HDMI HDBaseT Extender with PoH
VE1812 User Manual
www.aten.com
VE1812 User Manual
EMC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
CE Warning: Operation of this equipment in a residential environment could cause
radio interference.
Warning: This equipment is compliant with Class A of CISPR 32. In a residential
environment this equipment may cause radio interference.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Suggestion: Shielded twisted pair (STP) cables must be used with the unit to ensure
compliance with FCC & CE standards.
RoHS
This product is RoHS compliant.
ii
VE1812 User Manual
User Information
Online Registration
Be sure to register your product at our online support center:
International http://eservice.aten.com
Telephone Support
For telephone support, call this number:
International 886-2-8692-6959
China 86-10-5255-0110
Japan 81-3-5615-5811
Korea 82-2-467-6789
North America 1-888-999-ATEN ext 4988
United Kingdom 44-8-4481-58923
User Notice
All information, documentation, and specifications contained in this m anual
are subject to change without prior notification by the manufacturer. The
manufacturer makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties as to merchantability or fitness for any particular purpose. Any of
the manufacturer's software described in this manual is sold or licensed as is.
Should the programs prove defective following their purchase, the buyer (and
not the manufacturer, its distributor, or its dealer), assumes the entire cost of all
necessary servicing, repair and any incidental or consequential damages
resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device. It is the
responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation
of this system if the correct operational voltage setting was not selected prior
to operation. PLEASE VERIFY THAT TH E VOLTAGE SETTING IS
CORRECT BEFORE USE.
iii
VE1812 User Manual
© Copyright 2017 ATEN® International Co., Ltd.
Manual Date: 2017-10-16
ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.
Package Contents
VE1812 Package Contents
1 VE1812T/R HDMI HDBaseT Extender with PoH
1 Power Adapter
1 IR Transmitter
1 IR Receiver*
2 RS-232 Terminal Blocks
1 User Instructions
VE1812T Package Contents
1 VE1812T HDMI HDBaseT Extender with PoH
1 Power Adapter
1 RS-232 Terminal Block
1 User Instructions
VE1812R Package Contents
1 VE1812R HDMI HDBaseT Extender with PoH
1 RS-232 Terminal Block
1 Power Adapter
1 User Instructions
Check to make sure that all the components are present and that nothing got
damaged in shipping. If you encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit, and/or any of the
devices connected to it.
Features may have been added to the VE1812 since this manual was published.
Please visit our website to download the most up-to-date version of the manual.
Note: The included IR receiver supports full frequency IR signals from 30kHz
to 60kHz. The IR receiver cable included with the package, however,
only supports signals from 30kHz to 56 kHz.
iv
VE1812 User Manual
Table of Contents
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
VE1812 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
VE1812T Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
VE1812R Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
1. Introduction
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Source Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Transmitter Panel View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Receiver Front and Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
LED Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Enabling the Long Reach Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2. Hardware Setup
Setting Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
RS-232 Channel Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Appendix
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
North America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
v
VE1812 User Manual
About this Manual
This User Manual is provided to help you get the most from your system. It
covers all aspects of installation, configuration and operation. An overview of
the information found in the manual is provided below.
Chapter 1, Introduction, introduces you to the VE1812 system. Its
purpose, features and benefits are presented, and its front and back panel
components are described.
Chapter 2, Hardware Setup, describes the steps that are necessary to
quickly and safely set up your installation.
An Appendix, provides specifications and other technical information
regarding the VE1812.
vi
VE1812 User Manual
Conventions
This manual uses the following conventions:
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to
press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦ Bullet lists provide information, but do not involve sequential steps.
→ Indicates selecting the option (on a menu or dialog box, for
example), that comes next. For example, Start
open the Start menu, and then select Run.
Indicates critical information.
→ Run means to
Product Information
For information about all ATEN products and how they can help you connect
without limits, visit ATEN on the Web or contact an ATEN Authorized
Reseller. Visit ATEN on the Web for a list of locations and telephone numbers:
International http://www.aten.com
North America http://www.aten-usa.com
vii
VE1812 User Manual
This Page Intentionally Left Blank
viii
Chapter 1
Introduction
Overview
The USB DVI KVMP™ Switch extends an HDBaseT signal up to 100m from
the HDBaseT source using one Cat 5e/6/6a cable. With Long Reach mode
enabled, the VE1812 can extend HDMI signal up to 150m. The VE1812
supports RS-232 and IR signaling pass-through, allowing you to control the
HDMI source device from the VE1812 receiver while also granting access to
the HDMI display device from the VE1812 transmitter unit. IR signals can also
be extended in both directions. The VE1812 features Power over HDBaseT
(PoH) which can send power over Cat 5e/6/6a cable without an additional
power supply. The VE1812 is HDMI (3D, Deep Color,4K x 2K) and HDCP
compatible. The VE1812 is perfect for a digital entertainment center or any
installation that requires superior video quality.
