Screen
ATS003972 RevD 11/12
2 Color: White, PMS 293 U
Remote Activation Wiring Chart
Overrides Front Panel Activation Switch.
Using DCV
+
–
From External DC Source
Note: Overrides Front Panel Activation Switch.
GND
RMT V IN
5-24V
EPD
Emergency Power Down
Remote Latching (CC) Contact Closure Switch
Note: When Control Port Pins are Shorted,
(Front)
ECS-204 - Silk Screen
ATS003972 RevD 11/12
2 Color: White, PMS 293 U
Note: Overrides Front Panel Activation Switch.
EPD
Emergency Power Down
Remote Latching (CC) Contact Closure Switch
Note: When Control Port Pins are Shorted,
Owner’s Manual
20A Power Conditioner & Sequencer
Rear Panel Features
Using DCV
RMT V IN
GND
5-24V
+
–
From External DC Source
8. Remote DC Voltage 5- 24V Activation – The ECS-204 can be remotely activated from hundreds of feet away using a RMT V IN
for activation. DC voltages ranging from 5V DC to 24V DC can be applied to the two terminal connections on the Remote Activation
port marked “RMT V IN” and “GND”. When these two points have the proper voltage applied, the unit will be active, when the DC
voltage is removed the unit will shut off. When the proper DC voltage is applied the Front Panel Activation Switch is overridden.
The Remote Trigger Activation LED will illuminate on the Front panel indicating the status of the activation mode.
Using Momentary Type Switch
GNDMMSW
Remote Momentary Switch
Note:
9. Remote Momentary Switch Activation – The ECS-204 can be remotely activated from hundreds of feet away. A simple low
voltage/current Momentary switch can be applied to the two terminal Pin 2 (GND) and Pin 3 (MM SW) on the Remote Activation
port. We suggest using the Atlas WPD-KSWM or WPS-SWM wall plate switches. When using the momentarily activation method
the Front Panel Activation Switch IS NOT over ridden by the External Momentary Switch. The Remote Trigger Activation LED will
illuminate on the Front panel indicating the status of the activation mode.
Using Latching (CC) Contact Closure
Remote Latching (CC) Contact Closure Switch
Note:
RMT
V IN
+12VDC
10. Remote Latching Contact Closures Switch Activation – The ECS-204 can be remotely activated from hundreds of feet away.
A simple low voltage/current latching contact closure switch can be applied to the two terminals Pin 1 (RMT V IN) and Pin 4
(+12VDCV) on the Remote Activation port. We suggest using the Atlas WPD-KSWCC or WPS-SWCC wall plate switches. When
using the Latching activation method the Front Panel Activation Switch IS over ridden by the Remote Latching CC Switch.
The Remote Trigger Activation LED will illuminate on the Front panel indicating the status of the activation mode.
11. DC Voltage 12V Output – This pin provides a constant +12VDC output when the ECS-204 is plugged into a 12V source. The unit
does not need to be turn on for voltage to be present. This voltage can be used for remote activation triggering.
EPD
Emergency Power Down
Remote Latching (CC) Contact Closure Switch
Note: When Control Port Pins are Shorted,
All Outputs Turn Off Together.
Release and Start a New Sequence.
12. Emergency Power Down (EPD) – An EPD may be required by the local fire codes to pass site inspections. To activate short the
two pins together and all Sequenced outputs will turn off at once. To restart a sequence, the EPD short must be released.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AtlasSound.com – 12 –
Specifications are subject to change without notice.
Owner’s Manual
ECS-204
20A Power Conditioner & Sequencer
Rear Panel Features
13. Link Out – This port is used when daisy chaining more than one ECS-204 together. Up to three units can be connected in series.
Connection is via a RJ45 connector. A common Ethernet cable can be used. Note: This is NOT an IP Ethernet port and is only used
for ECS-204 connectivity between units. Distance between units can be several feet apart. This port is used to send data from the
Master Out port to Slave 1 IN port or from Slave 1 Out port to the Slave 2 IN port. Note: You must first assign the unit’s sequence
position via the Rear Panel System Link Dip Switches.
