KLN Series Programmable Power Supply:
KEPCO SERIES KLN - High Power, Low Prole, Many Models
The Kepco Series KLN is a new family of automatic crossover, low-profile, high-performance, low-cost programmable power supplies. The KLN Series offers stable d-c power in a 1U high, half-rack package for 750W, a 1U high, full-rack package for 1500W and a 2U high, full-rack package for 3000W. A total of 39 voltage-current combinations are offered. Output voltages range from 0-6 Volts to 0-600 Volts and output currents range from 0-400 Amps down to 0-1.25 Amps. Speed-controlled fans limit acoustic noise for bench-top applications when full power is not needed.
Precise programming of voltage, current and their limits may be achieved from the front panel, or by analog means or by RS 485 digital control. GPIB or LAN interfaces are factory­installed options.
For more information visit
www.kepcopower.com/kln.htm
MARKETS AND APPLICATIONS
• Aerospace and Satellite Test
• Telecom and IT Industry
• Automated Test Equipment
• Factory Automation
• QC Testing
• Burn-in
• Solar
• Water Purification
• Thermal Process Control
• Chemical Processing
• Semiconductor Manufacturing
• Battery Charging and Testing
• Electroplating, Sputtering and Coating
• New Energy R&D
KEPCO, INC. • 131-38 Sanford Avenue • Flushing, NY 11355 USA • Tel: (718) 461-7000 • Fax: (718) 767-1102
2
Email: hq@kepcopower.com • www.kepcopower.com
750 WATTS
750 WATTS
If you are looking for a high resolution (16 bit D/A for setting of voltage and current, 24 bit A/D for measurement), stable, quiet (speed-controlled fan) d-c power supply for your rack or bench,
choose the 750W Series KLN.
Front View
1U High
KLN 750 WATT MODEL TABLE
MODEL
(8) (9) (10)
KLN 6-100
KLN 8-90
KLN 12.5-60
KLN 20-38
KLN 30-25
KLN 40-19
KLN 50-15
KLN 60-12.5
KLN 80-9.5
KLN 100-7.5
D-C OUTPUT RANGE
(1)
CV
0-6
0-100
0-8
0-12.5
0-20
0-30
0-40
0-50
0-60
0-12.5
0-80
0-100
(2)
CC
A d-cV d-c
0-90
0-60
0-38
0-25
0-19
0-15
0-9.5
0-7.5
mV rms
10
10
10
10
10
10
10
10
10
10
CV
RIPPLE
(3)
CC
mA rms
180
180
120
76
63
48
43
38
29
23
(4)
LINE REGULATION
CV CC
0.05% +mV
2.8
2.8
4
4
5
6
8
8
10
12
(5) (11)
+mA
11
11
8.5
5.8
4.5
3.9
3.6
3.25
2.95
2.75
Rear View
LOAD REGULATION
(6)
CV
0.05% +mV
CC
2.8
2.8
4
4
12.6
5
6
8
8
10
12
0.1% +mA
23
23
18
10
8.8
8.2
7.5
6.9
6.5
FULL
LOAD
DOWN
0.05
0.05
0.05
0.05
0.08
0.08
0.08
0.08
0.15
0.15
(7)
NO
LOAD
DOWN
0.6
0.6
0.8
0.8
0.9
1
1.1
1.1
1.2
1.5
REMOTE
SENSE
VOLTAGE
DROP (max)
1
1
1
1
1.5
2
2
3
4
5
(11)
(6)
RESPONSE TIME
FULL
LOAD
UP
Sec Sec Sec V0.1%
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.15
0.15
KLN 150-5
KLN 300-2.5
KLN 600-1.25
(1) Actual output voltage is ≤0.1% of rated voltage when output voltage is set to zero. (2) Actual output current is ≤0.2% of the rated current when output current is set to zero (resistive load). (3) Measured when output is within 10%-100% of rated value; ripple bandwidth: 300kHz (rms), noise bandwidth: <20MHz (p-p). (4) For 6V model: measured when output voltage 2-6V and rated current; all other models measured when output 10-100% of rated voltage and rated current. (5) Input voltage 100~240V a-c 50/60Hz, constant load. (6) Constant input voltage and output from no load to full load. (7) With rated input, resistive load output voltage changes from 10% to 90% or from 90% to 10%. (8) Rated power output with input 115V or 230V a-c (9) Specifications met after 30 minutes of operation, ambient temperature 23±5°C, humidity under 80% R. H,
a-c input voltage nominal ±5% of nominal, THD is 2%, not using the remote compensation, not operating in series or parallel. (10) Add G suffix for models with optional GPIB interface, add E suffix for optional LAN interface. (11) For example, the spec for KLN 6-100 line regulation and load regulation in CV mode is 0.05% + 2.8mV (or 6 x 0.0005 = +3mV +2.8mV = 5.8mV).