1
Chapter 1. Introduction
Features
HDBaseT Connectivity – extends an HDMI connection over a long
distance via one Cat 5e/6/6a cable
4K x 2K HDMI transmission up to 100m over one Cat 6a / A TEN 2L-2910
Cat 6 cable
Long Reach Mode – extends HDMI signal up to 150m @ 1080p
HDBaseT Anti-jamming – resists signal interference during high-quality
video transmission using HDBaseT technology
PoH (Power over HDBaseT) – supplies power from Transmitter to
Receiver over a long distance via one Cat 5e/6/6a cable
A bi-directional RS-232 serial port to connect with a high-end system for
more device control
A bi-directional IR channel for IR signal control; IR transmission is
processed one way at a time
Supports IR signal frequencies from 30 kHz to 60 kHz*
Rack-mountable
Note: The included IR receiver supports full frequency IR signals from 30
kHz to 60 kHz. The IR receiver cable included with the package,
however, only supports signals from 30 kHz to 56 kHz.
2
VE1812 User Manual
Requirements
Display
An HDMI display capable of the highest required resolution
Source Device
A source device with an HDMI port
Cables
To connect the VE1812 transmitter and receiver units, we recommend
using cables of Cat 5e/6/6a to ensure video quality.
For better video quality, we strongly suggest using ATEN 2L-2910 Cat 6
cable.
Maximum cable distances are as follows:
Connection Interface Distance
Computer to Transmitter (VE1812T) HDMI 1.8 m
Transmitter (VE1812T) to Receiver
(VE1812R)
Receiver (VE1812R) to monitor HDMI 5 m
Cat 5e / 6 / 6a 100 m*
Note: The maximum transmission distance using a Cat 5e/6/6a is 100m and 150m
when Long Reach Mode is enabled.
3
Chapter 1. Introduction
4
1
2
3
7
5
6
Components
Transmitter Panel View
No. Component Description
1 F/W Upgrade Switch The Firmware upgrade port is reserved for tech
2 IR Port Connect an IR Receiver to the IR port on the
3 RS-232 Port You can connect RS-232 serial devices or
4 HDMI Input Port Connect the HDMI Input Port on the VE1812T to
5 HDBaseT Output Port The Cat 5e/6/6a cables that connects the
6 HDBaseT Long Reach
mode Switch
7 Power Jack The cable from the Power adapter connects here.
support. If you would like to do a firmware
upgrade yourself, please contact your dealer.
VE1812R.
peripherals to the VE1812, such as touchscreens
and bar code scanners.
the HDMI Output Port on the video source device
using an HDMI cable.
Receiver Units, plug in here.
Use the dip switch to enable long reach mode.
When long reach mode is enabled, signal
transmission can be extended up to 150 m @
1080p.
4
VE1812 User Manual
4
1
2
3
7
5
6
Receiver Front and Rear View
No. Component Description
1 F/W Upgrade Switch The Firmware upgrade port is reserved for tech
2 IR Port Connect an IR Transmitter to the IR port on the
3 RS-232 Port You can connect the RS-232 main controller to the
4 HDMI Output Port Connect the HDMI display to this port.
5 HDBaseT Input Port The Cat 5e/6/6a cable that connects to the
6 HDBaseT Long Reach
mode Switch
7 Power Jack The cable from the Power adapter connects here.
support. If you would like to do a firmware
upgrade yourself, please contact ATEN technical
support.
VE1812T.
VE1812, such as the PC or Control system.
Transmitter Unit plugs in here.
Use the dip switch to enable long reach mode.
When long reach mode is enabled, signal
transmission can be extended up to 150 m
@1080p.
5
Chapter 1. Introduction
123
2 3
VE1812 Transmitter
VE1812 Receiver
LED Display
The VE1812 Transmitter and Receiver units have top panel LEDs to indicate
their operating status, as shown in the table below:
2
1
No. LED Indication
1 HDMI Out* (Orange)
2 Link (Orange) Light is static to indicate that the connection to the
3 Power (Green) Lights to indicate that the system is receiving power.
Light is static when HDMI display is normal with HDCP
key.
Flashes when HDMI display is normal without HDCP
key.
OFF when there is no HDMI signal.
