Wellness Steam Shower Cabins (S6)
Please read the user's manual carefully before using the product.
SAFETY NOTES
1.The power supply must be installed according to the local standard and wi th
GFCI (Ground Fault Current Interrupter). Test the GFCI before using to confirm
its security and validity.
2. The earthing for electrical appliances should be conne cted to fi xed ear th wir e
forever.
3. To avoid electric shock, replacing of power supply wire sho uld be done by
professional electrician or distributor. User sho uld n ot ch ange it by hims elf.
4. To avoid electric shock, no extending power supply should be used. The socket
should be in right position. Broken electric wire should be changed in time.
5. It's forbidden to make any change, adding or cutting to the product.
6. It's forbidden to use the product after drinking or taking hypnotic medicine.
7. Children should use the product under custody from adults.
INDEX
Safety Notes
Parameter for Steam Cabin
Parts Information
User's Manual
Steam Generator Cleaning
Trouble Shooting
8. Adjust the low water temperature to high water temperature slowly to avoid
scald.
9. Stop using the product in case user feels uncomfortable.
Parameter for Steam Cabin
Parts Information
Rated Power: 3.0KW 4.5KW
Rated Voltage: Single Phase AC220V Double Phase AC240V
Single Phase AC110V
Rated Electric Current: 16A 20A
Frequency: 60Hz 50Hz
Power Supply Location: on wall on floor
Rated Water Pressure: 0.2--0.6 MPa
Water Supply: DN15 tie-in hot/cold water
Water Supply Location: on wall on floor
Diameter of Drainage Pipe: 50 drainage pipe supplied with product)
Length of Drainage Pipe:1000mm the maximum length after stretched)
Parts Information
LCD DISPLAY
Fahrenheit degree
1.
Celsius degree
2.
Temperature
3.
4. Temperature indicator
5. Time setting
6. FM radio frequency
7. FM radio volume
8. FM radio channel
9. Chromatherapy on/off
10. Ventilator on/off
11. Steam on/off
12. Power on indicator
13. FM radio frequency
14. Mp3 on/off
50 50
122122
MINMIN
MHZMHZ
DBDB
CHCH
8686
3030
MM
EE AA
CC
FF
MP3MP3
Control Panel for Steam Cabin
Power on/off
CC
Steam temeprature setting
CC
System time setting
Ventilator
Chromatherapy
Steam on/off
MP3
Radio
Volume/Frequency
Radio memory
+ adjustment
- adjustment
Control Parts Information for Steam Cabin
Steam Temperature Sensor
LCD Display
Control Panel
Water Diverter
Water Volume Adjustment
Water Temperature Adjustment
Back Massage Jet
Steam Outlet
Hand Shower Set
Steam Generator Cleaning
Liquid Inlet
User's Manual
User's Manual
Power on/off
Push any button to light the display and
picture 1 shows on screen. Push power
on/off button now to start the system
and picture 2 shows on the display.
Push power on/off button again to shut
off the system. The display and
background light for push buttons are
turned off. The drain valve for steam
generator keeps on for 1 minute.
CC
Steam temprature setting
Keep on pushing this button and picture
3 shows on display. The figure of
temperature is changing from 20 to 59
circularly. Loosen the button when the
figure reaches the desired temperature
and the figure is set as steam setting
temperature. The steam generator stops
working when the temperature inside
steam cabin is higher than setting
temperature. The steam generator starts
working automatically when the
temperature is lower than setting
temperature. The default steam setting
temperature is 45 /113F if the user does
not make any steam temperature setting.
50 50
122122
CC
FF
MINMIN
MHZMHZ
DBDB
CHCH
8686
3030
MM
MP3MP3
EE AA
Chromatherapy
This button controls the color of
chromatherapy lamps (picture 5).
When chromatherapy function starts,
the lamp symbol on LCD display
twinkles (picture 5). .
50 50
122122
8686
3030
CC
MM
EE AA
Picture 5
Picture 1
Yellow
Orange
Green
Red
50 50
122122
CC
Ventilator
White
Blue
Purple
Cyan
Circle
Off
Picture 6
This button turns ventilation on/off.
When ventilation is on, the ventilation
8686
3030
MM
EE AA
Picture 2
CC
symbol on LCD display twinkles. .
Celsius/Fahrenheit Conversion
Keep on pushing this button for ateast 3
seconds to make conversion between
Celsius degree and Fahrenheit degree.
And the picture is changing between
PICTURE 7 and picture 8. .
50 50
3030
Celsius degree
122122
Picture 7
CC
MM
EE AA
FF
System time setting
Keep on pushing this button and picture
4 shows on display. The figure is changing
from 20-59 circularly. Loosen the button
when the figure reaches the desired one
and the figure is set as working time for
system.
