Chapter 1
Introduction
1.1 Introduction
Thank you for purchasing the IP Security Cam, a camera device that can be connected directly to an Ethernet or
Fast Ethernet network and also supported by the wireless transmission based on the IEEE 802.11b standard.
Compared to the conventional PC Camera, the IP Security Cam features a built-in CPU and web-based solutions
that can provide a cost-effective solution to transmit real-time high-quality video images and sounds for
monitoring. The IP Security Cam can be managed remotely, accessed and controlled from any PC/Notebook over
the Intranet or Internet via a web browser. The simple installation procedures and web-based interface allow you to
integrate it into your network easily. With comprehensive applications supported, the IP Security Cam is your best
solution for remote monitor, high quality, and high performance video images.
IP Security Cam
Chapter 2
System Requirement
2.1 Network:
Local Area Network: 10Base-T Ethernet or 100Base TX Fast Ethernet
Wireless Local Area Network: IEEE 802.11b Wireless LAN
Recommended PC or Notebook to Access the IP Security Cam
2.2 Web Browser:
System requirement:
CPU: Pentium II, 266 MHz or above
Memory Size: 32 MB (64 MB recommended)
VGA card resolution: 800x600 or above
• Internet Explorer 5.0 or above (ActiveX & JAVA Mode – Image View for Windows OS and JAVA Mode
– Image View for other OS)
• Netscape 6.0 or above (JAVA Mode – Image View)
2.3 IPView SE Application:
Support OS: Win 98 SE, Win 2000, Win Me, Win XP
System requirement for IPView SE:
CPU: Pentium III, 450 MHz or above
Memory Size: 128 MB (256 MB recommended)
VGA card resolution: 800x600 or above
1
IP Security Cam
Chapter 3
Features and Benefits
This section describes the features and benefits of the IP Security Cam
3.1 Simple To Use
The IP Security Cam is a standalone system with built-in CPU requiring no special hardware or software such as
PC frame grabber cards. The IP Security Cam supports both ActiveX mode (for Internet Explorer users) and Java
mode (for Internet Explorer and Netscape Navigator users). Therefore, all that is required is a web browser
software such as Internet Explorer 5.0 or above or Netscape 6.0 or above. Just plug and view the picture from your
IP Security Cam with a valid IP Address.
3.2 Support Variety of Platforms
The IP Security Cam supports TCP/IP networking, SMTP e-mail, HTTP and other Internet related protocols, and
can be utilized in a mixed operating system environment such as Windows, Unix, and Mac. It can be integrated
easily into other www/Intranet applications.
3.3 Web Configuration
Applying a standard web browser, the administrator can configure and manage the IP Security Cam directly from
its own web page via the Intranet or Internet. Up to 64 users name and password are permitted with privilege
setting controlled by the administrator.
3.4 Remote Utility
The powerful IPView SE application assigns the administrator with a pre-defined user ID and password, allowing
the administrator to modify the IP Security Cam settings from the remote site via Intranet or Internet. When new
firmware is available, you can also upgrade remotely over the network for added convenience. Users are also
allowed to monitor the image, and take snapshots.
3.5 Broad Range of Applications
With today’s high-speed Internet services, the IP Security Cam can provide the ideal solution for live video images
over the Intranet and Internet for remote monitoring. The IP Security Cam allows remote access from a web
browser for live image viewing and allows administrator to manage and control the IP Security Cam anywhere and
any time in the world. Apply the IP Security Cam to monitor various objects and places such as homes, offices,
banks, hospitals, child-care centers, amusement parks and other varieties of industrial and public monitoring. The
IP Security Cam can also be used for intruder detection; in addition, it can capture still images for archiving and
many more applications.
2
IP Security Cam
Chapter 4
Physical Description
This section describes the externally visible features of the IP Security Cam.
4.1 Front Panel
Link LED
Power LED
Power LED
The Power LED is positioned on the right side of the IP Security Cam’s lens while facing the IP Security Cam.
A steady blue light confirms that the IP Security Cam is powered on.
Link LED
The Link LED is positioned on the right side of the IP Security Cam’s lens while facing the IP Security Cam. It is
located right of the Power LED
A steady orange light confirms that the camera has good connection to LAN connectivity.
