SDA200 and SMDA200

STEREO DISTRIBUTION AMPLIFIER

MODULES for SYSTEM 10K

OPERATING AND MAINTENANCE MANUAL

ATI Audio Inc. ■ Tel: [phone] ■ Fax: [phone] ■ [e-mail] ■ www.

audio.com

DESCRIPTION

The SDA200 and SMDA200 modules are both two-input and eight-output audio
distribution amplifiers designed as plug-in components for the SYSTEM 10K
Modular Audio Distribution System. The SYSTEM 10K provides proper mounting,
shielding and power for a family of interchangeable amplifier modules.
Performance to published specifications and operational life of these modules
are covered by ATI's standard warranty on the SYSTEM 10K only when they are
used as part of a SYSTEM 10K consisting of an RM100 Rack Enclosure and
PS100 Power Supplies.

The SDA200 and SMDA200 modules feature eight active balanced outputs in
two groups of four. Both output groups are controlled together by a single, stereo,
full range, audio taper level control. Individual left and right multi-turn trimmers
provide fine matching adjustment with a limited range of ±4dB.

A board mounted DIP switch selects normal left/right stereo outputs or can select
either the left or the right input to drive all eight outputs or can even be used to
sum both left and right (L+R) inputs into either or both sets of outputs. By
reversing the phase of the right input signal on the external connector, an L-R
difference signal can be generated in the same manner.

A TRS (tip-ring-shield) stereo headphone output jack is mounted on the front
panel. Both low and high impedance stereo headphones will be driven properly
without output loading.

The SMDA200 incorporates an LED peak-indicating bargraph meter which is
switchable to either the inputs or the outputs and will monitor either the Left
Channel, the Right Channel or the Left plus Right (L+R) Sum signal as selected
by a pair of front panel switches.

CIRCUIT OPERATION

The audio input lines are bridged by a 30,000 ohm active balanced differential
input stage with a loss of 2.5dB. The bridging resistor network is split and heavily
bypassed for maximum RF protection. Trimmers R13 and R14 null out common
mode hum inputs and are factory set to 90dB. To field-adjust, apply a 60 Hz input
to HI and LO input terminals together referenced to ground and adjust the
trimmer to null the output. The input stage will bridge a +24dBm input line without
clipping. The input stages use two sections of a quad bi-fet LF347N IC.

A full range, ganged stereo OUTPUT control, R23 and R24, adjusts both
channels simultaneously; unity channel gain is at 50 percent rotation. Individual
multi-turn trimpots, R17 and R18, allow fine TRIM and precise matching of each

ATI Audio Inc. ■ Tel: [phone] ■ Fax: [phone] ■ [e-mail] ■ www.

audio.com

channel’s gain over a 4dB range above and below the nominal stage gain of
22dB.

Board mounted DIP switch S1 provides four normally open switch sections to
independently direct the left and right input signals to either or both output
amplifiers. Resistive mixing allows both left and right inputs to be summed (L+R)
into either or both outputs.

The output stages consist of a bridged pair of high current output ICs
(NE5532AN) that provide the first 20ma. of output current directly. Above that
level, the complimentary class B output booster transistors take over. This simple
but unique, wide bandwidth, high slew rate design provides effective class AB
operation with minimal crossover distortion from a power output stage operating
in true class B with zero quiescent power dissipation. The outputs provide 3.5dB
of stage gain, 6dB additional due to the balanced configuration and 3.5dB of
output loss through the build-out resistors when loaded by 600 ohms.

The HI and LO amplifier outputs are split into four isolated balanced outputs
through 150 ohm build-out resistors. The build-out resistors are individually
bypassed to prevent RF pickup on an output line from affecting the operation of
the DA. The build-out resistors totally isolate disturbances on one output line
from all other outputs. All outputs will tolerate short circuits across the outputs, or
to ground, without damage. However since all outputs are driven by active
stages, DO NOT CONNECT EITHER HI or LO OUTPUT TERMINALS TO
GROUND or to the grounded side of an unbalanced load to avoid excessive
power supply loading and loss of headroom. Instead, connect the unbalanced
load between the HI output and DC GROUND (rather than HI and LO) or use a
transformer output equipped DA module such as an ATI MIDA100-1 or isolate
the unbalanced load through a balanced-to-unbalanced converter such as an ATI
L1000-1 Line Amplifier or an isolation transformer.

