DATA SHEET > LD 200N > 20081103
LD 200N
LOAD DUMP GENERATOR
FOR TESTS ACCORDING TO ...
> Case New Holland ENS0310 > Chrysler PF 9326 > Cummins 14269 (982022-026) > DaimlerChrysler DC-10842 > DaimlerChrysler PF-10540 > EN 300329 > EN 300340 > EN 300342-1 > EN 301489-1 > EN 301489-17 > FAW Diesel ECU MY06.0 (Rev.7) > Fiat 9.90110 > Ford ES-XW7T-1A278-AB > Ford ES-XW7T-1A278-AC > Ford WDR 00.00EA > Freightliner 49-00085 > GMW 3097 > GMW 3097 (2001) > GMW 3097 (2004) > GMW 3100 > GMW 3100 (2001) > GOST 28751-90 > Honda 3982Z-SDA-0030 > Hyundai/Kia ES 96100-02 (2006) > ...
LD 200N - COMPACT HIGH-ENERGY LOAD DUMP GENERATOR
Load Dump pulses simulate the sudden disconnection (e.g. by corrosion) of the battery from the alternator while the alternator is generating current to load the battery. Such Load Dump pulses are high energy pulses with a high potential of destruction. The LD 200N simulates these high energy pulses having a duration time in the range of hundreds of milliseconds. The LD 200N generates the Load Dump pulses as per ISO 7637, SAE J1113, SAE J1455, JASO and many more manufacturer specification, e.g. Ford, Chrysler, Renault, PSA, NISSAN etc. By means of a built-in clipping circuit (optional) the LD 200N also generates clipped load dump pulses as per international standards as well as manufacturer requirements.
HIGHLIGHTS
> LOAD DUMP GENERATOR ACCORDING TO ISO
APPLICATION AREAS
AUTOMOTIVE
7637, SAE J1113, SAE J1455, JASO, NISSAN AND MOST CAR MANUFACTURER REQUIREMENTS
TELECOM
> GENERATES CLIPPED LOAD DUMP PULSES
(OPTIONAL BUILT-IN MODULE)
> BUILT-IN 0.5 - 38 OHM SOURCE IMPEDANCE,
SELECTABLE IN 0.1 OHM STEPS
www.emtest.com © EM TEST > PAGE 1/5
DATA SHEET > LD 200N > 20081103
TECHNICAL DETAILS
LOAD DUMP GENERATOR
PULSE SPECIFICATION
Voltage (o.c.) 20V - 200V ± 10%
ISO PULSE 5 AND 7
Rise time 5ms - 10ms (10 - 90%) Pulse duration 40 - 400ms (10 - 10%) Int. resistor 0.5ohm - 38ohm, selectable in steps
of 0.1ohm
Repetition rate Min. 30s
SAE J1455 FOR 12V BATTERY SUPPLY
Voltage (o.c.) +86V ± 10% Rise time 100us (10% - 90%) Pulse duration 400ms ± 10% (10 - 10%) Int. resistor 0.4ohm
JASO PULSE D1
Voltage (o.c.) +110V ± 10% Rise time 1us (10% - 90%) Pulse duration 400ms (measured at tau) Int. resistor 1.5ohm Capacitor 73mF
CHRYSLER PF 9326 PULSE 5
Voltage (o.c.) +91.5V ± 10% Rise time 5 - 10ms (10% - 90%) Pulse duration 300ms td (10 - 10%) Loaded pulse +45.75V ± 10% into a 0.5ohm load Pulse duration > 95ms (10 - 10%) Int. resistor 0.5ohm Repetition rate 120s
FORD ES-XW7T CI 240 (AB-VERSION)
Voltage (o.c.) +60V ± 10%
SAE J1455 FOR 24V BATTERY SUPPLY
Voltage (o.c.) +122V ± 10% Rise time 100us Pulse duration 400ms ± 10% (10 - 10%) Int. resistor 0.8ohm
JASO PULSE A1
Voltage (o.c.) +70V ± 10% Rise time 1us (10% - 90%) Pulse duration 200ms ± 10% (measured at tau) Int. resistor 0.8ohm Capacitor 110mF
JASO PULSE B1 (FIELD DECAY)
Voltage (o.c.) -80V ± 10% Rise time 1us (10% - 90%) Pulse duration 60ms (measured at tau) Int. resistor 8ohm
Rise time 1 - 10ms (10% - 90%) Pulse duration 300ms (10% - 10%) Voltage (loaded) +30V ± 10% into a 0.7ohm load Pulse duration 150ms ± 10% (10 - 10%) Int. resistor 0.5ohm Repetition rate 3 pulses every 30s
FORD ES-XW7T CI 220G (AC-VERSION)
