300XAC Series

Modular AC
Power Sources

Overview

Our 300XAC Series modular AC power sources

incorporate the latest in modular technology, making
them ideal for the most demanding applications.
These versatile AC power sources can be congured
for 1Φ stand-alone operation or linked together for
up to 18 kVA of AC power in both 1Φ and 3Φ
output congurations.

Our smartDETECT ® feature automatically assigns
the appropriate master/slave designation for

each source without the need for the operator to
recongure internal hardware. The easy-to-use
push-button interface allows the operator to select
1Φ or 3Φ operation, setup and perform tests, and
simulate the effect of voltage surges and drops for
transient testing.

The 300XAC Series comes with your choice of an
automated interface at no extra charge. Choose
from USB, Ethernet, RS-232, or GPIB.

Features

• Modular design allows operator to connect up to 3 instruments
together for 1Φ or 3Φ applications requiring up to 18 kVA
of AC power

• Congure 2 sources for 1Φ/3W output voltages up to 600 VAC

• smartCONFIG® feature allows for push-button setup of
1Φ/3Φ output

• 50 built-in memory locations with 9 test steps can be linked to
quickly store and recall test parameters for multiple product
testing applications

• Transient feature simulates voltage variations, brownouts, and
transient voltage conditions

• Adjust the starting and ending angle of the output waveform

APT...The Power of Value!

• Industry-leading standard 2-year warranty

• Guaranteed 24-hour shipment or we pay the freight

• 48-hour turnaround on all repairs

• Prompt feature allows operator to display instructions between

test steps

• Frequency output up to 1000 Hz

• Constant current output with over current fold back feature

• Advanced metering circuits monitor voltage, current, peak
current, power, apparent power, reactive power, power factor,
and crest factor

• External voltage sensing for accurate metering

• DC Output Capability

• Standard USB/RS-232 interface with optional GPIB and
Ethernet interfaces available at no extra charge

• Rotary knob to adjust voltage and frequency on the y

• 45-day return policy – no questions asked

4

Toll Free: [phone]

The Benefits of the 300XAC Modular
AC Power Sources

The APT Link Card (Option 08)

The 300XAC Series can be used as a stand-alone
instrument which provides 1Φ output power. If the
Linking Card option is installed, up to three 300XAC
instruments can be interconnected for Parallel or
Polyphase output.

Master/Slave Relationship

The master/slave relationship between linked 300XAC
instruments synchronizes the rmware of each power
source so the output and phase angle separation is

The APT 300XAC Modular Power Sources

can link several AC power sources to

give you the maximum flexibility that your

regulated. It also gives the operator the capability to
program parameters for all linked sources from the front
panel of the master instrument.

operation requires

What is a modular AC
power source?

We use the term modular to dene the capability
of the 300XAC Series of AC power sources to be
interconnected in order to produce higher power
outputs and different power congurations than
an individual instrument. When multiple 300XAC
instruments are interconnected the operator can
congure the output for Parallel or Polyphase
modes. Parallel mode allows the operator to
increase the output current of the system by
a factor of 2 or 3 depending on the number of
sources that are interconnected. Polyphase
mode allows the operator to increase the total
power output of the system as well as change
the output power conguration of the system.

SmartDETECT

®

The SmartDETECT feature automatically determines
how many power sources are linked together. After the
check is completed the 300XAC Series will automatically
change the programming output function based on the
number of linked sources.

SmartCONFIG® Feature

The SmartCONFIG feature allows the operator to
change the output of the linked sources to Parallel or
Polyphase mode with the push of a button.

The Modular AC Source Advantage

Easy to change from 1Φ to 3Φ output

No need to have separate sources for 1Φ to 3Φ applications

Allows for future expansion if power requirements change

Greater mobility of the AC Power Source

The ability to generate greater current or voltage if only 1Φ power is available

The ability to generate 3Φ power if only 1Φ power is available

APT...The Power of Value! Toll Free: [phone]

5

Specifications – 300XAC Series

INPUT

Phase

Voltage

Frequency

OUTPUT

Voltage

Max Power

Max Current 1

Phase

Frequency

THD

Crest Factor

Line Regulation

Load Regulation

Φ

DC OUTPUT VOLTAGE

Voltage

Max Power

Max Current 1

Ripple & Noise

Φ

MEASUREMENT

Voltage

Frequency

Current (rms)

