WaveSurfer® MXs-B and
MSO MXs-B Oscilloscopes
200 MHz – 1 GHz
Engineered for Efficient
Design and Debug
ESSENTIAL TOOLS FOR VALIDATION AND DEBUG
WaveSurfer® MXs-B
• 200 MHz, 400 MHz, 600 MHz
and 1 GHz Bandwidths
• Up to 10 GS/s Sample Rate
• 16 Mpts/Ch Memory,
32 Mpts Interleaved
• Fast Processing of Long
Memory and Math
The WaveSurfer® MXs-B and MSO MXs-B oscilloscopes pack
high performance hardware, powerful waveform processing
and advanced math, measurement and debug tools into a
compact form factor with a large touch screen display and
intuitive user interface.
• Responsive User Interface
• WaveStream™ Fast
Viewing Mode
• WaveScan™ – Advanced
Search and Find
• LabNotebook Documentation
and Report Generation
• 10.4” Touch Screen Display
• LXI Compliant
MSO MXs-B
All the great features of the
WaveSurfer MXs-B plus:
• 18 Digital Channels
• Max. Digital Signal Speed
of 250 MHz
• Analog and Digital Cross
Pattern Triggering
With up to 10 GS/s sample rate and 32 Mpts of memory WaveSurfer can
capture large amounts of data at very high sample rates. Other oscilloscopes offer
long memory but they bog down trying to process or display it. WaveSurfer handles
large amounts of data quickly providing fast processing of long memory even when
using math and measurement functions. The software responds
immediately to the user inputs even while processing data.
System debug often requires more than analog channels. The MSO MXs-B
delivers 18 digital channels which can capture digital signals of up to 250 MHz.
The MSO MXs-B offer analog
and digital cross-triggering
plus measurement tools to
help debug digital busses.
™
LeCroy’s WaveScan
and find tool will scan both
analog and digital channels
for anamolies plus
scan multiple digital
lines for a parallel
bus pattern.
search
2
WaveScan Advanced Search
WaveScan allows searching in a
single acquisition using more than
20 different criteria. Or, set up a
Scan condition and scan for an
event over hours or even days.
When using an MSO model
WaveScan will search digital lines
for parallel bus patterns.
Advanced Math and Measure
With 18 math functions including
averaging, enhanced resolution and
FFT plus 23 measurement parameters
WaveSurfer can measure and
analyze every aspect of a waveform.
Beyond just measuring waveforms,
WaveSurfer provides statistics and
histicons to show how waveforms
change over time.
WaveStream Fast
Viewing Mode
WaveStream provides a vibrant,
intensity graded (256 levels) display
with a fast update to closely simulate
the look and feel of an analog
oscilloscope. Turn WaveStream ON
or OFF, and adjust intensity, using
the front panel knob. Use it only
when you want to.
Touch Screen Simplicity
Keep your testing efficient with a
thoughtfully designed user interface
that provides the busy engineer with
a GUI that is smooth, transparent, and
easy to use. Use the touch screen
to quickly access all triggers, math
functions and measurement parameters
or to “draw a box” around the area
of interest and zoom all channels to
the desired area.
Embedded Controller
Design and Debug
Save time when working with
embedded controllers by adding
high-performance mixed signal
capability with the MSO MXs-B.
Capture digital signals up to 250 MHz
with up to 10 Mpts/Ch memory,
1 GS/s and 18 channels. Quickly and
easily isolate specific serial data
events with optional I2C, SPI, UART,
RS-232, USB 1.0/1.1/2.0, USB 2.0-
HSIC, Audio (I2S, LJ, RJ, TDM), MIL-
STD-1553, ARINC 429, MIPI D-PHY,
DigRF, CAN, LIN and FlexRay™ trigger
and decode options.
LabNotebook Documentation
and Report Generation Tool
LabNotebook provides a report
generation tool to save and
document all your work. Saving
all displayed waveforms, settings,
and screen images is all done
through LabNotebook, eliminating
the need to navigate multiple menus
to save all these files independently.
