JD745A

CellAdvisor™ Base Station Analyzer

Spectrum Analyzer: 100 kHz to 4 GHz

Cable and Antenna Analyzer: 5 MHz to 4 GHz

Power Meter: 10 MHz to 4 GHz

Specication Conditions

Specications apply under these conditions:

• e instrument has been turned on for at least 15 minutes

• e instrument is operating within a valid calibration period

• Data with no tolerance are considered typical values

• Cable and antenna measurements apply aer calibration to the OSL standard

• Typical and nominal values are dened as:

– Typical: expected performance of the instrument operating under 20° to 30°C

aer being at this temperature for 15 minutes

– Nominal: a general, descriptive term or parameter

WEBSITE: www.jdsu.com/test

Spectrum Analyzer (standard)

JD745A CELLADVISOR BASE STATION ANALYZER

Frequency

Frequency range 100 kHz to 4 GHz

Internal 10 MHz Frequency Reference

Accuracy ±0.05 ppm + aging (0 to 50°C) Aging ±0.5 ppm/year

Frequency Span

Range 0 Hz (zero span)

10 Hz to 4 GHz

Resolution 1 Hz

Resolution Bandwidth (RBW)

–3 dB bandwidth 1 Hz to 3 MHz 1-3-10 sequence Accuracy ±10% (nominal)

Video Bandwidth (VBW)

–3 dB bandwidth 1 Hz to 3 MHz 1-3-10 sequence Accuracy ±10% (nominal)

Single Sideband (SSB) Phase Noise

Fc 1 GHz, RBW 10 kHz, VBW 1 kHz, RMS detector Carrier oset:

30 kHz 100 kHz 1 MHz

<–90 dBc/Hz (typical) <–95 dBc/Hz (typical) <–102 dBc/Hz (typical)

Measurement Range

DANL to +20 dBm Input attenuator range 0 to 50 dB, 5 dB steps

Maximum Input Level

Average continuous power +20 dBm DC voltage ±50 VDC

Displayed Average Noise Level (DANL)

1 Hz RBW, 1 Hz VBW, 50 Ω termination, 0 dB attenuation, RMS detector Preamplier O:

10 MHz to 2.3 GHz >2.3 GHz to 3 GHz >3 GHz to 4 GHz

Preamplier On: 10 MHz to 2.3 GHz >2.3 GHz to 3 GHz >3 GHz to 4 GHz

–140 dBm (–146 dBm, typical) –138 dBm (–144 dBm, typical) –135 dBm (–140 dBm, typical)

–155 dBm (–160 dBm, typical) –153 dBm (–158 dBm, typical) –150 dBm (–156 dBm, typical)

Display Range

Log scale and units (10 divisions displayed)

Linear scale and units (10 divisions displayed)

Detectors Normal, positive peak, sample,

Number of traces 6 Trace functions Clear/write, maximum hold,

1 to 20 dB/division in 1 dB steps dBm, dBV, dBmV, dBµV

V, mV, mW, W

negative peak, RMS

minimum hold, capture, load view on/o

Total Absolute Amplitude Accuracy

Preamplier o, power level >–50 dBm, auto-coupled (20 to 30°C) 5 MHz to 4 GHz ±1.25 dB, ±0.5 dB (typical)

±1.55 dB, ±1.0 dB (typical)

Attenuation <40 dB Attenuation ≥40 dB

Reference Level

Setting range –120 to +100 dBm Setting resolution

Log scale Linear scale

0.1 dB 1% of reference level

Markers

Marker types Normal, delta, delta pair, noise,

frequency count marker

Number of markers 6

Marker functions Peak, next peak, peak left,

peak right, minimum search marker to center/start/stop

RF Input VSWR

20 MHz to 4 GHz 1.5:1 (typical)

Second Harmonic Distortion

Mixer level = –25 dBm 10 MHz to 1.3 GHz <–65 dBc (typical) >1.3 GHz to 4 GHz <–70 dBc (typical)

Third-Order Inter-Modulation (third-order intercept: TOI)

200 MHz to 2 GHz +10 dBm (typical) >2 GHz to 4 GHz +12 dBm (typical)

JD745A CELLADVISOR BASE STATION ANALYZER

Spurious

Inherent residual response Input terminated, 0 dB attenuation, preamplier o, RBW at 10 kHz

20 MHz to 3 GHz –90 dBm (nominal) >3 GHz to 4 GHz –85 dBm (nominal) Exceptions <–80 dBm @ 311.94 MHz

<–84 dBm @ 415.92 MHz <–85 dBm @ 519.90, 1599.00, and 2497.80 MHz

Input related spurious <–70 dBc (nominal)

Dynamic Range

2/3 (TOI-DANL) in 1 Hz RBW >95 dB

Sweep Time

Range 80 ms to 1000 s

24 µs to 200 s

Sweep mode Continuous, single

Span = 0 Hz (zero span)

Gated Sweep

Trigger source External, video, and GPS Gate length 1 µs to 100 ms Gate delay 0 to 100 ms

Trigger

Trigger source Free run, video, external Trigger delay

Range Resolution

0 to 200 s 6 µs

Measurements*

Channel power Occupied bandwidth Spectrum emission mask Adjacent channel power Spurious emissions Field strength AM/FM audio demodulation Route map PIM detect Dual spectrum

* CW signal generator (Option 003) can be set up simultaneously.

Cable and Antenna Analyzer (standard)

Frequency

Range 5 MHz to 4 GHz Resolution 10 kHz Accuracy ±25 ppm

Data Points

126, 251, 501, 1001 Measurement speed 1.65 ms/point (nominal)

Measurement Accuracy

Corrected directivity 40 dB (typical) Reection uncertainty ±(0.3 + |20log (1+10

Output Power

High 0 dBm (typical) Low –30 dBm (typical)

Dynamic Range

Reection 60 dB

Maximum Input Level

Average continuous power +25 dBm (nominal) DC voltage ±50 VDC Interference immunity

On channel

On frequency

Measurements

Reection (VSWR) VSWR range Return loss range Resolution

Distance to Fault (DTF) Vertical VSWR range Vertical return loss range Vertical resolution Horizontal range

Horizontal resolution

Cable Loss (1-port) Range Resolution

1-port Phase Range Resolution

Smith Chart Resolution

EP = directivity – measured return loss

+17 dBm at >1.4 MHz from carrier frequency (nominal) 0 dBm within ±10 kHz from the carrier frequency (nominal)

1 to 65 0 to 60 dB

0.01

1 to 65 1 to 60 dB

0.01 0 to (# of data points – 1) x Horizontal Resolution Maximum = 1500 m (4921 ft)