Dependent on the data traffic the LED will begin to flash to indicate that the IP Security Cam is receiving/sending
data from/to the network.
3
IP Security Cam
4.2 Rear Panel
Network Cable Connector
The IP Security Cam’s rear panel features an RJ-45 connector for connections to 10Base-T Ethernet cabling or
100Base-TX Fast Ethernet cabling (which should be Category 5 twisted-pair cable). The port supports the NWay
protocol, allowing the IP Security Cam to automatically detect or negotiate the transmission speed of the network.
10/100 Ethernet
Network Cable
Connector
ANT
Reset Button
Antenna
Connector
Reset
DC Power
Connector
DC 5V
DC Power Connector
The DC power input connector is located on the IP Security Cam’s rear panel, and is labeled DC 5V with a single
jack socket to supply power to the IP Security Cam. Power will be generated when the power supply is connected
to a wall outlet.
Reset Button
Reset will be initiated when the reset button is pressed once, and Power LED begins to flash.
Factory Reset will be initiated when the reset button is pressed continuously for three seconds or when Power LED
begins to light up. Release the reset button and the Power LED will begin to flash, indicating the IP Security Cam
is changing to factory reset. When factory reset is completed, the IP Security Cam will be set to default on channel
11 and ESS-ID is set as “NULL String” (This default setting will let the IP Security Cam connect to ANY access
point on the infrastructure network). The IP address will also return to the default setting as 192.168.0.20.
Antenna Connector
There is the SMA type antenna connector located on the rear panel of the IP Security Cam, providing connection
for one high sensitivity antenna included in the package.
4
IP Security Cam
4.3 Top Panel
Screw Hole
Screw Hole
Located on the top panel of the IP Security Cam, the screw hole is used to connect the camera stand onto the IP
Security Cam by attaching the screw head on the camera stand into the screw hole of the IP Security Cam.
4.4 Bottom Panel
Screw Hole
Screw Hole
Located on the bottom panel of the IP Security Cam, the screw hole is used to connect the camera stand onto the IP
Security Cam by attaching the screw head on the camera stand into the screw hole of the IP Security Cam.
5
IP Security Cam
Chapter 5
Unpacking The IP Security Cam
Carefully remove all items from the package. In addition to this User’s Guide, be certain that you have:
• One IP Security Cam
• One External Wireless Antenna
• One Installation CD-ROM
• One Quick Installation Guide
• One DC power adapter suitable for your country’s electric power
• One Camera Stand
• One RJ-45 Ethernet Cable
If any item is missing, or if you find any damage or mismatch, promptly contact your dealer for assistance.
5.1 Connecting the IP Security Cam to the Camera Stand
The IP Security Cam comes with a camera stand (optional) with a
swivel ball screw head that can be attached to the IP Security Cam's bottom
screw hole. Attach the camera stand to the IP Security Cam and station it
for your application. There are three holes located in the base of the camera
stand allowing the IP Security Cam to be mounted on the ceiling or any wall
securely.
Chapter 6
Hardware Installation
6
IP Security Cam
This section describes the Hardware installation procedure for the IP Security Cam.
6.1 Attach Wireless Antenna
From the rear panel of the IP Security Cam, screw the external Antenna that came
with the IP Security Cam into the antenna connector.
6.2 Connect an Ethernet cable
Connect an Ethernet cable to the network cable connector located on the IP Security
Cam’s rear panel, and then attach it to the network.
6.3 Attach the external power supply
Attach the external power supply to the DC power input connector located on
Wireless IP Security Cam’s rear panel, and then connect it to your local power
supply.
Confirm power source is supplied from the LED indicators
label Power on the IP Security Cam is illuminated.
Chapter 7
Security
7
IP Security Cam
To ensure the highest security and prevent unauthorized usage of the IP Security Cam the Administrator has the
exclusive privilege to access the System Administration for settings and control requirements to allow users the
level of entry and authorize the privileges for all users. The IP Security Cam supports multi-level password
protection and access to the IP Security Cam is strictly restricted to defined the user who has a "User Name" and
"User Password" that is assigned by the Administrator.