3
INTUITIVE USER INTERFACE TO FIND PROBLEMS FASTER
3
The WaveSurfer MXs-B and MSO
MXs-B oscilloscopes makes everyday
testing simpler and easier. The intuitive
user interface and streamlined front
panel make it easy to turn on the
oscilloscope and start making measure-
ments. The interface is designed so that
all the common measurements and
2
functions are just one touch away.
1. Only 15 cm (6”) Deep
The most space-efficient oscilloscope for your bench
from 200 MHz to 1 GHz.
2. Local Language User Interface
Select from 10 language preferences. Add a front
panel overlay with your local language.
3. Bright 10.4” Display
You’ll never use a small display oscilloscope again.
A fantastic viewing angle makes it easy to view.
1
4
6
4. “Push” Knobs
Trigger level, delay, and offset knobs all provide
shortcuts to common actions when pushed.
4
5. Zoom Control Knobs
Navigate zoom or math traces with the
multiplexed horizontal knobs.
5
7
6. LeCroy WaveStream Fast Viewing Mode
Provides a lively, analog-like feel similar to a phosphor
trace. Adjust “trace” intensity with the front panel
control, or toggle between LeCroy WaveStream and
real-time modes.
7. Dedicated Cursor Knobs
Select type of cursor, position them on your
signal, and read values without ever opening
a menu.
8. Touch Screen with Built-in Stylus
The most time-efficient user interface is even
8
easier to use with a built-in stylus.
Document and Share:
• Quickly save all files with LabNotebook
• Create custom reports with LabNotebook
• Save to internal hard drive or network drive
• Print to a USB printer
• Save to USB memory stick
• Connect with LAN or GPIB
• View data on a PC with free WaveStudio utility
5
IDENTIFY AND ISOLATE PROBLEMS FASTER
Advanced Waveform Capture
with Sequence Mode
Use Sequence mode to store up to
5,000 triggered events as “segments”
into memory. This can be ideal when
capturing many fast pulses in quick
succession or when capturing events
separated by long time periods.
Sequence mode provides timestamps
for each acquisition and minimizes
dead-time between triggers to less
than 1 μ s. Combine Sequence mode
with advanced triggers to isolate rare
events over time and analyze afterwards.
WaveScan Advanced Search
WaveScan provides powerful isolation capabilities that hardware triggers can’t provide. WaveScan provides the ability
to locate unusual events in a single capture (i.e., capture and
search), or “scan” for an event in many acquisitions over a
long period of time. Select from more than 20 search modes
to find events on any analog or digital channel or search for
a pattern across multiple digital channels.
Since the scanning “modes” are not
simply copies of the hardware trig gers,
the utility and capa bility is much higher.
For instance, there is no “frequency”
trigger in any oscilloscope, yet
WaveScan allows for “frequency”
to be quickly “scanned.” This allows the
user to accumulate a data set of
unusual events that are separated by
hours or days, enabling faster debug-
ging. When used in multiple acquisi-
tions, WaveScan builds on the
traditional LeCroy strength of fast
processing of data. A LeCroy X-Stream
oscilloscope will quickly scan millions of
events looking for unusual occurrences,
and do it much faster and more effi-
ciently than other oscilloscopes can.
WaveStream Fast
Viewing Mode
WaveStream provides a vibrant,
intensity graded (256 levels) display
with fast update rate to simulate the
look and feel of an analog oscilloscope.
WaveStream is helpful for seeing
jitter or identifying unusual events.
With sampling rate as high as 10 GS/s
WaveStream is an excellent runt
or glitch finder.
6
EMBEDDED SYSTEM DESIGN AND DEBUGIDENTIFY AND ISOLATE PROBLEMS FASTER
High-performance MSO
The MSO MXs-B models provide
an easy way to capture and display
analog and digital signals side by side.
With the ability to capture 250 MHz
signals at 1 GS/s sample rate on
18 lines simultaneously the MSO
MXs-B delivers performance that
other MSOs cannot. Memory and
sample rate are never shared with
analog channels and no special modes
are required to get full performance.