(1.5x10

) x (VP)/(delta) x (0.95)

VP = propagation velocity

Delta = stop freq. – start freq. (Hz)

0 to 30 dB

0.01 dB

–180° to +180°

0.01°

0.01

-EP/20

)|) (typical)

JD745A CELLADVISOR BASE STATION ANALYZER

RF Power Meter (standard)

General Parameters

Display range –100 to +100 dBm Oset range 0 to 60 dB Resolution 0.01 dB or 0.1xW (x = m, u, p)

Internal RF Power Sensor

Frequency range 10 MHz to 4 GHz Span 100 kHz to 100 MHz Dynamic range –120 to +20 dBm Maximum power +20 dBm Accuracy Same as spectrum analyzer

External RF Power Sensors

Directional Power Sensor JD731B

Frequency range 300 MHz to 3.8 GHz Dynamic range 0.15 to 150 W (average)

4 to 400 W (peak) Connector type Type-N female on both ends Measurement type Forward/reverse average power,

forward peak power, VSWR Accuracy ±(4% of reading + 0.05 W)

Directional Power Sensor

Frequency range Dynamic range 0.1 to 50 W (average)

Connector type Type-N female on both ends Measurement type Forward/reverse average power,

Accuracy ±(4% of reading + 0.05 W)

Terminating Power Sensor JD732B

Frequency range 20 MHz to 3.8 GHz Dynamic range –30 to +20 dBm Connector type Type-N male Measurement type Average Accuracy ±7%

Terminating Power Sensor JD734B

Frequency range 20 MHz to 3.8 GHz

Dynamic range –30 to +20 dBm

Connector type Type-N male

Measurement type Peak

Accuracy ±7%

Terminating Power Sensor JD736B

Frequency range 20 MHz to 3.8 GHz

Dynamic range –30 to +20 dBm

Connector type Type-N male

Measurement type Average and Peak

Accuracy ±7%

JD733A

150 MHz to 3.5 GHz

0.1 to 50 W (peak)

forward peak power, VSWR

1,2

Optical Power Meter (Option 13)

Optical Power Meter

Display range –100 to +100 dBm Oset range 0 to 60 dB Resolution 0.01 dB or 0.1 mW

External Optical Power Sensors

Optical Power Sensor

Wavelength range Max permitted input level +10 dBm Connector input Universal 2.5 and 1.25 mm Accuracy ±5%

Optical Power Sensor

Wavelength range Max permitted input level +23 dBm Connector input Universal 2.5 and 1.25 mm Accuracy ±5%

MP-60

780 to 1650 nm

MP-80

780 to 1650 nm

2-Port Transmission Measurements (Option 001)

Frequency

Frequency range 5 MHz to 4 GHz Frequency resolution 10 kHz

Output Power

High 0 dBm (typical) Low –30 dBm (typical)

Measurement Speed

Vector 2.2 ms/point (nominal)

Dynamic Range

Vector 5 MHz to 3 GHz, 80 dB

>3 GHz to 4 GHz, 75 dB

Scalar 5 MHz to 4 GHz, >100 dB

Measurements

Insertion Loss/Gain Range Resolution

2-Port Phase Range Resolution

–120 to 100 dB

0.01 dB

–180° to +180°

0.01°

1. CW condition at 25°C ±10°C.

2. Forward power.

JD745A CELLADVISOR BASE STATION ANALYZER

Bias Tee (Option 002)

Voltage

Voltage range +12 to +32 V Voltage resolution 0.1 V

Power

8 W Max

CW Signal Generator (Option 003)

Frequency

Frequency range 25 MHz to 4 GHz Frequency reference ±25 ppm Maximum Frequency resolution 10 kHz

Output Power

Range 0 dBm, –30 to –80 dBm Step 1 dB Accuracy ±1.5 dB (15 to 35°C)

GPS Receiver and Antenna (Option 010)

GPS Indicator

Latitude, longitude, altitude

Interference Analyzer (Option 011)

Measurements

Spectrum analyzer Sound indicator, AM/FM audio demodulation,

interference ID, spectrum recorder Spectrogram Collect up to 72 hours of data RSSI Collect up to 72 hours of data Interference nder Spectrum replayer Dual spectrogram

Channel Scanner (Option 012)

Frequency Range

10 MHz to 4 GHz

Measurement Range

–110 to +20 dBm

Measurements

Channel scanner 1 to 20 channels Frequency scanner 1 to 20 frequencies Custom scanner 1 to 20 channels or frequencies

High-Frequency Accuracy

Spectrum, interference, and signal analyzer GPS lock ±25 ppb Hold over (for 3 days) ±50 ppb (0 to 50°C) 15 minutes after

satellite locked

Connector SMA, female

JD745A CELLADVISOR BASE STATION ANALYZER

GSM/GPRS/EDGE Signal Analyzer (Option 022)

General Parameters

Frequency range 450 MHz to 500 MHz

820 MHz to 965 MHz

1.705 GHz to 1.995 GHz Input signal range –40 to +20 dBm Burst power ±1.0 dB Frequency error ±10 Hz + reference-frequency accuracy 99% condence level GMSK modulation quality Phase RMS accuracy

Residual error Phase peak accuracy 8 PSK modulation quality

EVM accuracy Residual error RF power vs. time

±1.0 degrees

0.7 degrees (typical)

±2.0 degrees

±1.5%

2.5%

±0.25 symbol

(0 < Phase RMS < 8)

(0 < Phase peak < 30)

(2% < EVM < 8%)

Measurements

Option 022 Option 042

Channel Power Constellation Auto Measure Channel/Frequency Scanner

Channel power Burst power Channel power Channels or frequencies Spectral density Modulation type Occupied bandwidth Absolute power Peak to average power Frequency error Spectrum emission mask Group (trac, control) Occupied Bandwidth Phase error RMS Spurious emission mask BSIC (NCC, BCC) Occupied bandwidth Phase error peak Burst power Multipath Prole Integrated power I/Q origin oset* PvsT – mask (10 strongest) Occupied power TSC Frame average power Frame average power Spectrum Emission Mask BSIC Frequency error SNR, delay Reference power C/I* Phase error RMS Modulation Analyzer Peak level at dened range EVM RMS* Phase error peak Frame avg power trend Spurious Emissions EVM peak* EVM RMS* C/I trend Peak frequency at dened range EVM 95 Peak level at dened range I/Q origin oset BSIC, frame no. and time Power vs. Time (slot) C/I* C/I, frequency error Burst power Burst power Max/min point Modulation type

Power vs. Time (frame)

Frame average power Burst power (Slot 0 to 7) TSC (Slot 0 to 7)

* Measurements performed for 8PSK modulation signals (EDGE) only.

