Industrial Videoscope
920-204D-EN
Versatile conveying videoscopes:
Compact, Tough, Easy-to-Use, and Feature Rich.
Combining superb ease of use with outstanding functionality, the IPLEX LX and LT provide accurate and
advanced inspections, allowing smooth operation regardless of the user’s experience level.
2
A winning combination you expect from an IPLEX
A trusted leader in the industrial endoscope market, Olympus presents the IPLEX LX and LT, setting a
new standard for small, lightweight videoscopes. The compact package includes features such as a 6.5 in.
daylight-view monitor and interchangeable tip adaptors. Advanced options such as WiDER™ image
processing, SmartTip™ technology, and Stereo Measurement are also available on the IPLEX LX.
Convenient Portability
• Compact and lightweight
• Robust main unit
• Integrated carrying handle / stand
• Li-ion battery or AC operation
Unsurpassed Ease of Use
• Multi-positioning design
• Ergonomic handset, weighing just 750 g (1.7 lb)
• TrueFeel™ precise scope tip articulation
• Quick-access menu buttons
• Intuitive icon-based menu commands
Rugged Durability
• MIL-STD and IP55 environmental compliant
• 1.2 m (3.9 ft) drop survivability
• New high-durability insertion tube braid
• 100 ºC (212 °F) capable insertion tube with
temperature alert*
Exceptional Functionality
• Large 6.5 in. VGA daylight-view monitor
• Advanced WiDER™ image processing*
• SmartTip™ Technology*
• Interchangeable LED tip adaptors
• Still and movie image recording to USB flash drive
• Available Stereo Measurement option*
*IPLEX LX only
3
Convenient Portability
Equipped with a removable Li-ion battery, the IPLEX LX and LT are ready for use wherever the inspection
takes place. Whether the operator is crawling in confined spaces or working stationary in an aircraft hangar,
the IPLEX LX and LT keep the size small without sacrificing features or functionality.
Compact and Lightweight
The IPLEX LX and LT weigh just 2.7 kg (6.0 lb), including the twohour running time Li-ion battery. They can be worn or carried with
ease and set up almost instantly. The complete system, including
all accessories and carrying case, is easily transported to job sites
and small enough to fit in the overhead compartment of most
aircraft.
99 mm (3.9 in.)
227 mm (8.9 in.)
Small Size, Large Monitor
6.5 in.
189 mm (7.4 in.)
Despite being only 227 mm (8.9 in.) wide and 189 mm (7.4 in.)
tall, the IPLEX LX and LT integrate a surprisingly large 6.5 in.
monitor for exceptional visibility, whether at arm’s length or across
a workbench. At less than 100 mm (3.9 in.) thick including the
pivoting handle/stand, the IPLEX LX and LT can be worn, stand
upright, or be fastened to a tripod or mounting arm for operation
in practically any environment.
64 mm (2.5 in.)
4
Unsurpassed Ease of Use
With their intuitive icon-based menu system, the IPLEX LX and LT require minimal or no training and can
be easily operated by users of any experience level. Almost every menu and feature can be accessed by a
maximum of three presses on the quick-access control buttons. And the TrueFeel™ scope tip articulation
achieves easy and precise control.
Choice of Connection and Positioning
The handheld controller can be operated either independently
or attached to the main unit during inspections, offering
a versatile choice of operation. The stand-alone monitor
can always be positioned for optimum viewing and is also
convenient for group inspections and training.
Innovative Features at
Operator Fingertips
The ergonomic lightweight handset with
TrueFeel™ articulation control has been
engineered for comfortable operation
even during prolonged inspections. The
user can operate diverse functions and
scope tip articulations easily, quickly,
and precisely. The controller maximizes
the use of buttons, levers, and joystick
for quick access to all essential menu
functions. Image enhancements,
recording buttons, and measurement
capabilities are among the many
basic-to-advanced features at the
operator’s fingertips.