The MSO MXs-B deliver uncompro-
mised performance in all situations.
Serial Data Trigger and
Decode
Debugging serial data busses can be
confusing and time consuming. The
serial data trigger and decode options
for WaveSurfer MXs-B and MSO MXs-B
provide time saving tools for serial bus
debug and validation.
The serial data trigger will quickly
isolate events on a bus eliminating
the need to set manual triggers and
hoping to catch the right information.
Trigger conditions can be entered
in binary or hexadecimal formats
and conditional trigger capabilities
even allow triggering on a range of
different events.
Protocol decoding is shown directly
on the waveform with an intuitive,
color-coded overlay and presented
in binary, hex or ASCII. Decoding
on the WaveSurfer is fast even with
long memory and zooming in to the
waveform shows precise byte by
byte decoding.
To further simplify the debug process
all decoded data can be displayed in
a table below the waveform grid.
Selecting an entry in the table with
the touch screen will display just
that event. Additionally, built-in
search functionality will find specific
decoded values.
Supported Serial Data
Protocols
2
• I
C, SPI, UART
• CAN, LIN, FlexRay™
• USB 1.0/1.1/2.0, USB 2.0-HSIC
• Audio (I
2
S, LJ, RJ, TDM)
• MIL-STD-1553, ARINC 429
• MIPI D-PHY, DigRF 3G, DigRF v4
7
LABNOTEBOOK™
A UniqUe Tool for DocUmenTATion AnD reporT GenerATion
The LabNotebook feature of WaveSurfer MXs-B and MSO MXs-B provides a report generation
tool to save and document all your work. Saving all displayed waveforms, relevant settings,
and screen images is all done through LabNotebook, eliminating the need to navigate multiple
menus to save all these files independently.
n
c
u
t
F
h
c
u
o
t
-
e
n
O
k
r
o
W
r
u
o
Y
t
n
e
m
u
c
o
D
P
RINT
E
R
HAR
D DRI
VE
VE
USB DRI
i
o
n
a
l
i
t
y
S
a
v
e
Y
o
u
r
W
o
r
k
R
e
c
a
l
l
J
o
b
s
WAVEFORM
V/div
T/div
Memory Length
Sample Rate
Measurement
Math
OSCILLOSCOPE SET UP
AIL
EM
Easy report generation helps you
share your findings and communicate
important results.
The touch screen and stylus
allow for easy annotation
of the screen. LabNotebook allows
you to add freehand
text and graphics in multiple
colors along with printed
text and arrows to help identify
important parts of your
waveforms and measurements.
Annotated screen captures can
be included in custom reports.
LABNOTEBOOK
LabNotebook adds a simple way to
report your work and save all essential
waveforms, settings, and screen images.
SCREEN DUMP
Quickly save all the
necessary files with
LabNotebook in a
single button press.
FLASHBACK
FLASHBACK
FLASHBACK
Recall your settings
from any report
by using the
Flashback capability.
8
BROAD RANGE OF PROBING SOLUTIONS
WaveSurfer MXs-B and MSO MXs-B support a broad range of probes for a variety of applications.