0-150
0-300
0-600
0-5
0-2.5
0-1.25
16
25
75
18
13
8
17
32
62
2.5
2.25
2.13
17
32
62
6
5.5
5.26
0.15
0.15
0.25
0.15
0.15
0.3
2
3
4
5
5
5
KEPCO, INC. • 131-38 Sanford Avenue • Flushing, NY 11355 USA • Tel: (718) 461-7000 • Fax: (718) 767-1102
Email: hq@kepcopower.com • www.kepcopower.com
3
1500 WATTS
1500 WATTS
If you are looking for a full rack, 1U, 1500 Watt d-c power supply which runs cool in your rack (with no air gap required between units) or on your bench,
choose the 1500W Series KLN.
Front View
1U High
Close up of the bus bars with the protective cover
Rear View
KLN 1500 WATT MODEL TABLE
MODEL
(8) (9) (10)
KLN 6-200
KLN 8-180
KLN 12.5-120
KLN 20-76
KLN 30-50
KLN 40-38
KLN 50-30
KLN 60-25
KLN 80-19
KLN 100-15
KLN 150-10
KLN 300-5
D-C OUTPUT RANGE
(1)
CV
0-6
0-8
0-12.5
0-200
0-180
0-120
0-20
0-30
0-40
0-50
0-60
0-80
0-100
0-150
0-300
CC
A d-cV d-c
0-76
0-50
0-38
0-30
0-25
0-19
0-15
0-10
0-5
(2)
mV
rms
15
15
15
15
15
15
15
15
15
15
24
38
CV
RIPPLE
(3)
CC
mA
rms
360
360
248
152
125
95
85
75
57
45
45
25
(4)
LINE REGULATION
CV CC
0.05% +mV
2.8
2.8
3.4
4
5
6
7
8
10
12
12
32
(5) (11)
+mA
18.5
18.5
14.5
9.6
7
5.8
5.2
4.5
3.9
3.5
3.5
2.5
LOAD REGULATION
(6)
CV
0.05% +mV
CC
2.8
2.8
4
4
20.2
5
6
7
12.6
11.4
8
10
12
12
32
0.1% +mA
38
38
28
15
10
8.8
8
8
6
FULL
LOAD
DOWN
0.05
0.05
0.05
0.05
0.08
0.08
0.08
0.08
0.15
0.15
0.15
0.15
(7)
NO
LOAD
DOWN
0.6
0.6
0.8
0.8
0.9
1
1.1
1.1
1.2
1.5
2
3
REMOTE
SENSE
VOLTAGE
DROP (max)
1
1
1
1
1.5
2
2
3
4
5
5
5
(11)
(6)
RESPONSE TIME
FULL
LOAD
UP
Sec Sec Sec V0.1%
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.15
0.15
0.15
0.15
KLN 600-2.5
See footnotes on 750 Watt Model Table, page 3.
0-600
0-2.5
113
15
62
2.26
62
5.5
0.25
0.3
4
5
KEPCO, INC. • 131-38 Sanford Avenue • Flushing, NY 11355 USA • Tel: (718) 461-7000 • Fax: (718) 767-1102
4
Email: hq@kepcopower.com • www.kepcopower.com
3000 WATTS
3000 WATTS
If you are looking for a 3000 Watt programmable d-c power supply that operates on single phase input with active PFC meeting EN 61000-3-2:2006 Class A standards,
choose the 3000W Series KLN.