Current Peak

Power

Power

Apparent (VA)

Power

Reactive (Q)

Power Factor

Crest Factor

OPTIONS

Grounded Neutral

GPIB Interface

7 Remote Memory

Ethernet Interface

Linking Card

GENERAL

Operation Environment

Dimensions

Net Weight Lbs. (kg)

6

W x H x D – inches/mm

310XAC 320XAC 340XAC 360XAC

Φ

1

90 - 264 VAC 180 - 264 VAC 180 - 457 VAC

47 - 63 Hz

5 - 300 V

1 kVA 2 kVA 4 kVA 6 kVA
0 - 150 V 9.2 A @ 110 V 18.4 A @ 110 V 36.8 A @ 110 V 55.2 A @ 110 V
0 - 300 V 4.6 A @ 220 V 9.2 A @ 220 V 18.4 A @ 220 V 27.6A @ 220 V

1Φ (Parallel/Poly-Phase Linking for 1Φ3W or 3Φ4W)

40.0 - 1000 Hz

<1% (Resistive Load)

Inrush CF ≥ 3 at 110 V, Continuous Current CF ≥ 3 at 110 V

± 0.1 V

±0.5 V

5 - 420 V

1000 W 2000 W 4000 W 6000 W
0 - 210 V 4.8 A 9.6 A 19.2 A 28.8 A
0 - 420 V 2.4 A 4.8 A 9.6 A 14.4 A

< 3.0 V p-p < 4.0 V p-p

Range 0.0 - 400.0 V
Accuracy ± (1% of reading + 2 counts) > 5 V ± (1% of reading + 5 counts) > 5 V
Range 0.0 - 1000 Hz
Accuracy 0.0 - 500 Hz ± 0.1 Hz, 501 - 1000 Hz ± 0.2 Hz
Range 0.005 A - 13.00 A 0.005 A - 26.00 A 0.05 A - 52.00 A 0.05 A - 78.00 A
Accuracy

Range 0.0 A - 38.0 A 0.0 A - 76.0 A 0.0 A - 152 A 0.0 A - 228 A
Accuracy ± (1% of reading + 5 counts)
Range 0.0 W - 1300 W 0.0 W - 2600 W 0.0 W - 5200 W 0.0 W - 7800 W

Accuracy

Range 0.0 VA - 1300 VA 0.0 VA - 2600 VA 0.0 VA - 5200 VA 0.0 VA - 7800 VA
Accuracy V×A , Calculated value
Range 0.0 VAR - 1300 VAR 0.0 VAR - 2600 VAR 0.0 VAR - 5200 VAR 0.0 VAR - 7800 VAR
Accuracy √(VA)²-(W)², Calculated value
Range 0.000 - 1.000
Accuracy W/VA, Calculated and displayed to three signicant digits
Range 0.0 - 10.0
Accuracy Apeak / Arms, Calculated and displayed to two signicant digits

L ± (2% of reading + 15 counts) at PF ≥ 0.2 ± (2% of reading + 5 counts) at PF ≥ 0.2
H

Option 2 Yes

Option 3 Yes

Option 4 Yes

Option 6 Yes

Option 8 Yes

16.92 x 5.26 x 20.87 in 16.92 x 5.26 x 20.87 in 16.92 x 10.51 x 19.69 in 16.92 x 15.77 x 19.69 in
430 x 133.5 x 530 mm 430 x 133.5 x 530 mm 430 x 267 x 500 mm 430 x 400.5 x 500 mm

± (1% of reading + 5 counts)

± (2% of reading + 5 counts)

0 - 40ºC / 20 - 80% RH

44 lbs (20 kg) 46.3 lbs (21 kg) 110.2 lbs (50 kg) 117 lbs (53 kg)