ZS Series High Impedance Active Probes
• 1 GHz (ZS1000) and 1.5 GHz
(ZS1500) bandwidths
• High Impedance (0.9 pF, 1 MΩ)
• Extensive standard and
available probe tip and ground
connection accessories
• ±12 Vdc offset (ZS1500)
• LeCroy ProBus system
High-Voltage Passive Probes
• Suitable for safe, accurate
high-voltage measurements
• 1.2 kV to 20 kV
• Works with any 1 MΩ
input oscilloscope
ZD Series Differential Probes
• 200 MHz, 500 MHz, 1 GHz
and 1.5 GHz bandwidths
• Wide range of probing
accessories
• LeCroy ProBus system
High-Voltage
Differential Probes
• 20 MHz and 100 MHz bandwidth
• 1,000 V
mode voltage
• 1,400 V
voltage
• EN 61010 CAT III
• 80 dB CMRR at 50/60 Hz
common
rms
differential
peak
Current Probes
• Range of probes from 30 A
to 500 A
• 2 MHz to 100 MHz bandwidths
• Small form factor
accommodates large
conductors with
small jaw size
• LeCroy ProBus system
rms
(700 A
peak
rms
)
(50 A
peak
)
• LeCroy ProBus system
AP031
• Lowest priced differential probe
• 15 MHz bandwidth
• 700 V maximum input voltage
• Works with any 1 MΩ input
oscilloscope
9
SPECIFICATIONS
WaveSurfer WaveSurfer WaveSurfer WaveSurfer WaveSurfer WaveSurfer
Analog Channels 24MXs-B 44MXs-B 42MXs-B 64MXs-B 62MXs-B 104MXs-B
– Vertical MSO 44MXs-B MSO 64MXs-B MSO 104MXs-B
Bandwidth (@ 50 Ω) 200 MHz 400 MHz 400 MHz 600 MHz 600 MHz 1 GHz
Rise Time 1.75 ns 875 ps 875 ps 525 ps 525 ps 350 ps
Input Channels 4 4 2 4 2 4
Vertical Resolution 8 bits
Vertical Sensitivity (V/div) 2 mV/div–10 V/div (1 MΩ); 2 mV/div–1 V/div (50 Ω)
Vertical (DC Gain) ±1.0% of full scale (typical); ±1.5% of full scale ≥ 10 mV/div (warranted)
Accuracy
BW Limit 20 MHz 20 MHz, 200 MHz
Maximum Input Voltage 50 Ω: 5 V
1 MΩ: 250 V max.
(DC + Peak AC
≤10 kHz)
Input Coupling AC, DC, GND (DC and GND for 50 Ω)
Input Impedance 1 MΩ || 16 pF, or 50 Ω
, 1 MΩ: 400 V max. (DC + Peak AC ≤ 5 kHz) 50 Ω: 5 Vrms
rms
Analog Channels
– Acquisition
Sample Rate 2.5 GS/s 5 GS/s 5 GS/s
(Single-shot) (10 GS/s Interleaved)
Sample Rate 50 GS/s
(Repetitive)
Record Length 16 Mpts/Ch (all channels), 32 Mpts (interleaved)
Capture Time Up to 3.2 ms at full sample rate on all four channels
Acquisition Modes Real Time, Roll, RIS (Random Interleaved Sampling), WaveStream (Fast Viewing Mode), Sequence (Segmented Memory
Time Base Range 200 ps/div–1000 s/div (roll mode from 500 ms/div–1000 s/div)
Time Base Accuracy
up to 5,000 segments with 1μ
≤ 5 ppm @ 25 °C (typical) (≤ 10 ppm @ 5–40 °C)
s intersegment time)
Digital Channels
– Vertical
Input Channels 18 (D0–D17) 18 (D0–D17) 18 (D0–D17)
Input Impedance 100 kΩ || 5.0 pF 100 kΩ || 5.0 pF 100 kΩ || 5.0 pF
Maximum Input Voltage ±30 V non-destruct ±30 V non-destruct ±30 V non-destruct
Threshold Groupings D0–D8, D9–D17 D0–D8, D9–D17 D0–D8, D9–D17
Threshold Selections TTL, ECL, CMOS, TTL, ECL, CMOS, TTL, ECL, CMOS,
PECL, LVDS, PECL, LVDS, PECL, LVDS,
User Defined User Defined User Defined
Digital Channels
– Acquisition
Sample Rate 1 GS/s 1 GS/s 1 GS/s
Record Length 10 Mpts/Ch 10 Mpts/Ch 10 Mpts/Ch
Minimum Detectable 2 ns 2 ns 2 ns
Pulse Width
Maximum Input 250 MHz 250 MHz 250 MHz
Frequency
10