The system is automatically shut off when
the working time reaches the setting time.
The default working time is 45 minutes if
the user does not make setting for working
time of the system.
Steam on/off
Picture 3
This button turns steam on/off. Push this
button, the steam symbol is twinkling on
8686
Fahrenheit degreee
Picture 8
LCD display. The steam function is
automatically turned off when the
122122
50 50
temperature inside steam cabin is
.
MINMIN
higher than the set temperature. And the
steam function will be turned on
automatically when the temperature
inside steam cabin is lower than the
8686
3030
set temperature. .
.
Picture 4
Picture 9
MM
EE AA
CC
MM
EE AA
User's Manual
User's Manual
MP3
MP3 Setting:
First choose a radio frequency as MP3
channel. Please note that the radio
frequency chosen should have no radio
station. Set the same frequency as the
emitting frequency of the MP3 emitter.
Start MP3 function.
.
Adjust frequency of FM radio to get the
same frequency as that of MP3 emitter.
Adjust volume of FM radio. It will be set
as the default volume of MP3.
.
Push Mp3 button for over 3 seconds to
finish setting.
.
FM radio on/off
Push this button and picture 11 shows on
the display. And FM radio is on. The radio
frequency by default is the same as the
radio frequency selected last time. .
Volume/Frequency
adjustment
Volume adjusting:
Push this button when FM radio is on
and picture 12 shows on the display.
Push button again to adjust
volume.
.
50 50
122 122
C C
Channel Memory
Channel Memory Setting
MHZMHZ
8686
3030
MM
MP3MP3
E E AA
Start FM radio .
Set serial number: push button
shortly and picture 14 shows on
CHCH
display; push button shortly
Picture 10
again, figure from 1 to 8 shows
circularly; stop pushing this button
Picture 14
when the wanted figure shows.
50 50
122122
CC
Adjust FM radio to your favorite
channel; push button to adjust
MHZMHZ
8686
3030
MM
EE AA
frequency and volume. .
Channel Memory Push button
for more than 3 seconds; the figure
shows +1 and turns to original setting
Picture 11
serial number. Stop pushing this
button to finish setting for one
channel. If the serial number is used
for another channel, this channel will
be replaced by the new channel
in memory. .
DBDB
.
Repeat the above steps to get the
favorite channels in memory. At
most 8 channels can be in memory.
Picture 12
Find channel:
Start FM radio. Push button shortly
to find right channel in memory.
Frequency adjusting:
Push this button twice when FM radio is on
and picture 13 shows on the display. Push
button again to adjust frequency.
MHZMHZ
Picture 13
+ adjustment
- adjustment
The above 2 buttons are used to adjust frequency
and volume.
Steam Generator Cleaning
Romove the cover of cleaning liquid inlet
and input around 1L of citric acid or acetic
acid. Then start steam function to fill steam
generator with water. Stop steam function
before steam coming out (acid steam has
causticity to plated parts. If a lot of acid
steam come out, the plated parts become
cloudiness after some time.) Do not shut off
the control system and keep it on. The scale
in the steam generator dissolves in acid
liquid and the system drains the dirty water
out automatically after 60 minutes. Clean
the steam generator every 3 months.
Trouble Shooting for Steam Cabin
Trouble Shooting for Steam Cabin
TROUBLE
No Steam
Steam
generator
keeps adding
water.
5.Thermal switch in the heater
is wrong
6.The heater is wrong.
7.The set temperature is lower
than room temperature.
1.The water inlet electro magnetic valve is wrong.
2.Water level sensor could not
detect signal.
CAUSE SOLUTION
Change thermal switch
installed inside the heater.
Change the heater.
Reset temperature.
Replace water inlet valve
Clean scale on water level
sensor or replace it.
TROUBLE
Touch panel
does not work.
No Steam
CAUSE SOLUTION
1.Communication line is short
circuit or open circuit.
2.The control system is wrong.
1.The water supply is shut off.
2.No water supply in this area.
3.The water inlet valve cannot
be turned on.
4.The water level sensor is
wrong.
Check connection between
control panel and power box.
Change control panel or power
box.
Turn on the water supply valve.
Use the product when water
supply is normal.
Check water inlet valve and
output signal from it.
Clean scale on water level
sensor or replace it.
Power supply is
off when on/off
button is pushed.
Water leaks
from valve.
Water flow
volume is low.
1.There is creepage from heater.
2.There is creepage from thermal
switch inside heater.
The seal is damaged.
Water supply has impurities
and jammed the filter net.
Replace heater.
Replace thermal switch.
Change the seal.
Get filter net cleaned.
S6 Wiring Diagram