Transmitter and Receiver units are stable.
Note: The HDMI Out LED is available on VE1812R only.
Enabling the Long Reach Mode
Long Reach mode provides a more robust modulation where the transmission
distance is extended while compromising on the maximum supported rate. If
your system is not required to support video rates higher than 1080p, 24 bpp,
60 Hz, you may activate Long Reach Mode to enable longer cable reach of 150
meters with a Cat 5e/6/6a cable.
To enable the Long Reach mode, put the dip switch to ON at either the
transmitter or the receiver.
6
Chapter 2
1. Please review important safety information regarding the
placement of this device in Safety Instructions, page 11.
2. Make sure no t to power on the VE1812 devices until all the
necessary hardware is connected.
Hardware Setup
Setting Up
Setting up the VE1812 USB DVI KVMP™ Switch system is simply a matter
of plugging in the cables. Make sure that all the equipment to be connected are
powered off, then refer to the installation diagram on the next page and do the
following:
1. Con nect the HDMI Input port on the VE1812T to the HDMI Output port
on your video source device using HDMI cable.
2. Con nect one end of the RJ-45 cable to the HDBaseT Output port on the
transmitter. Then connect the other end of the RJ-45 cable to the HDBaseT
Input port on the receiver.
3. Con nect the HDMI Output port on the VE1812R to the HDMI Input port
on your video display device using HDMI Cable.
4. (Optional) Connect your computer or control system to the RS-232
terminal block on the VE1812.
5. Optional) Connect an IR transmitter / receiver to the IR port on the
VE1812.
6. Plug the power adapter cable into the power jack on the VE1812T.
7. (O ptional) Plug the power adapter cable into the power jack on the
VE1812R.
7
Chapter 2. Hardware Setup
Installation Diagram
VE1812R
4
5
3
7
2
6
4
5
1
VE1812T
8
VE1812 User Manual
PIN
CONFIGURATION
(Captive screw
connectors)
Tx
Rx
Gnd
Tx
Rx
Gnd
Tx
Rx
Gnd
Tx
Rx
Gnd
Serial
Device
Cat 5e / 6 / 6a
RS-232 Channel Transmission
You can connect RS-232 serial devices/peripherals to the VE1812, such as
touchscreens and bar code scanners. The RS-232 signal transmission flow is
shown in the following example:
From a source device, the RS-232 signal is transmitted (Tx) to the VE1812T
receiving (Rx) unit; the VE1812R transmits (Tx) signals to the display device
(Rx).
9
Chapter 2. Hardware Setup
This Page Intentionally Left Blank
10
Appendix
Safety Instructions
General
Read all of these instructions. Save them for future reference.
Follow all warnings and instructions marked on the device.
This product is for indoor use only.
Do not place the device on any unstable surface (cart, stand, table, etc.). If
the device falls, serious damage will result.
Do not use the device near water.
Do not place the device near, or over, radiators or heat registers.
The device cabinet is provided with slots and openings to allow for
adequate ventilation. To ensure reliable operation, and to protect against
overheating, these openings must never be blocked or covered.
The device should never be placed on a soft surface (bed, sofa, rug, etc.) as
this will block its ventilation openings. Likewise, the device should not be
placed in a built in enclosure unless adequate ventilation has been provided.
Never spill liquid of any kind on the device.
Unplug the device from the wall outlet before cleaning. Do not use liquid
or aerosol cleaners. Use a damp cloth for cleaning.
The device should be operated from the type of power source indicated on
the marking label. If you are not sure of the type of power available,
consult your dealer or local power company.
The device is designed for IT power distribution systems with 230V
phase-to-phase voltage.
To prevent damage to your installation, it is important that all devices are
properly grounded.
The device is equipped with a 3-wire grounding type plug. This is a safety
feature. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not attempt to defeat the
purpose of the grounding-type plug. Always follow your local/national
wiring codes.
Do not allow anything to rest on the power cord or cables. Route the
power cord and cables so that they cannot be stepped on or tripped over.
11
Appendix
If an extension cord is used with this device make sure that the total of the
ampere ratings of all products used on this cord does not exceed the
extension cord ampere rating. Make sure that the total of all products
plugged into the wall outlet does not exceed 15 amperes.
To help protect your system from sudden, transient increases and
decreases in electrical power, use a surge suppressor, line conditioner, or
un-interruptible power supply (UPS).
Position system cables and power cables carefully; Be sure that nothing
rests on any cables.
Never push objects of any kind into or through cabinet slots. They may
touch dangerous voltage points or short out parts resulting in a risk of fire
or electrical shock.