Intuitive Icon-Based Menus
The IPLEX LX and LT feature a simple menu, utilizing intuitive,
internationally recognized icons that make it easy for the
operator to quickly choose the right menu option. Navigation
is simplified by a dedicated joystick, which functions
independently from the scope tip articulation.
5
6
Rugged Durability
The durability and environmental resistance of the IPLEX LX and LT provides exceptional reliability even
in the harshest environments. Whether you’re conducting inspections outdoors in a variety of weather
conditions, in a dusty or sandy climate, or in manufacturing areas, you can depend on the IPLEX LX and LT
to function reliably in any surroundings.
All Weather Resistance
You can confidently bring the IPLEX LX and LT to almost any
difficult environment. They can be used in rain, sand, and
dust, and withstand physical shocks caused by drops and
falls, ensured by IP55 and MIL-STD compliance. With its
low-reflection display, the daylight-view monitor reproduces
clear, vivid images even under the brightest sunlight.
RAIN DUSTSUNLIGHT
Impervious to Environmental Hazards
Complying with internationally recognized military standards
(MIL-STD-810G / MIL-STD-461F)*, the IPLEX LX and LT pass a
wide variety of environmental hazard tests, including blowing
rain, humidity, salt fog, sand and dust, icing/
freezing rain, and explosive atmosphere. They also
withstand rough treatment such as vibration and
being dropped from heights up to 1.2 m (3.9 ft).
*Reference page 15 for MIL-STD compliance details
New Outer Braid
Conventional Outer Braid
Resistance to High Temperatures
and Abrasion
The insertion tubes of the IPLEX LX** withstand
temperatures up to 100 ºC (212 °F). A hightemperature sensor cautions with an audible
beep and displays a visual warning if the scope
is in danger of becoming overheated.
The crush-proof insertion tubes of the IPLEX LX and LT are equipped
with an innovative fine mesh tungsten outer braid that results in
outstanding abrasion resistance. The tube’s strength combined with
its flexibility allows operation in the most difficult and hazardous
inspection areas.
The IPLEX LX and LT are designed with the unique Tapered Flex™
achieving superb scope maneuverability with optimized stiffness
and flexibility. In addition, the increased stiffness of the new
8.5 mm scope allows it to be easily pushed deep into an inspection
area without the use of a guide tube, making it ideal for long pipe
inspections.
** The IPLEX LX IV88100L1 withstands temperatures up to 80 º C (176 °F).
High temperature warning display
7
Exceptional Functionality – Viewing Capability
Building on decades of experience in optical imaging, the innovative IPLEX LX and LT design provides superb
image quality of inspected objects.
Excellent color reproduction and superb clarity
The industry-leading 6.5 in. daylight-view monitor is larger than comparable
videoscopes on the market, always allowing for a comfortable viewing position
and convenience for group viewing. Superb image clarity permits the accurate
detection of very small defects.
ACTUAL SIZE
8
Clear, Crisp Images
The IPLEX LX features our unique image
processing capability, WiDER™ (Wide
Dynamic Extended Range). This innovative
technology brings out detail in shadowed
and highlighted areas to produce bright,
contrast-balanced images across the entire
depth of field.
With WiDER™ gain appliedImage at standard gain setting
Ultra-Bright, Interchangeable
LED Tip Adaptors
For optimum magnification and direction suitable for a variety
of inspection environments, the IPLEX LX and LT offer a
comprehensive range of interchangeable optical adaptors.
The integrated LED illumination system brightly light targets.
For inspection of large voids where plenty of light is required,
the 8.5 mm scope is an ideal solution. Fitted within the scope
tip, it delivers vivid illumination regardless of scope length and
eliminates the need for a fiber light guide.
In addition, the IPLEX LX is equipped with Hi-Beam mode
boosting illumination up to 2X for expanded inspection capability,
and the SmartTip™ automatic recognition function. Our unique
SmartTip feature installed in optical adaptors permits recording
of the adaptor information, along with captured images for
inspection traceability.
