Communication
00_BTDriveFree411_Cover.indd 148-149
01.11.11 16:53
BT Drive Free 411 1 021 104 411
Blaupunkt AudioVision GmbH & Co. KG
Robert-Bosch-Str. 200
D-31139 Hildesheim
5 101 040 002
11/11 450 177 - de, gb, fr, es, pt, it, nl, sf, pl, hu, ro, bg
00_BTDriveFree411_Cover.indd 148-149
www.blaupunkt.com
01.11.11 16:53
Technische Daten
001_BTDriveFree411_all.indd 14-15
01.11.11 16:55
Bluetooth-Spezi kation Version 2.1 + EDR (Enhanced Data
Rate) + SSP (Secure Simple Pairing)*
Unterstützte Bluetooth-Pro le Headset- und Freisprechpro le
Frequenzbereich 2,4 bis 2,48 GHz ISM-Band
Bluetooth-Reichweite Bis zu 10 Meter (Klasse 2)
Abmessungen 46 (L) x 36 (B) x 95 (H) mm
Gewicht ca. 40 g
Akku-Ladedauer ca. 3 Stunden
Gesprächszeit Bis zu
Stand-by-Zeit Bis zu 300 Stunden
Akku-Typ Lithium-Polymer, 3,7 V, 160 mAh,
Ladegerät DC 5 V - 6 V, 300 mA
* Zum Koppeln von Freisprecheinrichtungen ohne die Eingabe des PIN-Codes,
wenn auch das andere Bluetooth-Gerät die Version 2.1 unterstützt.
7 Stunden
au adbar, nicht austauschbar
Contents
BT Drive Free 411 ..............................................................................................................15
Bluetooth technology ..................................................................................................... 16
Safety and general information .................................................................................. 16
Disposal notes ................................................................................................................... 17
Scope of delivery ..............................................................................................................17
Installation on the steering wheel .............................................................................17
Overview ............................................................................................................................. 18
Battery information .........................................................................................................18
Charging the battery .......................................................................................................19
Switching on/o ............................................................................................................... 20
Registering (pairing) and connecting with the cell phone ............................... 20
Multi-connection function ............................................................................................ 21
Establishing a connection with two cell phones ................................................. 21
Using the BT Drive Free 411 .......................................................................................... 22
Resetting the BT Drive Free 411 .................................................................................. 24
Light indicators and signal tones ...............................................................................24
Fault removal ..................................................................................................................... 25
Declaration of conformity ............................................................................................. 25
Warranty ..............................................................................................................................25
Technical data .................................................................................................................... 26
ENGLISH
Änderungen vorbehalten!
14
001_BTDriveFree411_all.indd 14-15
BT Drive Free 411
This wireless Bluetooth hands-free system was developed speci cally for
users who want to use their cell phone while driving. The BT Drive Free 411 is
conveniently attached to the steering wheel. The multi-connection function
allows the simultaneous use of the BT Drive Free 411 with two cell phones. Its
improved microphone system and DSP technology for echo cancelling and
noise suppression achieve an excellent hand-free quality.
15
01.11.11 16:55
Bluetooth technology
001_BTDriveFree411_all.indd 16-17
01.11.11 16:55
BluetoothTM is a registered trademark of Bluetooth SIG, lnc. Bluetooth is a
wireless communication technology with short range. It enables wireless
connections between all compatible portable and stationary communication
devices. The technology is based on a radio connection that ensures a fast
and reliable transmission of voice and data information.
Bluetooth is oriented to the worldwide applicable standard for operating in
the internationally recognised ISM frequency band (Industrial Scienti c &
Medical). Within the ISM band (2.4 GHz to 2.48 GHz), the Bluetooth transmission operates 1600 times per second between 79 di erent frequencies with
a data transmission range of up to 10 metres (Class 2).
Safety and general information
– Carefully read the operating instructions and follow the instructions.
– Observe all locally applicable laws for the use of cell phones and hands-free
systems while driving. Operate the BT Drive Free 411 only if the tra c situation allows it and you are not creating a risk for other tra c participants.
– To avoid any damages and malfunctions, do not drop the device from
an elevated height.
– Protect the device against humidity, water and other liquids. If the device
should have been exposed to water, humidity or other liquids, do not use
it since it may lead to damages of the device and to injuries from electrical
shock or explosion.
– Do not expose the device to extreme heat sources, such as direct sunlight.
This can cause explosions as well as reduce the performance and/or service
life of the battery.
– Do not make any changes or repairs to the device and do not attempt to
disassemble it. (Particularly not on the battery since the risk of explosion
exists.) It will immediately void the warranty.
– Do not place any heavy objects on the device.
– Use only the supplied charger.
– Repairs and service work may be performed only by a quali ed service
centre or the manufacturer.
– In case of extended non-use or thunderstorms, disconnect the device
from the power supply.
Disposal notes
Use the return and collection systems available to dispose of the old
device.
Scope of delivery
The scope of delivery includes:
– BT Drive Free 411
– 12-volt DC vehicle charger adapter
– USB charger cable
– Operating instructions
Installation on the steering wheel
Fasten the BT Drive Free 411 to the steering wheel using the Velcro strap.
Firmly pull the Velcro strap together so that the device will not loosen while
driving. Attach the BT Drive Free 411 to the inside circle of the steering wheel
and select a position so that it does not interfere with steering the vehicle.
Warning: The BT Drive Free 411 may not be positioned within the deployment area of an air bag.
ENGLISH
16 17
001_BTDriveFree411_all.indd 16-17
01.11.11 16:55