* EVM peak* Frame average power

Longitude, latitude, and satellite in all screens

JD745A CELLADVISOR BASE STATION ANALYZER

WCDMA/HSPA+ Signal Analyzer (Option 023)

General Parameters

Frequency range Band 1 to 14, 19 to 22, 25, 26 Input signal range –40 to +20 dBm RF channel power accuracy ±1.0 dB, ±0.7 dB (typical) Occupied bandwidth accuracy ±100 kHz Adjacent channel leakage ratio

(ACLR) WCDMA modulation QPSK HSPA+ modulations QPSK, 16 QAM, 64 QAM Frequency error ±10 Hz + reference-frequency accuracy 99% condence level EVM accuracy ±2.0% 2% ≤ EVM ≤ 20% Residual EVM 2.5% (typical) Code domain power ±0.5 dB relative power

CPICH power accuracy ±0.8 dB (typical)

Measurements

Channel Power Constellation Codogram Channel Scanner (up to 6)

Channel power CPICH power Code utilization Frequencies or channels Spectral density Rho, EVM RCSI Channel power, scramble Peak to average power Peak CDE CPICH, P-CCPCH, S-CCPCH, code, CPICH power, Ec/Io Occupied Bandwidth Frequency error PICH, P-SCH, S-SCH Scramble Scanner (up to 6) Occupied bandwidth Time oset CDP Table Channel power Integrated power Carrier feed-through Reference power CPICH dominance Occupied power Scramble code Code utilization Scramble code Spectrum Emission Mask Code Domain Power Code, spreading factor Ec/Io, CPICH power, delay Reference power Abs/Rel code power Allocation (channel type) Multipath Prole Peak level at dened range Individual code EVM EVM, modulation type Channel, multipath power ACLR and its constellation Relative, absolute power Ec/Io, delay Reference power Channel power Auto Measure Code Domain Power Abs power at dened range Power bar graph Channel power Abs/Rel code power Rel power at dened range (Abs/Rel/Delta power) Occupied bandwidth Individual code EVM Multi-ACLR CPICH, P-CCPCH, S-CCPCH Spectrum emission mask Channel power Lowest reference power PICH, P-SCH, S-SCH ACLR Scramble code Highest reference power Max, avg active power Multi-ACLR CPICH, P-CCPCH, S-CCPCH, Abs power at dened range Max, avg inactive power Spurious emission mask PICH, P-SCH, S-SCH Rel power at dened range Scramble code Frequency error Max, avg active power Spurious Emissions Relative Code Domain Error EVM Max, avg inactive power Peak frequency at dened range Abs/Rel code power Peak CDE Frequency error Peak level at dened range Code error Carrier feed-through Time oset, Rho

<–56 dB, ±0.7 dB at 5 MHz oset <–58 dB, ±0.8 dB at 10 MHz oset

Code channel power >–25 dB

±1.5 dB absolute power

Option 023 Option 043

Individual code EVM, RCDE CPICH absolute power Carrier feed-through and its constellation CPICH relative power (Composite) EVM Channel power Max inactive power CPICH EVM, P-CCPCH EVM Power bar graph Scramble code Amplier capacity (Abs/Rel/Delta power) Power Statistics CCDF Peak amplier capacity CPICH, P-CCPCH, S-CCPCH, PICH, Average amplier capacity P-SCH, S-SCH Code, peak utilization AVG RCDE QPSK, 16 QAM, 64 QAM Average utilization

Longitude, latitude, and satellite in all screens

Code channel power >–25 dB

Route Map

CPICH power, Ec/Io

JD745A CELLADVISOR BASE STATION ANALYZER

cdmaOne/cdma2000® Signal Analyzer (Option 020)

General Parameters

Frequency range Band 0 to 10 Input signal level –40 to +20 dBm RF channel power accuracy ±1.0 dB (typical) CDMA compatibility cdmaOne and cdma2000 Frequency error ±10 Hz + ref freq accuracy 99% condence level Rho accuracy ±0.005 0.9 < Rho < 1.0 Residual Rho >0.995 (typical) PN oset 1 x 64 chips Code domain power ±0.5 dB relative power

±1.5 dB absolute power Pilot power accuracy ±1.0 dB (typical) Time oset ±1.0 μs, ±0.5 μs (typical) External trigger

Measurements

Option 020 Option 040

Channel Power Constellation Auto Measure Channel Scanner (up to 6)

Channel power Pilot power Channel power Frequencies or channels Spectral density Rho Occupied bandwidth Channel power, PN oset Peak to average power EVM Spectrum emission mask Pilot power, Ec/Io Occupied Bandwidth Frequency error ACPR PN Scanner (up to 6) Occupied bandwidth Time oset Multi-ACPR Channel power Integrated power Carrier feed-through Rho Pilot dominance Occupied power PN oset Frequency error PN oset Spectrum Emission Mask Code Domain Power Time oset Ec/Io, pilot power, delay Reference power Abs/Rel code power Carrier feed-through Multipath Prole Peak level at dened range Channel power Pilot power Channel power ACPR Power bar graph (Abs/Rel) Max inactive power Multipath power Reference power Pilot, Paging, Sync, Q-Paging PN oset Ec/Io, delay Abs power at dened range Max, avg active power Power Statistics CCDF Code Domain Power Rel power at dened range Max, avg inactive power Abs/Rel code power Multi-ACPR PN oset Channel power Lowest reference power Codogram PN oset Highest reference power Code utilization Pilot, Paging, Sync, Q-Paging power Abs power at dened range RCSI Max, avg active power Rel power at dened range Pilot, paging, sync, q-paging Max, avg inactive power Spurious Emissions CDP Table Frequency error Peak freq at dened range Reference power Time oset, Rho, EVM Peak level at dened range Code utilization Carrier feed-through

Code, spreading factor Amplier capacity

Allocation (channel type) Peak amplier capacity

Relative, absolute power Average amplier capacity

Longitude, latitude, and satellite in all screens

Code channel power >–25 dB Code channel power >–25 dB

Code utilization Peak utilization Average utilization

Route Map

Pilot power Ec/Io

JD745A CELLADVISOR BASE STATION ANALYZER

EV-DO Signal Analyzer (Option 021)

General Parameters

Frequency range Band 0 to 10 Input signal level –40 to +20 dBm RF channel power accuracy ±1.0 dB (typical) EV-DO compatibility Rev 0, Rev A and Rev B Frequency error ±10 Hz + ref freq accuracy 99% condence level Rho accuracy ±0.005 0.9 < Rho < 1.0 Residual Rho >0.995 (typical) PN oset 1 x 64 chips Code domain power ±0.5 dB relative power