± (1% of reading + 5 counts) @ 40 - 100 Hz, ± (1% of
reading + 5 counts) @ 101 - 500 Hz > 0.1 A, ± (1% of

reading + 5 counts) @ 501 - 1000 Hz > 0.2 A

at PF ≥ 0.2

Specifications subject to change

1Φ or 3

Φ

300XAC Specifications

Linking Parallel Output 1Φ2W

Linked Units

Voltage

Power

Max

Max Current

Line

Phase 5 - 300 V

# Units

0 - 150 V L(2) 14.72 A @ 20 V -110 V 29.44 A @ 20 V -110 V 58.88 A @ 20V - 110 V 88.32 A @ 20 V - 110 V

0 - 300 V H(2) 7.36 A @ 20 V - 220 V 14.72 A @ 20 V - 220 V 29.44 A @ 20 V - 220 V 44.16 A @ 20 V - 220 V

Linking Polyphase Output 1Φ3W

Linked Units

Voltage

Power

Max Current

Phase

Max Current

Line

Phase 10 - 600 V
Line 5 - 300 V
Max 2 kVA 4 kVA 8 kVA 12 kVA

0 - 300 V L(1) 9.2 A @ 110 V 18.4 A @ 110 V 36.8 A @ 110 V 55.2 A @ 110 V
0 - 600 V H(1) 4.6 A @ 220 V 9.2 A @ 220 V 18.4 A @ 220 V 27.6 A @ 220 V

0 - 300 V L(2) 9.2 A @ 220 V 18.4 A @ 220 V 36.8 A @ 220 V 55.2 A @ 220 V
0 - 600 V H(2) 4.6 A @ 440 V 9.2 A @ 440 V 18.4 A @ 440 V 27.6 A @ 440 V

Linking Polyphase Output 3Φ4W

Linked Units

Voltage

Power

Max Current

Phase

Max Current

Line

Max Current

Phase Delta

Phase 5 - 300 V
Line 5 - 520 V
Max 3 kVA 6 kVA 12 KVA 12 kVA 18 kVA

0 - 150 V L(1) 9.2 A @ 110 V 18.4 A @ 110 V 36.8 A @ 110 V 55.2 A @ 110 V
0 - 300 V H(1) 4.6 A @ 220 V 9.2 A @ 220 V 18.4 A @ 220 V 27.6 A @ 220 V

0 - 150 V L(3) 9.2 A @ 190.5 V 18.4 A @ 190.5 V 36.8 A @ 190.5 V 55.2 A @ 190.5 V
0 - 300 V H(3) 4.6 A @ 381 V 9.2 A @ 381 V 18.4 A @ 381 V 27.6 A @ 381 V

0 - 260 V L(3) 5.31 A @ 190.5 V 10.62 A @ 190.5 V 21.24 A @ 190.5 V 31.87 A @ 190.5 V
0 - 520 V H(3) 2.65 A @ 381 V 5.31 A @ 381 V 10.62 A @ 381 V 15.93 A @ 381 V

Linking Parallel DC Output 1Φ2W

Linked Units

Voltage Power

Power

Max

Max Current

Line

Line 5 - 420 V

# Units

0 - 210 V L(2) 7.68 A @ 50 V - 210 V 15.36 A @ 50 V - 210 V 30.72 A @ 50 V - 210 V 46.08 A @ 50 V - 210 V

0 - 420 V H(2) 3.84 A @ 50 V - 420 V 7.68 A @ 50 V - 420 V 15.36 A @ 50 V - 420 V 23.04 A @ 50 V - 420 V

310XAC 320XAC 340XAC 360XAC

2 - 3 Units, 1Φ2W (L1 - N)