Front View
2U High
Rear View
KLN 3000 WATT MODEL TABLE
MODEL
(8) (9) (10)
KLN 6-400
KLN 8-360
KLN 12.5-240
KLN 20-150
KLN 30-100
KLN 40-76
KLN 50-60
KLN 60-50
KLN 80-38
KLN 100-30
KLN 150-20
KLN 300-10
D-C OUTPUT RANGE
(1)
CV
0-6
0-8
0-12.5
0-20
0-30
0-40
0-50
0-60
0-80
0-100
0-150
0-300
CC
0-400
0-360
0-240
0-150
0-100
0-76
0-60
0-50
0-38
0-30
0-20
0-10
(2)
A d-cV d-c
RIPPLE
CV CC
mV rms
23
23
23
23
23
23
23
23
23
23
36
57
(3)
mA
rms
1000
1000
800
600
310
250
200
150
110
90
90
50
(4)
LINE REGULATION
CV
0.05% +mV
2.8
2.8
3.2
4
5
6
7
8
10
12
17
32
(5) (11)
CC
+mA
42
42
29
18.5
13
10.5
9
7.5
6.2
5.3
4.2
3.1
LOAD REGULATION
(6)
CV
0.05% +mV
CC
6.2
6.2
7.1
8
9.5
11
13
14
17
20
13.4
11.6
27.5
50
0.1% +mA
85
85
60
38
27
22
19
16
9.4
7.2
(11)
(6)
RESPONSE TIME
FULL
LOAD
UP
Sec Sec Sec V0.1%
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.08
0.15
0.15
0.15
0.15
FULL
LOAD
DOWN
0.02
0.02
0.1
0.1
0.16
0.16
0.16
0.16
0.3
0.3
0.3
0.3
(7)
NO
LOAD
DOWN
0.5
0.5
0.8
0.8
0.9
1
1.1
1.1
1.2
1.5
2
3.5
REMOTE
SENSE
VOLTAGE
DROP (max)
1
1
1
1
1.5
2
2
3
4
5
5
5
KLN 600-5
(5) Input voltage: 190-240V a-c. 50/60Hz, constant load.
For others, see footnotes on 750 Watt Model Table, page 3.
0-600
0-5
170
KEPCO, INC. • 131-38 Sanford Avenue • Flushing, NY 11355 USA • Tel: (718) 461-7000 • Fax: (718) 767-1102
Email: hq@kepcopower.com • www.kepcopower.com
30
62
2.55
95
6.1
0.25
0.5
4
5
5
KLN INPUT SPECIFICATIONS
SPECIFICATION RATING/DESCRIPTION
Input Voltage 750 & 1500 Watt 100-240Vac, 50/60Hz
3000 Watt 190-240Vac, 50/60Hz
Input Current (Full load) 750 Watt 8.1A@115V a-c; 4.1A@230V a-c
1500 Watt 16.2A@115V a-c; 8.1A@230V a-c
3000 Watt 15.6A@230V a-c
Inrush Current 750 Watt 12.5A@230V a-c
1500 Watt 25A@230V a-c
3000 Watt 50A@230V a-c
Power Factor (PF) 750 & 1500 Watt 0.99 (at 115V a-c, rated output) Typical
Efficiency 750 Watt 76% - 87%
Isolation Voltage Input-Outputs 2000V a-c: 1 minute
3000 Watt 0.99 (at 230V a-c, rated output)
1500 Watt 77% - 88%
3000 Watt 82% - 88%
Input-Ground 2000V a-c: 1 minute
Output-Ground 350V d-c, leakage current: 100µA
(6V-150V)
Output-Ground 1200V d-c, leakage current: 100µA
(300V-600V)
Parallel connection of two identical KLN power supplies
(up to five possible) using optional Parallel Socket Board 536-0129
and Programming Port Cable 518-0119
KLN OUTPUT SPECIFICATIONS
SPECIFICATION RATING/DESCRIPTION
Type of Stabilizer Constant Voltage (CV)/Constant
Adjustment Range Voltage 0 to 100% of rated voltage
Current 0 to 100% of rated current
Protective Functions Programmable overvoltage (OVP)
Protection Setting Overvoltage 0% to 110% of rated voltage Range
Remote Error Sense Compensation 5V max. (See Applicable Model Table)
Parallel Operation Up to 5 units maximum,
Series Operation 2 units maximum
Temperature, Constant Voltage Mode 100ppm/°C of rated output voltage Coefficient Constant Current Mode or current, after 30 minute warm-up
Time Drift Constant Voltage Mode 0.05% of rated output voltage
Constant Current Mode or current over 8 hrs interval following
Transient Constant Voltage Mode 20V and under: ≤1.5ms;
Overcurrent 0% to 110% of rated current
Current (CC), automatic crossover
Programmable overcurrent (OCP) Overtemperature (OTP) Fuse blown
automatic load sharing
(total voltage must not exceed 600V)
30 minutes warm-up. Constant line, load and temperature.