±1.5 dB absolute power Pilot power accuracy ±1.0 dB (typical) Time oset ±1.0 μs, ±0.5 μs (typical) External trigger

Measurements

Option 021 Option 041

Channel Power Constellation MAC Codogram Channel Scanner (up to 6)

Channel power (Composite 64/128) Code utilization Frequencies or channels Spectral density Channel power RCSI PN oset Peak to average power Rho, EVM, Peak CDE Slot, pilot, MAC, data Pilot, MAC, data power Occupied Bandwidth Frequency error MAC CDP Table PN Scanner (up to 6) Occupied bandwidth Time oset Reference power Channel power Integrated power Carrier feed-through Code utilization Pilot dominance Occupied power PN oset Code, spreading factor PN oset Spectrum Emission Mask Pilot, MAC, data power Allocation (channel type) Ec/Io, pilot power, delay Reference power Pilot, MAC, data EVM Relative, absolute power Multipath Prole Peak level at dened range Constellation Auto Measure Channel power ACPR (Pilot, MAC 64/128, and data) Channel power Multipath power Reference power Channel power Occupied bandwidth Ec/Io, delay Abs power at dened range Rho, EVM, peak CDE Spectrum emission mask Code Domain Power Rel power at dened range Frequency error ACPR Slot average power Multi-ACPR Time oset Multi-ACPR PN oset Lowest reference power Carrier feed-through Pilot, MAC, data power Pilot, MAC, data power Highest reference power PN oset On/o ratio Pilot, MAC, data Rho Abs power at dened range Modulation type* PvsT mask (idle slot) or (Composite) EVM Rel power at dened range Code Domain Power PvsT mask (active slot) Frequency error Spurious Emissions (Pilot and MAC 64/128) Frequency error Time oset Peak frequency at dened range Pilot/MAC channel power Time oset Carrier feed-through Peak level at dened range Slot average power Carrier feed-through Max active I/Q power

Power vs. Time Max active I/Q power Pilot, MAC, data Rho Avg active I/Q power (Idle and Active Slot) Avg active I/Q power Max inactive I/Q power Code utilization

Slot average power Max inactive I/Q power PN oset Peak utilization On/o ratio Avg inactive I/Q power Power Statistics CCDF Average utilization Idle activity PN oset Route Map Pilot, MAC, data power Code Domain Power (Data) Pilot power

Data channel power Ec/Io

Slot average power

Max, avg active power

Max, avg inactive power

PN oset

Longitude, latitude, and satellite in all screens

*Measurement is performed in Data Constellation only.

Code channel power >–25 dB Code channel power >–25 dB

JD745A CELLADVISOR BASE STATION ANALYZER

TD-SCDMA Signal Analyzer (Option 025)

General Parameters

Frequency range 1.785 GHz to 2.22 GHz Input signal level –40 to +20 dBm Channel power (RRC) accuracy ±1.0 dB (typical) Modulations QPSK, 8 PSK, 16 QAM, 64 QAM Frequency error ±10 Hz + ref freq accuracy 99% condence level Residual EVM (RMS) 2.0% (typical) P-CCPCH slot and 1 channel Time error (Tau) ±0.2 μs (typical) External trigger Spreading factor Auto (DL, UL), 1, 2, 4, 8, 16

Measurements

Option 025 Option 045

Channel Power Midamble power Code Error Sync-DL ID Scanner (32) Channel power (TS [0 to 6], DwPTS, UpPTS) Code power and error Scramble code group Spectral density Data power right Individual code EVM Ec/Io, Tau Peak to average power (TS [0 to 6], DwPTS, UpPTS) and its constellation DwPTS power Occupied Bandwidth Time oset Data format Pilot dominance Occupied bandwidth (TS [0 to 6], DwPTS, UpPTS) Slot, DwPTS power Sync-DL ID vs. Tau (up to 6) Integrated power Power vs. Time (mask) No. of active code ID, power, Ec/Io, Tau Occupied power Slot power Scramble code DwPTS power Spectrum Emission Mask On/o slot ratio Max active code power Pilot dominance Reference power O power Avg active code power Sync-DL ID Multipath Peak level at dened range Timogram Max inactive code power Ec/Io, Tau ACLR Constellation Avg inactive code power DwPTS power Reference power Rho Peak CDE and peak active CDE Pilot dominance Abs power at dened range EVM RMS, EVM peak Auto Measure Sync-DL ID Analyzer Rel power at dened range Peak CDE Channel power DwPTS power, Ec/Io trend Multi-ACLR Frequency error Occupied bandwidth DwPTS power Lowest reference power I/Q origin oset Spectrum emission mask Pilot dominance Highest reference power Time oset ACLR EVM, frequency error Abs power at dened range Midamble Power Multi-ACLR Ec/Io, CINR Rel power at dened range Slot power Slot power Route Map Spurious Emissions DwPTS power DwPTS power DwPTS Power Peak frequency at dened range Midamble power (1 to 16) UpPTS power Peak level at dened range Code Power On/o slot ratio Power vs. Time (slot) Abs/Rel code power Frequency error Slot power Individual code EVM EVM RMS DwPTS power and its constellation Peak CDE UpPTS power Data format Max inactive power On/o slot ratio Slot power, DwPTS power Scramble code Slot PAR No. of active code DwPTS code Scramble code Power vs. Time (frame) Max active code power Slot power Avg active code power (TS [0 to 6], DwPTS, UpPTS) Max inactive code power Data power left Avg inactive code power (TS [0 to 6], DwPTS, UpPTS)

Longitude, latitude, and satellite in all screens

JD745A CELLADVISOR BASE STATION ANALYZER

Mobile WiMAX Signal Analyzer (Option 026)

General Parameters

Frequency range 2.1 GHz to 2.7 GHz

Input signal level –40 to +20 dBm Channel power accuracy ±1.0 dB (typical) Supported bandwidth 7 MHz, 8.75 MHz, and 10 MHz Frequency error ±10 Hz + reference-frequency accuracy 99% condence level Residual EVM (RMS) 1.5% (typical)

Measurements

Channel Power Constellation Auto Measure Preamble Scanner (up to 6)