SPECIFICATIONS
WaveSurfer WaveSurfer WaveSurfer WaveSurfer WaveSurfer WaveSurfer
24MXs-B 44MXs-B 42MXs-B 64MXs-B 62MXs-B 104MXs-B
Trigger System MSO 44MXs-B MSO 64MXs-B MSO 104MXs-B
Trigger Modes Normal, Auto, Single, and Stop
Trigger Sources Any input channel, External, Ext/10, or line; slope and level unique to each source (except for line trigger)
Trigger Coupling DC, AC, HFRej, LFRej
Pre-trigger Delay 0–100% of full scale
Post-trigger Delay 0–10,000 divisions
Trigger Hold-off 1 ns to 20 s or 1 to 1,000,000,000 events
Internal Trigger ±4.1 div from center
Level Range
External Trigger Range EXT/10 ±4V; EXT ±400 mV
Trigger Types Edge, Glitch, Width, Logic (Pattern), TV (NTSC, PAL, SECAM, HDTV–720p, 1080i, 1080p), Runt, Slew Rate, Interval
(signal or Pattern), Dropout, Qualified (State or Edge)
Probes
Standard Probes One PP009 (5 mm) per channel One PP011 (5 mm)
per channel
Probing System BNC and LeCroy ProBus for Active voltage, current and differential probes
Measure, Zoom, and Math Tools
Measurement Up to 6 of the following parameters can be calculated at one time on any waveform: Amplitude, Area, Base (Low), Delay,
Parameters Duty, Fall Time (90%–10%), Fall Time (80%–20%), Frequency, Maximum, Mean, Minimum, Overshoot+, Overshoot-,
Zooming Use front panel QuickZoom button, or use touch screen or mouse to draw a box around the zoom area.
Math Functions Functions include Sum, Difference, Product, Ratio, Absolute Value, Averaging (summed and continuous), Derivative,
Period, Peak-Peak, Phase, Rise Time (10%–90%), Rise Time (20%–80%), RMS, Skew, Standard Deviation, Top (High),
Width+, Width-. Measurements can be gated.
Envelope, Enhanced Resolution (to 11-bits), Floor, Integral, Invert, Reciprocal, Rescale (change scale and units), Roof,
Square, Square Root and FFT (up to 1 Mpts with power spectrum output and rectangular, VonHann, and FlatTop
windows). 1 math function may be defined at a time, 2 functions may be chained together.
Display System
Display Type Color, 10.4” TFT-LCD Touch Screen
Display Resolution SVGA: 800 x 600 pixels
Connectivity
Ethernet Port 10/100/1000Base-T Ethernet interface (RJ-45 connector)
USB Ports (5) USB Ports
GPIB Port (Optional) Supports IEEE – 488.2
External Monitor Port Standard 15-pin D-Type SVGA-compatible DB-15 connector
Remote Control Via Windows Automation, or via LeCroy Remote Command Set
Network Communication VXI-11 or VICP, LXI Class C Compliant
Standard
Physical
Dimensions (HWD) 260 mm x 340 mm x 152 mm Excluding accessories and projections (10.25” x 13.4” x 6”)
Net Weight 7.26 kg. (16.0 lbs.)
11
ORDERING INFORMATION
Product Description Product Code
WaveSurfer MXs-B Oscilloscopes
200 MHz, 2.5 GS/s, 4 Ch, 16 Mpts/Ch DSO WaveSurfer 24MXs-B
with 10.4” Color Touch Screen Display.
32 Mpts Interleaved
400 MHz, 5 GS/s, 2 Ch, 16 Mpts/Ch DSO WaveSurfer 42MXs-B
with 10.4” Color Touch Screen Display.
32 Mpts Interleaved
400 MHz, 5 GS/s, 4 Ch, 16 Mpts/Ch DSO WaveSurfer 44MXs-B
with 10.4” Color Touch Screen Display.
32 Mpts Interleaved
600 MHz,5 GS/s, 2 Ch, 16 Mpts/Ch DSO WaveSurfer 62MXs-B
with 10.4” Color Touch Screen Display.