30V-100V: ≤1ms
150V-600V: ≤2ms
Series connection of two identical KLN power supplies
using optional Series Socket Board 536-0130
and Programming Port Cable 518-0119
KEPCO, INC. • 131-38 Sanford Avenue • Flushing, NY 11355 USA • Tel: (718) 461-7000 • Fax: (718) 767-1102
6
Email: hq@kepcopower.com • www.kepcopower.com
KLN PROGRAMMING CHARACTERISTICS - LOCAL
SPECIFICATION RATING/DESCRIPTION
Local Control Rotary encoder
Setting Resolution Voltage & Current 4 digits
Display Resolution Voltage & Current 4 digits
Setting Accuracy Voltage ±0.1% ± 3C
Current ±0.5% ± 3C
Display Reading Voltage ±0.2% ± 3C Accuracy
Current ±0.5% ± 3C
Overvoltage Protection Programmable, 0 to 110% of rated voltage
Overcurrent Protection Programmable, 0 to 110% of rated current
(1) C = 1 count of the last displayed digit.
(1)
at rated voltage
(1)
at rated current
(1)
at rated voltage
(1)
at rated current
Analog Interface RS 485 Interface
(Standard)
KLN PROGRAMMING CHARACTERISTICS - DIGITAL
SPECIFICATION RATING/DESCRIPTION
Command Setting Resolution ±0.002% of full scale
Command Readback Resolution ±0.002% of full scale
(1)
Command and D/A Voltage ±0.1% ± 3C Setting Accuracy
Current ±0.5% ± 3C
Command and A/D Voltage ±0.2% ± 2C
at rated voltage
(1)
at rated current
(1)
at rated voltage
Measurement Accuracy (Average Measurement)
Current ±0.5% ± 3C
(1)
at rated current
(Average Measurement)
Command Response Time ≤20ms (After received)
(2)
RS-485 Digital Interface Default baud rate: 115.2K (Standard) Baud rates: 4.8K, 9.6K, 19.2K, 38.4K, 57.6K,
115.2K user selectable Max number of units connected to bus: 254 Max. effective control distance: 1000 meters
GPIB IEEE 488.2 Digital Interface Optional (G suffix)
LAN Digital Interface Optional (E suffix)
(1) C = 1 count of the last displayed digit. (2) Programming time = Command response time + Output response time. The output response time differs
for different models, from 30mS ~ 200mS.