Channel power Channel power Channel power Total preamble power Spectral density RCE RMS, RCE peak Occupied bandwidth Preamble, relative power Peak to average power EVM RMS, EVM peak Spectrum emission mask Cell ID, sector ID Occupied Bandwidth Frequency error Spurious emission mask Time oset Occupied bandwidth Time oset Preamble power Multipath Prole Integrated power Segment ID, cell ID DL burst power Total preamble power Occupied power Preamble index UL burst power Multipath power Spectrum Emission Mask Spectral Flatness Frame average power Relative power, delay Reference power Average subcarrier power Time oset Preamble Power Trend Peak level at dened range Subcarrier power variation I/Q origin oset Preamble power trend Spurious Emissions Max, min, avg power Spectral atness Relative power trend Peak frequency at dened range EVM vs. Subcarrier Frequency error Preamble power Peak level at dened range RCE RMS, RCE peak RCE RMS Frame avg power Power vs. Time (frame) EVM RMS, EVM peak RCE peak Relative power Channel power Segment ID, cell ID EVM RMS C/I Frame average power Preamble index EVM peak Preamble Preamble power EVM vs. Symbol Power Statistics CCDF Cell ID, sector ID DL burst power RCE RMS, RCE peak Time oset UL burst power EVM RMS, EVM peak Route Map I/Q origin oset Segment ID, cell ID Preamble power Time oset Preamble index

3.4 GHz to 3.85 GHz

Option 026 Option 046

Longitude, latitude, and satellite in all screens

JD745A CELLADVISOR BASE STATION ANALYZER

LTE/LTE Advanced-FDD Signal Analyzer (Options 028/030)

General Parameters

Frequency range Band 1 to 14, 17 to 26 Input signal level –40 to +20 dBm Channel power accuracy ±1.0 dB (typical) Supported bandwidths 1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15 MHz, and 20 MHz Frequency error ±10 Hz + reference-frequency accuracy 99% condence level Residual EVM (RMS) 2.0% (typical) Data EVM

JD745A CELLADVISOR BASE STATION ANALYZER

Measurements

Options 028/030 Option 048

Channel power Control channel Data allocation map Channel Scanner (up to 6)

Channel power Control channel summary Data allocation vs frame Frequency or channels Spectral density (P-SS, S-SS, PBCH, PCFICH, PHICH, Resource block power Cell, group, sector ID Peak to average power PDCCH, RS, MBSFN*) OFDM symbol power Channel power Occupied bandwidth EVM, relative or absolute Data utilization RSRP/RSRQ Occupied bandwidth power, modulation type Data allocation vs subframe RS-SINR Integrated power Each control channels’ Resource block power Antenna port Occupied power I/Q diagram Data utilization ID scanner (up to 6) Spectrum emission mask Modulation format Auto measure RSRP/RSRQ dominance Reference power Frequency error Channel power S-SS RSSI dominance Peak level at dened range I/Q origin oset Occupied bandwidth S-SS Ec/Io dominance ACLR EVM RMS, EVM peak Spectrum emission mask Cell, group, sector ID Reference power Subframe ACLR RSRP/RSRQ Abs power at dened range MBSFN* Multi-ACLR RS-SINR/S-SS RSSI Rel power at dened range Subframe summary table Spurious emission mask P-SS/S-SS Power Multi-ACLR (P-SS, S-SS, PBCH, PCFICH, PHICH, Frame average power S-SS Ec/Io Lowest reference power PDCCH, RS, MBSFN*, PDSCH/Data* Time alignment error Multipath prole Highest reference power QPSK, PDSCH/Data* 16 QAM, Frequency error Cell, group, sector ID Abs power at dened range PDSCH/Data* 64 QAM) MBSFN* Ant 0 RS Ec/Io, delay Rel power at dened range EVM, relative or absolute power, PDSCH/Data* QPSK EVM Ant 1 RS Ec/Io, delay Spurious emissions modulation type PDSCH/Data* 16 QAM EVM Ant 2 RS Ec/Io**, delay** Peak frequency at dened range Subframe power PDSCH/Data* 64 QAM EVM Ant 3 RS Ec/Io**, delay** Peak level at dened range OFDM symbol power Data EVM RMS, peak Control channel Power vs. time (frame) Frequency, time error RS, P-SS, S-SS EVM RS power trend Frame average power Data EVM RMS, peak RS, P-SS, S-SS power Cell, group, sector ID Subframe power RS EVM RMS, peak PBCH power Control channel table First slot power Cell, group, sector ID Subframe power (P-SS, S-SS, PBCH, PCFICH, RS 0, RS 1, Second slot power Frame OFDM power RS 2**, RS 3**) Cell ID, I/Q origin oset MBSFN* Time error Absolute power Time oset Frame summary table I/Q origin oset Relative power Constellation (P-SS, S-SS, PBCH, PCFICH, PHICH, Carrier Aggregation** EVM RSM, phase MBSFN* PDCCH, RS, MBSFN*, PDSCH/Data* Component carriers: up to 5 Frequency error RS TX power QPSK, PDSCH/Data* 16 QAM, Subframe power Time alignment error PDSCH/Data* QPSK EVM PDSCH/Data* 64 QAM) P-SS, S-SS, PBCH, RS power and EVM Time oset PDSCH/Data* 16 QAM EVM EVM, relative or absolute power, PDSCH/Data* QPSK Power and EVM Datagram

PDSCH/Data* 64 QAM EVM modulation type PDSCH/Data* 16 QAM Power and Datagram Data EVM RMS Frame average power EVM Resource block power Data EVM peak OFDM symbol power PDSCH/Data* 64 QAM Power and Data utilization Frequency error Frequency error EVM Route Map Time error I/Q origin oset Cell ID RSRP Data channel EVM RMS, peak Frequency error RSRQ MBSFN* Data EVM RMS, peak Time alignment error RS-SINR Resource block power Cell, group, sector ID Antenna port S-SS RSSI I/Q diagram Time alignment error Power statistics CCDF P-SS, S-SS power

RB power Time alignment error trend S-SS Ec/Io Modulation format Time alignment error I/Q origin oset RS power dierence EVM RMS, EVM peak Antenna 0 RS power and EVM

Antenna 1 RS power and EVM

Antenna 2 RS power and EVM**

Antenna 3 RS power and EVM**

Cell, group, sector ID

* Measurement is performed when MBMS is enabled. ** Measurement is performed when Option 030 is enabled.

