Introduction

INTRODUCTION

Thank you for purchasing the Atek OnBoard Travel Keyboard. This
small and lightweight keyboard fits inside most shoulder bags and
laptop computer carrying cases and is convenient to take with you
wherever you go. It enables you to work more productively because it
features desktop keyboard type keycaps and a numeric keypad that
allow you to type faster and/or with fewer errors (see the Features
section of this user’s manual for a detailed explanation about why
desktop keyboard type keycaps enable you to type more efficiently).
Whether you spend time in the evening working in a hotel room, have a
meeting in a conference room, or do field work at remote locations, you
will find that the OnBoard Travel Keyboard makes using your laptop
computer an even more enjoyable and productive experience.

Please register at www.atek.com for product updates. On our website
you can also learn about other Atek products, including the Tote-

®

Remote
Organizer, LogKey

presentation remote control, Logio® Secure Password

®

Password Manager, Super MiniTM Optical Mouse
for laptop computers, and other laptop and desktop computer
accessories.

Please read this user’s manual thoroughly. It contains important
information about your OnBoard Travel Keyboard. Failure to follow
instructions for proper installation and use of this product may cause
damage to the product, your computer, and/or connected devices, may
be detrimental your health and safety, and may also void the warranty.

OnBoard User’s Manual, Page 4

Compatibility & System Requirements

COMPATIBILITY & SYSTEM REQUIREMENTS

Your OnBoard Travel Keyboard must be plugged into the USB port
(USB 1.1 or 2.0) on your computer or into a USB hub or USB
extension cable. The computer must be running Windows Vista®,
Windows XP®, Windows 2000®, Windows Me®, or Windows 98®SE
(Second Edition).

OnBoard User’s Manual, Page 5

Features

FEATURES

The Atek OnBoard Travel Keyboard features membrane-type switch
mechanisms inside the keys, full height desktop keyboard type keycaps,
normal spacing between keys, and a separate numeric keypad area. Put
the OnBoard Travel Keyboard below a desktop keyboard and you’ll see
the alphanumeric sections are almost identical in width.

Number of Keys

A typical laptop computer keyboard may have only about 90 keys. By
comparison, the OnBoard Travel Keyboard has 99 keys, including all
the alphanumeric keys, all the navigation keys, a full numeric keypad,
and most of the function keys found on a standard 104-key desktop
keyboard.

The five keys the OnBoard Travel Keyboard does not have that are
found on a typical desktop keyboard are:

Print Screen
Scroll Lock
Pause Break
Right side Ctrl key
Right side Windows Start key

OnBoard User’s Manual, Page 6

Features

Size and position of non-crucial keys

The Esc, Function, Page (Up, Down), Arrow (Up, Down, Left, Right),
Insert, Delete, Home, and End keys on the OnBoard Travel Keyboard
are smaller than on a standard desktop keyboard. Some of them are in
non-standard positions, but they are easy to find. In fact, if you have
ever had the experience of accidentally hitting the insert key when you
meant to hit the backspace key and then you started overwriting text,
you may be glad not to have the Insert key right next to the Backspace
key.

Numeric keypad closer to main part of keyboard

In order for the overall width of the OnBoard Travel Keyboard to be
narrow enough to fit inside most shoulder bags and laptop computer
cases, we moved the numeric keypad closer to the alphanumeric part of
the keyboard.

Overall Size

The OnBoard Travel Keyboard is enclosed in a compact frame. When
in the stored position, it measures approximately 5” from front to back
(at the widest point where the connector is stored, and about 1/4” less
elsewhere), 15” wide, and 1” high. The keyboard’s small size and light
weight (approximately 1.3 lbs., which is about half the weight of many
desktop keyboards) makes it easy to carry along with you and should
have little or no impact on ease of use.

OnBoard User’s Manual, Page 7

Features

Why the OnBoard Travel Keyboard is easier to use than a laptop
keyboard

Most people find that their typing productivity (speed and accuracy) is
lower on a laptop keyboard than on a desktop keyboard. They have to
type more slowly on a laptop keyboard in order to maintain the same
accuracy, otherwise they have to spend a lot of time correcting
mistakes. Although there is a difference in feel between the
“membrane” switch mechanism typically used inside desktop keyboard
keys and the “scissor” switch mechanism often used in laptop computer
keyboards, this difference does not fully or even substantially account
for the difference in typing productivity. Nor does the spacing of the
keys. The general impression is that laptop keyboards are cramped, and
although it is true that laptop keyboards do not have separate numeric
keypads, careful measurement of many laptop keyboards (not including
miniature types) shows that the spacing between the centers of adjacent
keys (called “pitch”) is the same as or very close to the pitch on a
desktop keyboard! And the width of the keycaps is about the same too.
So why are laptop keyboards harder to use than desktop keyboards?

The reason a desktop keyboard is easier to use is because of the
height and shape of the keycaps and the amount of distance they
travel.

OnBoard User’s Manual, Page 8

Features

Standard desktop keyboard keycaps look something like this:

Standard laptop keyboard keycaps look something like this:

Note three things about these keycaps:

1) Desktop keyboard keycaps are more concave on the top than most
laptop keyboard keycaps.

2) A desktop keyboard keycap is taller than a laptop keyboard
keycap. Desktop and laptop keyboard keycaps have nearly
identical widths at the top and at the base of the keycap, but
because a desktop keyboard keycap is taller, the side flares out
more gradually going from top to bottom of the keycap.

3) A desktop keyboard key travels further before it engages.

So how do these factors come together to make desktop keyboard
keycaps easier to use? The determining factors are the relative travel

between adjacent keycaps and the reality that we do not always hit
keycaps in the center.
