Atlantis A02-PL200, A02-PL200-GF01 User Manual

PowerLine Ethernet Turbo
Adapter
A02-PL200
GUIDE RAPIDE
FRANCAIS
ENGLISH
This product is covered by Atlantis Land 3 years Fast-Swap warranty. For more detailed informations please refer to the web site www.atlantis-land.com. For more detailed instructions on configuring and using the device please refer to the online manual.
ITALIANO
Questo prodotto è coperto da garanzia Atlantis Land Fast-Swap della durata di 3 anni. Per maggiori dettagli in merito o per accedere alla documentazione completa in Italiano fare riferimento al CDRom o al sito www.atlantis-land.com.
FRANCAIS
Ce produit est couvert par une garantie Atlantis Land Fast-Swap de 3 ans. Pour des informations plus détaillées, référez-vous svp au site Web www.atlantis-land.com
. Le manuel complet en Francais est disponible dans le CDRom ou sur le WEB.
DEUTSCH
Dieses Produkt ist durch die Atlantis Land 3 Jahre Fast-Swap Garantie gedeckt. Für weitere Informationen, beziehen Sie sich bitte auf Web Site www.atlantis-land.com.
FRANCAIS
ESPAÑOL
Este producto està cubierto de garantía Atlantis Land Fast-Swap por 3 años. Para una información más detallada, se refiera por favor al Web site www.atlantis-land.com
Register your product!
.
www.atlantis-land.com
Registration on the web site www.atlantis­land.com within 15 days from the purchase of the product dismiss the customer from showing a valid proof of purchase (Sale Receipt or Invoice) in case of the request of intervention. For further information we invite you to look at our web site at the section WARRANTY.
FRANCAIS
Ce guide d’installation rapide vous aidera à installer rapidement et facilement votre adaptateur ETHERNET Courant Porteur. Pour de plus amples détails, référez vous au manuel d’utilisation.
1.1 Contenu de la boite
Assurez vous d’y trouver:
Si un de ces éléments venait à manquer ou à être endommagé, contactez immédiatement votre revendeur. * 2 dans le code A02-PL200KIT
1 x Adaptateur ETHERNET Courant Porteur (PowerLine Ethernet Turbo Adapter)* 1 x Câble réseau Ethernet CAT-5 UTP (RJ45)* 1 x Guide de démarrage rapide 1 x CD-ROM avec Utilitaires et documentation 1 x Feuillet de garantie
1.2 Besoins materiels
L’adaptateur ETHERNET Courant Porteur est utilisable avec tous les systèmes gérant TCP/IP. Aucun driver n’est requis pour cet adaptateur, le logiciel de configuration fourni ne fonctionne qu’avec les systèmes d’exploitation Microsoft Windows. Configuration minimale de votre ordinateur :
Note: Votre ordinateur ou l’appareil que vous souhaitez raccorder à votre adaptateur doit avoir un port Ethernet (carte ou adaptateur réseau).
Windows 98SE, Me, 2000 ou XP avec connection réseau Pentium II 300 MHz MMX 64MB memoire vive et dispo sur disque dur Lecteur de CD-ROM
FRANCAIS
1.3 Connection et Indicateur LED
L’adaptateur ETHERNET Courant Porteur dispose de trois indicateurs (LED) et d’un Port Ethernet:
LED FONCTION
PWR
PL-LINK
ETH­LINK/ACT:
PORT FONCTION
ETHERNET: Pour la connection à un
Allumée lorsque connecté à l’adaptateur secteur
Allumée lorsque connecté à un autre adaptateur à travers le réseau
Allumée lorsque connecté au réseau Ethernet Clignotante pendant le passage des données
FRANCAIS
ordinateur ou autre périphérique doté d’un port Ethernet
1.4 Installation matérielle
Connectez l’adaptateur ETHERNET Courant Porteur sur une prise secteur, en aucun cas sur une rallonge ou un para-surtenseur. Raccordez avec le cable Réseau RJ45 fourni, l’adaptateur à votre PC ou autre péripherique. Installez le logiciel de configuration fourni (Optionnel).
1.5 Logiciel de configuration
Inserez le CD dans votre lecteur. Lancez l’utilitaire d’installation (CD-Rom:\Utility\Setup.exe). Suivez les instructions pour configurer votre installation.
FRANCAIS
Atlantis Land S.p.A.
Viale De Gasperi, 122
Mazzo di Rho – MI – Italy