10 GS/s, 32 Mpts Interleaved
600 MHz,5 GS/s, 4 Ch, 16 Mpts/Ch DSO WaveSurfer 64MXs-B
with 10.4” Color Touch Screen Display.
10 GS/s, 32 Mpts Interleaved
1 GHz, 5 GS/s, 4 Ch, 16 Mpts/Ch DSO WaveSurfer 104MXs-B
with 10.4” Color Touch Screen Display.
10 GS/s, 32 Mpts Interleaved
Product Description Product Code
Serial Data Options
I2C, SPI and UART Trigger and Decode Option WSXs-EMB
I2C Bus Trigger and Decode Option
UART and RS-232 Trigger and Decode Option WSXs-UART-RS232bus TD
CAN, LIN and FlexRay Trigger and Decode Option WSXs-AUTO
SPI Bus Trigger and Decode Option WSXs-SPIbus TD
LIN Trigger and Decode Option WSXs-LINbus TD
CAN TD Trigger and Decode Option
FlexRay Trigger and Decode
MIL-STD-1553 Trigger and Decode Option WSXs-1553 TD
ARINC 429 Symbolic Decode Option WSXs-ARINC429bus DSymbolic
USB 2.0 Decode Option
USB2-HSIC Decode Option WSXs-USB2-HSICbus D
D-PHY Decode Option
DigRF 3G Decode Option WSXs-DigRF3Gbus D
DigRF v4 Decode Option WSXs-DigRFv4bus D
Audiobus Trigger and Decode Option WSXs-Audiobus TD
for I2S, LJ, RJ, and TDM
MSO MXs-B Mixed Signal Oscilloscopes
400 MHz, 5 GS/s, 4+18 Ch, 16 Mpts/Ch MSO with MSO 44MXs-B
10.4” Color Touch Screen Display. 32 Mpts Interleaved
600 MHz, 5 GS/s, 4+18 Ch, 16 Mpts/Ch MSO MSO 64MXs-B
with 10.4” Color Touch Screen Display.
10 GS/s, 32 Mpts Interleaved
1 GHz, 5 GS/s, 4+18 Ch, 16 Mpts/Ch MSO MSO 104MXs-B
with 10.4” Color Touch Screen Display.
10 GS/s, 32 Mpts Interleaved
Included with Standard Configuration
(WaveSurfer MXs-B and MSO MXs-B)
÷10, 500 MHz, 10 M Passive Probe (Total of 1 Per Channel),
Manual and Quick Reference Guide, Standard Ports: Ethernet, USB 2.0 (5),
SVGA Video Out, Audio In/Out, Protective Front Cover, Anti-virus Software
(Trial Version), Standard Commercial Calibration and Performance Certificate,
3-year Warranty
Getting Started
Included with MSO MXs-B
MS-250 Mixed Signal Oscilloscope Module,
LeCroy Bus and USB2.0 Cables (1.3 m),
Ground Leads (Qty. 5), Carrying Case,
ence Guide
18 Channel Digital Lead Set,
Ground Extenders (Qty. 20),
Operator’s Manual and Quick Refer-
Flexible
General Accessories
Keyboard Accessory WSXs-KYBD
Optical Mouse Accessory WSXs-MOUSE
External GPIB Accessory USB2-GPIB
Hard Carrying Case WSXs-HARDCASE
Soft Carrying Case WSXs-SOFTCASE
Rack Mount Accessory WSXs-RACK
Accessory Pouch WSXs-POUCH
Mounting Accessory
Clamp Mounting Stand WSXs-MS-CLAMP
Local Language Overlays
German Front Panel Overlay WSXs-A-FP-GERMAN
French Front Panel Overlay WSXs-A-FP-FRENCH
Italian Front Panel Overlay WSXs-A-FP-ITALIAN
Spanish Front Panel Overlay WSXs-A-FP-SPANISH
Japanese Front Panel Overlay WSXs-A-FP-JAPANESE
Korean Front Panel Overlay WSXs-A-FP-KOREAN
Chinese (Tr) Front Panel Overlay WSXs-A-FP-CHNES-TR
Chinese (Simp) Front Panel Overlay WSXs-A-FP-CHNES-SI
Russian Front Panel Overlay WSXs-A-FP-RUSSIAN
1-800-5-LeCroy
www.lecroy.com
© 2012 by LeCroy Corporation. All rights reserved. Specifications, prices, availability, and delivery subject to change
without notice. Product or brand names are trademarks or requested trademarks of their respective holders.