Diverse Applications
Heat exchanger
Gas turbine blade
Wind turbine gear box
Automotive part
9
Exceptional Functionality – Image Management
The versatile IPLEX LX and LT offer far more than just on-site inspection. From image archiving to defect
measurement and image management on a PC, post inspection tasks are made easier after returning from
the inspection site.
High-Quality Images and Movies
The IPLEX LX and LT feature high-quality JPEG still images and
MPEG-4 movies that record into a removable USB flash drive.
Saving or retrieving images requires only a single button press,
and the thumbnail view makes it easy to instantly review the
inspection results.
Never before has a compact videoscope system offered such
high-quality recording while retaining ease of use.
Title Input Function
For off-site inspection efficiency and report generation, the
IPLEX LX and LT let you quickly and easily input titles in captured
images. You can quickly identify the inspection location or result
through the title to assist in archiving images.
Post-Inspection Image Management
IPLEX Viewer Plus software features image data management
and precise measurement of objects in recorded images.
Available from our website free of charge, it’s the ideal tool
for remote users to re-measure or validate existing saved
measurement results.
In addition, IPLEX Viewer PRO is now available as an
option. This advanced software features information editing
and report generation, enabling you to efficiently prepare
inspection reports.
Protection for Interior Components
The main unit’s removable USB flash drive and Li-ion battery are
contained inside a latched, sealed compartment for protection
against environmental hazards and rough treatment.
10
Proven Stereo Measurement
Our advanced Stereo Measurement technology offers outstanding
reliability and accuracy for your inspections. By capturing image
information through two parallax lenses, the IPLEX LX permits
accurate measurement of almost any object from any angle.
Accurate Measurement on the First Try
The measurement accuracy of a videoscope is greatly affected
by the scope’s tip-to-target distance. Our unique Spot-Ranging™
feature on the IPLEX LX, the industry’s only real-time tip-totarget distance measurement tool, navigates the scope tip to the
optimum distance from a target. The operator can then easily
determine whether the tip is close enough to calculate the most
accurate measurement on the first try.
11
Accessories
The IPLEX LX and LT offer a number of complementary
accessories, some included with the system and others
available as options.
Rigid Sleeve Sets*
MAJ-1253 (for 6.0 mm insertion tube)
MAJ-1737 (for 4.0 mm insertion tube)
Sets are available for 6.0 mm and 4.0 mm scopes.
Each set consists of three rigid sleeves of 250 mm (9.84 in.),
340 mm (13.38 in.) and 450 mm (17.71 in.) lengths.
AC Power Adaptor
The IPLEX LX and LT
can be operated with
either the provided AC
power adaptor or the
battery.
Standard
case for the
IPLEX LX/LT.
Long Scope is
supplied with an
exclusive carrying
case.
Lithium-ion Battery*
NC2040OL24 Battery charger*
CH5000C (USA type) /
CH5000X (European type)
The battery provides long-lasting
operations.
Handheld Controller
Holder* MB-937
Allows the controller to be affixed
to a tripod, making it useful for
prolonged inspections.
Guide Tube for 6.0mm
diameter Long Scope*
MAJ-1825-75
Protects the scope and assists in
smooth entry when inserting it
into a wide pipe. Available on the
6.0 mm diameter scope in
7.5 m length.
Carrying Case
Carrying case shown is included with the 2.0
and 3.5 m videoscopes. A carrying case for long
scopes is also available.
Optical Tip Adaptors*
The wide range of the IPLEX
LX and LT tip adaptors meets
the optical requirements of any
application.
USB Flash Drive
A USB flash drive with
1 GB capability is supplied
as standard.
Centering Device for
8.5 mm diameter Long Scope*
MAJ-1935
The Centering Device Set allows you
to center the scope inside a pipe by
attaching it to the scope distal end.