Longitude, latitude, and satellite in all screens

JD745A CELLADVISOR BASE STATION ANALYZER

LTE/LTE Advanced-TDD Signal Analyzer (Options 029/031)

General Parameters

Frequency range Band 33 to 43 Input signal level –40 to +20 dBm Channel power accuracy ±1.0 dB (typical) Supported bandwidth 1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15 MHz, and 20 MHz Frequency error ±10 Hz + reference-frequency accuracy 99% condence level Residual EVM (RMS) 2.0% (typical) Data EVM

JD745A CELLADVISOR BASE STATION ANALYZER

Measurements

Options 029/031 Option 049

Channel Power Data Channel Data Allocation Map Channel Scanner (up to 6)

Channel power MBSFN* Data allocation vs frame Frequency or channels Spectral density Resource block power Resource block power Cell, group, sector ID Peak to average power I/Q diagram OFDM symbol power Channel power Occupied Bandwidth RB power Data utilization RSRP/RSRQ Occupied bandwidth Modulation format Data allocation vs subframe RS-SINR Integrated power I/Q origin oset Resource block power Antenna port Occupied power EVM RMS, EVM peak Data utilization ID Scanner (up to 6) Spectrum Emission Mask Control Channel Auto Measure RSRP/RSRQ dominance Reference power Control channel summary Channel power S-SS RSSI dominance Peak level at dened range (P-SS, S-SS, PBCH, PCFICH, PHICH, Occupied bandwidth S-SS Ec/Io dominance ACLR PDCCH, RS, MBSFN*) Spectrum emission mask Cell, group, sector ID Reference power EVM, relative or absolute power, ACLR RSRP/RSRQ Abs power at dened range modulation type Mult-ACLR RS-SINR/S-SS RSSI Rel power at dened range Each control channels’ Spurious emission mask P-SS/S-SS power Multi-ACLR I/Q diagram Slot average power S-SS Ec/Io Lowest reference power Modulation format O power Multipath Prole Highest reference power Frequency error Transition period Cell, group, sector ID Abs power at dened range I/Q origin oset Time alignment error Ant 0 RS Ec/Io, delay Rel power at dened range EVM RMS, EVM peak Frequency error Ant 1 RS Ec/Io, delay Spurious Emissions Subframe MBSFN* Ant 2 RS Ec/Io**, delay** Peak frequency at dened range MBSFN* PDSCH/Data* QPSK EVM Ant 3 RS Ec/Io**, delay** Peak level at dened range Subframe summary table PDSCH/Data* 16 QAM EVM Control Channel Power vs. Time (frame) (P-SS, S-SS, PBCH, PCFICH, PHICH, PDSCH/Data* 64 QAM EVM RS power trend Frame average power PDCCH, RS, MBSFN*, PDSCH/Data* Data EVM RMS, peak Cell, group, sector ID Subframe power QPSK, PDSCH/Data* 16 QAM, RS, P-SS, S-SS EVM Control channel table First slot power PDSCH/Data* 64 QAM) RS, P-SS, S-SS power (P-SS, S-SS, PBCH, Second slot power EVM, relative or absolute power, PBCH power PCFICH, RS 0, RS 1, RS 2**, RS 3**) Cell ID, I/Q origin oset modulation type Subframe power Absolute power Time oset Subframe power OFDM power Relative power Power vs. Time (slot) OFDM symbol power Time error EVM RSM, phase Slot average power Frequency, time error I/Q origin oset Frequency error Transient period length Data EVM RMS, peak Carrier Aggregation** Time alignment error O power RS EVM RMS, peak Component carriers: up to 5 Time oset Constellation Cell, group, sector ID Subframe power Datagram MBSFN* Time Alignment Error P-SS, S-SS, PBCH, RS power and EVM Datagram RS TX power Time alignment error trend PDSCH/Data* QPSK power and EVM Resource block power PDSCH/Data* QPSK EVM Time alignment error PDSCH/Data* 16 QAM power and Data utilization PDSCH/Data* 16 QAM EVM RS power dierence EVM Route Map PDSCH/Data* 64 QAM EVM Antenna 0 RS power and EVM PDSCH/Data* 64 QAM power and RSRP Data EVM RMS Antenna 1 RS power and EVM EVM RSRQ Data EVM peak Antenna 2 RS power and EVM** Cell ID RS-SINR Frequency error Antenna 3 RS power and EVM** Frequency error S-SS RSSI Time error Cell, group, sector ID Time alignment error P-SS, S-SS power

Antenna port S-SS Ec/Io

Power Statistics CCDF

* Measurement is performed when MBMS is enabled. ** Measurement is performed when Option 031 is enabled

Longitude, latitude, and satellite in all screens

JD745A CELLADVISOR BASE STATION ANALYZER

E1 Analyzer (Option 004)

Electrical Interface

Connectors RX/TX RJ45 (120 Ω) Output 0 dB, –6 dB (ITU-T Rec.G.703) Line code AMI, HDB3 Impedance Term, monitor 120 Ω,

Input

Term/bridge/monitor 0 to −20 dB

Transmitter and Receiver

Framing PCM-30, PCM-30 with CRC

Channel formats Full E1 Test pattern 1-4, 1-8, ALL1, ALL0, 0101

Additional Functions

Reference clock Received or internal Event log capability Internal memory Error insertion 1, 1E–3, 1E–4, 1E–5 Error rate count CRC, frame, code, bit

Measurements

Monitoring BERT

Indicators Indicators

E1 signal Frame sync Pattern sync Code sync FAS RAI AIS HDB3

Bit error

Error count/rate Error count/rate

Frame error Code error

Bit error

Alarm count Alarm count

FAS AIS

Loss count Loss count

Frame sync Pattern sync

1. When CRC-4 is set to On.

2. When PCM31 is set to On.

bridge >1000 Ω

PCM-31, PCM-31 with CRC

E1 signal Frame sync Pattern sync Code sync FAS RAI AIS HDB3

Bit error

CRC error

Frame error Code error

Bit error

FAS AIS

Frame sync Pattern sync

T1 Analyzer (Option 005)

Electrical Interface

Connectors RX/TX RJ45 (120 Ω) Output 0 dB, –7.5 dB, –15 dB Line code AMI, B8ZS Impedance 100 Ω or 1000 Ω

Input

Term/bridge/monitor 0 to −20 dB

Transmitter and Receiver

Framing D4, ESF Channel formats Full T1 Test pattern 1–8, 1–16, ALL1, ALL0, 0101

Additional Functions

Reference clock Received or internal Event log capability Internal memory Error insertion 1, 1E–3, 1E–4, 1E–5 Alarm insertion AIS, RAI Error/alarm count Bit RAI, AIS, BPV, BER Loopback modes Self, CSU, NIU, line, network

Measurements

Monitoring/BERT/loop test RX signal level

Indicators Indicators

T1 signal Frame sync Pattern sync B8ZS Red alarm RAI (yellow alarm) AIS (blue alarm) BPV indicator

Loss count Vp-p

Signal loss Frame sync loss Patten sync loss

Alarm count

RAI AIS BPV

Error rate

Bit error rate Bit error count

(bridge)