The SMDA200 includes a bargraph peak-reading meter. Front panel switches S2
and S3 select input or output and either Left, Right or the L+R sum signal. A4A
sums and amplifies the switch output with a 3dB gain reduction allowance for the
L+R rms sum. The meter circuit is designed for equal input and output levels and
as shipped is calibrated by R71 for +4dBm at 0VU. A4B and A4C form an active
full wave meter rectifier driving the LED bargraph with a range of 12dB above
and 15dB below 0VU in 3dB increments. The display and circuit time constants
approximate PPM ballistics. The meter driver, A5, is a National LM3915 and A6
is a General Instrument MV50164 ten segment LED display.

Unregulated input power at ±18VDC nominal is filtered and limited to 16VDC
maximum by zener diodes CR2 and CR3. Power indicator LED CR5 detects the
loss of either power supply voltage. On-board fuses, PI and F2, (3/8 A) protect
the main power buss from module faults. Zener diode CR1 provides 11VDC
maximum to the meter display.

ATI Audio Inc. ■ Tel: [phone] ■ Fax: [phone] ■ [e-mail] ■ www.

audio.com

An electrostatic shield is mounted to the PC board just behind the panel to shield
the low level circuitry. To achieve optimum shielding, SYSTEM 10K modules
should be mounted side-by-side starting on the left side of the rack frame with no
spaces left between modules. Panel retaining screws should be tight to
effectively ground the panel to the frame.

All parts with the exception of panels, shields and PC boards are standard
distributor items but are also available from ATI stock. A1 and A4 are National
LF347N quad bi-fet ICs interchangeable with TI TL074 and others. A2 and A3
are Signetics, TI or Exar NE5532AN dual, high output audio opamps. The output
boost transistors are GE D44C3 (NPN) and D45C3 (PNP).

INSTALLATION

A mating connector assembly is included with each amplifier module. The
connector assemblies may have been pre-assembled to the RM100 rack frame if
ordered together. If not, they should be mounted to the rear of the frame using
the (4) M2.5X6mm screws supplied. Install modules starting from the extreme left
(opposite power supplies); leave no spaces between modules to achieve the
most effective shielding. Plug on the DC power buss connector to the polarized
3-pin receptacle at the top of the connector assembly.

To make a connection to the 3.5mm modular connectors using Belden #8451
cable or equivalent cable with 22 to 24 gauge inner conductors, strip back the foil
shield about 1" to 1 1/2" exposing the inner conductors and shield drain wire.
Remove shield and cut off the drain wire. All connectors and 3.5mm modular
connectors are marked clearly for function and polarity.

The output ground connections "G" are used for connecting the LO side of
unbalanced, single ended, one-side grounded loads. They must NOT be used to
terminate the shields of the cables connected to the outputs or inputs since this
would degrade the RF immunity of the system by routing intercepted RF and
other noise pickup directly into the module. Cable shields should instead be tied
to studio ground at a punch block, Christmas tree block or jack field interconnect
point and allowed to float at the input and outputs of the DA.

All inputs, whether balanced or unbalanced should be treated and wired as
balanced sources to achieve maximum immunity to hum, noise and RF which
may be picked up on the input wiring. All inputs should use two-conductor-plus­foil shielded cable. Connect source HI to DA input HI, connect source LO or GND
to the DA input LO, tie cable shield to source or studio ground (allow shield to
float at the DA) and make sure there is a connection from the source chassis to
the studio ground.

ATI Audio Inc. ■ Tel: [phone] ■ Fax: [phone] ■ [e-mail] ■ www.

audio.com

SPECIFICATIONS

INPUT

Channels

2 (Configurable as Dual Mono or Single Stereo)

Input Impedance

>30 K ohm balanced

CMR Range

+20V

CMR Ratio

>90 dB @60Hz

OUTPUT

Channels

8 total Mono or 4 per Stereo Input Channel

Output Impedance

<600 ohm

Output-to-Output isolation

>70 dB, 20Hz to 20kHz

Nominal Output Level

+4dBm @ 600 ohm = 0 VU Indication

Maximum Output Level

+24dBm @ 600 ohm

Headphone Output

10Vrms maximum through 150 ohms

PERFORMANCE

S/N Ratio

>90dB (unweighted) 20Hz to 20kHz

Gain Range

-4 to +24 dB Front Panel Adjustable

Frequency Response

<-0.25, +0dB 20Hz to 20kHz

Total Harmonic Distortion

<0.025% @ 1kHz

Intermodulation Distortion

<0.05% @ 1kHz

Channel Crosstalk

>90 dB @ 1KHz

ENVIRONMENTAL

Power Supply

120 or 230 VAC ±10% @50/60 Hz (determined by
power supply wiring)

Operating Temperature

0 deg C to 40 deg C

Humidity

0 to 90% non-condensing

Specifications reflect performance in a typical SYSTEM 10K consisting of ten
mixed distribution amplifier modules and two PS100 power supplies mounted
together in an RM100 rack frame.