The set consists of two devices in
75 mm (2.95 in.) and 140 mm finger
(5.51 in.) lengths.
*Option
121314
IPLEX LX/LT Features and Specifications
*
SCOPE VARIATION
IPLEX LX Model No. IV8420L1 IV8435L1 IV8620L1 IV8635L1 IV8675L1 IV8835L1 IV88100L1 IV88200L1
IPLEX LT Model No. IV8420L2 IV8435L2 IV8620L2 IV8635L2 IV8675L2 IV8835L2 IV88100L2 IV88200L2
2.7 kg
(6.0 lb)
φ4.0 mm
(0.157 in.)
Uniformed
stiffness
130° 150° 130° 90° 140° 115° 70°
2.8 kg
(6.2 lb)
2.8 kg
(6.2 lb)
Scope Diameter
Scope Length 2.0 m (6.6 ft) 3.5 m (11.5 ft) 2.0 m (6.6 ft) 3.5 m (11.5 ft) 7.5 m (24.6 ft) 3.5 m (11.5 ft) 10 m (32.8 ft) 20.0 m (65.6 ft)
Exterior High durability tungsten braid
Tube Flexibility
Articulation angle
UP/DOWN/RIGHT/LEFT
Approx. System Weight
(with battery)
φ6.0 mm
(0.236 in.)
Tough Tapered Flex™ tube with flexibility gradually
increasing toward the distal end.
2.9 kg
(6.4 lb)
3.2 kg
(7.1 lb)
3.0 kg
(6.6 lb)
φ8.5 mm
(0.335 in.)
3.9 kg
(9.0 lb)
Uniformed
stiffness
5.2 kg
(11.5 lb)
INSERTION TUBE
Articulation Mechanics TrueFeel™ scope tip articulation with electronic power-assisted, manual articulation
Temperature Sensor 2-stage indicator for high temperature warning. N/A
Illumination
Optical Tip Adaptor Identification
Optical Tip Adaptor Locking Mechanism Double threaded attachment, with O-ring seal
Multiple ultra-high intensity LEDs,
2-stage setting for extra-bright illumination
1
SmartTip™ Automatic Recognition Technology N/A
Multiple ultra-high intensity LEDs
HANDHELD CONTROL UNIT
Dimensions (W x H x D) 311 mm x 192 mm x 92 mm (12.2 in. x 7.6 in. x 3.7 in.)
Weight Approx. 750 g (1.7 lb)
Quick Access Buttons
The following features have dedicated quick access buttons, levers or joysticks on the hand control unit:
Live mode, WiDER™ Gain Control (IPLEX LX only), Brightness, Zoom, Freeze Image, Record Still/Video,
Articulation Control, Articulation Lock, Menu Access, Saved Recording Index Access, Quick Last Image Recall.
MAIN UNIT
Dimensions (W x H x D)
LCD Monitor 6.5 in. daylight-view LCD, anti-reflective type
Power Supply
Output Connector RCA composite video output
USB Connector Type A connector, Version 2.0 standards
Main Unit: 227 mm x 189 mm x 64 mm (8.9 in. x 7.4 in. x 2.5 in.)
Maximum Dimension: 239 mm x 215 mm x 99 mm (9.4 in. x 8.5 in. x 3.9 in.)
Battery: 10.8 V nominal.
IV84 and IV86 Series: over 120-minute operating time. IV88 Series: over 100-minute operating time.
AC power: 100 V to 240 V, 50/60 Hz (with supplied AC adaptor)
SOFTWARE MANIPULATIONS
Image Manipulations 3 step digital zoom, 8 step brightness control
Adjustable Gain Control
Display Text Options 30-character title display
3 step adjustable gain control with exclusive
WiDER™ brightness level balancing technology.
N/A
RECORDING MANAGEMENT FUNCTIONS
Recording Media USB flash drive (1 GB standard, compatible with recommended USB flash device).