Voltage (o.c.) +60V ± 10% Rise time 1 - 10ms (10% - 90%) Pulse duration 300ms (10% - 10%) Voltage (loaded) +30V ± 10% into a 0.5ohm load Pulse duration 150ms ± 10% (10 - 10%) Int. resistor 0.5ohm Repetition rate 3 pulses every 30s
Capacitor 3mF
www.emtest.com © EM TEST > PAGE 2/5
DATA SHEET > LD 200N > 20081103
TECHNICAL DETAILS
MERCEDES BENZ MBN 10 284 PART 2
Voltage (o.c.) 100V ± 10% (Pulse 5a for 12V) Rise time < 0.1ms (10% - 90%) Pulse duration 400ms (10 - 10%) Int. resistor 2ohm Voltage (o.c.) 200V ± 10% (Pulse 5a for 24V) Rise time < 0.1ms (10% - 90%) Pulse duration 500ms (10 - 10%) Int. resistor 2ohm Voltage (o.c.) 100V ± 10% (Pulse 5a for 42V) Rise time < 0.1ms (10% - 90%) Pulse duration 400ms (10 - 10%) Int. resistor 2ohm Repetition rate 120s
SCANIA TB1400
Voltage (o.c.) +90V ± 10% for trucks Rise time 1 - 10ms (10% - 90%) Pulse duration 300ms (10 - 10%) Voltage (o.c.) +125V ± 10% for buses Rise time 1 - 10ms (10% - 90%) Pulse duration 480ms (10 - 10%) Int. resistor 1.5ohm
NISSAN PULSE A2
Voltage (o.c.) +60V ± 10% Rise time 1ms ± 50% (10% - 90%) Int. resistor R1 11ohm Int. resistor R2 0.8ohm Capacitor 1mF
NISSAN PULSE B1
Voltage (o.c.) +80V ± 10% Rise time 1ms ± 50% (10% - 90%) Int. resistor R1 20ohm Int. resistor R2 20ohm Capacitor 1mF
TEST ROUTINES
ISO 7637-2 Load Dump & Field Decay PF-9326 Pulse 5a and 5b Ford ES-XW7T AB & AC version MBN 10284 Pulse 5a, 5b and 5c SCANIA Pulse 5 & 5b (TB1400 and TB1700) JASO Pulse A1, B1, D1 NISSAN Pulse A1, A2, B1 Service Service, setup, self test
SCANIA TB1700
Voltage (o.c.) +125V ± 10% Rise time 1 - 10ms (10% - 90%) Pulse duration 480ms (10 - 10%) Int. resistor 1.5ohm
NISSAN PULSE A1
Voltage (o.c.) +60V ± 10% Rise time 1ms ± 50% (10% - 90%) Int. resistor R1 18ohm Int. resistor R2 0.66ohm Capacitor 15mF
www.emtest.com © EM TEST > PAGE 3/5
DATA SHEET > LD 200N > 20081103
TECHNICAL DETAILS
FREESTYLE MODE LOAD DUMP
PULSE PROGRAMMING MODE
Rise time <1us
10us - 90us with 10us steps 100us - 900us with 100us steps
1ms - 10ms with 1ms steps Pulse duration 10ms - 1,200ms Int. resistor 0.5ohm - 38ohm, in steps of 0.1ohm
MODULE CLIPPED LOAD DUMP
TEST ROUTINES (REQUIRES OPTIONAL CLD MODULE)
Standard Test routines
ISO 7637-2 Pulse 5b for 12V and 24V ISO/WD 16750 Pulse 5b SAE J1113-11 Pulse 5b
pre-programmed and controlled via
iso.control
GENERAL DATA
DIMENSIONS AND WEIGHT
Dimensions 19"/6HU, 500mm x 450mm x
290mm Weight approx. 25kg Supply voltage 115V/230V +10%/-15% Fuses 2x T2AT (230V) or 2x T4AT (115V)
OUTPUT
+/- output Safety laboratory connectors Coupling To the battery +line Decoupling Via diode DUT supply Max. 60V/30A
INTERFACE
Serial interface USB Parallel interface IEEE 488, addresses 1 - 30 CN interface To control external CN - UCS 200N
FIAT 9.90110 Pulse 5a PSA B21 7110 Pulse 5b for 12V Volvo Pulse 5a and 5c GS 95003-2 Pulse 5b Porsche EMV Pulse 5 GMW 3097 Pulse 5b
36.00.808/--H Pulse 5b TSC 7034G Pulse 5b Iveco Pulse 5b Scania TB1400 Pulse 5b Scania TB1700 Pulse 5b ES 96100-02 Pulse 5b
PULSE PROGRAMMING MODE (REQUIRES OPTIONAL CLD MODULE)
Clipped Voltage 15V - 95.5V, in steps of 0.5V Rise time 100us - 10ms Pulse duration 10ms - 1,200ms
OPTIONS
iso.control Software to control the test,
including standard library, test
report facility and data conversion
generator
Int. resistor 0.5ohm - 38ohm, in steps of 0.1ohm
www.emtest.com © EM TEST > PAGE 4/5