KLN PROGRAMMING CHARACTERISTICS - ANALOG
LAN Interface
(Optional) Added
GPIB (IEEE 488) Interface
(Optional) Added
SPECIFICATION RATING/DESCRIPTION
Analog Setting Accuracy Constant Voltage Voltage ± 5%
Mode (CV)
Current ± 5%
Analog Setting Accuracy Constant Current Voltage ± 5%
Mode (CC)
Current ± 5%
Analog Monitor Rated voltage output 10.00V ± 0.25V Accuracy
Zero voltage output 0.00V ± 0.25V
Rated current output 10.00V ± 0.25V
Zero current output 0.00V ± 0.25V
KEPCO, INC. • 131-38 Sanford Avenue • Flushing, NY 11355 USA • Tel: (718) 461-7000 • Fax: (718) 767-1102
Email: hq@kepcopower.com • www.kepcopower.com
7
KLN PHYSICAL SPECIFICATIONS
SPECIFICATION RATING/DESCRIPTION
Weight 750 Watt 11.2 lbs (5.1 Kg)
1500 Watt 20.3 lbs (9.2 Kg)
3000 Watt 33.2 lbs (15.1 Kg)
Dimensions 750 Watt 8.46" x 1.73" x 18.5" W x H x D (215mm x 44mm x 470mm)
1500 Watt 16.93" x 1.73" x 18.5"
3000 Watt 16.93" x 3.46" x 18.5"
Source Power 750 Watt IEC 320 inlet Connector
Load 6V to 100V models ± bus bars with protective cover Connections
Programming Control port 26-pin connector
SER IN port 2-position Euroblock
Sense port 3-position Euroblock
RS-485 port 3-position Euroblock
LAN port (optional) RJ 45 connector
GPIB port (optional) Standard IEEE 488.2
1500 & 3000 Watt 3-position terminal block
150V to 600V models (750W) 5-position Euroblock
150V to 600V models (1500W & 3000W)
(430mm x 44mm x 470mm)
(430mm x 88mm x 470mm)
4-position terminal block
(mating connector supplied)
(mating connector supplied)
(mating connector supplied)
(mating connector supplied)
GPIB connector
KLN GENERAL (ENVIRONMENTAL) SPECIFICATIONS
SPECIFICATION RATING/DESCRIPTION
Temperature Operating 0 to 50°C (indoor use)
Storage -20 to +70°C
Humidity Operating 30%~90% RH
Storage 10%~90% RH
Altitude 3000m max
Cooling Speed-Controlled Fan
Acoustic Noise <70 dB (A)
EMC Conducted Disturbance EN 55011:2007 + A2:2007 Emissions Class B (EN 61326-1)
EMC Electrostatic Discharge EN 61000-4-2:2009 Immunity (ESD) Class B (EN 61326-1)
NOTE: All specifications apply after power on for 30 minutes, ambient temperature: 23±5°C, Humidity: under 80% RH, AC Voltage: ±5%, Frequency: ±5%.
Radiated Disturbance EN 55011:2007 + A2:2007
Harmonic Distortion EN 61000-3-2:2006 Class A
Voltage Fluctuations EN 61000-3-3:2008
and Flicker Section 5
Radiated RF EN 61000-4-3:2006
Magnetic Field + A1:2008 + A2:2010
Electrical Fast EN 61000-4-4:2004
Transients and Bursts + A1:2010 Class B
Surge EN 61000-4-5:2006 Class B
Conducted Disturbance EN 61000-4-6:2009,
Induced by RF Fields Class A
Voltage Dips and EN 61000-4-11:2004,
Short Interruptions Class C
(no condensation)
(no condensation)
Class B
Class A
For more information visit www.kepcopower.com/kln.htm
Looking For More High Power
SERIES KLR
Kepco introduces Series KLR, offering 2400 Watts of stable, controllable d-c power in the industry standard 1U package. Five models from 20 Volts to 300 Volts are available with a conventional rectangular operating area. Input is 185-264V a-c, single phase. GPIB, RS232 and isolated analog programming are all standard, LXI Ethernet is a factory installed option replacing RS232.
www.kepcopower.com/klr.htm
Low Prole Power Supplies?
,
SERIES KLP
Using high-frequency switch-mode topology for high efficiency and small size, the KLP provides 1200 watts of well-regulated, controllable d-c power in a 1U (1.75 inch high) by 19 inch rack-mountable package. KLP replaces the need for multiple power supplies by expanding the operating region. The breakthrough of a hyperbolic power limit delivers a full 1200 Watts over an expanded operating range, not just the conventional rectangular operating area.
www.kepcopower.com/klp.htm
KEPCO, INC. • 131-38 Sanford Avenue • Flushing, NY 11355 USA • Tel: (718) 461-7000 • Fax: (718) 767-1102
8
Email: hq@kepcopower.com • www.kepcopower.com
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