2 1.8 kVA 3.6 kVA 7.2 kVA 10.8 kVA

3 2.7 kVA 5.4 kVA 10.8 K 10.8 kVAA A 16.2 kVA

L(3) 22.08 A @ 20 V - 110 V 44.16 A @ 20 V - 110 V 88.32 A @ 20 V - 110 V 132.48 A @ 20 V - 110 V

H(3) 11.04 A @ 20 V - 220 V 22.08 A @ 20 V - 220 V 44.16 A @ 20 V - 220 V 66.24 A @ 20 V - 220 V

2 1.8 kVA 3.6 kVA 7.2 kVA 10.8 kVA
3 2.7 kVA 5.4 kVA 10.8 kVA 16.2 kVA

L(3) 11.52 A @ 50 V - 210 V 23.04 A @ 50 V - 210 V 46.08 A @ 50 V - 210 V 69.12 A @ 50 V - 210 V

H(3) 5.76 A @ 50 V - 420 V 11.52 A @ 50 V - 420 V 23.04 A @ 50 V - 420 V 34.56 A @ 50 V - 420 V

310XAC 320XAC 340XAC 360XAC

2 Units @ 180º, 1Φ3W (L1-L2 - N)

310XAC 320XAC 340XAC 360XAC

3 Units @ 120º, 3Φ4W (L1-L2-L3 - N)

310XAC 320XAC 340XAC 360XAC

2 - 3 Units, 1Φ2W (L1 - N )

7

300XAC Specifications

Measurement (Total)
Linking Parallel 1Φ2W

Voltage

Range 0.0 - 400.0 V
Accuracy ± (1% of reading + 2 counts) > 5 V ± (1% of reading + 5 counts) > 5 V

Frequency

Range 0.0 - 1000.0 Hz
Accuracy L ± 0.1 Hz @ 0.0 - 500 Hz

Current (rms)

Range 2 0.00 A - 26.00 A 0.00 A - 52.00 A 0.00 A - 104.0 A 0.00 A - 156.0 A

Accuracy L

Power (W)

Range 2 0 W - 2600 W 0 W - 5200 W 0 W -10400 W 0 W - 15600 W

Accuracy ± (2% of reading + 10 counts) x (# of Linked Units) at PF ≥ 0.2, 40 - 500 Hz, and Current > 5.0 A

Power Apparent

(VA)

Range 2 0 W - 2600 VA 0 W - 5200 VA 0 W -10400 VA 0 W - 15600 VA

Accuracy V x A, Calculated Value

Power Reactive
(Q)

Range 2 0 W - 2600 VA 0 W - 5200 VA 0 W -10400 VA 0 W - 15600 VA

Accuracy √(VA)² - (W)², Calculated Value

Power Factor

Range

Accuracy

Measurement (Total)
Linking Polyphase 1Φ3W

Voltage

Range 2 L1 Voltage + L2 Voltage

Accuracy

Frequency

Range 0.0 - 1000.0 Hz
Accuracy L ± 0.1 Hz @ 0.0 - 500 Hz

Current (rms)

Range 2 (L1 Current + L2 Current)/2

Accuracy

310XAC 320XAC 340XAC 360XAC

H ± 0.2 Hz @ 501 - 1000 Hz

3 0.00 A - 39.00 A 0.00 A - 78.00 A 0.00 A - 156.0 A 0.00 A - 234.0 A

± (1.5% of reading +15 counts) x # of Linked Units

@ 40.0 - 70.0 Hz & Current is > 1.0 A

H

± (1.5% of reading +15 counts) x # of Linked Units

@ 70.1- 1000 Hz & Current is > 5.00 A

± (1.5% of reading +15

counts) x Link Units @ 40.0

- 70.0 Hz and current(r.m.s.)
> 2.00 A, ± (1.5% of reading

+15 counts) x Link Units

@ 70.1 - 1000 Hz, and

current(r.m.s.) > 10.00 A

± (1.5% of reading +15

counts) x Link Units @ 40.0

- 70.0 Hz and current(r.m.s.)
> 3.00 A, ± (1.5% of read-

ing +15 counts) x Link Units

@ 70.1 - 1000 Hz, and

current(r.m.s.) > 15.00 A

3 0 W - 3900 W 0 W - 7800 W 0 W - 15600 W 0 W - 23400 W

± (2% of reading + 10 counts) x (# of Linked Units) at PF ≥ 0.3, 501 - 1000 Hz, and Current > 5.0 A

3 0 W - 3900 VA 0 W - 7800 VA 0 W - 15600 VA 0 W - 23400 VA

3 0 W - 3900 VA 0 W - 7800 VA 0 W - 15600 VA 0 W - 23400 VA

0 - 1.000

W / VA, Calculated and displayed to three signicant digits

310XAC 320XAC 340XAC 360XAC

L Summation of linked sources, Calculated and displayed to one signicant digit

H ± 0.2 Hz @ 501 - 1000 Hz

± (1% of reading + 5 counts) at 40 - 70 Hz

± (1% of reading + 5 counts) at 70.1 - 500 Hz, and output current (r.m.s.) > 0.200 A