2E–24, QRSS, 2E–23, 2E–15, 2E–23 inverse, 2E–15 inverse

T1 signal Frame sync Pattern sync B8ZS Red alarm RAI (yellow alarm) AIS (blue alarm) BPV indicator

Vp-p Max Vp-p Min dB

dsx

Wireless Connectivity (Option 006)

Bluetooth Connectivity

Personal area networking (PAN) File transfer protocol (FTP)

General Information

JD745A CELLADVISOR BASE STATION ANALYZER

Inputs and Outputs

RF in Spectrum analyzer Connector

Impedance Damage level

Type-N, female 50 Ω (nominal)

>+40 dBm, ±50 VDC (nominal) Reection/RF out Cable and antenna analyzer Connector

Impedance Damage level

Type-N, female

50 Ω (nominal)

>+37 dBm, ±50 VDC (nominal) RF in Cable and antenna analyzer Connector

Impedance Maximum level

Type-N, female

50 Ω (nominal)

>+25 dBm, ±50 VDC (nominal)

External trigger, GPS

Connector Impedance

SMA, female

50 Ω (nominal)

External ref

Connector Impedance Input frequency Input range

SMA, female

50 Ω (nominal)

10 MHz, 13 MHz, 15 MHz

–5 to +5 dBm

USB

USB host USB client

Type A, 1 port

Type B, 1 port LAN RJ45, 10/100Base-T E1/T1 RJ45 Audio jack 3.5 mm headphone jack External power 5.5 mm barrel connector Speaker Built-in speaker

Display

Type Resistive touch screen

(as of serial number BEK11791) Size 8 inch, LED backlight Resolution 800 x 600

Battery

Type 10.8 V, 7800 mA/hr (Lithium ion) Operating time >3 hours (typical) Charge time 2.5 hours (80%), 4 hours (100%) Charging temperature 0° to 45 °C (32° to 113 °F) ≤85% RH Discharging temperature –10° to 60 °C (14° to 140 °F) ≤85% RH

Storage temperature

–20° to 50 °C (-4° to 122 °F)

≤85% RH (non-condensing)

Data Storage

Internal External

Minimum 20 MB Limited by size of USB ash drive

Environmental

Operating temperature

AC Power 0° to 40°C (32° to 104°F) with no derating Battery 0° to 40°C (32° to 104°F) @charging

–10° to 55°C (14° to 131°F) @discharging Maximum humidity ≤85% RH (non-condensing) Shock and vibration MIL-PRF-28800F Class 2

Storage temperature

–30° to 71°C (–22° to 160°F)

EMC

EN 61326-2-1 Complies with European EMC

Size and Weight (standard configuration)

Weight (with battery) <4 kg (8.8 lb) Size (W x H x D) 295 x 195 x 82 mm

(11.6 x 7.7 x 3.2 in)

Warranty

2 years

Power

External DC input 12 to 19 VDC Power consumption 32.5 W 45 W maximum

(when charging battery)

Calibration Cycle

1 year

1. Connects flash drive and power sensor.

2. Connects to PC for data transfer.

3. 20 to 85% RH, store battery pack in low-humidity environment. Extended exposure to temperature above 45°C could significantly degrade battery

performance and life.

4. Up to 700 traces.

5. Supports USB 2.0 compatible memory devices.

6. With the battery pack removed.

Ordering Information

JD745A CELLADVISOR BASE STATION ANALYZER

Standard

JD745A 100 kHz to 4 GHz Spectrum Analyzer

5 MHz to 4 GHz Cable and Antenna Analyzer

10 MHz to 4 GHz RF Power Meter (Internal mode)

Options

NOTE: Upgrade options for the JD745A use the designation JD745AU before the respective last three-digit option number.

JD745A001 2-Port Transmission Measurement

JD745A002 Bias Tee (requires option 01) JD745A003 CW Signal Generator JD745A004 E1 Analyzer JD745A005 T1 Analyzer JD745A006 Bluetooth connectivity

JD745A010 GPS Receiver and Antenna JD745A011 Interference Analyzer

5,6

JD745A012 Channel Scanner JD745A013 Optical Power Meter

JD745A020 cdmaOne/cdma2000 Signal Analyzer JD745A021 EV-DO Signal Analyzer

JD745A022 GSM/GPRS/EDGE Signal Analyzer JD745A023 WCDMA/HSPA+ Signal Analyzer JD745A025 TD-SCDMA Signal Analyzer JD745A026 Mobile WiMAX Signal Analyzer JD745A028 LTE-FDD Signal Analyzer JD745A029 LTE-TDD Signal Analyzer JD745A030 LTE Advanced-FDD Signal Analyzer JD745A031 LTE Advanced-TDD Signal Analyzer JD745A040 cdmaOne/cdma2000 OTA Analyzer JD745A041 EV-DO OTA Analyzer

6, 11

JD745A042 GSM/GPRS/EDGE OTA Analyzer JD745A043 WCDMA/HSPA+ OTA Analyzer

JD745A045 TD-SCDMA OTA Analyzer

6, 11

JD745A046 Mobile WiMAX OTA Analyzer JD745A048 LTE-FDD OTA Analyzer JD745A049 LTE-TDD OTA Analyzer

6, 11

Standard Accessories

G710550326 AC/DC power adapter G710550335 Cross LAN cable (1.5 m) GC73050515 USB A to B cable (1.8 m) GC72450518 >1 G Byte USB memory G710550325 Rechargeable lithium ion battery G710550323 Automotive cigarette lighter 12 VDC adapter G710550316 Stylus pen

JD740A361 JD740A series user’s manual and application software

— CD

Optional Calibration Kits

JD72450509 Y-calibration kit, Type-N(m), DC to 6 GHz, 50 Ω JD72450510 Y-calibration kit DIN(m), DC to 4 GHz, 50 Ω JD71050507 Dual-port Type-N calibration kit, 50 Ω