Overlay Selectable 30 character title with date, time and system setting.
Thumbnail Image Display Recorded images can be displayed as thumbnails.
Resolution — NTSC: H 640 x V 480 (Pixel), PAL: H 768 x V 576 (Pixel)
Still Image Recording
Video Recording
Recording Format — Compressed JPEG format
Size of a single image — Approx. 300 KB (Approx. 3,400 images per 1 GB memory)
Resolution — H 640 ×V 480 (Pixel)
Recording Format — AVI MPEG-4 format. Can be played on the Windows Media Player.
Size of a single image — Approx. 500 KB per second (Approx. 30 min. per 1 GB memory)
STEREO MEASUREMENT FUNCTIONS — Optional function for IPLEX LX
Distance Distance between two points.
Point-to-Line
Depth
1. On the 8.5 mm scope tip, the SmartTip function is limited to recognition of the tip adaptor attachment to the scope only and manual selection of the tip adaptor model is
required by the user.
Perpendicular distance between a point and a userdefined line.
Orthogonal depth/height distance between a point
and a user-defined plane.
Note: Stereo Measurement functions are available by
upgrading the IPLEX LX.
1
1
OPERATING ENVIRONMENT
In air: –25 ºC to 100 ºC (–13 ºF to 212 ºF) IPLEX LX
Operating Temperature
Insertion Tube
–25 ºC to 80 ºC (–13 ºF to 176 ºF) IPLEX LT and IPLEX LX IV88 series
In water: 10 ºC to 30 ºC (50 ºF to 86 ºF)
Other parts than above In air: –10 °C to 40 ºC (14 ºF to 104 ºF)
In air: 1013 hPa
In water: IV84 series — 1013 to 1368 hPa
IV86 series — 1013 to 1772 hPa
IV88 series — 1013 to 2026 hPa
Operating Atmospheric Pressure
Insertion Tube
Other parts than above In air: 1013 hPa
Relative Humidity All parts 15 % to 90 %
Liquid Resistance All parts Operable when exposed to machine oil, light oil or 5 % saline solution.
Insertion Tube
Waterproofing
Other parts than above
Operable under water with viewing tip adaptor attached.
Not operable underwater with stereo measurement tip adaptors.
Operable in blowing rain conditions (Battery compartment must be closed).
Not operable underwater.
MIL-STD COMPLIANCE
The operating environment performance is confirmed by the following MIL-STD-810G and MIL-STD-461F under battery operation.
Type Method
Vibration
Shock MIL-STD-810G, Method 516.5, Procedure IV (Transit drop test)
Water Resistance
Humidity
Salt Fog
Sand and Dust
Icing/Freezing Rain
Electromagnetic Interference (EMI)2MIL-STD-461F, RS-103, (Radiated susceptibility test for non-metallic above deck shipboard conditions)