± (1% of reading + 5 counts) at 501 - 1000 Hz, and output current (r.m.s.) > 0.300 A

Power (W)

Power Apparent

(VA)

Power Reactive
(Q)

Power Factor

8

Range 2 L1 Power + L2 Power
Accuracy 2 L1 Power + L2 Power, Calculated Value

Range 2 L1 VA + L2 VA
Accuracy 2 L1 VA + L2 VA, Calculated Value

Range 2 L1 VAR + L2 VAR
Accuracy 2 L1 VAR + L2 VAR, Calculated Value
Range 0 - 1.000
Accuracy (L1 P + L2 P) / (L1 VA + L2 VA), Calculated and displayed to three signicant digits

300XAC Specifications

Measurement (Total)

Linking Polyphase 3Φ

Voltage

Frequency

Current (rms)

Power (W)

Power Apparent

(VA)

Power Reactive
(Q)

Power Factor

Measurement (Total)

Linking Parallel DC

Voltage

Current (rms)

Power (W)

4W

Range (A+B+C)/3
Accuracy (A+B+C)/3 , Calculated and displayed to one signicant digit
Range 0.0 - 1000.0 Hz
Accuracy L ± 0.1 Hz @ 0.0 - 500 Hz

H ± 0.2 Hz @ 501 - 1000 Hz

Range (A+B+C)/3

Accuracy

Range A Power + B Power + C Power
Accuracy Calculated Value
Range A VA + B VA + C VA
Accuracy Calculated Value
Range A VAR + B VAR + C VAR

Accuracy Calculated Value

Range 0 - 1.000
Accuracy Sum P / Sum VA, Calculated and displayed to three signicant digits

310XAC 320XAC 340XAC 360XAC

± (1% of reading + 5 counts) at 40 - 70 Hz

± (1% of reading + 5 counts) at 70.1 - 500 Hz, and output current (r.m.s.) > 0.200 A

± (1% of reading + 5 counts) at 501 - 1000 Hz, and output current (r.m.s.) > 0.300 A

310XAC 320XAC 340XAC 360XAC

Range 0.0 - 420.0 V

Accuracy ± (1% of reading + 2 counts) > 5 V ± (1% of reading + 5 counts) > 5 V
Range 2 0.05 A - 26.00 A 0.05 A - 52.00 A 0.05 A - 104.00 A 0.05 A - 156.00 A

3 0.05 A - 39.00 A 0.05 A - 78.00 A 0.05 A - 156.00 A 0.05 A - 234.00 A

Accuracy

Range 2 0 W - 2600 W 0 W - 25200 W 0 W -10400 W 0 W - 15600 W

3 0 W - 3900 W 0 W - 7800 W 0 W - 15600 W 0 W - 23400 W

Accuracy ± (2% of reading + 5 counts) x # of Linked Units

± (1% of reading + 5 counts) x # of Linked Units,

Current > 1.00 A

± (1% of reading + 5 counts)

x # of Linked Units, Current

> 2.00 A

± (1% of reading + 5 counts)

x # of Linked Units, Current

> 3.00 A

Key

L = Low Limit Range L (2) = Low Limit Range 2 Units Linked H (2 ) = High Limit Range 2 Units Linked 2 = 2 Units Linked
H = High Limit Range L (3) = Low Limit Range 3 Units Linked H (3) = High Limit Range 3 Units Linked 3 = 3 Units Linked

9

APT...The Power of Value!

AC Power Sources for All Applications

300XAC Series

Modular AC Power Sources

6000 Series

Automated AC Power Sources

LS Series

Linear AC Power Sources

7000 Series

Automated AC Power Sources

5000 Series

Manual AC Power Sources

VariPLUS

Power Converter

®

Model 104 Only

To order or for more information
please give us a call today!

Toll Free: [phone] or [phone]

9/12

1142 S. Diamond Bar Blvd. #106, Diamond Bar, CA USA 91765 • P: [phone] • F: [phone] • www.aspowertechnologies.com