• Y-calibration kit, Type-N(m), DC to 4 GHz, 50 Ω

• Two adapters Type-N(f ) to Type-N(f), DC to 4 GHz, 50 Ω

• Two 1 m RF test cables, Type-N(m) to Type-N(m),

DC to 18 GHz, 50 Ω

JD71050508 Dual-Port DIN calibration kit, 50 Ω

• Y-calibration kit DIN(m), DC to 4 GHz, 50 Ω

• Two 1 m RF test cables, Type-N(m) to Type-N(m),

DC to 18 GHz, 50 Ω

• Adapter Type-N(f ) to DIN(f ), DC to 4 GHz, 50 Ω

• Adapter Type-N(f ) to DIN(m), DC to 4 GHz, 50 Ω

• Adapter DIN(f) to DIN(f), DC to 4 GHz, 50 Ω

• Adapter DIN(m) to DIN(m), DC to 4 GHz, 50 Ω

Optional RF Cables

G710050530 1.0 m (3.28 ft) RF cable, DC to 18 GHz, Type-N(m) to

Type-N(m), 50 Ω

G710050531 1.5 m (4.92 ft) RF cable, DC to 18 GHz, Type-N(m) to

Type-N(f), 50 Ω

G710050532 3.0 m (9.84 ft) RF cable, DC to 18 GHz, Type-N(m) to

Type-N(f), 50 Ω

G710050533 1.5 m (4.92 ft) RF cable, DC to 18 GHz, Type-N(m) to

SMA(m), 50 Ω

G710050534 1.5 m (4.92 ft) RF cable, DC to 18 GHz, Type-N(m) to

QMA(m), 50 Ω

G710050535 1.5 m (4.92 ft) RF cable, DC to 18 GHz, Type-N(m) to

SMB(m), 50 Ω

1. Requires calibration kit.

2. Requires dual-port calibration kit.

3. Requires test cable.

4. Includes two Bluetooth USB dongles with 5 dBi dipole antenna (JD70050006).

5. Recommend adding GPS receiver JD745A010.

6. Recommend adding antennas G70005035x and/or G70005036x.

7. Requires an optical power sensor (MP-60 or MP-80).

8. Requires Option 020.

9. Requires Option 028.

10. Requires Option 029.

11. Requires Option 010.

12. Standard accessory, can be purchased separately.

Ordering Information (cont'd.)

JD745A CELLADVISOR BASE STATION ANALYZER

Optional Omni Antennas

G700050351 RF omni antenna Type-N(m), 400 MHz to 450 MHz G700050352 RF omni antenna Type-N(m), 450 MHz to 500 MHz G700050353 RF omni antenna Type-N(m), 806 MHz to 896 MHz G700050354 RF omni antenna Type-N(m), 870 MHz to 960 MHz G700050355 RF omni antenna Type-N(m), 1.71 GHz to 2.17 GHz G700050356 RF omni antenna Type-N(m), 720 MHz to 800 MHz G700050357 RF omni antenna Type-N(m), 2.3 GHz to 2.7 GHz

Optional Yagi Antennas

G700050364 RF Yagi antenna Type-N(f), 806 MHz to 896 MHz, 10.2 dBd G700050365 RF Yagi antenna Type-N(f), 866 MHz to 960 MHz, 10.2 dBd G700050363 RF Yagi antenna Type-N(f), 1.75 GHz to 2.39 GHz, 9.8 dBd G700050366 RF Yagi antenna SMA(f), 700 MHz to 4 GHz, 1.85 dBd

Optional RF Power Sensors

JD731B Directional Power Sensor (peak and average power)

Frequency: 300 MHz to 3.8 GHz Power: average 0.15 to 150 W, Peak 4 to 400 W

JD733A Directional Power Sensor (peak and average power)

Frequency: 150 MHz to 3.5 GHz Power: average/peak 0.1 to 50 W

JD732B Terminating Power Sensor (average power)

Frequency: 20 MHz to 3.8 GHz Power: –30 to +20 dBm

JD734B Terminating Power Sensor (peak power)

Frequency: 20 MHz to 3.8 GHz Power: –30 to +20 dBm

JD736B Terminating Power Sensor (peak and average power)

Frequency: 20 MHz to 3.8 GHz Power: –30 to +20 dBm

Optional Optical Power Sensors

MP-60 Miniature USB 2.0 Optical Power Sensor

Wavelength range: 780 to 1650 nm 1300, 1310, 1490, 1550 nm: –50 to +10 dBm 850 nm: –45 to +10 dBm

MP-80 Miniature USB 2.0 Optical Power Sensor

Wavelength range: 780 to 1650 nm 1300, 1550 nm: –35 to +23 dBm 980 nm: –30 to +23 dBm

Optional RF Adapters

G710050570 Adapter Type-N(f) to Type-N(f ), DC to 6 GHz, 50 Ω G710050571 Adapter Type-N(m) to DIN(f), DC to 4 GHz, 50 Ω G710050572 Adapter DIN(m) to DIN(m), DC to 4 GHz, 50 Ω G710050573 Adapter Type-N(m) to SMA(f), DC to 18 GHz, 50 Ω G710050574 Adapter Type-N(m) to BNC(f), DC to 1.5 GHz, 50 Ω G710050575 Adapter Type-N(f) to Type-N(f), DC to 4 GHz, 50 Ω G710050576 Adapter Type-N(m) to DIN(m), DC to 4 GHz, 50 Ω G710050577 Adapter Type-N(f) to DIN(f), DC to 4 GHz, 50 Ω G710050578 Adapter Type-N(f) to DIN(m), DC to 4 GHz, 50 Ω

G710050579 Adapter DIN(f ) to DIN(f ), DC to 4 GHz, 50 Ω

Optional E1/T1 Test Cables

G710050317 RJ45 to Y Bantam cable G710050318 RJ45 to Y BNC cable G710050319 RJ45 to 4 alligator clips

Optional Miscellaneous

G710050581 Attenuator 40 dB, 100 W, DC to 4 GHz

(unidirectional) JD74050341 Soft carrying case JD71050342 Hard carrying case JD70050342 Hard carrying case with wheels JD74050343 Backpack carrying case G710050585 RF directional coupler, 700 MHz to 4 GHz, 30 dB,

Input/Output; Type-N(m) to Type-N(f ), Tap O;

Type-N(f) G710050586 RF combiner, 700 MHz to 4 GHz, Type-N(f) to

Type-N(m) G710050587 4x1 RF combiner 700 MHz to 4 GHz, Type-N(f) to

Type-N(m)

G710550324 External battery charger JD740A362 JD740A series user’s manual – printed version

1. Requires RF cable G710050530.

2. Requires RF cable G710050533.

3. Recommended for LTE testing.

4. Recommended for LTE Advanced testing.

JD745A CELLADVISOR BASE STATION ANALYZER

Test & Measurement Regional Sales

NORTH AMERICA

ToLL FrEE: 1 855 ASK-JDSU

1 855 275-5378

LATIN AMERICA

TEL: +1 954 688-5660 FAX: +1 954 3454668

ASIA PACIFIC

TEL:+852 2892 0990 FAX:+852 2892 0770

EMEA

TEL:+49 7121 86 2222 FAX:+49 7121 86 1222

www.jdsu.com/test

Atec JD745A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