Administrator can release a public user name and password so when remote users access the IP Security Cam they
will have the right to view the image transmitted by the IP Security Cam.
Since the default settings are Null String, it is highly recommended to set the "Admin ID"
and "Admin Password" when you are the first time to use the IP Security Cam. Once the
ID and Password are defined, only the administrator has the access to management the IP
Security Cam. This procedure should be done as soon as possible since the security
features with the IP Security Cam will not be enabled until the "Admin ID" and "Admin
Password" is defined.
Chapter 8
Software Installation
8
IP Security Cam
This section describes the Software installation procedure of the IP Security Cam for Web Configuration and
IPView SE application.
8.1 Web Configuration
The IP Security Cam must be configured through its built-in Web-based Configuration.
Extensive knowledge of LAN will be helpful in setting up the IP Security Cam
From the web browser, enter the default IP address to access the Welcome screen of the IP Security Cam. To
configure your IP Security Cam, type http://192.168.0.20 in the address box. The number is the default IP address
of your IP Security Cam. Then, press [Enter]
.
The PC’s IP address must correspond with the IP Security Cam’s IP address in the same
segment for the two devices to communicate.
8.2 Main Menu Image
9
IP Security Cam
After the default IP address is entered from the browser, the IP Security Cam Welcome screen will appear with a
still image. There will be three options to choose from to set-up and view your IP Security Cam, including:
View Image – ActiveX Mode
View Image – Java Mode
System Administration
8.3 System Administration
Click “System Administration” from the Welcome screen to access the settings required for the IP Security Cam.
There will be several options in the System menu bar to choose from to set your IP Security Cam, including:
System
Users
DateTime
Upload
E-mail
Information
Tools
10
IP Security Cam
8.3.1 System Administration
The System menu contains commands for settings that are required for inputting key details to set-up the IP
Security Cam for operation.
Click "System" in the system administration menu bar, and the System screen will appear as illustrated below:
Click “Home” to
return to Welcome
Screen
Camera Name:
This field is used to enter a descriptive name for the device.
The default setting for the Camera Name is CS-xxxxxx, where xxxxxx is the last six digit of the MAC Address.
The maximum length is 32 (Printable ASCII).
Location:
This field is used to enter a descriptive name for the location used by the IP Security Cam.
Admin:
11
IP Security Cam
This field is used to enter the Administrator ID along with the password to access the System Administration
settings. Be sure to enter the password twice to confirm the details once in the Admin Password field and again in
the Confirm Password field.
The default setting for Admin is blank space (Null String), and you need to key in the Admin ID with a maximum
length of 12 (Printable ASCII) characters and enter the Admin Password with a maximum length of 8 (Printable
ASCII) characters.
It is highly recommended to set the Admin ID and Admin Password as soon as possible to enable security option
for the IP Security Cam to function.
IP Assignment:
Access to the IP Security Cam is done through assigning a proper IP address. Please
make sure to use a vacant IP address when you assign the IP address for the IP Security
Cam. This will prevent errors from occurring if the IP address is overlapped.
There are two options to select from the IP Assignment: Manually Assign or Assign Automatically Using.
Manually Assign
You can click “Manually Assign” and directly enter the IP address.
The default settings are as follows:
• Default IP – 192.168.0.20
• Subnet Mask – 255.255.255.0
• Default Gateway – 0.0.0.0
Assign Automatically Using
If your network is using RARP, BOOTP or DHCP server, you can click “Assign Automatically Using” and then
click “RARP”, “BOOTP” or “DHCP”. Under this setting the IP Security Cam will automatically assign an IP
address from RARP, BOOTP or DHCP server. Every time when the camera starts up, please make sure that the
DHCP server is set to assign a static IP address to your camera.
If your application requires direct connection from an ADSL modem through the IP Security Cam’s RJ-45 LAN
port, and you also have an ISP PPPoE account, click “PPPoE” option and enter the Service Name, User ID and
Password into the respective fields. The IP Security Cam will get an IP address from the ISP as starting up.