Explosive Atmosphere
1. Excluding IV88 series.
2. Excluding IV8675L1, IV8675L2, and IV88 series.
1
1
1
1
1
1
1
MIL-STD-810F, Method 514.5, Procedure I (General vibration test)
MIL-STD-810F, Method 506.4, Procedure I (Rain and Blowing rain test)
MIL-STD-810F, Method 507.4
MIL-STD-810F, Method 509.4
MIL-STD-810G, Method 510.4, Procedure I (Blowing dust test)
MIL-STD-810F, Method 521.2
MIL-STD-810F, Method 511.4, Procedure I (Operation in an explosive atmosphere test)
Tip Adaptor Optical Specifications
OPTICAL TIP ADAPTOR VARIATION
6.0 mm Viewing Tip Adaptors
AT80D/
NF-IV86
Optical
system
Distal
end
AT40D-IV86
Field of view 40º 80º 80º 120º 120º 80º 120º 120º
Direction of view Forward Forward Forward Forward Forward Side Side Side
3
Depth of field
Outer diameter
Distal end
5
200 to ∞ mm 8 to ∞ mm 35 to ∞ mm 4 to 190 mm 25 to ∞ mm 18 to ∞ mm 1 to 25 mm 5 to ∞ mm
4
ø6.0 mm ø6.0 mm ø6.0 mm ø6.0 mm ø6.0 mm ø6.0 mm ø6.0 mm ø6.0 mm
19.8 mm 19.8 mm 19.8 mm 19.8 mm 19.8 mm 25.2 mm 25.2 mm 25.2 mm
4.0 mm Viewing Tip Adaptors 8.5 mm Viewing Tip Adaptors
Optical
system
Distal
end
AT120D/
NF-IV84
Field of view 120º 120º 120º 120º 80º 120º 120º 120º 120º
Direction of view Forward Forward Side Side Forward Forward Forward Side Side
3
Depth of field
Outer diameter
Distal end
5
4 to 190 mm 25 to ∞ mm 1 to 20 mm 6 to ∞ mm 35 to ∞ mm 4 to 190 mm 25 to ∞ mm 1 to 25 mm 5 to ∞ mm
4
ø4.0 mm ø4.0 mm ø4.0 mm ø4.0 mm ø8.5mm ø8.5mm ø8.5 mm ø8.5 mm ø8.5 mm
19.7 mm 19.6 mm 22.2 mm 22.2 mm 22.9 mm 22.9 mm 22.9 mm 29.5 mm 29.5 mm
AT120D/
FF-IV84
Stereo Tip Adaptors (4.0 mm, 6.0 mm, and 8.5 mm)
AT50D/50D-IV84 AT50S/50S-IV84 AT60D/60D-IV86 AT60S/60S-IV86 AT60D/60D-IV88 AT60S/60S-IV88
Optical
system
Distal
end
3. Indicates the viewing distance with optimal focus.
4. The adaptor can be inserted into a ø4.0 mm, ø6.0 mm or ø8.5 mm hole when it is mounted on the scope.
5. Indicates the length of the rigid portion at the scope’s distal end when mounted.
Field of view 50º/50º 50º/50º 60º/60º 60º/60º 60º/60º 60º/60º
Direction of view Forward/Forward Side/Side Forward/Forward Side/Side Forward/Forward Side/Side
Depth of field
Outer diameter
Distal end
5
3
5 to ∞ mm 4 to ∞ mm 5 to ∞ mm 4 to ∞ mm 5 to ∞ mm 4 to ∞ mm
4
ø4.0 mm ø4.0 mm ø6.0 mm ø6.0 mm ø8.5 mm ø8.5 mm
25.0 mm 28.8 mm 25.9 mm 32.2 mm 28.9 mm 36.5 mm
AT120S/
NF-IV84
AT80D/
FF-IV86
AT120S/
FF-IV84
AT120D/
NF-IV86
AT80D/
FF-IV88
AT120D/
FF-IV86
AT120D/
NF-IV88
AT80S-IV86
AT120D/
FF-IV88
AT120S/
NF-IV86
6
AT120S/
NF-IV88
AT120S/
FF-IV86
AT120S/
FF-IV88
15
www.olympus-ims.com
info@olympusNDT.com
is ISO 9001 and 14001 certified.
48 Woerd Avenue, Waltham, MA 02453, USA, Tel.: (1) 781-419-3900
12569 Gulf Freeway, Houston, TX 77034, USA, Tel.: (1) 281-922-9300
505, boul. du Parc-Technologique, Québec (Québec) G1P 4S9, Tel.: (1) 418-872-1155
1109 78 Ave, Edmonton (Alberta) T6P 1L8
IPLEX-LT-LX-US-201202• Printed in the USA • Copyright © 2012 by Olympus NDT.
*All specications are subject to change without notice. All brands are trademarks or registered trademarks of their respective owners and third party entities.
Loading...