Local sales offices are located throughout the world.
Visit our website to find the most convenient location.
Mixed Signal Solutions
500 MHz, 18 Channels, 2 GS/s, 50 Mpts/ch Mixed
Signal Oscilloscope Option
250 MHz,36 Ch,1 GS/s,25 Mpts/ch (500MHz,18 Ch,2 GS/s, MS-500-36
50 Mpts/ch Interleaved) Mixed Signal Option
250 MHz, 18 Channels, 1 GS/s, 10 Mpts/ch Mixed Signal MS-250
Oscilloscope Option (included in all WaveRunner MSO models)
MSO MXs-B Accessories
Large Gripper Probe Set for 0.10 Inch (2.54 mm) PK400-1
Pin Pitch. Includes 10 Probes with Color-coded Leads
Medium Gripper Probe Set for 0.04 Inch (1.0 mm) PK400-2
Pin Pitch. Includes 10 Probes with Color-coded Leads
Small Gripper Probe Set for 0.008 Inch (0.2 mm) PK400-3
Pin Pitch. Includes 10 Probes with Color-coded Leads
18-pin 3M Interface Cable MSO-3M MSO-3M
(Mates with 3M Part Number 2520-6002)
36 Channel Mictor Connector MSO-Mictor
(Includes 1 MSO-MICTOR-SHROUD)
Probes and Amplifiers*
Set of 4 ZS1500, 1.5 GHz, 0.9 pF, 1 M ZS1500-QUADPAK
High Impedance Active Probe
Set of 4 ZS1000, 1 GHz, 0.9 pF, 1 M ZS1000-QUADPAK
High Impedance Active Probe
200 MHz, 3.5 pF, 1 M Active Differential Probe ZD200
500 MHz, 1.0 pF, 1 M Active Differential Probe ZD500
1 GHz, 1.0 pF, 1 M Active Differential Probe ZD1000
1.5 GHz, 1.0 pF, 1 M Active Differential Probe ZD1500
30 A; 100 MHz Current Probe – AC/DC; 30
30 A; 50 MHz Current Probe – AC/DC;
30 A; 50 MHz Current Probe – AC/DC;
150 A; 10 MHz Current Probe – AC/DC; 150 A
500 A; 2 MHz Current Probe – AC/DC; 500 A
1,400 V, 100 MHz High-Voltage Differential Probe ADP305
1,400 V, 20 MHz High-Voltage Differential Probe ADP300
1 Ch, 100 MHz Differential Amplifier DA1855A
with Precision Voltage Source
* A wide variety of other passive, active, and differential probes are also available.
Consult LeCroy for more information.
Customer Service
LeCroy oscilloscopes and probes are designed, built, and tested to ensure high
reliability. In the unlikely event you experience difficulties, our digital oscilloscopes
are fully warranted for three years, and our probes are warranted for one year.
This warranty includes: No charge for return shipping • Long-term 7-year support
• Upgrade to latest software at no charge
WSXs-CANbus TD
Option
WSXs-FlexRaybus TD
WSXs
WSXs
MS-500
A
; 50 A
rms
30
A
; 50 A
rms
30
A
; 50 A
rms
rms
; 700
rms
WSMXs-B-MSO-MXs-B-DS-26july12
; 500
peak
peak
A
peak
A
peak
Pulse
Pulse
peak
Pulse CP031
WSXs-
I2Cbus TD
-USB2bus D
-DPHYbus D
CP030
AP015
Pulse CP150
Pulse CP500
PDF
Loading...