14. Link In – This port is used when daisy chaining more than one ECS-204 together. Up to three units can be connected in series.
Connection is via a RJ45 connector. A common Ethernet cable can be used. Note: This is NOT an IP Ethernet port and is only used
for ECS-204 connectivity between units. Distance between units can be several feet apart. This port is to be set as Slave 1 and is
to receive data from the Master Out port to set as Slave 2 and receive data from Slave 1 Out port. Note: You must first assign the
unit’s sequence position via the Rear Panel System Link DIP Switches.
15. XLR Light Socket – A 12VDC XLR light socket is to provide power for the optional Atlas Power AP-GNL18 light.
16. Light Socket Power Switch – This switch turns the XLR light socket On or Off.
Installation
Before installing we strongly suggest you read the entire manual to ensure you benefit from all the features of the ECS-204. The
ECS-204 can be placed on a shelf or rack mounted in a standard 19" width rack. Placement within a rack is not critical but the rack
should be within 6' of dedicated 20A AC outlet. Always make sure the 20A outlet is properly inspected by a certified electrician prior to
connecting the ECS-204. Below are a few installation tips.
• After plugging the ECS-204 into a 20A AC Mains outlet inspect the Wiring Fault LED for illumination. The LED should not be on.
• Inspect the equipment that is to be plugged into the ECS-204 to ensure it does not exceed 15A total amperage draw.
• Divide the equipment into three categories. Pick the outlets that match the outlets equipment use.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
– 13 – AtlasSound.com
Specifications are subject to change without notice.
ECS-204
Owner’s Manual
20A Power Conditioner & Sequencer
AC Power Cord Retainer System
Your Atlas Power product comes with an AC Mains Power Cord Retainer System. This system prevents the power cord
from being removed without the use of a screwdriver. Follow these steps for installation.
Note: Installation of this product must be done by a certified electrician for a permanently connected apparatus provided
neither with an all-pole mains switch nor an all-pole circuit breaker. A readily accessible disconnect device shall be
incorporated in the building installation power wiring. The installation shall be carried out in accordance with all applicable
installation rules in accordance with all applicable federal, state, and local laws, regulations, safety codes and ordinances.
1. Locate the 6⁄32 screw, retainer clip, and zip tie.
2. Locate the AC wall outlet that will be used to power the
Atlas Power product. Remove the center screw securing the
cover plate to the AC outlet.
4. Wrap the zip tie around the power cord as shown in Figure 4.
Figure 1
3. Place the screw through the retainer clip and insert into the
cover plate making sure to securely tighten. Inset the zip tie
through the retainer clip slots as shown in Figure 3.
Figure 2 Figure 3
Figure 4
5. Feed the end of the zip tie through the retainer and pull tightly
to secure. Note: Some adjustment of the retainer may be
needed in order to properly align it as shown in Figure 6.
Figure 5 Figure 6
6. Cut the excess zip tie off as shown in Figure 7.
Figure 7
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AtlasSound.com – 14 –
Specifications are subject to change without notice.
Owner’s Manual
ECS-204
20A Power Conditioner & Sequencer
Troubleshooting
Note: ALL TROUBLESHOOTING SHOULD BE DONE BY A CERTIFIED ELECTRICIAN
Issue 1 - Wiring Fault LED is illuminated.
Possible Cause - AC Mains outlet is wired incorrectly.
Action Needed - Contact a certified electrician to inspect the building’s wiring.
Issue 2 - No power to the AC outlets.
Possible Cause - Circuit breaker has tripped due to excessive load.
Action Needed - Remove one piece of equipment from the ECS-204, and push the breaker re-set tab located on the front panel.
Note: We suggest first locating the highest power-consumer such as a power amplifier and disconnecting or turning down that
unit. If the ECS-204 breaker continues to trip, relocating some of the gear may be required.
Issue 3 - No power to the AC outlets, “Abnormal Voltage” indicator is illuminated, the Volt Meter is Flashing and you hear a buzzer
from the unit.
Possible Cause - The AC Mains Voltage exceeded 132VAC or the voltage dropped below 101VAC.