Do not attempt to service the device yourself. Refer all servicing to
qualified service personnel.
If the following conditions occur, unplug the device from the wall outlet
and bring it to qualified service personnel for repair.
The power cord or plug has become damaged or frayed.
Liquid has been spilled into the device.
The device has been exposed to rain or water.
The device has been dropped, or the cabinet has been damaged.
The device exhibits a distinct change in performance, indicating a need
for service.
The device does not operate normally when the operating instructions
are followed.
Only adjust those controls that are covered in the operating instructions.
Improper adjustment of other controls may result in damage that will
require extensive work by a qualified technician to repair.
This product is for indoor use only.
12
VE1812 User Manual
Technical Support
International
For online technical support – including troubleshooting, documentati on,
and software updates: http://eservice.aten.com
For telephone support, see Telephone Support, page ii i.
North America
Email Support support@aten-usa.com
Online Technical
Support
Telephone Support 1-888-999-ATEN ext. 4988
When you contact us, please have the following information ready beforehand:
Product model number, serial number, and date of purchase
Your computer configuration, including operating system, revision level,
expansion cards, and software
Any error messages displayed at the time the error occurred
The sequence of operations that led up to the error
Any other information you feel may be of help
Troubleshooting
Documentation Software
Updates
http://www.aten-usa.com/support
13
Appendix
Specifications
Function VE1812R VE1812T
Video Input
Interfaces N/A 1 x HDMI Type A Female
(Black)
Impedance N/A 100W
Max. Distance N/A 1.8 m
Video Output
Interfaces 1 x HDMI Type A
Female (Black)
Impedance 100 Ώ N/A
Video
Max. Data Rate 10.2Gbps (3.4Gbps per lane)
Max. Pixel Clock 340 MHz
Compliance HDMI (3D, Deep Color, 4K)
HDCP Compatible
Consumer Electronics Control (CEC)
Max. resolutions /
Distances
Up to:
4K@70m (Cat 5e/6) / 100m (Cat 6a / ........
ATEN 2L-2910 Cat 6)
1080p@100m (Cat 5e/6/6a)
N/A
4K supported:
4069 x 2160 / 3840 x 2160 @ 60Hz (4:2:0)
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Audio
Input N/A 1 x HDMI Type A Female
(Black)
Output 1 x HDMI Type A
Female (Black)
14
N/A
VE1812 User Manual
Function VE1812R VE1812T
Control
RS-232 Connector 1 x Terminal Block, 3 pole
Baud Rate 19200
Data Bits 8
Stop Bits 1, no parity and flow control
IR 1 x Mini Stereo Jack Female (Black)
Switches
Long Reach Mode
1 x Slide Switch - ON/OFF
Switch
Firmware Upgrade 1 x Slide Switch - ON/OFF
Power
Connectors 1 x DC Jack (Black) with locking
Consumption DC 5V, 6.4W DC 5V, 4.3W
Environment
Operating Temperature 0 - 40ºC
Storage Temperature -20 - 60°C
Humidity 0 - 80% RH, Non-Condensing
Physical Properties
Housing Metal
Weight 0.45 Kg (0.99 lb) 0.47 Kg (1.04 lb)
Dimensions (L x W x H)
14.04 x 12.30 x 3.00 cm (5.53 x 4.84 x 1.18 in.)
with bracket
Dimensions (L x W x H)
13.60 x 10.10 x 2.90 cm (5.35 x 3.98 x 1.14 in.)
without bracket
15
Appendix
Limited Warranty
ATEN warrants its hardware in the country of purchase against flaws in
materials and workmanship for a Warranty Period of two [2] years (warranty
period may vary in certain regions/countries) commencing on the date of
original purchase. This warranty period includes the LCD panel of ATEN LCD
KVM switches. Select products are warranted for an additional year (see A+
Warranty for further details). Cables and accessories are not covered by the
Standard Warranty.
What is covered by the Limited Hardware Warranty
ATEN will provide a repair service, without charge, during the Warranty
Period. If a product is detective, ATEN will, at its discretion, have the option
to (1) repair said product with new or repaired components, or (2) replace the
entire product with an identical product or with a similar product which fulfills
the same function as the defective product. Replaced products assume the
warranty of the original product for the remaining period or a period of 90 days,
whichever is longer. When the products or components are replaced, the
replacing articles shall become customer property and the replaced articles
shall become the property of ATEN.
To learn more about our warranty policies, please visit our website:
http://www.aten.com/global/en/legal/policies/warranty-policy
16
Loading...