DNS IP Address:
DNS (Domain Name System) server is an Internet service that translates domain names into IP addresses. Enter at
least one DNS IP Address.
Dynamic DNS:
The Dynamic DNS service allows you to alias a dynamic IP address to a static hostname in any of the domains,
allowing your computer to be more easily accessed from various locations on the Internet.
Wireless Interface:
Connection Mode:
Use the Connection Mode to determine the type of wireless communication for the IP Security Cam. There are
three choices of Infrastructure mode, and Adhoc mode. The default setting for the Connection Mode is
Infrastructure.
Network Name:
This field is used to setup which wireless network (ESS-ID Extended Service Set ID) the IP Security Cam is to be
connected for communication. The ESS-ID is a unique identifier shared among all points in a wireless network
environment.
12
IP Security Cam
The default Network Name is blank space (NULL String), and this default setting will let the IP Security Cam
connect to ANY access point under the infrastructure network mode.
To connect the IP Security Cam to a specific access point on the network, please make sure to set the ESS-ID of the
IP Security Cam to correspond with the access point’s ESS-ID for communication. Type any string up to 32
characters long (spaces, symbols, and punctuation are not allowed) in the Network Name box.
To connect the IP Security Cam to an Ad-hoc wireless workgroup, please make sure to set the same wireless
channel and ESS-ID to match with the PC/Notebook wireless channel and ESS-ID for direct wireless
communication under the Ad-hoc wireless workgroup.
Wireless Channel:
The pull down menu provides the wireless channel for communication. A "channel" is a range of frequencies to be
used in communication between the IP Security Cam and Access Point in infrastructure mode or the IP Security
Cam and PC/Notebook in Ad-hoc mode. Select the appropriate channel from the list provided depending on the
regulatory region where the unit is sold. The default setting is at channel 11.
Encryption WEP Key:
Wireless network communications are easily intercepted. WEP (Wired Equivalent Privacy) is an encryption
method specified by the IEEE 802.11b standard to make any intercepted communications extremely difficult to
interpret by unauthorized parties.
To enable WEP Encryption, you should decide which WEP key format will be applied first. Click the ASCII or
HEX check box to select input format as ASCII format or HEX format, and then input WEP key. To confirm the
WEP key, you must enter the data once again in the Confirm WEP Key field.
ASCII input format:
ASCII format causes each character you type to be interpreted as an eight-bit value. All unaccented upper- and
lower-case Western European characters that can be input through your keyboard's typing zone are valid. To setup
64-bit WEP key, input 5 ASCII characters, for example, ‘12345’. To setup 128-bit WEP key, input 13 ASCII
characters, for example, ‘1234567890123’. These character counts result in bit counts of 40 and 104, respectively;
the IP Security Cam will automatically pad your input to a bit count of 64 or 128.
HEX input format:
Hex format causes each pair of characters you type to be interpreted as an eight-bit value in hexadecimal (base 16)
notation. Only the digits 0 through 9 and the letters A through F (in upper or lower case) are valid. To setup 64-bit
WEP key, input 10 HEX format, for example, ‘3132333435’, this is the same with ASCII input ‘12345’. To setup
128-bit WEP key, input 26 HEX format, for example, ‘31323334353637383930313233’, this is the same with
ASCII input ‘1234567890123’. These character counts result in bit counts of 40 and 104, respectively; the IP
Security Cam will automatically pad your input to a bit count of 64 or 128.
On the Confirm WEP Key field, input the same characters as the Encryption Code field.
Make sure the Encryption Code is the same with the access point’s encryption code that the IP Security Cam is to
be connected under Infrastructure mode. Your PC/Notebook’s encryption code also needs to be setup the same
with the IP Security Cam's encryption code under either Infrastructure mode or Ad-hoc mode.
The default setting for the Encryption Key is Disable therefore, to secure the wireless transmission be sure to
Enable the Encryption Key by entering the relevant data.
Carefully input Encryption Code, any error setting will cause communication link to fail.
LED Control:
The LED control allows user to setup the LED illumination as desired. This feature provides the flexibility when
surveillance activity is ON.
There are three options as follows:
Normal –
Power - Steady On of the LED indicator.
13
Loading...