Action Needed - Measure the AC mains before the ECS-204. If the voltage is between 117VAC and 123VAC you may proceed to
reset the ECS-204 by restarting the sequence. Note: It is important to have all equipment that was connected to that AC
Mains Line inspected for proper operation. If the problem persists, contact your local power company for the cause of unstable
AC line conditions.
Issue 4 - Abnormal LED Flashing when you have power to all outlets.
Possible Cause - The AC Mains Voltage exceeded 128VAC or the voltage dropped below 107VAC.
Action Needed - The ECS-204 must be re-sequenced to turn off the LED. Measure the AC mains before the ECS-204. If the
voltage is between 117VAC and 123VAC you may proceed to reset the ECS-204 by restarting the sequence. Note: It is
important to have all equipment that was connected to that AC Mains Line inspected for proper operation. If the problem persists,
contact your local power company for the cause of unstable AC line conditions.
Issue 5 - AC Fault LED is Flashing, a buzzer is sounding and you have no power at any outlets.
Possible Cause - Although the Dual Clamping Suppression (DCS) circuit virtually assures protection from most transient voltage
spikes and surges, nature has a way of occasionally creating electrical forces that are beyond the capabilities of any device to
absorb without some degree of damage. In the rare instance that this occurs, the DCS circuit has been damaged during the
suppression.
Action Needed - If this happens, the ECS-204 will shut off and the unit will need to be repaired or replaced. It is important to
have all equipment that was connected to that AC Mains Line inspected for proper operation.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
– 15 – AtlasSound.com
Specifications are subject to change without notice.
ECS-204
Owner’s Manual
20A Power Conditioner & Sequencer
Specifications
Type Power Sequencer, Power Conditioner & Suppressor
Sequencer Sections 3 Internal Sections and 1 External Output
Load Rating 20A
Safety Listing ETL (UL 60065 Standard)
Front Panel
AC Outlets 2 Unswitched
Lights USB Port for Aftermarket Light
Activation Switch Momentary
Circuit Breaker 20A Resettable
AC Mains Voltmeter Three Digits (Digital) 1.5% Tolerance
Indicators Sequencer Sections 1, 2, 3 & 4, Abnormal Voltage, AC Fault, Breaker Open,
Wiring Fault, External Trigger Mode, System ON, Slave Mode
Rear Panel
AC Outlets 7 Total, Sequence Section 1 (3 Outlets), Sequence Section 2 (2 Outlets),
Sequence Section 3 (1 Outlet), Unswitched (1 Outlet)
Remote Activation Trigger Momentary Contacts, DC V In 5-24VDC, Momentary, Latching, 4 Position
Euro/Phoenix Type Connector
EPD (Emergency Power Down) Latching Switch Activated, 2 Position Euro/Phoenix Type Connector
DC Output 12VDC 100mA Output (Always On)
Light Socket XLR Socket to Provide 12VDC for Optional 16" Gooseneck Lamp
Light Socket Switch Two Position On/Off
System Link Port Link In & Link Out Ports, RJ45 (Not Ethernet or IP)
System Setting DIP Switches 5 Position DP SW, Sequence Delay, System Link, EVS Settings
Grounding Terminal Hand Screw Type Terminal to Chassis Ground
AC Mains Power Cord 9' (3 Meters) 12-gauge, AC Male Plug is 20A NEMA 5-20
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AtlasSound.com – 16 –
Specifications are subject to change without notice.
Owner’s Manual
ECS-204
20A Power Conditioner & Sequencer
Specifications
Technical Data
Current Rating 20 amps
Power Consumption 12 watts
Operating Voltage 102 - 132VAC
Delay Adjustments (Assignable) Min 3 Seconds to 15 Seconds, Max 6 Seconds to 2 Minutes
High Voltage Surge Protection Trigger at 133VAC, 1ms Typically
Low Voltage Protection Trigger at 101VAC, 1ms Typically
Voltmeter Accuracy ±1.5VAC
Spike Protection Modes DCS (Dual Clamping Suppression) Circuitry on Incoming AC Mains and
Each Sequential Section Output
Min. Spike Clamping Voltage 460 VRMS @ 3,000A
Max. Spike Clamping Voltage 6000V
Max. Spike Clamping Resp. Time 1 nanosecond
Spike Clamping Voltage @ 100A 1250Vp for 20µs
Maximum Surge Current 6,500A
Energy Rating @ 2ms 2000 Joules
Noise Attenuation EMI/RFI Seq. Section 1 & 2 10dB @ 10 kHz, 40dB @ 100 kHz, 100dB @ 10 MHz
Temperature Range 5° to 35° C
Humidity Range 5% to 95% R.H.
Mechanical
Chassis Finish Black
Mounting Rack Mount, 19", 1 RU
Dimensions Height 1.75" (44.45mm)
Width 19" (482.6mm)
Depth 8.5" (215.9mm)
Weight 10 lbs (4.53kg)
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
– 17 – AtlasSound.com
Specifications are subject to change without notice.
Notes:
ECS-204
Owner’s Manual
20A Power Conditioner & Sequencer
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AtlasSound.com – 18 –
Specifications are subject to change without notice.
Owner’s Manual
Notes:
ECS-204
20A Power Conditioner & Sequencer
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
– 19 – AtlasSound.com
Specifications are subject to change without notice.
ECS-204
Owner’s Manual
20A Power Conditioner & Sequencer
Limited Warranty
All products manufactured by Atlas Sound are warranted to the original dealer/installer, industrial or commercial purchaser to be free
from defects in material and workmanship and to be in compliance with our published specifications, if any. This warranty shall extend
from the date of purchase for a period of three years on all Atlas Sound products, including SOUNDOLIER brand, and ATLAS SOUND
brand products except as follows: one year on electronics and control systems; one year on replacement parts; and one year on
Musician Series stands and related accessories. Additionally, fuses and lamps carry no warranty. Atlas Sound will solely at its discretion,
replace at no charge or repair free of charge defective parts or products when the product has been applied and used in accordance
with our published operation and installation instructions. We will not be responsible for defects caused by improper storage, misuse
(including failure to provide reasonable and necessary maintenance), accident, abnormal atmospheres, water immersion, lightning
discharge, or malfunctions when products have been modified or operated in excess of rated power, altered, serviced or installed
in other than a workman like manner. The original sales invoice should be retained as evidence of purchase under the terms of this
warranty. All warranty returns must comply with our returns policy set forth below. When products returned to Atlas Sound do not
qualify for repair or replacement under our warranty, repairs may be performed at prevailing costs for material and labor unless there is
included with the returned product(s) a written request for an estimate of repair costs before any nonwarranty work is performed. In
the event of replacement or upon completion of repairs, return shipment will be made with the transportation charges collect.
EXCEPT TO THE EXTENT THAT APPLICABLE LAW PREVENTS THE LIMITATION OF CONSEQUENTIAL DAMAGES FOR PERSONAL
INJURY, ATLAS SOUND SHALL NOT BE LIABLE IN TORT OR CONTRACT FOR ANY DIRECT, CONSEQUENTIAL OR INCIDENTAL
LOSS OR DAMAGE ARISING OUT OF THE INSTALLATION, USE OR INABILITY TO USE THE PRODUCTS. THE ABOVE WARRANTY IS
IN LIEU OF ALL OTHER WARRANTIES INCLUDING BUT NOT LIMITED TO WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE.
Atlas Sound does not assume, or does it authorize any other person to assume or extend on its behalf, any other warranty, obligation,
or liability. This warranty gives you specific legal rights and you may have other rights which vary from state to state.
Service
Should your ECS-204 require service, please contact the Atlas Sound warranty department at
1-877-689-8055, ext. 277 to obtain an RA number.
Atlas Sound Tech Support can be reached at 1-800-876-3333.
Visit our website at www.AtlasSound.com to see other Atlas products.
©2013 Atlas Sound L.P. All rights reserved. Atlas Sound and Atlas Power are trademarks of Atlas Sound L.P.
All other trademarks are the property of their respective owners. ATS004484 RevA 5/13
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AtlasSound.com – 20 –
Specifications are subject to change without notice.
Loading...
